Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4824101
Gene symbol: Ccn2
Gene name: cellular communication network factor 2
Probe: MGC clone 8122
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen Table S9 - Ctgf: embryonic day 14.5 (more )
Note: The probe used to generate this data was not specified; another gene-specific probe may have been used.
Structure Level Pattern Image Note
TS23: liver Present Single cells Expression is present in single cells in which the intercellular distance between stained cells is much larger than the cell diameter of an individual cell. A thumbnail photo of the staining is contained in the table.
Specimen euxassay_004838_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_004838_01
TS23: pharyngo-tympanic tube Strong Regionally restricted euxassay_004838_01
TS23: tubotympanic recess Strong Regionally restricted euxassay_004838_01
TS23: temporal bone Strong Regionally restricted euxassay_004838_01
TS23: humerus Weak Regionally restricted euxassay_004838_01
TS23: scapula Weak Regionally restricted euxassay_004838_01
TS23: hindlimb digit 4 mesenchyme Strong Regionally restricted euxassay_004838_01
TS23: foot mesenchyme Strong Regionally restricted euxassay_004838_01
TS23: hindlimb digit 3 mesenchyme Strong Regionally restricted euxassay_004838_01
TS23: hindlimb digit 2 mesenchyme Strong Regionally restricted euxassay_004838_01
TS23: hand mesenchyme Strong Regionally restricted euxassay_004838_01
Specimen euxassay_004838_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_004838_02
TS23: temporal bone petrous part Strong Regionally restricted euxassay_004838_02
TS23: exoccipital bone Strong Regionally restricted euxassay_004838_02
TS23: vault of skull Strong Regionally restricted euxassay_004838_02
TS23: tubotympanic recess Strong Regionally restricted euxassay_004838_02
TS23: temporal bone Strong Regionally restricted euxassay_004838_02
TS23: humerus Weak Regionally restricted euxassay_004838_02
TS23: scapula Weak Regionally restricted euxassay_004838_02
TS23: lung Weak Regionally restricted euxassay_004838_02
TS23: hindlimb digit 1 phalanx Strong Regionally restricted euxassay_004838_02
TS23: hindlimb digit 2 metatarsal Strong Regionally restricted euxassay_004838_02
TS23: hindlimb digit 2 phalanx Strong Regionally restricted euxassay_004838_02
TS23: hindlimb digit 3 metatarsal Strong Regionally restricted euxassay_004838_02
TS23: hindlimb digit 3 phalanx Strong Regionally restricted euxassay_004838_02
TS23: hindlimb digit 4 phalanx Strong Regionally restricted euxassay_004838_02
TS23: hindlimb digit 4 metatarsal Strong Regionally restricted euxassay_004838_02
TS23: forelimb digit 2 phalanx Strong Regionally restricted euxassay_004838_02
TS23: forelimb digit 1 phalanx Strong Regionally restricted euxassay_004838_02
TS23: telencephalon meninges Weak Regionally restricted euxassay_004838_02
Specimen euxassay_004838_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_004838_03
TS23: temporal bone petrous part Strong Regionally restricted euxassay_004838_03
TS23: tubotympanic recess Strong Regionally restricted euxassay_004838_03
TS23: exoccipital bone Strong Regionally restricted euxassay_004838_03
TS23: humerus Moderate Regionally restricted euxassay_004838_03
TS23: lung Weak Regionally restricted euxassay_004838_03
TS23: hindlimb digit 2 phalanx Strong Regionally restricted euxassay_004838_03
TS23: hindlimb digit 3 phalanx Strong Regionally restricted euxassay_004838_03
TS23: hindlimb digit 4 phalanx Strong Regionally restricted euxassay_004838_03
TS23: hindlimb digit 5 phalanx Strong Regionally restricted euxassay_004838_03
TS23: telencephalon meninges Weak Regionally restricted euxassay_004838_03
TS23: telencephalon ventricular layer Weak Regionally restricted euxassay_004838_03
