Gene Expression Data
Assay Details
Assay
Reference: J:171409 GUDMAP Consortium, GUDMAP: the GenitoUrinary Development Molecular Anatomy Project. www.gudmap.org. 2004;
Assay type: RNA in situ
MGI Accession ID: MGI:5543198
Gene symbol: Dnmt3a
Gene name: DNA methyltransferase 3A
Probe: CVprobeDnmt3a(0262)
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Results
Specimen GUDMAP:20663: embryonic day 14.0 (more )
Note: This specimen was generated and annotated by the lab of Chad Vezina, University of Wisconsin-Madison. Labeling was visualized using BM purple. The section was also labeled by immunohistochemistry to visualize cadherin 1 in epithelium (red) and actin alpha 2 in smooth muscle (green).
Structure Level Pattern Image Note
TS22: epithelium of nephric duct of male Present Spotted GUDMAP:20663
TS22: mesenchyme of nephric duct of male Present Spotted GUDMAP:20663
TS22: nephric duct of male, rest of Present GUDMAP:20663
TS22: male reproductive system Present GUDMAP:20663
TS22: reproductive system Present GUDMAP:20663
TS22: urinary system Present GUDMAP:20663
TS22: mesenchymal layer of pelvic urethra Present GUDMAP:20663
TS22: pelvic urethra Present GUDMAP:20663
TS22: urethra Present GUDMAP:20663
TS22: urogenital sinus Present GUDMAP:20663
TS22: epithelium of pelvic urethra Present Regionally restricted GUDMAP:20663 Expression restricted to basal and intermediate urothelium only; expression absent from superficial urothelium.
TS22: mesenchymal layer of dorsal pelvic urethra Present GUDMAP:20663
TS22: mesenchymal layer of ventral pelvic urethra Present GUDMAP:20663
TS22: muscle layer of dorsal pelvic urethra Present GUDMAP:20663
TS22: muscle layer of ventral pelvic urethra Present GUDMAP:20663
TS22: muscle layer of pelvic urethra Present GUDMAP:20663
Specimen GUDMAP:20664: embryonic day 14.0 (more )
Note: This specimen was generated and annotated by the lab of Chad Vezina, University of Wisconsin-Madison. Labeling was visualized using BM purple. The section was also labeled by immunohistochemistry to visualize cadherin 1 in epithelium (red) and actin alpha 2 in smooth muscle (green).
Structure Level Pattern Image Note
TS22: mesenchymal layer of pelvic urethra Present GUDMAP:20664
TS22: muscle layer of pelvic urethra Present GUDMAP:20664
TS22: pelvic urethra Present GUDMAP:20664
TS22: urethra Present GUDMAP:20664
TS22: urogenital sinus Present GUDMAP:20664
TS22: urinary system Present GUDMAP:20664
TS22: epithelium of pelvic urethra Present Regionally restricted GUDMAP:20664 Expression restricted to basal and intermediate urothelium only; expression absent from superficial urothelium.
TS22: muscle layer of ventral pelvic urethra Present GUDMAP:20664
TS22: muscle layer of dorsal pelvic urethra Present GUDMAP:20664
TS22: mesenchymal layer of ventral pelvic urethra Present GUDMAP:20664
TS22: mesenchymal layer of dorsal pelvic urethra Present GUDMAP:20664
Specimen GUDMAP:20665: embryonic day 15.0 (more )
Note: This specimen was generated and annotated by the lab of Chad Vezina, University of Wisconsin-Madison. Labeling was visualized using BM purple. The section was also labeled by immunohistochemistry to visualize cadherin 1 in epithelium (red) and actin alpha 2 in smooth muscle (green).
Structure Level Pattern Image Note
TS23: muscle layer of pelvic urethra of female Present GUDMAP:20665
TS23: mesenchymal layer of pelvic urethra of female Present GUDMAP:20665
TS23: epithelium of pelvic urethra of female Present GUDMAP:20665
TS23: pelvic urethra of female Present GUDMAP:20665
TS23: urethra of female Present GUDMAP:20665
TS23: urinary system Present GUDMAP:20665
TS23: basal cell layer of ventral pelvic urethra of female Present GUDMAP:20665
TS23: intermediate cell layer of ventral pelvic urethra of female Present GUDMAP:20665
TS23: superficial cell layer of ventral pelvic urethra of female Present GUDMAP:20665
TS23: basal cell layer of dorsal pelvic urethra of female Present GUDMAP:20665
TS23: intermediate cell layer of dorsal pelvic urethra of female Present GUDMAP:20665
TS23: superficial cell layer of dorsal pelvic urethra of female Present GUDMAP:20665
TS23: epithelium of dorsal pelvic urethra of female Present GUDMAP:20665
TS23: epithelium of ventral pelvic urethra of female Present GUDMAP:20665
TS23: muscle layer of ventral pelvic urethra of female Present GUDMAP:20665
TS23: muscle layer of dorsal pelvic urethra of female Present GUDMAP:20665
TS23: mesenchymal layer of ventral pelvic urethra of female Present GUDMAP:20665
TS23: mesenchymal layer of dorsal pelvic urethra of female Present GUDMAP:20665
Specimen GUDMAP:20666: embryonic day 16.0 (more )
Note: This specimen was generated and annotated by the lab of Chad Vezina, University of Wisconsin-Madison. Labeling was visualized using BM purple. The section was also labeled by immunohistochemistry to visualize cadherin 1 in epithelium (red) and actin alpha 2 in smooth muscle (green).
