Dlx5 RNA in situ Gene Expression Assay

Gene Expression Data
Assay Details

Assay

Reference:	J:226028 Lewandowski JP, et al., Spatiotemporal regulation of GLI target genes in the mammalian limb bud. Dev Biol. 2015 Oct 1;406(1):92-103
Assay type:	RNA in situ
MGI Accession ID:	MGI:5823604
Gene symbol:	Dlx5
Gene name:	distal-less homeobox 5

Probe:	Dlx5 cDNA
Probe preparation:	Antisense labelled with digoxigenin RNA
Visualized with:	Alkaline phosphatase

Results

Dlx5_b70_E10.5a_RF_JL ©

Specimen Dlx5_b70_E10.5a_RF_JL: embryonic day 10.5 (more

)

Structure	Level	Pattern	Image	Note
TS17: forelimb bud apical ectodermal ridge	Strong		Dlx5_b70_E10.5a_RF_JL

Dlx5_b70_E10.5a_RF-dp_JL ©

Specimen Dlx5_b70_E10.5a_RF-dp_JL: embryonic day 10.5 (more

)

Structure	Level	Pattern	Image	Note
TS17: forelimb bud apical ectodermal ridge	Strong		Dlx5_b70_E10.5a_RF-dp_JL

Dlx5_b70_E10.5b_RF_JL ©

Specimen Dlx5_b70_E10.5b_RF_JL: embryonic day 10.5 (more

)

Structure	Level	Pattern	Image	Note
TS17: forelimb bud apical ectodermal ridge	Strong		Dlx5_b70_E10.5b_RF_JL

Dlx5_b70_11.5b_RF_JL ©

Specimen Dlx5_b70_11.5b_RF_JL: embryonic day 11.5 (more

)

Structure	Level	Pattern	Image	Note
TS19: handplate apical ectodermal ridge	Present		Dlx5_b70_11.5b_RF_JL

Dlx5_b70_E11.5a_RF_JL ©

Specimen Dlx5_b70_E11.5a_RF_JL: embryonic day 11.5 (more

)

Structure	Level	Pattern	Image	Note
TS19: handplate apical ectodermal ridge	Present		Dlx5_b70_E11.5a_RF_JL

Dlx5_b70_E11.5b_RF-dp_JL ©

Specimen Dlx5_b70_E11.5b_RF-dp_JL: embryonic day 11.5 (more

)

Structure	Level	Pattern	Image	Note
TS19: handplate apical ectodermal ridge	Present		Dlx5_b70_E11.5b_RF-dp_JL

Dlx5_b70_E10.5a_RHL_JL ©

Specimen Dlx5_b70_E10.5a_RHL_JL: embryonic day 10.5 (more

)

Structure	Level	Pattern	Image	Note
TS17: hindlimb bud	Present		Dlx5_b70_E10.5a_RHL_JL

Dlx5_b70_E10.5a_RHL-dp_JL ©

Specimen Dlx5_b70_E10.5a_RHL-dp_JL: embryonic day 10.5 (more

)

Structure	Level	Pattern	Image	Note
TS17: hindlimb bud	Present		Dlx5_b70_E10.5a_RHL-dp_JL

Dlx5_b70_E10.5a_JL ©

Specimen Dlx5_b70_E10.5a_JL: embryonic day 10.5 (more

)

Structure	Level	Pattern	Image	Note
TS17: ear	Weak		Dlx5_b70_E10.5a_JL
TS17: branchial arch	Strong		Dlx5_b70_E10.5a_JL

Specimen Dlx5_b70_E10.5b_JL: embryonic day 10.5 (more

)

Structure	Level	Pattern	Image	Note
TS17: ear	Weak		Dlx5_b70_E10.5b_JL
TS17: branchial arch	Strong		Dlx5_b70_E10.5b_JL

Specimen Dlx5_b70_E10.5b_JL2: embryonic day 10.5 (more

)

Structure	Level	Pattern	Image	Note
TS17: ear	Weak		Dlx5_b70_E10.5b_JL2
TS17: branchial arch	Strong		Dlx5_b70_E10.5b_JL2

Specimen Dlx5_b70_E11.5a_JL: embryonic day 11.5 (more

)

Structure	Level	Pattern	Image	Note
TS19: embryo	Present	Regionally restricted	Dlx5_b70_E11.5a_JL	Staining is similar to that observed at E10.5. At that time it was seen in the ear and branchial arch.

Specimen Dlx5_b70_E11.5b_JL: embryonic day 11.5 (more

)

Structure	Level	Pattern	Image	Note
TS19: embryo	Present	Regionally restricted	Dlx5_b70_E11.5b_JL	Staining is similar to that observed at E10.5. At that time it was seen in the ear and branchial arch.
