Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4825480
Gene symbol: Hspb2
Gene name: heat shock protein 2
Probe: MGC clone 73576
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_006798_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Strong Regionally restricted euxassay_006798_01
TS23: diaphragm Strong Regionally restricted euxassay_006798_01
TS23: lower leg rest of mesenchyme Strong Regionally restricted euxassay_006798_01
TS23: forearm rest of mesenchyme Strong Regionally restricted euxassay_006798_01
TS23: upper arm muscle Strong Regionally restricted euxassay_006798_01
TS23: hand Moderate Regionally restricted euxassay_006798_01
Specimen euxassay_006798_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Regionally restricted euxassay_006798_02
TS23: vertebral axis musculature Strong Regionally restricted euxassay_006798_02
TS23: lower leg rest of mesenchyme Strong Regionally restricted euxassay_006798_02
TS23: upper leg muscle Strong Regionally restricted euxassay_006798_02
TS23: forearm rest of mesenchyme Strong Regionally restricted euxassay_006798_02
TS23: upper arm muscle Strong Regionally restricted euxassay_006798_02
TS23: hand Moderate Regionally restricted euxassay_006798_02
Specimen euxassay_006798_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Regionally restricted euxassay_006798_03
TS23: vertebral axis musculature Strong Regionally restricted euxassay_006798_03
TS23: upper leg muscle Strong Regionally restricted euxassay_006798_03
TS23: lower leg rest of mesenchyme Strong Regionally restricted euxassay_006798_03
TS23: hand Moderate Regionally restricted euxassay_006798_03
TS23: upper arm muscle Strong Regionally restricted euxassay_006798_03
TS23: forearm rest of mesenchyme Strong Regionally restricted euxassay_006798_03
Specimen euxassay_006798_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Regionally restricted euxassay_006798_04
TS23: vertebral axis musculature Strong Regionally restricted euxassay_006798_04
TS23: upper leg muscle Strong Regionally restricted euxassay_006798_04
TS23: lower leg rest of mesenchyme Strong Regionally restricted euxassay_006798_04
TS23: hand Moderate Regionally restricted euxassay_006798_04
TS23: upper arm muscle Strong Regionally restricted euxassay_006798_04
TS23: forearm rest of mesenchyme Strong Regionally restricted euxassay_006798_04
Specimen euxassay_006798_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Regionally restricted euxassay_006798_05
TS23: vertebral axis musculature Strong Regionally restricted euxassay_006798_05
TS23: upper leg muscle Strong Regionally restricted euxassay_006798_05
TS23: lower leg rest of mesenchyme Strong Regionally restricted euxassay_006798_05
TS23: tarsus rest of mesenchyme Strong Regionally restricted euxassay_006798_05
TS23: upper arm muscle Strong Regionally restricted euxassay_006798_05
TS23: hand Strong Regionally restricted euxassay_006798_05
Specimen euxassay_006798_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Regionally restricted euxassay_006798_06
TS23: vertebral axis musculature Strong Regionally restricted euxassay_006798_06
TS23: tarsus rest of mesenchyme Strong Regionally restricted euxassay_006798_06
TS23: upper leg muscle Strong Regionally restricted euxassay_006798_06
TS23: upper arm muscle Strong Regionally restricted euxassay_006798_06
Specimen euxassay_006798_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Regionally restricted euxassay_006798_07
TS23: vertebral axis musculature Strong Regionally restricted euxassay_006798_07
TS23: upper leg muscle Strong Regionally restricted euxassay_006798_07
TS23: upper arm muscle Strong Regionally restricted euxassay_006798_07
Specimen euxassay_006798_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Regionally restricted euxassay_006798_08
TS23: vertebral axis musculature Strong Regionally restricted euxassay_006798_08
TS23: tail paraxial mesenchyme Strong Regionally restricted euxassay_006798_08
TS23: upper leg muscle Strong Regionally restricted euxassay_006798_08
Specimen euxassay_006798_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Regionally restricted euxassay_006798_09
TS23: vertebral axis musculature Strong Regionally restricted euxassay_006798_09
TS23: tail paraxial mesenchyme Strong Regionally restricted euxassay_006798_09
TS23: upper leg muscle Strong Regionally restricted euxassay_006798_09
Specimen euxassay_006798_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Regionally restricted euxassay_006798_10
TS23: vertebral axis musculature Strong Regionally restricted euxassay_006798_10
TS23: tail paraxial mesenchyme Strong Regionally restricted euxassay_006798_10
Specimen euxassay_006798_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Regionally restricted euxassay_006798_11