TS23: rest of cerebellum ventricular layer Weak Regionally restricted euxassay_004838_03
Specimen euxassay_004838_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_004838_04
TS23: temporal bone petrous part Strong Regionally restricted euxassay_004838_04
TS23: basisphenoid bone Strong Regionally restricted euxassay_004838_04
TS23: basioccipital bone Strong Regionally restricted euxassay_004838_04
TS23: exoccipital bone Strong Regionally restricted euxassay_004838_04
TS23: lung Weak Regionally restricted euxassay_004838_04
TS23: hindlimb digit 5 phalanx Strong Regionally restricted euxassay_004838_04
TS23: hindlimb digit 4 phalanx Strong Regionally restricted euxassay_004838_04
TS23: hindlimb digit 3 phalanx Strong Regionally restricted euxassay_004838_04
TS23: hindbrain meninges Weak Regionally restricted euxassay_004838_04
TS23: telencephalon meninges Weak Regionally restricted euxassay_004838_04
TS23: rest of cerebellum ventricular layer Weak Regionally restricted euxassay_004838_04
TS23: telencephalon ventricular layer Weak Regionally restricted euxassay_004838_04
TS23: heart ventricle Moderate Regionally restricted euxassay_004838_04
Specimen euxassay_004838_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_004838_05
TS23: otic capsule Strong Regionally restricted euxassay_004838_05
TS23: exoccipital bone Strong Regionally restricted euxassay_004838_05
TS23: orbito-sphenoid Strong Regionally restricted euxassay_004838_05
TS23: upper jaw molar Weak Regionally restricted euxassay_004838_05
TS23: lower jaw molar Weak Regionally restricted euxassay_004838_05
TS23: lung Weak Regionally restricted euxassay_004838_05
TS23: hindlimb digit 5 phalanx Strong Regionally restricted euxassay_004838_05
TS23: hindbrain meninges Weak Regionally restricted euxassay_004838_05
TS23: telencephalon meninges Weak Regionally restricted euxassay_004838_05
TS23: rest of cerebellum ventricular layer Weak Regionally restricted euxassay_004838_05
TS23: telencephalon ventricular layer Weak Regionally restricted euxassay_004838_05
TS23: heart ventricle Moderate Regionally restricted euxassay_004838_05
Specimen euxassay_004838_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_004838_06
TS23: turbinate bone primordium Strong Regionally restricted euxassay_004838_06
TS23: otic capsule Strong Regionally restricted euxassay_004838_06
TS23: midgut Moderate Regionally restricted euxassay_004838_06
TS23: orbito-sphenoid Strong Regionally restricted euxassay_004838_06
TS23: exoccipital bone Strong Regionally restricted euxassay_004838_06
TS23: lung Weak Regionally restricted euxassay_004838_06
TS23: midbrain meninges Weak Regionally restricted euxassay_004838_06
TS23: hindbrain meninges Weak Regionally restricted euxassay_004838_06
TS23: telencephalon meninges Weak Regionally restricted euxassay_004838_06
TS23: rest of cerebellum ventricular layer Weak Regionally restricted euxassay_004838_06
TS23: telencephalon ventricular layer Weak Regionally restricted euxassay_004838_06
TS23: metanephros Weak Regionally restricted euxassay_004838_06
TS23: adrenal cortex Weak Regionally restricted euxassay_004838_06
TS23: heart ventricle Moderate Regionally restricted euxassay_004838_06
Specimen euxassay_004838_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_004838_07
TS23: turbinate bone primordium Strong Regionally restricted euxassay_004838_07
TS23: otic capsule Strong Regionally restricted euxassay_004838_07
TS23: axial skeleton Weak Regionally restricted euxassay_004838_07
TS23: clavicle Moderate Regionally restricted euxassay_004838_07
TS23: pelvic girdle skeleton Strong Regionally restricted euxassay_004838_07
TS23: midgut Moderate Regionally restricted euxassay_004838_07
TS23: orbito-sphenoid Strong Regionally restricted euxassay_004838_07
TS23: lung Weak Regionally restricted euxassay_004838_07
