Gene Expression Data
Assay Details
Assay
Reference: J:171409 GUDMAP Consortium, GUDMAP: the GenitoUrinary Development Molecular Anatomy Project. www.gudmap.org. 2004;
Assay type: RNA in situ
MGI Accession ID: MGI:5541569
Gene symbol: Ttr
Gene name: transthyretin
Probe: RIKEN clone 3830432G21 subclone
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Results
Specimen GUDMAP:10026: embryonic day 10.5 (more )
Note: This specimen was generated and annotated by the lab of Melissa H. Little, Murdoch Children's Research Institute. Labeling was visualized using NBT/BCIP.
Structure Level Pattern Image Note
TS17: genitourinary system Ambiguous GUDMAP:10026 expression uncertain
Specimen GUDMAP:10394: embryonic day 13.5 (more )
Note: This specimen was generated and annotated by the lab of Melissa H. Little, Murdoch Children's Research Institute. Labeling was visualized using NBT/BCIP.
Structure Level Pattern Image Note
TS21: mesonephric tubule of male Absent GUDMAP:10394
TS21: nephric duct of male, mesonephric portion Absent GUDMAP:10394
TS21: paramesonephric duct of male, mesonephric portion Absent GUDMAP:10394
TS21: nephric duct of male, rest of Absent GUDMAP:10394
TS21: paramesonephric duct of male, rest of Absent GUDMAP:10394
TS21: coelomic epithelium of male mesonephros Absent GUDMAP:10394
TS21: interstitium of the testis Absent GUDMAP:10394
TS21: mesonephric mesenchyme of male Ambiguous GUDMAP:10394 possible expression
TS21: primary sex cord Ambiguous GUDMAP:10394 possible expression
Specimen GUDMAP:10395: embryonic day 13.5 (more )
Note: This specimen was generated and annotated by the lab of Melissa H. Little, Murdoch Children's Research Institute. Labeling was visualized using NBT/BCIP. Male and female were examined; only the male is shown. Annotators reported the male expression pattern in the metanephros is identical to female.
Structure Level Pattern Image Note
TS21: urinary system Ambiguous GUDMAP:10395 uncertain expression
Specimen GUDMAP:10396: embryonic day 13.5 (more )
Note: This specimen was generated and annotated by the lab of Melissa H. Little, Murdoch Children's Research Institute. Labeling was visualized using NBT/BCIP. Male and female were examined; only the male is shown. Annotators reported the male expression pattern in the urogenital sinus is identical to female.
Structure Level Pattern Image Note
TS21: urinary system Present GUDMAP:10396
TS21: urogenital sinus Present Ubiquitous GUDMAP:10396
TS21: primitive bladder Present GUDMAP:10396
TS21: ureter Ambiguous GUDMAP:10396 uncertain expression
Specimen GUDMAP:10397: embryonic day 13.5 (more )
Note: This specimen was generated and annotated by the lab of Melissa H. Little, Murdoch Children's Research Institute. Labeling was visualized using NBT/BCIP.
Structure Level Pattern Image Note
TS21: mesonephric tubule of female Absent GUDMAP:10397
TS21: nephric duct of female, mesonephric portion Absent GUDMAP:10397
TS21: paramesonephric duct of female, mesonephric portion Absent GUDMAP:10397
TS21: nephric duct of female, rest of Absent GUDMAP:10397
TS21: paramesonephric duct of female, rest of Absent GUDMAP:10397
TS21: coelomic epithelium of female mesonephros Absent GUDMAP:10397
TS21: mesonephric mesenchyme of female Ambiguous GUDMAP:10397 uncertain expression
TS21: ovary Ambiguous GUDMAP:10397 uncertain expression
Specimen GUDMAP:11015: postnatal adult (more )
Note: This specimen was generated and annotated by the lab of Melissa H. Little, Murdoch Children's Research Institute. This animal was sexually mature. Labeling was visualized using BM purple.