TS23: vertebral axis musculature Strong Regionally restricted euxassay_006798_11
TS23: tongue extrinsic muscle Strong Regionally restricted euxassay_006798_11
TS23: tail paraxial mesenchyme Strong Regionally restricted euxassay_006798_11
Specimen euxassay_006798_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Regionally restricted euxassay_006798_12
TS23: vertebral axis musculature Strong Regionally restricted euxassay_006798_12
TS23: tongue muscle Strong Regionally restricted euxassay_006798_12
TS23: tail paraxial mesenchyme Strong Regionally restricted euxassay_006798_12
Specimen euxassay_006798_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Regionally restricted euxassay_006798_13
TS23: vertebral axis musculature Strong Regionally restricted euxassay_006798_13
TS23: tongue muscle Strong Regionally restricted euxassay_006798_13
TS23: tail paraxial mesenchyme Strong Regionally restricted euxassay_006798_13
Specimen euxassay_006798_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Regionally restricted euxassay_006798_14
TS23: vertebral axis musculature Strong Regionally restricted euxassay_006798_14
TS23: tongue muscle Strong Regionally restricted euxassay_006798_14
TS23: tail paraxial mesenchyme Strong Regionally restricted euxassay_006798_14
Specimen euxassay_006798_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Regionally restricted euxassay_006798_15
TS23: vertebral axis musculature Strong Regionally restricted euxassay_006798_15
TS23: tongue muscle Strong Regionally restricted euxassay_006798_15
TS23: tail paraxial mesenchyme Strong Regionally restricted euxassay_006798_15
Specimen euxassay_006798_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Regionally restricted euxassay_006798_16
TS23: vertebral axis musculature Strong Regionally restricted euxassay_006798_16
TS23: tongue muscle Strong Regionally restricted euxassay_006798_16
TS23: tail paraxial mesenchyme Strong Regionally restricted euxassay_006798_16
Specimen euxassay_006798_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Regionally restricted euxassay_006798_17
TS23: vertebral axis musculature Strong Regionally restricted euxassay_006798_17
TS23: tongue muscle Strong Regionally restricted euxassay_006798_17
TS23: tail paraxial mesenchyme Strong Regionally restricted euxassay_006798_17
Specimen euxassay_006798_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Regionally restricted euxassay_006798_18
TS23: vertebral axis musculature Strong Regionally restricted euxassay_006798_18
TS23: tongue muscle Strong Regionally restricted euxassay_006798_18
TS23: tail paraxial mesenchyme Strong Regionally restricted euxassay_006798_18
Specimen euxassay_006798_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Regionally restricted euxassay_006798_19
TS23: vertebral axis musculature Strong Regionally restricted euxassay_006798_19
TS23: tongue muscle Strong Regionally restricted euxassay_006798_19
TS23: tarsus rest of mesenchyme Strong Regionally restricted euxassay_006798_19
TS23: upper leg muscle Strong Regionally restricted euxassay_006798_19
Specimen euxassay_006798_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Regionally restricted euxassay_006798_20
TS23: vertebral axis musculature Strong Regionally restricted euxassay_006798_20
TS23: upper leg muscle Strong Regionally restricted euxassay_006798_20
TS23: tarsus rest of mesenchyme Strong Regionally restricted euxassay_006798_20
Specimen euxassay_006798_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Regionally restricted euxassay_006798_21
TS23: vertebral axis musculature Strong Regionally restricted euxassay_006798_21
TS23: upper leg muscle Strong Regionally restricted euxassay_006798_21
TS23: tarsus rest of mesenchyme Strong Regionally restricted euxassay_006798_21
Specimen euxassay_006798_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Regionally restricted euxassay_006798_22
TS23: vertebral axis musculature Strong Regionally restricted euxassay_006798_22
TS23: upper leg muscle Strong Regionally restricted euxassay_006798_22
Specimen euxassay_006798_23: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Regionally restricted euxassay_006798_23
TS23: vertebral axis musculature Strong Regionally restricted euxassay_006798_23
TS23: upper leg muscle Strong Regionally restricted euxassay_006798_23
TS23: lower leg rest of mesenchyme Strong Regionally restricted euxassay_006798_23
Specimen euxassay_006798_24: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Regionally restricted euxassay_006798_24
TS23: vertebral axis musculature Strong Regionally restricted euxassay_006798_24
TS23: upper leg muscle Strong Regionally restricted euxassay_006798_24
TS23: lower leg rest of mesenchyme Strong Regionally restricted euxassay_006798_24
TS23: upper arm muscle Strong Regionally restricted euxassay_006798_24
