Gene Expression Data
Assay Details
Assay
Reference: J:171409 GUDMAP Consortium, GUDMAP: the GenitoUrinary Development Molecular Anatomy Project. www.gudmap.org. 2004;
Assay type: RNA in situ
MGI Accession ID: MGI:5543229
Gene symbol: Foxd1
Gene name: forkhead box D1
Probe: RIKEN clone D230009L10 subclone
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Results
Specimen GUDMAP:14189: embryonic day 15.5 (more )
Note: Labeling was visualized using BM purple.
Structure Level Pattern Image Note
TS23: nephrogenic zone Present GUDMAP:14189
TS23: nephrogenic interstitium Present GUDMAP:14189
TS23: renal cortex Present GUDMAP:14189
TS23: renal cortical interstitium Present Regionally restricted GUDMAP:14189
TS23: maturing renal corpuscle Present GUDMAP:14189
TS23: maturing glomerular tuft Present GUDMAP:14189
TS23: visceral epithelium of maturing renal corpuscle Present GUDMAP:14189
TS23: ureter Present GUDMAP:14189
TS23: ureteral mesenchyme Present GUDMAP:14189
TS23: ureteral mesenchyme outer layer Present GUDMAP:14189
TS23: cap mesenchyme Absent GUDMAP:14189
TS23: ureteric tip Absent GUDMAP:14189
TS23: ureteric tree terminal branch excluding tip itself Absent GUDMAP:14189
TS23: renal vesicle Absent GUDMAP:14189
TS23: comma-shaped body Absent GUDMAP:14189
TS23: s-shaped body Absent GUDMAP:14189
TS23: capillary loop renal corpuscle Absent GUDMAP:14189
TS23: glomerular capillary system of maturing glomerular tuft Absent GUDMAP:14189
TS23: glomerular mesangium of maturing glomerular tuft Absent GUDMAP:14189
TS23: Bowman's capsule of maturing renal corpuscle Absent GUDMAP:14189
TS23: juxtaglomerular arteriole Absent GUDMAP:14189
TS23: cortical renal tubule Absent GUDMAP:14189
TS23: cortical collecting duct Absent GUDMAP:14189
TS23: renal cortical vasculature Absent GUDMAP:14189
TS23: early tubule Absent GUDMAP:14189
TS23: renal pelvis Absent GUDMAP:14189
TS23: pelvic urothelial lining Absent GUDMAP:14189
TS23: pelvic smooth muscle Absent GUDMAP:14189
TS23: perihilar interstitium Absent GUDMAP:14189
TS23: renal medulla Absent GUDMAP:14189
TS23: immature loop of Henle Absent GUDMAP:14189
TS23: medullary collecting duct Absent GUDMAP:14189
TS23: renal medullary interstitium Absent GUDMAP:14189
TS23: renal medullary vasculature Absent GUDMAP:14189
TS23: associated interstitium of capillary loop renal corpuscle Absent GUDMAP:14189
TS23: parietal epithelium of capillary loop renal corpuscle Absent GUDMAP:14189
TS23: presumptive mesangium of capillary loop renal corpuscle Absent GUDMAP:14189
TS23: visceral epithelium of capillary loop renal corpuscle Absent GUDMAP:14189
TS23: presumptive endothelium of capillary loop renal corpuscle Absent GUDMAP:14189
TS23: developing capillary loop stage nephron group Absent GUDMAP:14189
TS23: maturing nephron Present GUDMAP:14189
Specimen GUDMAP:14190: postnatal day 0 (more )
Note: Labeling was visualized using BM purple.
Structure Level Pattern Image Note
TS27: metanephros Present GUDMAP:14190
TS27: nephrogenic zone Present GUDMAP:14190
TS27: nephrogenic interstitium Present GUDMAP:14190
TS27: renal cortex Present GUDMAP:14190
TS27: renal cortical interstitium Present Regionally restricted GUDMAP:14190
TS27: mature renal corpuscle Present GUDMAP:14190
TS27: maturing renal corpuscle Present GUDMAP:14190
TS27: maturing glomerular tuft Present GUDMAP:14190
TS27: visceral epithelium of maturing renal corpuscle Present GUDMAP:14190
TS27: glomerular tuft Present GUDMAP:14190
TS27: visceral epithelium of mature renal corpuscle Present GUDMAP:14190
Specimen GUDMAP:14191: postnatal day 4 (more )
Note: Labeling was visualized using BM purple.
Structure Level Pattern Image Note
TS27: metanephros Present GUDMAP:14191
TS27: nephrogenic zone Present GUDMAP:14191
TS27: nephrogenic interstitium Present GUDMAP:14191
TS27: renal cortex Present GUDMAP:14191
TS27: renal cortical interstitium Present Regionally restricted GUDMAP:14191
TS27: mature renal corpuscle Present GUDMAP:14191
TS27: maturing renal corpuscle Present GUDMAP:14191
TS27: maturing glomerular tuft Present GUDMAP:14191
TS27: visceral epithelium of maturing renal corpuscle Present GUDMAP:14191
TS27: glomerular tuft Present GUDMAP:14191
TS27: visceral epithelium of mature renal corpuscle Present GUDMAP:14191
