Gene Expression Data
Assay Details
Assay
Reference: J:122989 Visel A, et al., GenePaint.org: an atlas of gene expression patterns in the mouse embryo. Nucleic Acids Res. 2004 Jan 1;32(Database issue):D552-6
Assay type: RNA in situ
MGI Accession ID: MGI:5421243
Gene symbol: Tcf7l1
Gene name: transcription factor 7 like 1 (T cell specific, HMG box)
Probe: MH770 probe 648
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure. These data were downloaded from GenePaint.org on 1/30/12.
Results
Specimen MH770; Specimen C1238: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS22: nervous system Moderate Regionally restricted Embryo_C1238_3_4B
TS22: central nervous system Moderate Regionally restricted Embryo_C1238_3_4B
TS22: telencephalon Moderate Regionally restricted Embryo_C1238_3_3B
TS22: cerebral cortex Moderate Regionally restricted Embryo_C1238_3_3B
TS22: neocortex Moderate Regionally restricted Embryo_C1238_3_3B
TS22: olfactory cortex Moderate Regionally restricted Embryo_C1238_3_4D
TS22: main olfactory bulb Moderate Regionally restricted Embryo_C1238_3_4D
TS22: piriform cortex Absent
TS22: hippocampus Moderate Regionally restricted Embryo_C1238_3_2C
TS22: basal ganglia Moderate Regionally restricted Embryo_C1238_3_2B
TS22: corpus striatum Moderate Regionally restricted Embryo_C1238_3_2B Expression was detected in the corpus striatum (lateral ganglionic eminence).
TS22: basal forebrain Absent
TS22: amygdala Moderate Regionally restricted Embryo_C1238_3_2B
TS22: telencephalon septum Moderate Regionally restricted Embryo_C1238_3_4B
TS22: pallidum Weak Regionally restricted Embryo_C1238_3_3B Expression was weak in the pallidum (medial ganglionic eminence).
TS22: diencephalon Moderate Regionally restricted Embryo_C1238_3_4A
TS22: thalamus Moderate Regionally restricted Embryo_C1238_3_4A
TS22: hypothalamus Moderate Regionally restricted Embryo_C1238_3_4A
TS22: midbrain Moderate Regionally restricted Embryo_C1238_3_4B
TS22: pretectum Moderate Regionally restricted Embryo_C1238_3_4B
TS22: superior colliculus Moderate Regionally restricted Embryo_C1238_3_4B
TS22: inferior colliculus Moderate Regionally restricted Embryo_C1238_3_4C
TS22: midbrain tegmentum Moderate Regionally restricted Embryo_C1238_3_4B
TS22: hindbrain Moderate Regionally restricted Embryo_C1238_3_4B
TS22: cerebellum Moderate Regionally restricted Embryo_C1238_3_4B
TS22: pons Moderate Regionally restricted Embryo_C1238_3_4C
TS22: medulla oblongata Moderate Regionally restricted Embryo_C1238_3_4B
TS22: spinal cord Moderate Regionally restricted Embryo_C1238_3_3C
TS22: choroid plexus Moderate Regionally restricted Embryo_C1238_3_4B
TS22: meninges Weak Regionally restricted Embryo_C1238_3_2B
TS22: peripheral nervous system Weak Regionally restricted Embryo_C1238_3_3A
TS22: cranial ganglion Weak Regionally restricted Embryo_C1238_3_2C
TS22: dorsal root ganglion Weak Regionally restricted Embryo_C1238_3_3A
TS22: eye Weak Regionally restricted Embryo_C1238_3_1A
TS22: retina Absent
TS22: lens Weak Regionally restricted Embryo_C1238_3_1A
TS22: optic nerve Weak Regionally restricted Embryo_C1238_3_2D
TS22: nose Weak Regionally restricted Embryo_C1238_3_3B
TS22: olfactory epithelium Weak Regionally restricted Embryo_C1238_3_3B
TS22: ear Weak Regionally restricted Embryo_C1238_3_3A
TS22: inner ear Weak Regionally restricted Embryo_C1238_3_3A
TS22: cochlea Weak Regionally restricted Embryo_C1238_3_3A
TS22: inner ear labyrinth Absent
TS22: middle ear Absent
TS22: alimentary system Strong Regionally restricted Embryo_C1238_3_4A Expression was strong in the digestive system.
