Antibody:	anti-CAPS1
Detection system:	Secondary antibody

Structure	Level	Pattern	Image	Note
TS24: main olfactory bulb	Moderate	Widespread	1B
TS24: telencephalon septum	Moderate	Regionally restricted	1B	Expression is in the septal nucleus.

Structure	Level	Pattern	Image	Note
TS24: cerebral cortex	Moderate	Regionally restricted	1D	Expression is in the corpus callosum.
TS24: thalamus	Present	Regionally restricted		Expression is in the laterodorsal thalamic nucleus.

Structure	Level	Pattern	Image	Note
TS24: cerebral cortex	Moderate	Regionally restricted	1F	Expression is in the corpus callosum.

Structure	Level	Pattern	Image	Note
TS24: hypothalamus	Present	Regionally restricted	1H	Expression is in the arcuate hypothalamic nucleus.

Structure	Level	Pattern	Image	Note
TS24: midbrain	Moderate	Widespread	1J

Structure	Level	Pattern	Image	Note
TS24: cerebellum	Moderate	Regionally restricted	1L	Moderate levels in the superior cerebellar peduncle and low to moderate scattered throughout the cerebellar primordium.

Structure	Level	Pattern	Image	Note
TS24: pons	Moderate		1N
TS24: spinal cord	Present		1N

Structure	Level	Pattern	Image	Note
TS24: dorsal root ganglion	Present		1P

Structure	Level	Pattern	Image	Note
TS28: brain	Present	Widespread	2A

Structure	Level	Pattern	Image	Note
TS28: main olfactory bulb mitral cell layer	Strong		2C

Structure	Level	Pattern	Image	Note
TS28: anterior olfactory nucleus	Present		2D

Structure	Level	Pattern	Image	Note
TS28: corpus striatum	Strong	Regionally restricted	2E	Expression is in the cortico-striatal fiber system.

Structure	Level	Pattern	Image	Note
TS28: neocortex layer	Present	Widespread	2G , 2H

Structure	Level	Pattern	Image	Note
TS28: hippocampus CA1	Strong		2I

Structure	Level	Pattern	Image	Note
TS28: hippocampus CA3	Strong	Regionally restricted	2J	Expression is all areas except the stratum pyramidale.
TS28: dentate gyrus molecular layer	Present		2J

Structure	Level	Pattern	Image	Note
TS28: lateral habenular nucleus	Absent		2K
TS28: medial habenular nucleus	Absent		2K

Structure	Level	Pattern	Image	Note
TS28: anterior dorsal thalamic nucleus	Very strong		2N , 2M

Structure	Level	Pattern	Image	Note
TS28: midbrain tegmentum	Weak		3A

Structure	Level	Pattern	Image	Note
TS28: substantia nigra	Absent		3B

Structure	Level	Pattern	Image	Note
TS28: red nucleus	Absent		3C

Structure	Level	Pattern	Image	Note
TS28: pontine nucleus	Strong		3D

Structure	Level	Pattern	Image	Note
TS28: cerebellum Purkinje cell layer	Strong	Regionally restricted	3E	Expression is in the cell somata and primary dendrites.
TS28: cerebellum granule cell layer	Strong	Regionally restricted	3E	Expression is in the glomerular rosettes and Golgi cells.

Structure	Level	Pattern	Image	Note
TS28: deep cerebellar nucleus	Strong		3F

Structure	Level	Pattern	Image	Note
TS28: brain	Present		3G

Structure	Level	Pattern	Image	Note
TS28: medulla oblongata	Present	Regionally restricted	3H	Expression is in vestibular neurons.

Structure	Level	Pattern	Image	Note
TS28: inferior olivary nucleus	Present		3I

Structure	Level	Pattern	Image	Note
TS28: cuneate nucleus	Present		3J

Structure	Level	Pattern	Image	Note
TS28: spinal cord	Present		3K

Structure	Level	Pattern	Image	Note
TS28: spinal cord	Present		3L

Structure	Level	Pattern	Image	Note
TS28: hippocampus molecular layer	Strong	Regionally restricted	4F , 4G	In the CA3 region.
TS28: hippocampus stratum lacunosum	Strong	Regionally restricted	4F , 4G	In the CA3 region.
TS28: hippocampus stratum oriens	Strong	Regionally restricted	4F , 4G	In the CA3 region.
TS28: hippocampus stratum radiatum	Strong	Regionally restricted	4F , 4G	In the CA3 region.
TS28: dentate gyrus molecular layer	Present	Regionally restricted	4G , 4F	Expression is in the outer molecular layer.
TS28: hippocampus	Present	Regionally restricted	4G , 4F	Expression is in small cell populations that are scattered over the hippocampus.