Structure Level Pattern Image Note
TS24: pelvic urethra of male Present GUDMAP:20666
TS24: urethra of male Present GUDMAP:20666
TS24: urinary system Present GUDMAP:20666
TS24: prostate bud Present GUDMAP:20666
TS24: male accessory gland Present GUDMAP:20666
TS24: ejaculatory duct Present GUDMAP:20666
TS24: seminal vesicle Present GUDMAP:20666
TS24: male reproductive system Present GUDMAP:20666
TS24: reproductive system Present GUDMAP:20666
TS24: peri-prostatic mesenchyme Present GUDMAP:20666
TS24: prostate epithelium Present GUDMAP:20666
TS24: muscle of seminal vesicle Present GUDMAP:20666
TS24: lamina propria of ejaculatory duct Present GUDMAP:20666
TS24: muscle of ejaculatory duct Present GUDMAP:20666
TS24: serosa of seminal vesicle Absent GUDMAP:20666
TS24: vasculature of seminal vesicle Absent GUDMAP:20666
TS24: vasculature of ejaculatory duct Absent GUDMAP:20666
TS24: epithelium of seminal vesicle Present GUDMAP:20666
TS24: epithelium of ejaculatory duct Present GUDMAP:20666
TS24: muscle layer of pelvic urethra of male Present GUDMAP:20666
TS24: mesenchymal layer of pelvic urethra of male Present GUDMAP:20666
TS24: epithelium of dorsal pelvic urethra of male Present GUDMAP:20666
TS24: epithelium of ventral pelvic urethra of male Present GUDMAP:20666
TS24: epithelium of pelvic urethra of male Present GUDMAP:20666
TS24: mesenchymal layer of dorsal pelvic urethra of male Present GUDMAP:20666 Higher intensity staining in urogenital sinus region than along urethra.
TS24: mesenchymal layer of ventral pelvic urethra of male Present GUDMAP:20666 Higher intensity staining in urogenital sinus region than along urethra.
TS24: muscle layer of dorsal pelvic urethra of male Present GUDMAP:20666
TS24: muscle layer of ventral pelvic urethra of male Present GUDMAP:20666
TS24: superficial cell layer of dorsal pelvic urethra of male Absent GUDMAP:20666
TS24: superficial cell layer of ventral pelvic urethra of male Absent GUDMAP:20666
TS24: intermediate cell layer of dorsal pelvic urethra of male Present GUDMAP:20666
TS24: basal cell layer of dorsal pelvic urethra of male Present GUDMAP:20666
TS24: basal cell layer of ventral pelvic urethra of male Present GUDMAP:20666
TS24: intermediate cell layer of ventral pelvic urethra of male Present GUDMAP:20666
Specimen GUDMAP:20667: embryonic day 16.0 (more )
Note: This specimen was generated and annotated by the lab of Chad Vezina, University of Wisconsin-Madison. Labeling was visualized using BM purple. The section was also labeled by immunohistochemistry to visualize cadherin 1 in epithelium (red) and actin alpha 2 in smooth muscle (green).
