Gene Expression Data
Assay Details
Assay
Reference: J:122989 Visel A, et al., GenePaint.org: an atlas of gene expression patterns in the mouse embryo. Nucleic Acids Res. 2004 Jan 1;32(Database issue):D552-6
Assay type: RNA in situ
MGI Accession ID: MGI:5423072
Gene symbol: Il10rb
Gene name: interleukin 10 receptor, beta
Probe: MY257 probe 122
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure. These data were downloaded from GenePaint.org on 1/30/12.
Results
Specimen MY257; Specimen C1336: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS22: nervous system Moderate Regionally restricted Embryo_C1336_4_4A
TS22: central nervous system Moderate Regionally restricted Embryo_C1336_4_4B
TS22: telencephalon Moderate Regionally restricted Embryo_C1336_4_4A
TS22: cerebral cortex Moderate Regionally restricted Embryo_C1336_4_6A
TS22: neocortex Moderate Scattered Embryo_C1336_4_6A
TS22: olfactory cortex Weak Regionally restricted Embryo_C1336_4_4A
TS22: main olfactory bulb Weak Scattered Embryo_C1336_4_4A
TS22: piriform cortex Absent
TS22: hippocampus Moderate Scattered Embryo_C1336_4_6A
TS22: basal ganglia Moderate Regionally restricted Embryo_C1336_4_4A
TS22: corpus striatum Moderate Scattered Embryo_C1336_4_6A Expression was detected in the corpus striatum (lateral ganglionic eminence).
TS22: basal forebrain Absent
TS22: amygdala Absent
TS22: telencephalon septum Moderate Scattered Embryo_C1336_4_4A
TS22: pallidum Moderate Scattered Embryo_C1336_4_4A Expression was detected in the pallidum (medial ganglionic eminence).
TS22: diencephalon Weak Regionally restricted Embryo_C1336_4_4C
TS22: thalamus Weak Regionally restricted Embryo_C1336_4_4B
TS22: hypothalamus Weak Regionally restricted Embryo_C1336_4_4C
TS22: midbrain Moderate Regionally restricted Embryo_C1336_4_4C
TS22: pretectum Weak Scattered Embryo_C1336_4_4A
TS22: superior colliculus Weak Scattered Embryo_C1336_4_3A
TS22: inferior colliculus Weak Scattered Embryo_C1336_4_4A
TS22: midbrain tegmentum Moderate Regionally restricted Embryo_C1336_4_4C
TS22: hindbrain Moderate Regionally restricted Embryo_C1336_4_4A
TS22: cerebellum Weak Regionally restricted Embryo_C1336_4_4B
TS22: pons Moderate Regionally restricted Embryo_C1336_4_4A
TS22: medulla oblongata Weak Regionally restricted Embryo_C1336_4_4B
TS22: spinal cord Moderate Regionally restricted Embryo_C1336_4_4B
TS22: choroid plexus Moderate Regionally restricted Embryo_C1336_4_4B
TS22: meninges Moderate Regionally restricted Embryo_C1336_4_2B
TS22: peripheral nervous system Weak Regionally restricted Embryo_C1336_4_3A
TS22: cranial ganglion Weak Regionally restricted Embryo_C1336_4_2B
TS22: dorsal root ganglion Weak Regionally restricted Embryo_C1336_4_3A
TS22: eye Weak Regionally restricted Embryo_C1336_4_1B
TS22: retina Weak Regionally restricted Embryo_C1336_4_1B
TS22: lens Weak Regionally restricted Embryo_C1336_4_1C
TS22: cornea Weak Regionally restricted Embryo_C1336_4_1A
TS22: optic nerve Absent
TS22: nose Moderate Regionally restricted Embryo_C1336_4_4A
TS22: olfactory epithelium Moderate Regionally restricted Embryo_C1336_4_4A
TS22: ear Moderate Regionally restricted Embryo_C1336_4_6A
TS22: inner ear Moderate Regionally restricted Embryo_C1336_4_6A
TS22: cochlea Weak Regionally restricted Embryo_C1336_4_3B
TS22: inner ear labyrinth Moderate Regionally restricted Embryo_C1336_4_6A
TS22: middle ear Weak Regionally restricted Embryo_C1336_4_1B
TS22: alimentary system Weak Regionally restricted Embryo_C1336_4_4A Expression was weak in the digestive system.