Structure	Level	Pattern	Image	Note
TS28: hippocampus molecular layer	Strong	Regionally restricted	4J , 4I	In the CA3 region.
TS28: hippocampus stratum lacunosum	Strong	Regionally restricted	4J , 4I	In the CA3 region.
TS28: hippocampus stratum oriens	Strong	Regionally restricted	4J , 4I	In the CA3 region.
TS28: hippocampus stratum radiatum	Strong	Regionally restricted	4J , 4I	In the CA3 region.
TS28: dentate gyrus molecular layer	Present	Regionally restricted	4I , 4J	Expression is in the outer molecular layer.

Structure	Level	Pattern	Image	Note
TS28: hippocampus molecular layer	Present	Regionally restricted	4L , 4M	Expressing cells are near the interface region between these layers of the CA1 region.
TS28: hippocampus stratum lacunosum	Present	Regionally restricted	4L , 4M	Expressing cells are near the interface region between these layers of the CA1 region.
TS28: hippocampus stratum radiatum	Present	Regionally restricted	4L , 4M	Expressing cells are near the interface region between these layers of the CA1 region.

Structure	Level	Pattern	Image	Note
TS28: dentate gyrus	Present	Regionally restricted	4P , 4O	Expression is between the granule cells and the polymorphic layers.

Structure	Level	Pattern	Image	Note
TS28: interpeduncular nucleus	Absent		5D , 5C
TS28: substantia nigra	Absent		5D , 5C
TS28: ventral tegmental area	Absent		5D , 5C

Structure	Level	Pattern	Image	Note
TS24: hypothalamus	Strong	Regionally restricted		Expression is in the arcuate hypothalamic nucleus and is weak in the dorsomedial hypothalamic and ventromedial hypothalamic nuclei.
TS24: dorsal root ganglion	Moderate
TS24: main olfactory bulb	Moderate
TS24: spinal cord	Moderate
TS24: thalamus	Moderate	Regionally restricted		Expression is in the laterodorsal thalamic nucleus and the stria medullaris, weak in the thalamus.
TS24: brain	Moderate	Regionally restricted		Expression is in the subcommissural organ.
TS24: cerebral cortex	Weak
TS24: telencephalon septum	Weak
TS24: midbrain	Weak	Regionally restricted		Expression is weak in the ventral tegmental area and is absent in the substantia nigra.
TS24: cerebellum	Weak	Regionally restricted		Weak in the superior cerebellar peduncle and absent in the external germinal layer.
TS24: pons	Weak	Regionally restricted		Expression is in the pontine nucleus.
TS24: adenohypophysis	Absent
TS24: choroid plexus	Absent

Structure	Level	Pattern	Image	Note
TS28: main olfactory bulb glomerular layer	Strong
TS28: anterior dorsal thalamic nucleus	Moderate
TS28: cerebellum Purkinje cell layer	Moderate
TS28: cerebellum internal granule cell layer	Moderate
TS28: cerebellum molecular layer	Moderate
TS28: cortical layer I	Moderate
TS28: cuneate nucleus	Moderate
TS28: deep cerebellar nucleus	Moderate
TS28: dentate gyrus molecular layer	Moderate
TS28: inferior olivary nucleus	Moderate
TS28: main olfactory bulb mitral cell layer	Moderate
TS28: pontine nucleus	Moderate
TS28: vestibular nucleus	Moderate
TS28: hippocampus pyramidal cell layer	Moderate	Regionally restricted		CA3 region absent in CA1.
TS28: hippocampus stratum radiatum	Moderate	Regionally restricted		CA1 and CA3 region.
TS28: hippocampus stratum oriens	Moderate	Regionally restricted		CA1 region.
TS28: hippocampus stratum lucidum	Moderate	Regionally restricted		CA1 region absent in CA3.
TS28: anterior olfactory nucleus	Weak
TS28: corpus striatum	Weak
TS28: cortical layer II	Weak
TS28: cortical layer III	Weak
TS28: dorsal root ganglion	Weak
TS28: main olfactory bulb external plexiform layer	Weak
TS28: main olfactory bulb granule cell layer	Weak
TS28: main olfactory bulb internal plexiform layer	Weak
TS28: spinal cord	Weak
TS28: hippocampus molecular layer	Weak	Regionally restricted
TS28: hippocampus stratum lacunosum	Weak	Regionally restricted
TS28: anterior ventral thalamic nucleus	Trace
TS28: cortical layer IV	Trace
TS28: cortical layer V	Trace
TS28: cortical layer VI	Trace
TS28: choroid plexus	Absent
TS28: dentate gyrus granule cell layer	Absent
TS28: dentate gyrus hilus	Absent
TS28: interpeduncular nucleus	Absent
TS28: lateral habenular nucleus	Absent
TS28: medial habenular nucleus	Absent
TS28: red nucleus	Absent
TS28: subiculum	Absent
TS28: substantia nigra	Absent
TS28: ventral tegmental area	Absent