TS23: diencephalon meninges Weak Regionally restricted euxassay_004838_07
TS23: telencephalon meninges Weak Regionally restricted euxassay_004838_07
TS23: hindbrain meninges Weak Regionally restricted euxassay_004838_07
TS23: midbrain meninges Weak Regionally restricted euxassay_004838_07
TS23: spinal cord meninges Weak Regionally restricted euxassay_004838_07
TS23: rest of cerebellum ventricular layer Weak Regionally restricted euxassay_004838_07
TS23: pons ventricular layer Weak Regionally restricted euxassay_004838_07
TS23: telencephalon ventricular layer Weak Regionally restricted euxassay_004838_07
TS23: metanephros Weak Regionally restricted euxassay_004838_07
TS23: adrenal cortex Weak Regionally restricted euxassay_004838_07
TS23: heart ventricle Moderate Regionally restricted euxassay_004838_07
Specimen euxassay_004838_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_004838_08
TS23: turbinate bone primordium Strong Regionally restricted euxassay_004838_08
TS23: otic capsule Strong Regionally restricted euxassay_004838_08
TS23: tongue muscle Moderate Regionally restricted euxassay_004838_08
TS23: aorta Strong Regionally restricted euxassay_004838_08
TS23: laryngeal cartilage Strong Regionally restricted euxassay_004838_08
TS23: axial skeleton Moderate Regionally restricted euxassay_004838_08
TS23: clavicle Moderate Regionally restricted euxassay_004838_08
TS23: pelvic girdle skeleton Moderate Regionally restricted euxassay_004838_08
TS23: midgut Moderate Regionally restricted euxassay_004838_08
TS23: upper jaw incisor Moderate Regionally restricted euxassay_004838_08
TS23: lower jaw incisor Moderate Regionally restricted euxassay_004838_08
TS23: lung Weak Regionally restricted euxassay_004838_08
TS23: spinal cord ventricular layer Moderate Single cells euxassay_004838_08
TS23: spinal cord meninges Weak Regionally restricted euxassay_004838_08
TS23: midbrain meninges Weak Regionally restricted euxassay_004838_08
TS23: hindbrain meninges Weak Regionally restricted euxassay_004838_08
TS23: telencephalon meninges Weak Regionally restricted euxassay_004838_08
TS23: diencephalon meninges Weak Regionally restricted euxassay_004838_08
TS23: pons ventricular layer Weak Regionally restricted euxassay_004838_08
TS23: heart ventricle Moderate Regionally restricted euxassay_004838_08
Specimen euxassay_004838_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_004838_09
TS23: turbinate bone primordium Strong Regionally restricted euxassay_004838_09
TS23: tongue muscle Moderate Regionally restricted euxassay_004838_09
TS23: aorta Strong Regionally restricted euxassay_004838_09
TS23: thyroid cartilage Strong Regionally restricted euxassay_004838_09
TS23: cricoid cartilage Strong Regionally restricted euxassay_004838_09
TS23: axial skeleton Moderate Regionally restricted euxassay_004838_09
TS23: palatal shelf Weak Regionally restricted euxassay_004838_09
TS23: sternum Strong Regionally restricted euxassay_004838_09
TS23: midgut Moderate Regionally restricted euxassay_004838_09
TS23: orbito-sphenoid Strong Regionally restricted euxassay_004838_09
TS23: lower jaw incisor Moderate Regionally restricted euxassay_004838_09
TS23: upper jaw incisor Moderate Regionally restricted euxassay_004838_09
TS23: lung Weak Regionally restricted euxassay_004838_09
TS23: spinal cord ventricular layer Moderate Single cells euxassay_004838_09
TS23: spinal cord meninges Weak Regionally restricted euxassay_004838_09
TS23: midbrain meninges Weak Regionally restricted euxassay_004838_09
TS23: hindbrain meninges Weak Regionally restricted euxassay_004838_09
TS23: telencephalon meninges Weak Regionally restricted euxassay_004838_09
TS23: diencephalon meninges Weak Regionally restricted euxassay_004838_09
TS23: pons ventricular layer Weak Regionally restricted euxassay_004838_09
TS23: bladder Weak Regionally restricted euxassay_004838_09