TS22: intestine Weak Regionally restricted Embryo_C1238_3_4B
TS22: salivary gland Absent
TS22: tongue Strong Regionally restricted Embryo_C1238_3_4A
TS22: tooth Weak Regionally restricted Embryo_C1238_3_3B
TS22: palatal shelf Weak Regionally restricted Embryo_C1238_3_3C
TS22: esophagus Weak Regionally restricted Embryo_C1238_3_4A
TS22: stomach Weak Regionally restricted Embryo_C1238_3_5A
TS22: liver Moderate Regionally restricted Embryo_C1238_3_4B
TS22: respiratory system Moderate Regionally restricted Embryo_C1238_3_4C
TS22: pharynx Weak Regionally restricted Embryo_C1238_3_4A
TS22: larynx Weak Regionally restricted Embryo_C1238_3_4A
TS22: trachea Weak Regionally restricted Embryo_C1238_3_4A
TS22: main bronchus Moderate Regionally restricted Embryo_C1238_3_4C
TS22: lung Weak Regionally restricted Embryo_C1238_3_2A
TS22: urinary system Moderate Regionally restricted Embryo_C1238_3_5A Expression was detected in the genito-urinary system.
TS22: metanephros Moderate Regionally restricted Embryo_C1238_3_5A
TS22: ureter Absent
TS22: bladder Weak Regionally restricted Embryo_C1238_3_4A
TS22: urethra Absent
TS22: reproductive system Moderate Regionally restricted Embryo_C1238_3_4A
TS22: genital tubercle Moderate Regionally restricted Embryo_C1238_3_4A
TS22: gonad Weak Regionally restricted Embryo_C1238_3_5C
TS22: gland Weak Regionally restricted Embryo_C1238_3_5A Expression was weak in the endocrine system.
TS22: thyroid gland Absent
TS22: pituitary gland Weak Regionally restricted Embryo_C1238_3_4A
TS22: pancreas Absent
TS22: adrenal gland Weak Regionally restricted Embryo_C1238_3_5A
TS22: cardiovascular system Moderate Regionally restricted Embryo_C1238_3_4B
TS22: heart Weak Regionally restricted Embryo_C1238_3_3D
TS22: heart atrium Weak Regionally restricted Embryo_C1238_3_3C
TS22: heart ventricle Weak Regionally restricted Embryo_C1238_3_3D
TS22: blood vessel Moderate Regionally restricted Embryo_C1238_3_4B
TS22: hemolymphoid system Weak Regionally restricted Embryo_C1238_3_6A Expression was weak in the immune system.
TS22: spleen primordium Weak Regionally restricted Embryo_C1238_3_6A
TS22: thymus primordium Absent
TS22: appendicular skeleton Moderate Regionally restricted Embryo_C1238_3_3A Expression was detected in the skeleton (limbs, shoulder, hip).
TS22: musculature Weak Regionally restricted Embryo_C1238_3_2A
TS22: face Strong Regionally restricted Embryo_C1238_3_3A Expression was strong in the face/soft tissues.
TS22: facial bone primordium Absent
TS22: cranium Moderate Regionally restricted Embryo_C1238_3_3C Expression was detected in the skull (base and vault).
TS22: axial skeleton Weak Regionally restricted Embryo_C1238_3_3D
TS22: tail Strong Regionally restricted Embryo_C1238_3_4B
TS22: forelimb Strong Regionally restricted Embryo_C1238_3_1A
TS22: hindlimb Strong Regionally restricted Embryo_C1238_3_1C
TS22: integumental system Strong Regionally restricted Embryo_C1238_3_3B
TS22: skin Strong Regionally restricted Embryo_C1238_3_3B
TS22: hair Absent
TS22: vibrissa follicle Absent Expression was not detected in whisker follicle.
