Probe:	Nkd1 exon probe
Probe preparation:	Antisense RNA

Structure	Level	Pattern	Image	Note
TS11: embryo	Absent		3A

Structure	Level	Pattern	Image	Note
TS13: neural ectoderm	Present		3B	Expression first detected in the central nervous system and in the presomitic mesoderm at E8.5.
TS13: trunk unsegmented mesenchyme	Present		3B	Expression first detected in the central nervous system and in the presomitic mesoderm at E8.5.

Structure	Level	Pattern	Image	Note
TS17: somite	Present	Regionally restricted	3C	Expression in newly formed somites.
TS17: central nervous system	Present		3C	Expression in the neural tube.
TS17: tail unsegmented mesenchyme	Present		3C	Expression maintained in presomitc mesoderm.

Structure	Level	Pattern	Image	Note
TS17: tail	Present	Regionally restricted	3D	Expression pattern in presomitic mesoderm varied among embryos. Expression detected in middle presomitic mesoderm and tailbud.
TS17: tail unsegmented mesenchyme	Present	Regionally restricted	3D	Expression pattern in presomitic mesoderm varied among embryos. Expression detected in middle presomitic mesoderm and tailbud.

Structure	Level	Pattern	Image	Note
TS17: tail unsegmented mesenchyme	Present	Regionally restricted	3E	Expression in more anterior presomitic mesenchyme without the tailbud.