TS23: heart ventricle Moderate Regionally restricted euxassay_004838_09
Specimen euxassay_004838_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: turbinate bone primordium Strong Regionally restricted euxassay_004838_10
TS23: tongue muscle Moderate Regionally restricted euxassay_004838_10
TS23: aorta Strong Regionally restricted euxassay_004838_10
TS23: trachea Strong Regionally restricted euxassay_004838_10
TS23: thyroid cartilage Strong Regionally restricted euxassay_004838_10
TS23: axial skeleton Moderate Regionally restricted euxassay_004838_10
TS23: palatal shelf Moderate Regionally restricted euxassay_004838_10
TS23: sternum Strong Regionally restricted euxassay_004838_10
TS23: midgut Moderate Regionally restricted euxassay_004838_10
TS23: orbito-sphenoid Strong Regionally restricted euxassay_004838_10
TS23: lower jaw incisor Moderate Regionally restricted euxassay_004838_10
TS23: lung Weak Regionally restricted euxassay_004838_10
TS23: spinal cord ventricular layer Moderate Single cells euxassay_004838_10
TS23: spinal cord meninges Weak Regionally restricted euxassay_004838_10
TS23: midbrain meninges Weak Regionally restricted euxassay_004838_10
TS23: hindbrain meninges Weak Regionally restricted euxassay_004838_10
TS23: telencephalon meninges Weak Regionally restricted euxassay_004838_10
TS23: diencephalon meninges Weak Regionally restricted euxassay_004838_10
TS23: bladder Weak Regionally restricted euxassay_004838_10
TS23: heart ventricle Moderate Regionally restricted euxassay_004838_10
Specimen euxassay_004838_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_004838_11
TS23: nasal septum Strong Regionally restricted euxassay_004838_11
TS23: vomeronasal organ Strong Regionally restricted euxassay_004838_11
TS23: tongue muscle Moderate Regionally restricted euxassay_004838_11
TS23: aorta Strong Regionally restricted euxassay_004838_11
TS23: trachea Strong Regionally restricted euxassay_004838_11
TS23: cricoid cartilage Strong Regionally restricted euxassay_004838_11
TS23: thyroid cartilage Strong Regionally restricted euxassay_004838_11
TS23: axial skeleton tail region Strong Regionally restricted euxassay_004838_11
TS23: axial skeleton Moderate Regionally restricted euxassay_004838_11
TS23: palatal shelf Moderate Regionally restricted euxassay_004838_11
TS23: sternum Strong Regionally restricted euxassay_004838_11
TS23: midgut Moderate Regionally restricted euxassay_004838_11
TS23: orbito-sphenoid Strong Regionally restricted euxassay_004838_11
TS23: lung Weak Regionally restricted euxassay_004838_11
TS23: spinal cord ventricular layer Moderate Single cells euxassay_004838_11
TS23: spinal cord meninges Weak Regionally restricted euxassay_004838_11
TS23: midbrain meninges Weak Regionally restricted euxassay_004838_11
TS23: hindbrain meninges Weak Regionally restricted euxassay_004838_11
TS23: telencephalon meninges Weak Regionally restricted euxassay_004838_11
TS23: diencephalon meninges Weak Regionally restricted euxassay_004838_11
TS23: diencephalon lateral wall ventricular layer Weak Regionally restricted euxassay_004838_11
TS23: bladder Weak Regionally restricted euxassay_004838_11
TS23: heart ventricle Moderate Regionally restricted euxassay_004838_11
Specimen euxassay_004838_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_004838_12
TS23: vomeronasal organ Strong Regionally restricted euxassay_004838_12
TS23: nasal septum Strong Regionally restricted euxassay_004838_12
TS23: cricoid cartilage Strong Regionally restricted euxassay_004838_12
TS23: axial skeleton tail region Strong Regionally restricted euxassay_004838_12
TS23: axial skeleton Moderate Regionally restricted euxassay_004838_12
TS23: clavicle Moderate Regionally restricted euxassay_004838_12
TS23: midgut Moderate Regionally restricted euxassay_004838_12
