Gene Expression Data
Assay Details
Assay
Reference: J:177786 Kaufmann LT, et al., Gadd45a, Gadd45b and Gadd45g expression during mouse embryonic development. Gene Expr Patterns. 2011 Dec;11(8):465-70
Assay type: RNA in situ
MGI Accession ID: MGI:5306772
Gene symbol: Gadd45b
Gene name: growth arrest and DNA-damage-inducible 45 beta
Probe: Gadd45b cDNA
Probe preparation: Antisense RNA labelled with digoxigenin
Results
Specimen 3A: embryonic day 7.5 (more )
Structure Level Pattern Image Note
TS11: chorion Present 3A
TS11: embryo Absent 3A

Specimen 3B: embryonic day 8.5 (more )
Structure Level Pattern Image Note
TS13: future hindbrain Weak Diffuse 3B
TS13: future midbrain Weak Diffuse 3B
TS13: heart Present Regionally restricted 3B Expression is in the anterior heart field.
TS13: somite Present Regionally restricted 3B Expression is in the first forming somites.
TS13: primitive streak Present Regionally restricted 3B Expression is in the posterior remnant.

Specimen 3C: embryonic day 8.75 (more )
Structure Level Pattern Image Note
TS14: future midbrain Present Regionally restricted 3C Expression is in the dorsal midbrain.
TS14: trunk somite Present Regionally restricted 3C Expression is in the first epithelial somites.

Specimen 3D: embryonic day 8.75 (more )
Structure Level Pattern Image Note
TS14: future midbrain Present Regionally restricted 3D Expression is in the dorsal midbrain.
TS14: trunk somite Present Regionally restricted 3D Expression is in the first epithelial somites.

Specimen 3E: embryonic day 9.0 (more )
Structure Level Pattern Image Note
TS14: dorsal aorta Present 3E
TS14: arterial system Present Regionally restricted 3E Expression is in branchial arch arteries.

Specimen 3F,I,J: embryonic day 9.5 (more )
Note: The dashed boxes in F indicate the regions magnified in I, and J.
Structure Level Pattern Image Note
TS15: dorsal aorta Present 3F , 3I , 3J
TS15: branchial arch artery Present 3F , 3J , 3I

Specimen 3G: embryonic day 9.5 (more )
Structure Level Pattern Image Note
TS15: dorsal aorta Present 3G

Specimen 3H: embryonic day 9.5 (more )
Structure Level Pattern Image Note
TS15: dorsal aorta Present 3H

Specimen 3L: embryonic day 10.5 (more )
Structure Level Pattern Image Note
TS17: forelimb bud Present 3L
TS17: trunk somite Present 3L
TS17: 1st branchial arch Present Regionally restricted 3L Expression is in the tip.

Specimen 3M: embryonic day 10.5 (more )
Structure Level Pattern Image Note
TS17: 1st branchial arch Present Regionally restricted 3M Expression is in the tip.
TS17: forelimb bud Present 3M

Specimen 3N,O: embryonic day 10.5 (more )
Note: The dashed box in N indicates the regions magnified in O.
Structure Level Pattern Image Note
TS17: trunk somite Present 3O , 3N
TS17: forelimb bud Present Regionally restricted 3N , 3O Expression is in the anterior necrotic zone and the zone of polarizing activity.

Specimen Table 1 E6.6-E7.5: embryonic day 7.5 (more )
Structure Level Pattern Image Note
TS11: chorion Strong

Specimen Table 1 E8.5: embryonic day 8.5 (more )
Structure Level Pattern Image Note
TS13: arterial system Weak
TS13: future brain Weak
TS13: somite Weak

Specimen Table 1 E9.5: embryonic day 9.5 (more )
Structure Level Pattern Image Note
TS15: future midbrain Weak Regionally restricted Expression is in the dosal midbrain.
TS15: branchial arch artery Weak
TS15: dorsal aorta Weak
TS15: somite Weak Regionally restricted Expression is in the most caudal somites.

Specimen Table 1 E10.5: embryonic day 10.5 (more )
Structure Level Pattern Image Note
TS17: telencephalon Weak
TS17: trunk somite Weak
TS17: forelimb bud mesenchyme Moderate Regionally restricted Moderate in the anterior necrotic zone and weak in the zone of polarizing activity.
