Gene Expression Data
Assay Details
Assay
Reference: J:116004 Haines BP, et al., Developmentally regulated expression of the LRRTM gene family during mid-gestation mouse embryogenesis. Gene Expr Patterns. 2007 Jan;7(1-2):23-9
Assay type: RNA in situ
MGI Accession ID: MGI:3694270
Gene symbol: Lrrtm1
Gene name: leucine rich repeat transmembrane neuronal 1
Probe: Lrrtm1 cDNA
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Results
Specimen 1A: embryonic day 9.0 (more )
Structure Level Pattern Image Note
TS14: forelimb bud ectoderm Present 1A
TS14: neural tube Present 1A
TS14: prosencephalon Present 1A
TS14: future midbrain Present Regionally restricted 1A Expression has a sharp boundary across the central midbrain.
Specimen 1B: embryonic day 9.0 (more )
Note: An alternate view of the head of the embryo in A.
Structure Level Pattern Image Note
TS14: prosencephalon Present 1B
TS14: future midbrain Present Regionally restricted 1B Expression has a sharp boundary across the central midbrain.
Specimen 1C: embryonic day 9.0 (more )
Structure Level Pattern Image Note
TS14: forelimb bud ectoderm Present 1C
Specimen 1D: embryonic day 9.0 (more )
Structure Level Pattern Image Note
TS14: forelimb bud ectoderm Present 1D
Specimen 1E: embryonic day 9.0 (more )
Structure Level Pattern Image Note
TS14: otic placode Present Regionally restricted 1E Expression is in the dorsal otic vesicle.
Specimen 1F: embryonic day 9.0 (more )
Structure Level Pattern Image Note
TS14: otic placode Present Regionally restricted 1F Expression is in the dorsal otic vesicle in the presumptive endolymphatic appendage.
Specimen 1G: embryonic day 9.0 (more )
Note: G, H and I are sections through the embryo in A.
Structure Level Pattern Image Note
TS14: future hindbrain Present 1G
TS14: prosencephalon Present 1G
TS14: future midbrain Present Regionally restricted 1G Expression has a sharp boundary across the central midbrain.
Specimen 1H: embryonic day 9.0 (more )
Note: G, H and I are sections through the embryo in A.
Structure Level Pattern Image Note
TS14: neural tube lateral wall Present Regionally restricted 1H Expression is in central neural progenitors with two areas of stronger expression ventrally, possibly in more differentiated neural cells.
Specimen 1I: embryonic day 9.0 (more )
Note: G, H and I are sections through the embryo in A.
Structure Level Pattern Image Note
TS14: neural tube lateral wall Present 1I Expression is in the ventricular layer of the central neural tube.
Specimen 1J: embryonic day 10.0 (more )
Structure Level Pattern Image Note
TS16: forelimb bud apical ectodermal ridge Present 1J
TS16: future forebrain Present 1J
TS16: future midbrain Present 1J
TS16: hindlimb bud ectoderm Present Regionally restricted 1J Expression is in the apical ectodermal ridge.
Specimen 1K: embryonic day 10.0 (more )
Structure Level Pattern Image Note
TS16: future forebrain Present 1K
TS16: future midbrain Present Regionally restricted 1K There is a a sharp boundary in the midbrain.
Specimen 1L: embryonic day 10.0 (more )
Structure Level Pattern Image Note
TS16: otocyst Present Regionally restricted 1L Expression is in the endolymphatic diverticular appendage of the otic vesicle.
Specimen 1M: embryonic day 10.0 (more )
Structure Level Pattern Image Note
TS16: otocyst Present Regionally restricted 1M Expression is in the endolymphatic diverticular appendage of the otic vesicle.
Specimen 1N: embryonic day 10.0 (more )
Structure Level Pattern Image Note
TS16: forelimb bud apical ectodermal ridge Present 1N
Specimen 1O: embryonic day 10.0 (more )
Structure Level Pattern Image Note
TS16: neural tube lateral wall Present Regionally restricted 1O Expression is in the ventricular layer of the central neural tube.
Specimen 1P: embryonic day 10.0 (more )
Structure Level Pattern Image Note
TS16: neural tube lateral wall Present Regionally restricted 1P Expression is in the ventricular layer of the central neural tube.
Specimen 1Q: embryonic day 11.0 (more )
Structure Level Pattern Image Note
TS18: endolymphatic appendage Present 1Q
TS18: forebrain Present 1Q
TS18: forelimb bud apical ectodermal ridge Present 1Q
TS18: hindlimb bud apical ectodermal ridge Present 1Q
TS18: midbrain Present 1Q