Structure Level Pattern Image Note
TS24: pelvic urethra of female Present GUDMAP:20667
TS24: urethra of female Present GUDMAP:20667
TS24: urinary system Present GUDMAP:20667
TS24: upper vagina Present GUDMAP:20667
TS24: sinovaginal bulb Present GUDMAP:20667
TS24: vagina Present GUDMAP:20667
TS24: female reproductive system Present GUDMAP:20667
TS24: reproductive system Present GUDMAP:20667
TS24: vasculature of sinovaginal bulb Absent GUDMAP:20667
TS24: vasculature of upper vagina Absent GUDMAP:20667
TS24: muscle of sinovaginal bulb Present GUDMAP:20667
TS24: epithelium of sinovaginal bulb Present GUDMAP:20667
TS24: epithelium of upper vagina Present GUDMAP:20667
TS24: muscle of upper vagina Present GUDMAP:20667
TS24: epithelium of vagina Present GUDMAP:20667
TS24: muscle of vagina Present GUDMAP:20667
TS24: developing vasculature of vagina Absent GUDMAP:20667
TS24: muscle layer of pelvic urethra of female Present GUDMAP:20667
TS24: mesenchymal layer of pelvic urethra of female Present GUDMAP:20667
TS24: epithelium of ventral pelvic urethra of female Present GUDMAP:20667
TS24: epithelium of dorsal pelvic urethra of female Present GUDMAP:20667
TS24: epithelium of pelvic urethra of female Present GUDMAP:20667
TS24: muscle layer of ventral pelvic urethra of female Present GUDMAP:20667
TS24: muscle layer of dorsal pelvic urethra of female Present GUDMAP:20667
TS24: mesenchymal layer of ventral pelvic urethra of female Present GUDMAP:20667 Higher intensity staining in urogenital sinus region than along urethra.
TS24: mesenchymal layer of dorsal pelvic urethra of female Present GUDMAP:20667 Higher intensity staining in urogenital sinus region than along urethra.
TS24: superficial cell layer of dorsal pelvic urethra of female Absent GUDMAP:20667
TS24: superficial cell layer of ventral pelvic urethra of female Absent GUDMAP:20667
TS24: intermediate cell layer of dorsal pelvic urethra of female Present GUDMAP:20667
TS24: intermediate cell layer of ventral pelvic urethra of female Present GUDMAP:20667
TS24: basal cell layer of dorsal pelvic urethra of female Present GUDMAP:20667
TS24: basal cell layer of ventral pelvic urethra of female Present GUDMAP:20667
Specimen GUDMAP:20668: embryonic day 17.0 (more )
Note: This specimen was generated and annotated by the lab of Chad Vezina, University of Wisconsin-Madison. Labeling was visualized using BM purple.
Structure Level Pattern Image Note
TS25: prostate bud Present GUDMAP:20668
TS25: male accessory gland Present GUDMAP:20668
TS25: ejaculatory duct Present GUDMAP:20668
TS25: ductus deferens Present GUDMAP:20668
TS25: seminal vesicle Present GUDMAP:20668
TS25: male reproductive system Present GUDMAP:20668
TS25: reproductive system Present GUDMAP:20668
TS25: urinary system Present GUDMAP:20668
TS25: epithelium of seminal vesicle Present GUDMAP:20668
TS25: prostate epithelium Present GUDMAP:20668
TS25: peri-prostatic mesenchyme Present GUDMAP:20668
TS25: epithelium of ejaculatory duct Present GUDMAP:20668
TS25: lamina propria of ejaculatory duct Present GUDMAP:20668
TS25: muscle of ejaculatory duct Present GUDMAP:20668
TS25: muscle of seminal vesicle Present GUDMAP:20668
TS25: vasculature of ejaculatory duct Absent GUDMAP:20668
TS25: vasculature of seminal vesicle Absent GUDMAP:20668
TS25: serosa of seminal vesicle Absent GUDMAP:20668
TS25: vasculature of ductus deferens Absent GUDMAP:20668
TS25: epithelium of ductus deferens Present GUDMAP:20668
TS25: muscle of ductus deferens Present GUDMAP:20668
TS25: mesenchymal layer of ventral pelvic urethra of male Present GUDMAP:20668
TS25: mesenchymal layer of dorsal pelvic urethra of male Present GUDMAP:20668
TS25: mesenchymal layer of pelvic urethra of male Present GUDMAP:20668
TS25: epithelium of ventral pelvic urethra of male Present GUDMAP:20668
TS25: epithelium of dorsal pelvic urethra of male Present GUDMAP:20668
TS25: epithelium of pelvic urethra of male Present GUDMAP:20668
TS25: pelvic urethra of male Present GUDMAP:20668
TS25: urethra of male Present GUDMAP:20668
TS25: presumptive neural crest derivative of pelvic urethra of male Absent GUDMAP:20668
TS25: vasculature of pelvic urethra of male Absent GUDMAP:20668
TS25: muscle layer of ventral pelvic urethra of male Present GUDMAP:20668
TS25: muscle layer of dorsal pelvic urethra of male Present GUDMAP:20668
TS25: mesenchymal pad of pelvic urethra of male Present GUDMAP:20668
TS25: muscle layer of pelvic urethra of male Present GUDMAP:20668
TS25: submucosa of dorsal pelvic urethra of male Present GUDMAP:20668 Stronger staining evident in urogenital sinus region than along urethra.