Structure Level Pattern Image Note
TS28: mature renal corpuscle Ambiguous GUDMAP:11015
TS28: segment 2 of proximal tubule Present GUDMAP:11015
TS28: renal proximal convoluted tubule Present Regionally restricted GUDMAP:11015
TS28: renal proximal tubule Present Regionally restricted GUDMAP:11015
TS28: cortical renal tubule Present GUDMAP:11015
TS28: proximal straight tubule, cortical portion Present GUDMAP:11015
TS28: renal medulla Present GUDMAP:11015
TS28: outer renal medulla Present GUDMAP:11015
TS28: loop of Henle, outer medullary portion Present Regionally restricted GUDMAP:11015
TS28: proximal straight tubule, outer medullary portion Present GUDMAP:11015
TS28: metanephros Present GUDMAP:11015
TS28: segment 1 of proximal tubule Ambiguous GUDMAP:11015
TS28: outer stripe of outer medulla Present GUDMAP:11015
TS28: distal straight tubule of outer stripe of outer medulla Ambiguous GUDMAP:11015
TS28: inner stripe of outer medulla Ambiguous GUDMAP:11015
TS28: inner renal medulla Ambiguous GUDMAP:11015
TS28: renal pelvis Ambiguous GUDMAP:11015
TS28: loop of Henle of outer stripe of outer medulla Present Regionally restricted GUDMAP:11015
TS28: proximal straight tubule of outer stripe of outer medulla Present GUDMAP:11015
TS28: premacula segment of distal straight tubule of outer medulla Ambiguous GUDMAP:11015
TS28: renal cortex Present GUDMAP:11015
Specimen GUDMAP:11016: embryonic day 15.5 (more )
Note: This specimen was generated and annotated by the lab of Melissa H. Little, Murdoch Children's Research Institute. Labeling was visualized using BM purple.
Structure Level Pattern Image Note
TS23: renal medulla Present GUDMAP:11016
TS23: renal cortex Present GUDMAP:11016
TS23: metanephros Present GUDMAP:11016 Strong expression in a restricted region of the maturing nephron renal tubule in the distal early proximal tubule and proximal immature loop of Henle. All other signal seen is background staining.
TS23: urinary system Present GUDMAP:11016
TS23: cortical renal tubule Present GUDMAP:11016
TS23: cortical early proximal tubule Present Regionally restricted GUDMAP:11016 Regional expression in the most distal early proximal tubule adjacent to the immature loop of Henle, and expression in the early S3 segment of the proximal tubule.
TS23: immature loop of Henle Present Regionally restricted GUDMAP:11016 Regional expression in the proximal immature loop of Henle adjacent to the early proximal tubule and closest to the renal cortex. Expression is absent from the more distal immature loop of Henle deeper in the medulla.
TS23: maturing nephron Present GUDMAP:11016
TS23: late tubule Present GUDMAP:11016
TS23: cortical early distal tubule Absent GUDMAP:11016
TS23: renal connecting tubule Absent GUDMAP:11016
TS23: anlage of loop of Henle of cortical renal tubule Absent GUDMAP:11016
TS23: early tubule Absent GUDMAP:11016
TS23: nephrogenic zone Absent GUDMAP:11016
TS23: renal vesicle Absent GUDMAP:11016
TS23: comma-shaped body Absent GUDMAP:11016
TS23: s-shaped body Absent GUDMAP:11016
TS23: capillary loop renal corpuscle Absent GUDMAP:11016
TS23: maturing renal corpuscle Absent GUDMAP:11016
TS23: cortical collecting duct Absent GUDMAP:11016
TS23: renal cortical interstitium Absent GUDMAP:11016
TS23: renal cortical vasculature Absent GUDMAP:11016
TS23: renal medullary interstitium Absent GUDMAP:11016
TS23: renal medullary vasculature Absent GUDMAP:11016
TS23: renal pelvis Absent GUDMAP:11016
TS23: cortical renal tubule of maturing nephron group Present GUDMAP:11016
TS23: early proximal tubule of maturing nephron Present GUDMAP:11016
TS23: cortical renal tubule of capillary loop nephron group Absent GUDMAP:11016
TS23: early distal tubule of maturing nephron Absent GUDMAP:11016
