Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4825223
Gene symbol: Grhl2
Gene name: grainyhead like transcription factor 2
Probe: MGC clone 62708
Probe preparation: Antisense RNA labelled with digoxigenin
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_004631_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: pharyngo-tympanic tube Moderate Regionally restricted euxassay_004631_01
TS23: cornea epithelium Moderate Regionally restricted euxassay_004631_01
TS23: stomach Moderate Regionally restricted euxassay_004631_01

Specimen euxassay_004631_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: pharyngo-tympanic tube Moderate Regionally restricted euxassay_004631_02
TS23: cornea epithelium Moderate Regionally restricted euxassay_004631_02
TS23: stomach Moderate Regionally restricted euxassay_004631_02
TS23: cochlea Weak Regionally restricted euxassay_004631_02

Specimen euxassay_004631_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: pharyngo-tympanic tube Moderate Regionally restricted euxassay_004631_03
TS23: cornea epithelium Moderate Regionally restricted euxassay_004631_03
TS23: stomach Moderate Regionally restricted euxassay_004631_03
TS23: left lung Weak Regionally restricted euxassay_004631_03
TS23: cochlea Weak Regionally restricted euxassay_004631_03

Specimen euxassay_004631_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: pharyngo-tympanic tube Moderate Regionally restricted euxassay_004631_04
TS23: vibrissa Moderate Regionally restricted euxassay_004631_04
TS23: stomach Moderate Regionally restricted euxassay_004631_04
TS23: left lung Weak Regionally restricted euxassay_004631_04
TS23: cochlea Weak Regionally restricted euxassay_004631_04

Specimen euxassay_004631_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: pharyngo-tympanic tube Moderate Regionally restricted euxassay_004631_05
TS23: vibrissa Strong Regionally restricted euxassay_004631_05
TS23: oral epithelium Strong Regionally restricted euxassay_004631_05
TS23: stomach Moderate Regionally restricted euxassay_004631_05
TS23: left lung Strong Regionally restricted euxassay_004631_05
TS23: renal calyx Moderate Regionally restricted euxassay_004631_05
TS23: cochlea Strong Regionally restricted euxassay_004631_05

Specimen euxassay_004631_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: pharyngo-tympanic tube Moderate Regionally restricted euxassay_004631_06
TS23: vibrissa Strong Regionally restricted euxassay_004631_06
TS23: lower jaw molar Strong Regionally restricted euxassay_004631_06
TS23: upper jaw molar Strong Regionally restricted euxassay_004631_06
TS23: oral epithelium Strong Regionally restricted euxassay_004631_06
TS23: stomach Moderate Regionally restricted euxassay_004631_06
TS23: left lung Strong Regionally restricted euxassay_004631_06
TS23: renal calyx Weak Regionally restricted euxassay_004631_06
TS23: submandibular gland primordium Strong Regionally restricted euxassay_004631_06
TS23: cochlea Strong Regionally restricted euxassay_004631_06

Specimen euxassay_004631_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: pharyngo-tympanic tube Moderate Regionally restricted euxassay_004631_07
TS23: vibrissa Strong Regionally restricted euxassay_004631_07
TS23: oral epithelium Strong Regionally restricted euxassay_004631_07
TS23: lower jaw molar Strong Regionally restricted euxassay_004631_07
TS23: stomach Moderate Regionally restricted euxassay_004631_07
TS23: left lung Strong Regionally restricted euxassay_004631_07
TS23: renal calyx Weak Regionally restricted euxassay_004631_07
TS23: olfactory epithelium Strong Regionally restricted euxassay_004631_07
TS23: submandibular gland primordium Strong Regionally restricted euxassay_004631_07
TS23: pancreas Weak Regionally restricted euxassay_004631_07
TS23: cochlea Moderate Regionally restricted euxassay_004631_07

Specimen euxassay_004631_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: oral epithelium Strong Regionally restricted euxassay_004631_08
TS23: stomach Moderate Regionally restricted euxassay_004631_08
TS23: left lung Strong Regionally restricted euxassay_004631_08
TS23: renal calyx Weak Regionally restricted euxassay_004631_08
TS23: olfactory epithelium Strong Regionally restricted euxassay_004631_08
TS23: submandibular gland primordium Strong Regionally restricted euxassay_004631_08
TS23: pancreas Weak Regionally restricted euxassay_004631_08
TS23: cochlea Moderate Regionally restricted euxassay_004631_08

Specimen euxassay_004631_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: oral epithelium Strong Regionally restricted euxassay_004631_09
TS23: stomach Moderate Regionally restricted euxassay_004631_09
TS23: midgut loop Strong Regionally restricted euxassay_004631_09
TS23: left lung Strong Regionally restricted euxassay_004631_09
TS23: renal calyx Weak Regionally restricted euxassay_004631_09
TS23: olfactory epithelium Strong Regionally restricted euxassay_004631_09
TS23: submandibular gland primordium Strong Regionally restricted euxassay_004631_09
TS23: pancreas Weak Regionally restricted euxassay_004631_09
TS23: cochlea Strong Regionally restricted euxassay_004631_09