TS25: muscularis mucosa of dorsal pelvic urethra of male Present GUDMAP:20668
TS25: lamina propria of dorsal pelvic urethra of male Present GUDMAP:20668 Stronger staining evident in urogenital sinus region than along urethra.
TS25: lamina propria of ventral pelvic urethra of male Present GUDMAP:20668
TS25: muscularis mucosa of ventral pelvic urethra of male Present GUDMAP:20668
TS25: submucosa of ventral pelvic urethra of male Present GUDMAP:20668
TS25: superficial cell layer of dorsal pelvic urethra of male Absent GUDMAP:20668
TS25: superficial cell layer of ventral pelvic urethra of male Absent GUDMAP:20668
TS25: basal cell layer of dorsal pelvic urethra of male Present GUDMAP:20668
TS25: basal cell layer of ventral pelvic urethra of male Present GUDMAP:20668
TS25: intermediate cell layer of dorsal pelvic urethra of male Present GUDMAP:20668
TS25: intermediate cell layer of ventral pelvic urethra of male Present GUDMAP:20668
Specimen GUDMAP:20669: embryonic day 18.0 (more )
Note: This specimen was generated and annotated by the lab of Chad Vezina, University of Wisconsin-Madison. Labeling was visualized using BM purple. The section was also labeled by immunohistochemistry to visualize cadherin 1 in epithelium (red) and actin alpha 2 in smooth muscle (green).
Structure Level Pattern Image Note
TS26: prostate bud Present GUDMAP:20669
TS26: male accessory gland Present GUDMAP:20669
TS26: ejaculatory duct Present GUDMAP:20669
TS26: seminal vesicle Present GUDMAP:20669
TS26: male reproductive system Present GUDMAP:20669
TS26: reproductive system Present GUDMAP:20669
TS26: urinary system Present GUDMAP:20669
TS26: epithelium of ejaculatory duct Present GUDMAP:20669
TS26: prostate epithelium Present GUDMAP:20669
TS26: peri-prostatic mesenchyme Present GUDMAP:20669
TS26: lamina propria of ejaculatory duct Present GUDMAP:20669
TS26: vasculature of ejaculatory duct Absent GUDMAP:20669
TS26: vasculature of seminal vesicle Absent GUDMAP:20669
TS26: serosa of seminal vesicle Absent GUDMAP:20669
TS26: muscle of ejaculatory duct Present GUDMAP:20669
TS26: muscle of seminal vesicle Present GUDMAP:20669
TS26: epithelium of seminal vesicle Present GUDMAP:20669
TS26: mesenchymal layer of ventral pelvic urethra of male Present GUDMAP:20669
TS26: mesenchymal layer of dorsal pelvic urethra of male Present GUDMAP:20669
TS26: mesenchymal layer of pelvic urethra of male Present GUDMAP:20669
TS26: epithelium of ventral pelvic urethra of male Present GUDMAP:20669
TS26: epithelium of dorsal pelvic urethra of male Present GUDMAP:20669
TS26: epithelium of pelvic urethra of male Present GUDMAP:20669
TS26: pelvic urethra of male Present GUDMAP:20669
TS26: urethra of male Present GUDMAP:20669
TS26: muscle layer of pelvic urethra of male Present GUDMAP:20669
TS26: mesenchymal pad of pelvic urethra of male Present GUDMAP:20669
TS26: presumptive neural crest derivative of pelvic urethra of male Absent GUDMAP:20669
TS26: vasculature of pelvic urethra of male Absent GUDMAP:20669
TS26: lamina propria of dorsal pelvic urethra of male Present GUDMAP:20669
TS26: lamina propria of ventral pelvic urethra of male Present GUDMAP:20669
TS26: muscularis mucosa of dorsal pelvic urethra of male Absent GUDMAP:20669
TS26: muscularis mucosa of ventral pelvic urethra of male Absent GUDMAP:20669
TS26: submucosa of ventral pelvic urethra of male Present GUDMAP:20669
TS26: submucosa of dorsal pelvic urethra of male Present GUDMAP:20669
TS26: superficial cell layer of dorsal pelvic urethra of male Absent GUDMAP:20669
TS26: superficial cell layer of ventral pelvic urethra of male Absent GUDMAP:20669
TS26: intermediate cell layer of dorsal pelvic urethra of male Present GUDMAP:20669
TS26: basal cell layer of dorsal pelvic urethra of male Present GUDMAP:20669
TS26: intermediate cell layer of ventral pelvic urethra of male Present GUDMAP:20669
TS26: basal cell layer of ventral pelvic urethra of male Present GUDMAP:20669
Specimen GUDMAP:20670: embryonic day 18.0 (more )
Note: This specimen was generated and annotated by the lab of Chad Vezina, University of Wisconsin-Madison. Labeling was visualized using BM purple. The section was also labeled by immunohistochemistry to visualize cadherin 1 in epithelium (red) and actin alpha 2 in smooth muscle (green).