TS23: orbito-sphenoid Strong Regionally restricted euxassay_004838_12
TS23: lung Weak Regionally restricted euxassay_004838_12
TS23: spinal cord ventricular layer Moderate Single cells euxassay_004838_12
TS23: spinal cord meninges Weak Regionally restricted euxassay_004838_12
TS23: midbrain meninges Weak Regionally restricted euxassay_004838_12
TS23: hindbrain meninges Weak Regionally restricted euxassay_004838_12
TS23: telencephalon meninges Weak Regionally restricted euxassay_004838_12
TS23: diencephalon meninges Weak Regionally restricted euxassay_004838_12
TS23: diencephalon lateral wall ventricular layer Weak Regionally restricted euxassay_004838_12
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_004838_12
TS23: bladder Weak Regionally restricted euxassay_004838_12
TS23: heart ventricle Weak Regionally restricted euxassay_004838_12
Specimen euxassay_004838_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: turbinate bone primordium Strong Regionally restricted euxassay_004838_13
TS23: otic capsule Strong Regionally restricted euxassay_004838_13
TS23: pelvic girdle skeleton Strong Regionally restricted euxassay_004838_13
TS23: midgut Moderate Regionally restricted euxassay_004838_13
TS23: lung Weak Regionally restricted euxassay_004838_13
TS23: midbrain meninges Weak Regionally restricted euxassay_004838_13
TS23: hindbrain meninges Weak Regionally restricted euxassay_004838_13
TS23: telencephalon meninges Weak Regionally restricted euxassay_004838_13
TS23: diencephalon meninges Weak Regionally restricted euxassay_004838_13
TS23: spinal cord meninges Weak Regionally restricted euxassay_004838_13
TS23: pons ventricular layer Weak Regionally restricted euxassay_004838_13
TS23: metanephros Weak Regionally restricted euxassay_004838_13
TS23: adrenal cortex Weak Regionally restricted euxassay_004838_13
TS23: heart ventricle Weak Regionally restricted euxassay_004838_13
Specimen euxassay_004838_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_004838_14
TS23: turbinate bone primordium Strong Regionally restricted euxassay_004838_14
TS23: otic capsule Strong Regionally restricted euxassay_004838_14
TS23: pelvic girdle skeleton Strong Regionally restricted euxassay_004838_14
TS23: upper jaw molar Weak Regionally restricted euxassay_004838_14
TS23: lower jaw molar Weak Regionally restricted euxassay_004838_14
TS23: lung Weak Regionally restricted euxassay_004838_14
TS23: midbrain meninges Weak Regionally restricted euxassay_004838_14
TS23: hindbrain meninges Weak Regionally restricted euxassay_004838_14
TS23: telencephalon meninges Weak Regionally restricted euxassay_004838_14
TS23: diencephalon meninges Weak Regionally restricted euxassay_004838_14
TS23: pons ventricular layer Weak Regionally restricted euxassay_004838_14
TS23: metanephros Weak Regionally restricted euxassay_004838_14
TS23: adrenal cortex Weak Regionally restricted euxassay_004838_14
TS23: heart ventricle Weak Regionally restricted euxassay_004838_14
Specimen euxassay_004838_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_004838_15
TS23: turbinate bone primordium Strong Regionally restricted euxassay_004838_15
TS23: otic capsule Strong Regionally restricted euxassay_004838_15
TS23: orbito-sphenoid Strong Regionally restricted euxassay_004838_15
TS23: upper jaw molar Weak Regionally restricted euxassay_004838_15
TS23: lower jaw molar Weak Regionally restricted euxassay_004838_15
TS23: lung Weak Regionally restricted euxassay_004838_15
TS23: hindlimb digit 5 phalanx Strong Regionally restricted euxassay_004838_15
TS23: hindlimb digit 4 phalanx Strong Regionally restricted euxassay_004838_15
TS23: midbrain meninges Weak Regionally restricted euxassay_004838_15
TS23: hindbrain meninges Weak Regionally restricted euxassay_004838_15
TS23: telencephalon meninges Weak Regionally restricted euxassay_004838_15