Specimen euxassay_004631_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lower jaw incisor Strong Regionally restricted euxassay_004631_10
TS23: oral epithelium Strong Regionally restricted euxassay_004631_10
TS23: upper jaw incisor Strong Regionally restricted euxassay_004631_10
TS23: midgut loop Strong Regionally restricted euxassay_004631_10
TS23: rectum Strong Regionally restricted euxassay_004631_10
TS23: left lung Strong Regionally restricted euxassay_004631_10
TS23: olfactory epithelium Strong Regionally restricted euxassay_004631_10
TS23: pancreas Weak Regionally restricted euxassay_004631_10
TS23: bladder fundus Strong Regionally restricted euxassay_004631_10
TS23: urethra Strong Regionally restricted euxassay_004631_10 Originally this result was annotated to a male-specific term, but as the specimen was not sexed, it is likely the data annotator intended to use a non-gender specific term.
TS23: adenohypophysis Weak Regionally restricted euxassay_004631_10
TS23: thyroid gland Weak Uniform euxassay_004631_10

Specimen euxassay_004631_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: oral epithelium Strong Regionally restricted euxassay_004631_11
TS23: lower jaw incisor Strong Regionally restricted euxassay_004631_11
TS23: upper jaw incisor Strong Regionally restricted euxassay_004631_11
TS23: midgut loop Strong Regionally restricted euxassay_004631_11
TS23: left lung Strong Regionally restricted euxassay_004631_11
TS23: naris Strong Regionally restricted euxassay_004631_11
TS23: nasal cavity respiratory epithelium Strong Regionally restricted euxassay_004631_11
TS23: olfactory epithelium Strong Regionally restricted euxassay_004631_11
TS23: bladder fundus Strong Regionally restricted euxassay_004631_11
TS23: urethra Strong Regionally restricted euxassay_004631_11 Originally this result was annotated to a male-specific term, but as the specimen was not sexed, it is likely the data annotator intended to use a non-gender specific term.
TS23: adenohypophysis Weak Regionally restricted euxassay_004631_11
TS23: thymus primordium Weak Uniform euxassay_004631_11
TS23: thyroid gland Weak Uniform euxassay_004631_11

Specimen euxassay_004631_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: oral epithelium Strong Regionally restricted euxassay_004631_12
TS23: midgut loop Moderate Regionally restricted euxassay_004631_12
TS23: midgut Moderate Regionally restricted euxassay_004631_12
TS23: left lung Strong Regionally restricted euxassay_004631_12
TS23: naris Strong Regionally restricted euxassay_004631_12
TS23: bladder fundus Strong Regionally restricted euxassay_004631_12
TS23: adenohypophysis Weak Regionally restricted euxassay_004631_12
TS23: esophagus Strong Regionally restricted euxassay_004631_12
TS23: thymus primordium Weak Uniform euxassay_004631_12
TS23: larynx Moderate Regionally restricted euxassay_004631_12

Specimen euxassay_004631_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: oral epithelium Strong Regionally restricted euxassay_004631_13
TS23: midgut loop Strong Regionally restricted euxassay_004631_13
TS23: right lung Strong Regionally restricted euxassay_004631_13
TS23: adenohypophysis Moderate Regionally restricted euxassay_004631_13
TS23: trachea Strong Regionally restricted euxassay_004631_13
TS23: esophagus Strong Regionally restricted euxassay_004631_13
TS23: larynx Moderate Regionally restricted euxassay_004631_13

Specimen euxassay_004631_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lower jaw incisor Strong Regionally restricted euxassay_004631_14
TS23: upper jaw incisor Strong Regionally restricted euxassay_004631_14
TS23: oral epithelium Strong Regionally restricted euxassay_004631_14
TS23: midgut loop Strong Regionally restricted euxassay_004631_14
TS23: right lung Strong Regionally restricted euxassay_004631_14
TS23: naris Strong Regionally restricted euxassay_004631_14
TS23: olfactory epithelium Strong Regionally restricted euxassay_004631_14
TS23: nasal cavity respiratory epithelium Strong Regionally restricted euxassay_004631_14
TS23: adenohypophysis Weak Regionally restricted euxassay_004631_14
TS23: trachea Strong Regionally restricted euxassay_004631_14
TS23: esophagus Strong Regionally restricted euxassay_004631_14
TS23: thymus primordium Moderate Uniform euxassay_004631_14

