Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4827832
Gene symbol: Rtn4rl2
Gene name: reticulon 4 receptor-like 2
Modification date: 09/14/2010
Probe: T39061
Probe preparation: Antisense RNA labelled with digoxigenin
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_013217_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013217_02

Specimen euxassay_013217_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_013217_03
TS23: facial ganglion Weak Regionally restricted euxassay_013217_03
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013217_03

Specimen euxassay_013217_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_013217_04
TS23: facial ganglion Weak Regionally restricted euxassay_013217_04
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013217_04

Specimen euxassay_013217_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_013217_05
TS23: facial ganglion Weak Regionally restricted euxassay_013217_05
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013217_05

Specimen euxassay_013217_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_013217_06
TS23: vestibulo-cochlear ganglion Weak Regionally restricted euxassay_013217_06
TS23: glossopharyngeal ganglion Weak Regionally restricted euxassay_013217_06
TS23: dorsal root ganglion Weak Regionally restricted euxassay_013217_06
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013217_06

Specimen euxassay_013217_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: glossopharyngeal ganglion Weak Regionally restricted euxassay_013217_07
TS23: trigeminal ganglion Weak Regionally restricted euxassay_013217_07
TS23: vestibulo-cochlear ganglion Weak Regionally restricted euxassay_013217_07
TS23: dorsal root ganglion Weak Regionally restricted euxassay_013217_07
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013217_07

Specimen euxassay_013217_08: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_013217_08
TS23: dorsal root ganglion Weak Regionally restricted euxassay_013217_08
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013217_08
TS23: medulla oblongata basal plate mantle layer Weak Regionally restricted euxassay_013217_08 facial motor nucleus

Specimen euxassay_013217_09: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: dorsal root ganglion Weak Regionally restricted euxassay_013217_09
TS23: medulla oblongata basal plate mantle layer Weak Regionally restricted euxassay_013217_09 facial motor nucleus

Specimen euxassay_013217_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Weak Regionally restricted euxassay_013217_10
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013217_10
TS23: olfactory cortex marginal layer Weak Regionally restricted euxassay_013217_10

Specimen euxassay_013217_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Weak Regionally restricted euxassay_013217_11
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013217_11
TS23: olfactory cortex marginal layer Weak Regionally restricted euxassay_013217_11

Specimen euxassay_013217_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Weak Regionally restricted euxassay_013217_12
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013217_12
TS23: olfactory cortex marginal layer Weak Regionally restricted euxassay_013217_12

Specimen euxassay_013217_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013217_13

Specimen euxassay_013217_15: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: dorsal root ganglion Weak Regionally restricted euxassay_013217_15
TS23: olfactory cortex marginal layer Weak Regionally restricted euxassay_013217_15
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013217_15
TS23: medulla oblongata basal plate mantle layer Weak Regionally restricted euxassay_013217_15 facial motor nucleus

Specimen euxassay_013217_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Weak Regionally restricted euxassay_013217_16

Specimen euxassay_013217_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_013217_17
TS23: vestibulo-cochlear ganglion Weak Regionally restricted euxassay_013217_17
TS23: glossopharyngeal ganglion Weak Regionally restricted euxassay_013217_17
TS23: dorsal root ganglion Weak Regionally restricted euxassay_013217_17
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013217_17

Specimen euxassay_013217_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_013217_18
TS23: facial ganglion Weak Regionally restricted euxassay_013217_18
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013217_18

Specimen euxassay_013217_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_013217_19
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013217_19

Specimen euxassay_013217_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_013217_20
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013217_20

Specimen euxassay_013217_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013217_21

Specimen euxassay_013217_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013217_22

Specimen euxassay_013217_23: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_013217_23
