Gene Expression Data
Assay Details
Assay
Reference: J:122989 Visel A, et al., GenePaint.org: an atlas of gene expression patterns in the mouse embryo. Nucleic Acids Res. 2004 Jan 1;32(Database issue):D552-6
Assay type: RNA in situ
MGI Accession ID: MGI:5421879
Gene symbol: Ckb
Gene name: creatine kinase, brain
Probe: T30969
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure. These data were downloaded from GenePaint.org on 1/30/12.
Results
Specimen EH3762; Specimen C3542: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS22: nervous system Strong Regionally restricted Embryo_C3542_6_4A
TS22: central nervous system Strong Regionally restricted Embryo_C3542_6_4A
TS22: telencephalon Strong Regionally restricted Embryo_C3542_6_3B
TS22: cerebral cortex Strong Regionally restricted Embryo_C3542_6_3B
TS22: neocortex Strong Regionally restricted Embryo_C3542_6_3B
TS22: olfactory cortex Strong Regionally restricted Embryo_C3542_6_3B
TS22: main olfactory bulb Strong Regionally restricted Embryo_C3542_6_3B
TS22: piriform cortex Absent
TS22: hippocampus Strong Regionally restricted Embryo_C3542_6_3B
TS22: basal ganglia Strong Regionally restricted Embryo_C3542_6_3B
TS22: corpus striatum Strong Regionally restricted Embryo_C3542_6_1D Expression was strong in the corpus striatum (lateral ganglionic eminence).
TS22: basal forebrain Absent
TS22: amygdala Absent
TS22: telencephalon septum Strong Regionally restricted Embryo_C3542_6_3B
TS22: pallidum Strong Regionally restricted Embryo_C3542_6_3B Expression was strong in the pallidum (medial ganglionic eminence).
TS22: diencephalon Strong Regionally restricted Embryo_C3542_6_4A
TS22: thalamus Strong Regionally restricted Embryo_C3542_6_4A
TS22: hypothalamus Strong Regionally restricted Embryo_C3542_6_4A
TS22: midbrain Strong Regionally restricted Embryo_C3542_6_4A
TS22: pretectum Absent
TS22: superior colliculus Strong Regionally restricted Embryo_C3542_6_4A
TS22: inferior colliculus Strong Regionally restricted Embryo_C3542_6_4A
TS22: midbrain tegmentum Strong Regionally restricted Embryo_C3542_6_4A
TS22: hindbrain Strong Regionally restricted Embryo_C3542_6_4A
TS22: cerebellum Strong Regionally restricted Embryo_C3542_6_4A
TS22: pons Strong Regionally restricted Embryo_C3542_6_4A
TS22: medulla oblongata Strong Regionally restricted Embryo_C3542_6_4A
TS22: spinal cord Strong Regionally restricted Embryo_C3542_6_4D
TS22: choroid plexus Absent
TS22: meninges Absent
TS22: peripheral nervous system Strong Ubiquitous Embryo_C3542_6_5C
TS22: cranial ganglion Strong Ubiquitous Embryo_C3542_6_5C
TS22: dorsal root ganglion Strong Ubiquitous Embryo_C3542_6_5C
TS22: eye Strong Ubiquitous Embryo_C3542_6_1A
TS22: retina Strong Ubiquitous Embryo_C3542_6_1A
TS22: lens Absent
TS22: cornea Absent
TS22: optic nerve Strong Ubiquitous Embryo_C3542_6_3B
TS22: nose Strong Regionally restricted Embryo_C3542_6_3B
TS22: olfactory epithelium Strong Regionally restricted Embryo_C3542_6_3B
TS22: ear Strong Regionally restricted Embryo_C3542_6_2A
TS22: inner ear Strong Regionally restricted Embryo_C3542_6_2A
TS22: cochlea Strong Regionally restricted Embryo_C3542_6_3A
TS22: inner ear labyrinth Strong Regionally restricted Embryo_C3542_6_2A
TS22: middle ear Absent
TS22: alimentary system Strong Regionally restricted Embryo_C3542_6_4C Expression was strong in the digestive system.
TS22: intestine Strong Regionally restricted Embryo_C3542_6_5A
TS22: salivary gland Absent
TS22: tongue Absent
TS22: tooth Absent
TS22: palatal shelf Absent
TS22: esophagus Strong Regionally restricted Embryo_C3542_6_4C
TS22: stomach Strong Regionally restricted Embryo_C3542_6_2C
TS22: liver Absent
TS22: respiratory system Strong Regionally restricted Embryo_C3542_6_3C
TS22: pharynx Absent
TS22: larynx Absent
TS22: trachea Absent
TS22: main bronchus Strong Regionally restricted Embryo_C3542_6_3C
TS22: lung Strong Regionally restricted Embryo_C3542_6_2C
TS22: urinary system Strong Regionally restricted Embryo_C3542_6_4A Expression was strong in the genito-urinary system.
TS22: metanephros Absent
TS22: ureter Absent
TS22: bladder Strong Regionally restricted Embryo_C3542_6_4A
TS22: urethra Absent
TS22: reproductive system Absent
TS22: genital tubercle Absent
TS22: gonad Absent
TS22: gland Strong Regionally restricted Embryo_C3542_6_3C Expression was strong in the endocrine system.
TS22: thyroid gland Absent
TS22: pituitary gland Absent
TS22: pancreas Absent
TS22: adrenal gland Strong Scattered Embryo_C3542_6_3C
TS22: cardiovascular system Absent
TS22: heart Absent
TS22: heart atrium Absent
TS22: heart ventricle Absent
TS22: blood vessel Absent
TS22: hemolymphoid system Absent Expression was not detected in the immune system.
TS22: spleen primordium Absent
TS22: thymus primordium Absent
TS22: appendicular skeleton Absent Expression was not detected in the skeleton (limbs, shoulder, hip).
TS22: musculature Absent
TS22: face Absent Expression was not detected in the face/soft tissues.
TS22: facial bone primordium Absent
TS22: cranium Absent Expression was not detected in the skull (base and vault).
TS22: axial skeleton Strong Regionally restricted Embryo_C3542_6_4B
TS22: tail Strong Regionally restricted Embryo_C3542_6_4B
TS22: forelimb Absent
TS22: hindlimb Strong Regionally restricted Embryo_C3542_6_1A
TS22: integumental system Absent
TS22: skin Absent
TS22: hair Absent
TS22: vibrissa follicle Absent Expression was not detected in whisker follicle.