Specimen euxassay_004631_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lower jaw incisor Strong Regionally restricted euxassay_004631_15
TS23: oral epithelium Strong Regionally restricted euxassay_004631_15
TS23: upper jaw incisor Strong Regionally restricted euxassay_004631_15
TS23: midgut loop Strong Regionally restricted euxassay_004631_15
TS23: right lung Strong Regionally restricted euxassay_004631_15
TS23: renal calyx Weak Regionally restricted euxassay_004631_15
TS23: olfactory epithelium Strong Regionally restricted euxassay_004631_15
TS23: nasal cavity respiratory epithelium Strong Regionally restricted euxassay_004631_15
TS23: naris Strong Regionally restricted euxassay_004631_15
TS23: pancreas Weak Regionally restricted euxassay_004631_15
TS23: adenohypophysis Weak Regionally restricted euxassay_004631_15
TS23: thymus primordium Moderate Uniform euxassay_004631_15
TS23: thyroid gland Weak Uniform euxassay_004631_15

Specimen euxassay_004631_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: oral epithelium Strong Regionally restricted euxassay_004631_16
TS23: lower jaw incisor Strong Regionally restricted euxassay_004631_16
TS23: midgut loop Strong Regionally restricted euxassay_004631_16
TS23: right lung Strong Regionally restricted euxassay_004631_16
TS23: renal calyx Weak Regionally restricted euxassay_004631_16
TS23: olfactory epithelium Strong Regionally restricted euxassay_004631_16
TS23: submandibular gland primordium Strong Regionally restricted euxassay_004631_16
TS23: pancreas Weak Regionally restricted euxassay_004631_16
TS23: thyroid gland Weak Uniform euxassay_004631_16
TS23: cochlea Strong Regionally restricted euxassay_004631_16

Specimen euxassay_004631_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: oral epithelium Strong Regionally restricted euxassay_004631_17
TS23: midgut loop Strong Regionally restricted euxassay_004631_17
TS23: right lung Strong Regionally restricted euxassay_004631_17
TS23: renal calyx Moderate Regionally restricted euxassay_004631_17
TS23: olfactory epithelium Strong Regionally restricted euxassay_004631_17
TS23: submandibular gland primordium Strong Regionally restricted euxassay_004631_17
TS23: pancreas Weak Regionally restricted euxassay_004631_17
TS23: cochlea Strong Regionally restricted euxassay_004631_17

Specimen euxassay_004631_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: upper jaw molar Strong Regionally restricted euxassay_004631_18
TS23: oral epithelium Strong Regionally restricted euxassay_004631_18
TS23: right lung Strong Regionally restricted euxassay_004631_18
TS23: olfactory epithelium Strong Regionally restricted euxassay_004631_18
TS23: submandibular gland primordium Strong Regionally restricted euxassay_004631_18
TS23: cochlea Moderate Regionally restricted euxassay_004631_18

Specimen euxassay_004631_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vibrissa Strong Regionally restricted euxassay_004631_19
TS23: oral epithelium Strong Regionally restricted euxassay_004631_19
TS23: lower jaw molar Strong Regionally restricted euxassay_004631_19
TS23: right lung Strong Regionally restricted euxassay_004631_19
TS23: submandibular gland primordium Strong Regionally restricted euxassay_004631_19
TS23: cochlea Moderate Regionally restricted euxassay_004631_19

Specimen euxassay_004631_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: pharyngo-tympanic tube Moderate Regionally restricted euxassay_004631_20
TS23: vibrissa Strong Regionally restricted euxassay_004631_20
TS23: oral epithelium Strong Regionally restricted euxassay_004631_20
TS23: right lung Strong Regionally restricted euxassay_004631_20
TS23: cochlea Moderate Regionally restricted euxassay_004631_20

Specimen euxassay_004631_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: pharyngo-tympanic tube Moderate Regionally restricted euxassay_004631_21
TS23: cornea epithelium Moderate Regionally restricted euxassay_004631_21
TS23: vibrissa Strong Regionally restricted euxassay_004631_21
TS23: right lung Moderate Regionally restricted euxassay_004631_21
TS23: cochlea Moderate Regionally restricted euxassay_004631_21

Specimen euxassay_004631_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: pharyngo-tympanic tube Moderate Regionally restricted euxassay_004631_22
TS23: cornea epithelium Moderate Regionally restricted euxassay_004631_22
TS23: vibrissa Moderate Regionally restricted euxassay_004631_22
TS23: right lung Moderate Regionally restricted euxassay_004631_22

Specimen euxassay_004631_23: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: pharyngo-tympanic tube Moderate Regionally restricted euxassay_004631_23
TS23: cornea epithelium Moderate Regionally restricted euxassay_004631_23

Specimen euxassay_004631_24: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: pharyngo-tympanic tube Moderate Regionally restricted euxassay_004631_24
TS23: cornea epithelium Moderate Regionally restricted euxassay_004631_24


Contributing Projects:
Mouse Genome Database (MGD), Gene Expression Database (GXD), Mouse Models of Human Cancer database (MMHCdb) (formerly Mouse Tumor Biology (MTB), Gene Ontology (GO)
Citing These Resources
Funding Information
Warranty Disclaimer & Copyright Notice
Send questions and comments to User Support.
last database update
10/12/2021
MGI 6.17
The Jackson Laboratory