TS22: intestine Weak Regionally restricted Embryo_C1336_4_4D
TS22: salivary gland Absent
TS22: tongue Weak Regionally restricted Embryo_C1336_4_4A
TS22: tooth Absent
TS22: palatal shelf Absent
TS22: esophagus Weak Regionally restricted Embryo_C1336_4_4B
TS22: stomach Weak Regionally restricted Embryo_C1336_4_5C
TS22: liver Weak Regionally restricted Embryo_C1336_4_6A
TS22: respiratory system Moderate Regionally restricted Embryo_C1336_4_4A
TS22: pharynx Weak Regionally restricted Embryo_C1336_4_4B
TS22: larynx Weak Regionally restricted Embryo_C1336_4_4B
TS22: trachea Moderate Regionally restricted Embryo_C1336_4_4A
TS22: main bronchus Weak Regionally restricted Embryo_C1336_4_4C
TS22: lung Weak Regionally restricted Embryo_C1336_4_3A
TS22: urinary system Weak Regionally restricted Embryo_C1336_4_5A Expression was weak in the genito-urinary system.
TS22: metanephros Weak Regionally restricted Embryo_C1336_4_6A
TS22: ureter Absent
TS22: bladder Weak Regionally restricted Embryo_C1336_4_4C
TS22: urethra Weak Regionally restricted Embryo_C1336_4_4D
TS22: reproductive system Weak Regionally restricted Embryo_C1336_4_5A
TS22: genital tubercle Weak Regionally restricted Embryo_C1336_4_5A
TS22: gonad Absent
TS22: gland Moderate Regionally restricted Embryo_C1336_4_6A Expression was detected in the endocrine system.
TS22: thyroid gland Weak Regionally restricted Embryo_C1336_4_4C
TS22: pituitary gland Moderate Regionally restricted Embryo_C1336_4_4A
TS22: pancreas Weak Regionally restricted Embryo_C1336_4_5D
TS22: adrenal gland Moderate Regionally restricted Embryo_C1336_4_6A
TS22: cardiovascular system Weak Regionally restricted Embryo_C1336_4_4A
TS22: heart Weak Regionally restricted Embryo_C1336_4_4A
TS22: heart atrium Weak Regionally restricted Embryo_C1336_4_4A
TS22: heart ventricle Weak Regionally restricted Embryo_C1336_4_4A
TS22: blood vessel Absent
TS22: hemolymphoid system Moderate Regionally restricted Embryo_C1336_4_4A Expression was detected in the immune system.
TS22: spleen primordium Absent
TS22: thymus primordium Moderate Regionally restricted Embryo_C1336_4_4A
TS22: appendicular skeleton Absent Expression was not detected in the skeleton (limbs, shoulder, hip).
TS22: musculature Weak Regionally restricted Embryo_C1336_4_1A
TS22: face Weak Regionally restricted Embryo_C1336_4_4A Expression was weak in the face/soft tissues.
TS22: facial bone primordium Absent
TS22: cranium Absent Expression was not detected in the skull (base and vault).
TS22: axial skeleton Weak Regionally restricted Embryo_C1336_4_6C
TS22: tail Weak Regionally restricted Embryo_C1336_4_5A
TS22: forelimb Moderate Regionally restricted Embryo_C1336_4_1C
TS22: hindlimb Moderate Regionally restricted Embryo_C1336_4_2B
TS22: integumental system Moderate Regionally restricted Embryo_C1336_4_6A
TS22: skin Moderate Regionally restricted Embryo_C1336_4_6A
TS22: hair Weak Regionally restricted Embryo_C1336_4_2A
TS22: vibrissa follicle Weak Regionally restricted Embryo_C1336_4_2A Expression was weak in whisker follicle.
