Gene Expression Data
Assay Details
Assay
Reference: J:185290 Song XF, et al., Expression of Bcl-2 and Bax in mouse renal tubules during kidney development. PLoS One. 2012;7(2):e32771
Assay type: Immunohistochemistry
MGI Accession ID: MGI:8212932
Gene symbol: Bax
Gene name: BCL2-associated X protein
Antibody: anti-Bax
Detection system: Secondary antibody coupled to horseradish peroxidase
Results
Specimen 1A: embryonic day 17.5 (more )
Note: Fixative was 4% paraformaldehyde and 1% glutaraldehyde with a post-fix in 1% osmium tetroxide.
Structure Level Pattern Image Note
TS25: renal proximal convoluted tubule Strong Non-Uniform 1A BAX The strongest expression was found in the mature proximal convoluted tubules in the juxta-medullary cortex. Weak expression in immature proximal tubules.
TS25: proximal straight tubule Present 1A BAX
TS25: renal distal tubule Weak 1A BAX
Specimen 2G: embryonic day 16.5 (more )
Note: Fixative was 4% paraformaldehyde and 1% glutaraldehyde with a post-fix in 1% osmium tetroxide.
Structure Level Pattern Image Note
TS24: renal tubule Strong Non-Uniform 2G The strongest expression was found in the mature proximal convoluted tubules in the juxta-medullary cortex. Weak expression in immature proximal tubules.
TS24: cortical early distal tubule Weak 2G
TS24: comma-shaped body Absent 2G
TS24: maturing glomerular tuft Absent 2G
TS24: s-shaped body Absent 2G
Specimen 2H: embryonic day 18.5 (more )
Note: Fixative was 4% paraformaldehyde and 1% glutaraldehyde with a post-fix in 1% osmium tetroxide.
Structure Level Pattern Image Note
TS26: renal proximal convoluted tubule Strong Non-Uniform 2H The strongest expression was found in the mature proximal convoluted tubules in the juxta-medullary cortex. Weak expression in immature proximal tubules.
TS26: renal distal tubule Weak 2H
TS26: comma-shaped body Absent 2H
TS26: glomerular tuft Absent 2H
TS26: s-shaped body Absent 2H
Specimen 2I: postnatal day 1 (more )
Note: Fixative was 4% paraformaldehyde and 1% glutaraldehyde with a post-fix in 1% osmium tetroxide.
Structure Level Pattern Image Note
TS27: renal proximal convoluted tubule Strong Non-Uniform 2I The strongest expression was found in the mature proximal convoluted tubules. Weak expression in immature proximal tubules.
TS27: proximal straight tubule Present 2I
TS27: renal distal tubule Weak 2I
TS27: comma-shaped body Absent 2I
TS27: glomerular tuft Absent 2I
TS27: s-shaped body Absent 2I
Specimen 2J: postnatal day 5 (more )
Note: Fixative was 4% paraformaldehyde and 1% glutaraldehyde with a post-fix in 1% osmium tetroxide.
Structure Level Pattern Image Note
TS28: renal proximal convoluted tubule Strong Non-Uniform 2J The strongest expression was found in the mature proximal convoluted tubules. Weak expression in immature proximal tubules.
TS28: renal distal tubule Weak 2J
TS28: comma-shaped body Absent 2J
TS28: glomerular tuft Absent 2J
TS28: s-shaped body Absent 2J
Specimen 2K: postnatal day 7 (more )
Note: Fixative was 4% paraformaldehyde and 1% glutaraldehyde with a post-fix in 1% osmium tetroxide.
Structure Level Pattern Image Note
TS28: renal proximal convoluted tubule Strong Non-Uniform 2K The strongest expression was found in the mature proximal convoluted tubules. Weak expression in immature proximal tubules.
TS28: proximal straight tubule Present 2K Expression is in both the medullary rays and the medulla.
TS28: renal distal tubule Weak 2K
TS28: comma-shaped body Absent 2K
TS28: glomerular tuft Absent 2K
TS28: s-shaped body Absent 2K
Specimen 2L: postnatal day 14 (more )
Note: Fixative was 4% paraformaldehyde and 1% glutaraldehyde with a post-fix in 1% osmium tetroxide.
Structure Level Pattern Image Note
TS28: renal proximal convoluted tubule Strong Non-Uniform 2L The strongest expression was found in the mature proximal convoluted tubules. Weak expression in immature proximal tubules.
TS28: renal distal tubule Weak 2L
TS28: comma-shaped body Absent 2L
TS28: glomerular tuft Absent 2L
TS28: s-shaped body Absent 2L
