Probe:	pCMV-Tag3B/Foxp2
Probe preparation:	Antisense labelled with digoxigenin RNA
Visualized with:	Alkaline phosphatase

Structure	Level	Pattern	Image	Note
TS20: corpus striatum	Present	Regionally restricted	1a E12.5	Expression includes the striatal subventricular zone.
TS20: ganglionic eminence	Present	Regionally restricted	1a E12.5	Expression is in the deep part of the ganglionic eminence.
TS20: cerebral cortex ventricular layer	Weak		1a E12.5
TS20: cortical plate	Absent		1a E12.5

Structure	Level	Pattern	Image	Note
TS22: cortical plate	Present	Regionally restricted	1a E14.5	Expression is in the inner layers in the lateral cortical plate and is weaker in the more medial area.
TS22: corpus striatum	Present	Regionally restricted	1a E14.5	Expression includes the striatal subventricular zone.
TS22: ganglionic eminence	Present	Regionally restricted	1a E14.5	Expression is in the deep part of the ganglionic eminence.
TS22: cerebral cortex ventricular layer	Weak		1a E14.5
TS22: hippocampus	Absent		1a E14.5

Structure	Level	Pattern	Image	Note
TS24: cortical plate	Present	Regionally restricted	1a E16.5	Expression is in the inner layers in the lateral cortical plate and is weaker in the more medial area.
TS24: corpus striatum	Present	Regionally restricted	1a E16.5	Expression includes the striatal subventricular zone.
TS24: ganglionic eminence	Present	Regionally restricted	1a E16.5	Expression is in the deep part of the ganglionic eminence.
TS24: cerebral cortex ventricular layer	Weak		1a E16.5
TS24: hippocampus	Absent		1a E16.5

Structure	Level	Pattern	Image	Note
TS25: cortical plate	Present	Regionally restricted	1a E17.5	Expression is in the inner layers in the lateral cortical plate and is weaker in the more medial area.
TS25: corpus striatum	Present	Regionally restricted	1a E17.5	Expression includes the striatal subventricular zone.
TS25: ganglionic eminence	Present	Regionally restricted	1a E17.5	Expression is in the deep part of the ganglionic eminence.
TS25: cerebral cortex ventricular layer	Weak		1a E17.5
TS25: hippocampus	Absent		1a E17.5

Structure	Level	Pattern	Image	Note
TS27: cortical plate	Present	Regionally restricted	1a P0.5	Expression is in the inner layers in the lateral cortical plate and is weaker in the more medial area.
TS27: corpus striatum	Present	Regionally restricted	1a P0.5	Expression includes the striatal subventricular zone.
TS27: dentate gyrus	Absent		1a P0.5
TS27: hippocampus CA1	Absent		1a P0.5
TS27: hippocampus CA3	Absent		1a P0.5
TS27: subiculum	Absent		1a P0.5

Structure	Level	Pattern	Image	Note
TS25: cortical plate	Present	Regionally restricted	1b E17.5 Cortex	Expression is in the inner layers.

Structure	Level	Pattern	Image	Note
TS25: hippocampus	Absent		1b E17.5 Hippocampus

Structure	Level	Pattern	Image	Note
TS27: cortical plate	Present	Regionally restricted	1b P0.5 Cortex	Expression is in the inner layers.

Structure	Level	Pattern	Image	Note
TS27: hippocampus	Absent		1b P0.5 Hippocampus

Structure	Level	Pattern	Image	Note
TS27: cortical plate	Present		2_Cortex P1.5

Structure	Level	Pattern	Image	Note
TS27: cortical layer VI	Present		2_Cortex P3.5

Structure	Level	Pattern	Image	Note
TS28: cortical layer VI	Present		2_Cortex P6.5

Structure	Level	Pattern	Image	Note
TS28: cortical layer VI	Present		2_Cortex P9.5

Structure	Level	Pattern	Image	Note
TS28: cortical layer VI	Present		2_Cortex P15.5

Structure	Level	Pattern	Image	Note
TS28: cortical layer VI	Present		2_Cortex Adult

Structure	Level	Pattern	Image	Note
TS27: corpus striatum	Present		2_Striatum P1.5

Structure	Level	Pattern	Image	Note
TS27: corpus striatum	Present		2_Striatum P3.5

Structure	Level	Pattern	Image	Note
TS28: corpus striatum	Present		2_Striatum P6.5

Structure	Level	Pattern	Image	Note
TS28: corpus striatum	Present		2_Striatum P9.5

Structure	Level	Pattern	Image	Note
TS28: corpus striatum	Present		2_Striatum P15.5

Structure	Level	Pattern	Image	Note
TS28: corpus striatum	Present		2_Striatum Adult

Structure	Level	Pattern	Image	Note
TS27: hippocampus	Absent		2_Hippocampus P1.5

Structure	Level	Pattern	Image	Note
TS27: hippocampus	Absent		2_Hippocampus P3.5

Structure	Level	Pattern	Image	Note
TS28: hippocampus	Absent		2_Hippocampus P6.5

Structure	Level	Pattern	Image	Note
TS28: hippocampus	Absent		2_Hippocampus P15.5

Structure	Level	Pattern	Image	Note
TS28: hippocampus	Absent		2_Hippocampus Adult

Structure	Level	Pattern	Image	Note
TS27: cerebellum Purkinje cell layer	Present		2_Cerebellum P1.5
TS27: cerebellum granule cell layer	Absent		2_Cerebellum P1.5

Structure	Level	Pattern	Image	Note
TS27: cerebellum Purkinje cell layer	Present		2_Cerebellum P3.5
TS27: cerebellum granule cell layer	Absent		2_Cerebellum P3.5

Structure	Level	Pattern	Image	Note
TS28: cerebellum Purkinje cell layer	Present		2_Cerebellum P6.5
TS28: cerebellum granule cell layer	Absent		2_Cerebellum P6.5

Structure	Level	Pattern	Image	Note
TS28: cerebellum Purkinje cell layer	Present		2_Cerebellum P15.5
TS28: cerebellum granule cell layer	Absent		2_Cerebellum P15.5

Structure	Level	Pattern	Image	Note
TS28: cerebellum Purkinje cell layer	Present		2_Cerebellum Adult
TS28: cerebellum granule cell layer	Absent		2_Cerebellum Adult

Structure	Level	Pattern	Image	Note
TS28: amygdala	Present
TS28: cerebellum	Present
TS28: corpus striatum	Present
TS28: cortical layer VI	Present
TS28: hypothalamus	Present
TS28: inferior colliculus	Present
TS28: inferior olivary nucleus	Present
TS28: main olfactory bulb	Present
TS28: substantia nigra	Present
TS28: superior colliculus	Present
TS28: thalamus	Present
TS28: telencephalon septum	Present	Single cells		Expression is in sporadic cells.
TS28: cortical layer I	Absent
TS28: cortical layer II	Absent
TS28: cortical layer III	Absent
TS28: cortical layer IV	Absent
TS28: cortical layer V	Absent
TS28: dentate gyrus	Absent
TS28: hippocampus CA1	Absent
TS28: hippocampus CA3	Absent
TS28: piriform cortex	Absent
TS28: subiculum	Absent

Structure	Level	Pattern	Image	Note
TS28: accumbens nucleus	Present
TS28: basal ganglia	Present
TS28: caudate-putamen	Present
TS28: substantia nigra	Present

Structure	Level	Pattern	Image	Note
TS28: deep cerebellar nucleus	Present