Structure Level Pattern Image Note
TS26: upper vagina Present GUDMAP:20670
TS26: sinovaginal bulb Present GUDMAP:20670
TS26: vagina Present GUDMAP:20670
TS26: female reproductive system Present GUDMAP:20670
TS26: reproductive system Present GUDMAP:20670
TS26: urinary system Present GUDMAP:20670
TS26: epithelium of sinovaginal bulb Present GUDMAP:20670
TS26: lamina propria of sinovaginal bulb Present GUDMAP:20670
TS26: muscle of sinovaginal bulb Present GUDMAP:20670
TS26: epithelium of upper vagina Present GUDMAP:20670
TS26: lamina propria of upper vagina Present GUDMAP:20670
TS26: muscle of upper vagina Present GUDMAP:20670
TS26: vasculature of upper vagina Absent GUDMAP:20670
TS26: vasculature of sinovaginal bulb Absent GUDMAP:20670
TS26: epithelium of vagina Present GUDMAP:20670
TS26: muscle of vagina Present GUDMAP:20670
TS26: developing vasculature of vagina Absent GUDMAP:20670
TS26: mesenchymal layer of ventral pelvic urethra of female Present GUDMAP:20670
TS26: mesenchymal layer of dorsal pelvic urethra of female Present GUDMAP:20670
TS26: mesenchymal layer of pelvic urethra of female Present GUDMAP:20670
TS26: epithelium of ventral pelvic urethra of female Present GUDMAP:20670
TS26: epithelium of dorsal pelvic urethra of female Present GUDMAP:20670
TS26: epithelium of pelvic urethra of female Present GUDMAP:20670
TS26: pelvic urethra of female Present GUDMAP:20670
TS26: urethra of female Present GUDMAP:20670
TS26: presumptive neural crest derivative of pelvic urethra of female Absent GUDMAP:20670
TS26: vasculature of pelvic urethra of female Absent GUDMAP:20670
TS26: muscle layer of pelvic urethra of female Present GUDMAP:20670
TS26: mesenchymal pad of pelvic urethra of female Present GUDMAP:20670
TS26: muscularis mucosa of dorsal pelvic urethra of female Absent GUDMAP:20670
TS26: muscularis mucosa of ventral pelvic urethra of female Absent GUDMAP:20670
TS26: lamina propria of dorsal pelvic urethra of female Present GUDMAP:20670
TS26: lamina propria of ventral pelvic urethra of female Present GUDMAP:20670
TS26: submucosa of dorsal pelvic urethra of female Present GUDMAP:20670
TS26: submucosa of ventral pelvic urethra of female Present GUDMAP:20670
TS26: basal cell layer of ventral pelvic urethra of female Present GUDMAP:20670
TS26: intermediate cell layer of ventral pelvic urethra of female Present GUDMAP:20670
TS26: basal cell layer of dorsal pelvic urethra of female Present GUDMAP:20670
TS26: intermediate cell layer of dorsal pelvic urethra of female Present GUDMAP:20670
TS26: superficial cell layer of dorsal pelvic urethra of female Absent GUDMAP:20670
TS26: superficial cell layer of ventral pelvic urethra of female Absent GUDMAP:20670
Specimen GUDMAP:20671: postnatal day 0 (more )
Note: This specimen was generated and annotated by the lab of Chad Vezina, University of Wisconsin-Madison. Labeling was visualized using BM purple. The section was also labeled by immunohistochemistry to visualize cadherin 1 in epithelium (red) and actin alpha 2 in smooth muscle (green).