TS23: diencephalon meninges Weak Regionally restricted euxassay_004838_15
TS23: metanephros Weak Regionally restricted euxassay_004838_15
TS23: adrenal cortex Weak Regionally restricted euxassay_004838_15
Specimen euxassay_004838_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_004838_16
TS23: orbito-sphenoid Strong Regionally restricted euxassay_004838_16
TS23: exoccipital bone Strong Regionally restricted euxassay_004838_16
TS23: basioccipital bone Strong Regionally restricted euxassay_004838_16
TS23: temporal bone petrous part Strong Regionally restricted euxassay_004838_16
TS23: humerus Moderate Regionally restricted euxassay_004838_16
TS23: scapula Weak Regionally restricted euxassay_004838_16
TS23: lung Weak Regionally restricted euxassay_004838_16
TS23: midbrain meninges Moderate Regionally restricted euxassay_004838_16
TS23: hindbrain meninges Moderate Regionally restricted euxassay_004838_16
TS23: telencephalon meninges Moderate Regionally restricted euxassay_004838_16
TS23: rest of cerebellum ventricular layer Weak Regionally restricted euxassay_004838_16
TS23: telencephalon ventricular layer Weak Regionally restricted euxassay_004838_16
Specimen euxassay_004838_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_004838_17
TS23: tubotympanic recess Strong Regionally restricted euxassay_004838_17
TS23: temporal bone petrous part Strong Regionally restricted euxassay_004838_17
TS23: orbito-sphenoid Strong Regionally restricted euxassay_004838_17
TS23: exoccipital bone Strong Regionally restricted euxassay_004838_17
TS23: humerus Weak Regionally restricted euxassay_004838_17
TS23: hindlimb digit 1 metatarsal Strong Regionally restricted euxassay_004838_17
TS23: hindlimb digit 1 phalanx Strong Regionally restricted euxassay_004838_17
TS23: hindlimb digit 2 metatarsal Strong Regionally restricted euxassay_004838_17
TS23: hindlimb digit 2 phalanx Strong Regionally restricted euxassay_004838_17
TS23: hindlimb digit 4 metatarsal Strong Regionally restricted euxassay_004838_17
TS23: hindlimb digit 4 phalanx Strong Regionally restricted euxassay_004838_17
TS23: hindlimb digit 3 phalanx Strong Regionally restricted euxassay_004838_17
TS23: hindlimb digit 3 metatarsal Strong Regionally restricted euxassay_004838_17
TS23: hindlimb digit 5 metatarsal Strong Regionally restricted euxassay_004838_17
TS23: hindlimb digit 5 phalanx Strong Regionally restricted euxassay_004838_17
TS23: midbrain meninges Moderate Regionally restricted euxassay_004838_17
TS23: hindbrain meninges Moderate Regionally restricted euxassay_004838_17
TS23: telencephalon meninges Moderate Regionally restricted euxassay_004838_17
TS23: rest of cerebellum ventricular layer Weak Regionally restricted euxassay_004838_17
TS23: telencephalon ventricular layer Weak Regionally restricted euxassay_004838_17
Specimen euxassay_004838_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_004838_18
TS23: pharyngo-tympanic tube Strong Regionally restricted euxassay_004838_18
TS23: tubotympanic recess Strong Regionally restricted euxassay_004838_18
TS23: temporal bone petrous part Strong Regionally restricted euxassay_004838_18
TS23: exoccipital bone Strong Regionally restricted euxassay_004838_18
TS23: humerus Weak Regionally restricted euxassay_004838_18
TS23: scapula Weak Regionally restricted euxassay_004838_18
TS23: foot mesenchyme Strong Regionally restricted euxassay_004838_18
TS23: hindlimb digit 2 metatarsal Strong Regionally restricted euxassay_004838_18
TS23: hindlimb digit 2 phalanx Strong Regionally restricted euxassay_004838_18
TS23: hindlimb digit 1 metatarsal Strong Regionally restricted euxassay_004838_18
TS23: hindlimb digit 3 metatarsal Strong Regionally restricted euxassay_004838_18
TS23: hindlimb digit 3 phalanx Strong Regionally restricted euxassay_004838_18
