Probe:	Kv1.1 cDNA
Probe preparation:	Antisense labelled with P33 RNA
Visualized with:	Autoradiography

Structure	Level	Pattern	Image	Note
TS15: future midbrain	Strong	Regionally restricted	2A	Expression is in the region of the tectum and tegmentum.
TS15: diencephalon	Strong	Regionally restricted	2A	Expression is in regions of the thalamus and hypothalamus.
TS15: future hindbrain	Strong	Regionally restricted	2A	Expression is in two broad dorsal stripes.

Structure	Level	Pattern	Image	Note
TS17: midbrain	Weak		2C
TS17: hindbrain	Absent		2C

Structure	Level	Pattern	Image	Note
TS22: cerebral cortex	Strong		4A
TS22: dorsal root ganglion	Strong		4A
TS22: hippocampus	Strong		4A
TS22: peripheral nerve	Strong		4A
TS22: trigeminal ganglion	Strong		4A
TS22: medulla oblongata	Strong	Regionally restricted	4A	Expression is in sensory nuclei.

Structure	Level	Pattern	Image	Note
TS25: dorsal root ganglion	Strong		4C
TS25: peripheral nerve	Strong		4C
TS25: trigeminal ganglion	Strong		4C
TS25: cerebral cortex	Present		4C
TS25: hippocampus	Present		4C

Structure	Level	Pattern	Image	Note
TS22: cerebral cortex	Strong	Regionally restricted	5A	Expression is in the outer aspects.
TS22: hippocampus	Strong	Regionally restricted	5A	Expression is in the outer aspects.

Structure	Level	Pattern	Image	Note
TS22: dorsal root ganglion	Strong	Regionally restricted	6A	Expression is in a subset of cells.

Structure	Level	Pattern	Image	Note
TS22: trigeminal ganglion	Strong		7A
TS22: trigeminal nerve mandibular division	Strong		7A
TS22: trigeminal nerve maxillary division	Strong		7A
TS22: trigeminal nerve ophthalmic division	Strong		7A

Structure	Cell Type	Level	Pattern	Image	Note
TS22: cerebral cortex		Strong
TS22: cranial ganglion		Strong
TS22: dorsal root ganglion		Strong
TS22: hippocampus		Strong
TS22: epithalamus		Strong	Non-Uniform		Expression is in the pineal gland and is moderate in the epithalamus.
TS22: forebrain	forebrain radial glial cell	Strong	Single cells		Expression is in radial glia, Schwann cells/precursors, and satellite cells.
TS22: forebrain	perineuronal satellite cell	Strong	Single cells		Expression is in radial glia, Schwann cells/precursors, and satellite cells.
TS22: forebrain	Schwann cell	Strong	Single cells		Expression is in radial glia, Schwann cells/precursors, and satellite cells.
TS22: forebrain	Schwann cell precursor	Strong	Single cells		Expression is in radial glia, Schwann cells/precursors, and satellite cells.
TS22: enteric nervous system		Moderate
TS22: hypothalamus		Moderate
TS22: inferior colliculus		Moderate
TS22: olfactory epithelium		Moderate
TS22: superior colliculus		Moderate
TS22: thalamus		Moderate
TS22: tongue epithelium		Moderate
TS22: pons		Moderate	Regionally restricted		Expression is in chief sensory and spinal trigeminal nuclei.
TS22: brainstem nucleus		Moderate	Regionally restricted		Expression is in the medial vestibular nucleus.
TS22: pituitary gland		Weak
TS22: thymus primordium		Weak

Structure	Cell Type	Level	Pattern	Image	Note
TS25: cranial ganglion		Strong
TS25: forebrain	forebrain radial glial cell	Strong	Single cells		Expression is in Schwann cells/precursors, and satellite cells and is moderate in radial glia.
TS25: forebrain	perineuronal satellite cell	Strong	Single cells		Expression is in Schwann cells/precursors, and satellite cells and is moderate in radial glia.
TS25: forebrain	Schwann cell	Strong	Single cells		Expression is in Schwann cells/precursors, and satellite cells and is moderate in radial glia.
TS25: forebrain	Schwann cell precursor	Strong	Single cells		Expression is in Schwann cells/precursors, and satellite cells and is moderate in radial glia.
TS25: dorsal root ganglion		Moderate
TS25: cerebral cortex		Weak
TS25: hippocampus		Weak
TS25: inferior colliculus		Weak
TS25: pineal gland		Weak
TS25: superior colliculus		Weak
TS25: pons		Weak	Regionally restricted		Expression is in chief sensory and spinal trigeminal nuclei.
TS25: brainstem nucleus		Weak	Regionally restricted		Expression is in the medial vestibular nucleus.
TS25: epithalamus		Weak	Regionally restricted		Expression is weak in the pineal gland and is absent in the rest of the epithalamus.
TS25: thalamus		Trace
TS25: hypothalamus		Absent
TS25: olfactory epithelium		Absent
TS25: pituitary gland		Absent
TS25: thymus		Absent
TS25: tongue epithelium		Absent