Structure Level Pattern Image Note
TS27: prostate bud Present GUDMAP:20671
TS27: male accessory gland Present GUDMAP:20671
TS27: ejaculatory duct Present GUDMAP:20671
TS27: seminal vesicle Present GUDMAP:20671
TS27: peri-prostatic mesenchyme Present GUDMAP:20671
TS27: prostate epithelium Present GUDMAP:20671
TS27: muscle of ejaculatory duct Present GUDMAP:20671
TS27: lamina propria of ejaculatory duct Present GUDMAP:20671
TS27: muscle of seminal vesicle Present GUDMAP:20671
TS27: epithelium of ejaculatory duct Present GUDMAP:20671
TS27: vasculature of ejaculatory duct Absent GUDMAP:20671
TS27: vasculature of seminal vesicle Absent GUDMAP:20671
TS27: serosa of seminal vesicle Absent GUDMAP:20671
TS27: epithelium of seminal vesicle Present GUDMAP:20671
TS27: male reproductive system Present GUDMAP:20671
TS27: reproductive system Present GUDMAP:20671
TS27: urinary system Present GUDMAP:20671
TS27: mesenchymal layer of ventral pelvic urethra of male Present GUDMAP:20671
TS27: mesenchymal layer of dorsal pelvic urethra of male Present GUDMAP:20671
TS27: mesenchymal layer of pelvic urethra of male Present GUDMAP:20671
TS27: epithelium of ventral pelvic urethra of male Present GUDMAP:20671
TS27: epithelium of dorsal pelvic urethra of male Present GUDMAP:20671
TS27: epithelium of pelvic urethra of male Present GUDMAP:20671
TS27: pelvic urethra of male Present GUDMAP:20671
TS27: urethra of male Present GUDMAP:20671
TS27: presumptive neural crest derivative of pelvic urethra of male Absent GUDMAP:20671
TS27: vasculature of pelvic urethra of male Absent GUDMAP:20671
TS27: mesenchymal pad of pelvic urethra of male Absent GUDMAP:20671
TS27: muscle layer of pelvic urethra of male Present GUDMAP:20671
TS27: muscularis mucosa of dorsal pelvic urethra of male Absent GUDMAP:20671
TS27: muscularis mucosa of ventral pelvic urethra of male Absent GUDMAP:20671
TS27: lamina propria of dorsal pelvic urethra of male Present GUDMAP:20671
TS27: submucosa of dorsal pelvic urethra of male Present GUDMAP:20671
TS27: lamina propria of ventral pelvic urethra of male Present GUDMAP:20671
TS27: submucosa of ventral pelvic urethra of male Present GUDMAP:20671
TS27: intermediate cell layer of ventral pelvic urethra of male Present GUDMAP:20671
TS27: basal cell layer of ventral pelvic urethra of male Present GUDMAP:20671
TS27: basal cell layer of dorsal pelvic urethra of male Present GUDMAP:20671
TS27: intermediate cell layer of dorsal pelvic urethra of male Present GUDMAP:20671
TS27: superficial cell layer of dorsal pelvic urethra of male Absent GUDMAP:20671
TS27: superficial cell layer of ventral pelvic urethra of male Absent GUDMAP:20671
Specimen GUDMAP:20672: postnatal day 0 (more )
Note: This specimen was generated and annotated by the lab of Chad Vezina, University of Wisconsin-Madison. Labeling was visualized using BM purple. The section was also labeled by immunohistochemistry to visualize cadherin 1 in epithelium (red) and actin alpha 2 in smooth muscle (green).
Structure Level Pattern Image Note
TS27: upper vagina Present GUDMAP:20672
TS27: sinovaginal bulb Present GUDMAP:20672
TS27: vagina Present GUDMAP:20672
TS27: female reproductive system Present GUDMAP:20672
TS27: reproductive system Present GUDMAP:20672
TS27: urinary system Present GUDMAP:20672
TS27: lamina propria of sinovaginal bulb Present GUDMAP:20672
TS27: lamina propria of upper vagina Present GUDMAP:20672
TS27: muscle of sinovaginal bulb Present GUDMAP:20672
TS27: muscle of upper vagina Present GUDMAP:20672
TS27: epithelium of upper vagina Present Spotted GUDMAP:20672
TS27: epithelium of sinovaginal bulb Present GUDMAP:20672
TS27: vasculature of sinovaginal bulb Absent GUDMAP:20672
TS27: vasculature of upper vagina Absent GUDMAP:20672
TS27: epithelium of vagina Present GUDMAP:20672
TS27: muscle of vagina Present GUDMAP:20672
TS27: developing vasculature of vagina Absent GUDMAP:20672
TS27: mesenchymal layer of ventral pelvic urethra of female Present GUDMAP:20672
TS27: mesenchymal layer of dorsal pelvic urethra of female Present GUDMAP:20672
TS27: mesenchymal layer of pelvic urethra of female Present GUDMAP:20672
TS27: epithelium of ventral pelvic urethra of female Present GUDMAP:20672
TS27: epithelium of dorsal pelvic urethra of female Present GUDMAP:20672
TS27: epithelium of pelvic urethra of female Present GUDMAP:20672
TS27: pelvic urethra of female Present GUDMAP:20672
TS27: urethra of female Present GUDMAP:20672
TS27: presumptive neural crest derivative of pelvic urethra of female Absent GUDMAP:20672
TS27: vasculature of pelvic urethra of female Absent GUDMAP:20672
TS27: mesenchymal pad of pelvic urethra of female Absent GUDMAP:20672
TS27: muscle layer of pelvic urethra of female Present GUDMAP:20672
TS27: muscularis mucosa of dorsal pelvic urethra of female Absent GUDMAP:20672