TS23: hindlimb digit 4 phalanx Strong Regionally restricted euxassay_004838_18
TS23: hindlimb digit 4 metatarsal Strong Regionally restricted euxassay_004838_18
TS23: forelimb digit 2 phalanx Strong Regionally restricted euxassay_004838_18
TS23: forelimb digit 1 phalanx Strong Regionally restricted euxassay_004838_18
TS23: telencephalon meninges Moderate Regionally restricted euxassay_004838_18
TS23: midbrain meninges Moderate Regionally restricted euxassay_004838_18
TS23: hindbrain meninges Moderate Regionally restricted euxassay_004838_18
TS23: rest of cerebellum ventricular layer Weak Regionally restricted euxassay_004838_18
TS23: telencephalon ventricular layer Weak Regionally restricted euxassay_004838_18
Specimen euxassay_004838_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_004838_19
TS23: pharyngo-tympanic tube Moderate Regionally restricted euxassay_004838_19
TS23: tubotympanic recess Strong Regionally restricted euxassay_004838_19
TS23: temporal bone petrous part Strong Regionally restricted euxassay_004838_19
TS23: exoccipital bone Strong Regionally restricted euxassay_004838_19
TS23: humerus Weak Regionally restricted euxassay_004838_19
TS23: scapula Weak Regionally restricted euxassay_004838_19
TS23: tibia Moderate Regionally restricted euxassay_004838_19
TS23: fibula Moderate Regionally restricted euxassay_004838_19
TS23: forelimb digit 2 phalanx Strong Regionally restricted euxassay_004838_19
TS23: forelimb digit 1 phalanx Strong Regionally restricted euxassay_004838_19
TS23: telencephalon meninges Moderate Regionally restricted euxassay_004838_19
TS23: rest of cerebellum ventricular layer Weak Regionally restricted euxassay_004838_19
TS23: telencephalon ventricular layer Weak Regionally restricted euxassay_004838_19
Specimen euxassay_004838_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_004838_20
TS23: pharyngo-tympanic tube Moderate Regionally restricted euxassay_004838_20
TS23: tubotympanic recess Strong Regionally restricted euxassay_004838_20
TS23: exoccipital bone Strong Regionally restricted euxassay_004838_20
TS23: temporal bone petrous part Strong Regionally restricted euxassay_004838_20
TS23: humerus Weak Regionally restricted euxassay_004838_20
TS23: scapula Weak Regionally restricted euxassay_004838_20
TS23: tibia Weak Regionally restricted euxassay_004838_20
TS23: fibula Weak Regionally restricted euxassay_004838_20
TS23: hand mesenchyme Strong Regionally restricted euxassay_004838_20
TS23: telencephalon meninges Moderate Regionally restricted euxassay_004838_20
TS23: telencephalon ventricular layer Weak Regionally restricted euxassay_004838_20
Specimen euxassay_004838_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_004838_21
TS23: pharyngo-tympanic tube Strong Regionally restricted euxassay_004838_21
TS23: exoccipital bone Strong Regionally restricted euxassay_004838_21
TS23: temporal bone petrous part Strong Regionally restricted euxassay_004838_21
TS23: tibia Weak Regionally restricted euxassay_004838_21
TS23: fibula Weak Regionally restricted euxassay_004838_21
TS23: hand mesenchyme Strong Regionally restricted euxassay_004838_21
TS23: telencephalon meninges Moderate Regionally restricted euxassay_004838_21
Specimen euxassay_004838_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: pharyngo-tympanic tube Strong Regionally restricted euxassay_004838_22
TS23: telencephalon meninges Moderate Regionally restricted euxassay_004838_22
Contributing Projects:
Mouse Genome Database (MGD), Gene Expression Database (GXD), Mouse Models of Human Cancer database (MMHCdb) (formerly Mouse Tumor Biology (MTB)), Gene Ontology (GO)
Citing These Resources
Funding Information
Warranty Disclaimer, Privacy Notice, Licensing, & Copyright
Send questions and comments to User Support. 		last database update
03/25/2025
MGI 6.24 		The Jackson Laboratory