TS27: muscularis mucosa of ventral pelvic urethra of female Absent GUDMAP:20672
TS27: lamina propria of ventral pelvic urethra of female Present GUDMAP:20672
TS27: submucosa of ventral pelvic urethra of female Present GUDMAP:20672
TS27: lamina propria of dorsal pelvic urethra of female Present GUDMAP:20672
TS27: submucosa of dorsal pelvic urethra of female Present GUDMAP:20672
TS27: superficial cell layer of dorsal pelvic urethra of female Absent GUDMAP:20672
TS27: superficial cell layer of ventral pelvic urethra of female Absent GUDMAP:20672
TS27: intermediate cell layer of ventral pelvic urethra of female Present GUDMAP:20672
TS27: basal cell layer of ventral pelvic urethra of female Present GUDMAP:20672
TS27: basal cell layer of dorsal pelvic urethra of female Present GUDMAP:20672
TS27: intermediate cell layer of dorsal pelvic urethra of female Present GUDMAP:20672
Specimen GUDMAP:20673: postnatal day 5 (more )
Note: This specimen was generated and annotated by the lab of Chad Vezina, University of Wisconsin-Madison. Labeling was visualized using BM purple. The section was also labeled by immunohistochemistry to visualize cadherin 1 in epithelium (red) and actin alpha 2 in smooth muscle (green).
Structure Level Pattern Image Note
TS28: prostate gland Present GUDMAP:20673
TS28: male accessory gland Present GUDMAP:20673
TS28: ejaculatory duct Present GUDMAP:20673
TS28: seminal vesicle Present GUDMAP:20673
TS28: male reproductive system Present GUDMAP:20673
TS28: reproductive system Present GUDMAP:20673
TS28: urinary system Present GUDMAP:20673
TS28: anterior prostate gland Present GUDMAP:20673
TS28: ventral prostate gland Present GUDMAP:20673
TS28: anterior prostatic epithelium Present GUDMAP:20673
TS28: ventral prostatic epithelium Present GUDMAP:20673
TS28: ventral prostatic interstitium Present GUDMAP:20673
TS28: anterior prostatic interstitium Present GUDMAP:20673
TS28: rest of interstitium of anterior prostate Present GUDMAP:20673
TS28: rest of interstitium of ventral prostate Present GUDMAP:20673
TS28: basal epithelium of anterior prostate Present Regionally restricted GUDMAP:20673 Expression detected in prostatic bud tips only.
TS28: basal epithelium of ventral prostate Present Regionally restricted GUDMAP:20673 Expression detected in prostatic bud tips only.
TS28: epithelium of seminal vesicle Present GUDMAP:20673
TS28: muscle of seminal vesicle Present GUDMAP:20673
TS28: vasculature of ejaculatory duct Absent GUDMAP:20673
TS28: vasculature of seminal vesicle Absent GUDMAP:20673
TS28: serosa of seminal vesicle Absent GUDMAP:20673
TS28: muscle of ejaculatory duct Present GUDMAP:20673
TS28: epithelium of ejaculatory duct Present GUDMAP:20673
TS28: mesenchymal layer of ventral pelvic urethra of male Present GUDMAP:20673
TS28: mesenchymal layer of dorsal pelvic urethra of male Present GUDMAP:20673
TS28: mesenchymal layer of pelvic urethra of male Present GUDMAP:20673
TS28: epithelium of ventral pelvic urethra of male Present GUDMAP:20673
TS28: epithelium of dorsal pelvic urethra of male Present GUDMAP:20673
TS28: epithelium of pelvic urethra of male Present GUDMAP:20673
TS28: pelvic urethra of male Present GUDMAP:20673
TS28: urethra of male Present GUDMAP:20673
TS28: muscularis mucosa of dorsal pelvic urethra of male Absent GUDMAP:20673
TS28: muscularis mucosa of ventral pelvic urethra of male Absent GUDMAP:20673
TS28: vasculature of pelvic urethra of male Absent GUDMAP:20673
TS28: muscle layer of pelvic urethra of male Absent GUDMAP:20673
TS28: lamina propria of ventral pelvic urethra of male Present GUDMAP:20673
TS28: submucosa of ventral pelvic urethra of male Present GUDMAP:20673
TS28: submucosa of dorsal pelvic urethra of male Present GUDMAP:20673
TS28: lamina propria of dorsal pelvic urethra of male Present GUDMAP:20673
TS28: superficial cell layer of dorsal pelvic urethra of male Absent GUDMAP:20673
TS28: superficial cell layer of ventral pelvic urethra of male Absent GUDMAP:20673
TS28: intermediate cell layer of dorsal pelvic urethra of male Present GUDMAP:20673
TS28: basal cell layer of dorsal pelvic urethra of male Present GUDMAP:20673
TS28: intermediate cell layer of ventral pelvic urethra of male Present GUDMAP:20673
TS28: basal cell layer of ventral pelvic urethra of male Present GUDMAP:20673
TS28: smooth muscle layer of prostatic urethra Absent GUDMAP:20673
TS28: muscle layer of prostatic urethra Absent GUDMAP:20673
TS28: vasculature of prostatic urethra Absent GUDMAP:20673
TS28: superficial cell layer of prostatic urethra Absent GUDMAP:20673
TS28: muscularis mucosa of prostatic urethra Absent GUDMAP:20673
TS28: submucosa of prostatic urethra Present GUDMAP:20673 More expression in submucosa of the ventral urethra than dorsal urethra.
TS28: lamina propria of prostatic urethra Present GUDMAP:20673 More expression in lamina propria of the ventral urethra than dorsal urethra.
TS28: basal cell layer of prostatic urethra Present GUDMAP:20673
TS28: intermediate cell layer of prostatic urethra Present GUDMAP:20673
TS28: mesenchymal layer of prostatic urethra Present GUDMAP:20673
TS28: epithelium of prostatic urethra Present GUDMAP:20673
TS28: prostatic urethra Present GUDMAP:20673
TS28: male urethral gland Absent GUDMAP:20673
Specimen GUDMAP:20674: postnatal day 5 (more )
Note: This specimen was generated and annotated by the lab of Chad Vezina, University of Wisconsin-Madison. Labeling was visualized using BM purple. The section was also labeled by immunohistochemistry to visualize cadherin 1 in epithelium (red) and actin alpha 2 in smooth muscle (green).
Structure Level Pattern Image Note
TS28: vagina Present GUDMAP:20674
TS28: female reproductive system Present GUDMAP:20674
TS28: rest of epithelium of vagina Absent GUDMAP:20674
TS28: vasculature of vagina Absent GUDMAP:20674
TS28: epithelium of vagina Absent GUDMAP:20674
TS28: reproductive system Present GUDMAP:20674
TS28: urinary system Present GUDMAP:20674
TS28: epithelium of ventral pelvic urethra of female Present GUDMAP:20674
TS28: epithelium of dorsal pelvic urethra of female Present GUDMAP:20674
TS28: epithelium of pelvic urethra of female Present GUDMAP:20674
TS28: pelvic urethra of female Present GUDMAP:20674
TS28: urethra of female Present GUDMAP:20674
TS28: muscle layer of pelvic urethra of female Absent GUDMAP:20674
TS28: vasculature of pelvic urethra of female Absent GUDMAP:20674
TS28: mesenchymal layer of pelvic urethra of female Absent GUDMAP:20674
TS28: submucosa of ventral pelvic urethra of female Absent GUDMAP:20674
TS28: muscularis mucosa of ventral pelvic urethra of female Absent GUDMAP:20674
TS28: lamina propria of ventral pelvic urethra of female Absent GUDMAP:20674
TS28: mesenchymal layer of ventral pelvic urethra of female Absent GUDMAP:20674
TS28: submucosa of dorsal pelvic urethra of female Absent GUDMAP:20674
TS28: muscularis mucosa of dorsal pelvic urethra of female Absent GUDMAP:20674
TS28: lamina propria of dorsal pelvic urethra of female Absent GUDMAP:20674
TS28: mesenchymal layer of dorsal pelvic urethra of female Absent GUDMAP:20674
TS28: superficial cell layer of dorsal pelvic urethra of female Absent GUDMAP:20674
TS28: superficial cell layer of ventral pelvic urethra of female Absent GUDMAP:20674
TS28: intermediate cell layer of dorsal pelvic urethra of female Present GUDMAP:20674
TS28: basal cell layer of dorsal pelvic urethra of female Present GUDMAP:20674
TS28: intermediate cell layer of ventral pelvic urethra of female Present GUDMAP:20674
TS28: basal cell layer of ventral pelvic urethra of female Present GUDMAP:20674
Contributing Projects:
Mouse Genome Database (MGD), Gene Expression Database (GXD), Mouse Models of Human Cancer database (MMHCdb) (formerly Mouse Tumor Biology (MTB)), Gene Ontology (GO)
Citing These Resources
Funding Information
Warranty Disclaimer, Privacy Notice, Licensing, & Copyright
Send questions and comments to User Support. 		last database update
12/30/2025
MGI 6.24 		The Jackson Laboratory
