Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4829034
Gene symbol: Txnl4a
Gene name: thioredoxin-like 4A
Probe: T31603
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_012641_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: liver lobe Weak Regionally restricted euxassay_012641_01
Specimen euxassay_012641_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Moderate Uniform euxassay_012641_02
TS23: liver lobe Weak Regionally restricted euxassay_012641_02
Specimen euxassay_012641_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Moderate Uniform euxassay_012641_03
TS23: trigeminal ganglion Weak Regionally restricted euxassay_012641_03
TS23: liver lobe Weak Regionally restricted euxassay_012641_03
Specimen euxassay_012641_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Moderate Uniform euxassay_012641_04
TS23: trigeminal ganglion Weak Regionally restricted euxassay_012641_04
TS23: liver lobe Weak Regionally restricted euxassay_012641_04
Specimen euxassay_012641_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Weak Uniform euxassay_012641_05
TS23: renal cortex Weak Regionally restricted euxassay_012641_05
TS23: trigeminal ganglion Weak Regionally restricted euxassay_012641_05
TS23: liver lobe Weak Regionally restricted euxassay_012641_05
Specimen euxassay_012641_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Weak Uniform euxassay_012641_06
TS23: renal cortex Weak Regionally restricted euxassay_012641_06
TS23: upper jaw molar Weak Regionally restricted euxassay_012641_06
TS23: trigeminal ganglion Weak Regionally restricted euxassay_012641_06
TS23: liver lobe Weak Regionally restricted euxassay_012641_06
Specimen euxassay_012641_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Weak Uniform euxassay_012641_07
TS23: renal cortex Weak Regionally restricted euxassay_012641_07
TS23: upper jaw molar Weak Regionally restricted euxassay_012641_07
TS23: lower jaw molar Weak Regionally restricted euxassay_012641_07
TS23: submandibular gland primordium Weak Regionally restricted euxassay_012641_07
TS23: trigeminal ganglion Weak Regionally restricted euxassay_012641_07
TS23: liver lobe Weak Regionally restricted euxassay_012641_07
Specimen euxassay_012641_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Weak Uniform euxassay_012641_08
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_012641_08
TS23: renal cortex Weak Regionally restricted euxassay_012641_08
TS23: submandibular gland primordium Weak Regionally restricted euxassay_012641_08
TS23: trigeminal ganglion Weak Regionally restricted euxassay_012641_08
TS23: liver lobe Weak Regionally restricted euxassay_012641_08
Specimen euxassay_012641_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Weak Uniform euxassay_012641_09
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_012641_09
TS23: renal cortex Weak Regionally restricted euxassay_012641_09
TS23: submandibular gland primordium Weak Regionally restricted euxassay_012641_09
TS23: liver lobe Weak Regionally restricted euxassay_012641_09
Specimen euxassay_012641_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Moderate Uniform euxassay_012641_10
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_012641_10
TS23: submandibular gland primordium Weak Regionally restricted euxassay_012641_10
TS23: liver lobe Weak Regionally restricted euxassay_012641_10
Specimen euxassay_012641_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Moderate Uniform euxassay_012641_11
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_012641_11
TS23: diencephalon lateral wall ventricular layer Weak Regionally restricted euxassay_012641_11
TS23: lower jaw incisor Weak Regionally restricted euxassay_012641_11
TS23: upper jaw incisor Weak Regionally restricted euxassay_012641_11
TS23: thymus primordium Weak Regionally restricted euxassay_012641_11
TS23: liver lobe Weak Regionally restricted euxassay_012641_11
Specimen euxassay_012641_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_012641_12
TS23: diencephalon lateral wall ventricular layer Weak Regionally restricted euxassay_012641_12
TS23: lower jaw incisor Weak Regionally restricted euxassay_012641_12
TS23: thymus primordium Weak Regionally restricted euxassay_012641_12
TS23: liver lobe Weak Regionally restricted euxassay_012641_12
Specimen euxassay_012641_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Moderate Uniform euxassay_012641_13
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_012641_13
TS23: thymus primordium Weak Regionally restricted euxassay_012641_13
TS23: liver lobe Weak Regionally restricted euxassay_012641_13
Specimen euxassay_012641_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Moderate Uniform euxassay_012641_14
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_012641_14
TS23: renal cortex Weak Regionally restricted euxassay_012641_14
TS23: lower jaw incisor Weak Regionally restricted euxassay_012641_14
TS23: upper jaw incisor Weak Regionally restricted euxassay_012641_14
TS23: thymus primordium Weak Regionally restricted euxassay_012641_14
TS23: liver lobe Weak Regionally restricted euxassay_012641_14
Specimen euxassay_012641_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Weak Uniform euxassay_012641_15
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_012641_15
TS23: renal cortex Weak Regionally restricted euxassay_012641_15
TS23: upper jaw incisor Weak Regionally restricted euxassay_012641_15
TS23: lower jaw incisor Weak Regionally restricted euxassay_012641_15
TS23: thymus primordium Weak Regionally restricted euxassay_012641_15
TS23: liver lobe Weak Regionally restricted euxassay_012641_15
Specimen euxassay_012641_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Moderate Uniform euxassay_012641_16
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_012641_16
TS23: renal cortex Weak Regionally restricted euxassay_012641_16
TS23: submandibular gland primordium Weak Regionally restricted euxassay_012641_16
TS23: liver lobe Weak Regionally restricted euxassay_012641_16
Specimen euxassay_012641_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Moderate Uniform euxassay_012641_17
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_012641_17
TS23: renal cortex Weak Regionally restricted euxassay_012641_17
TS23: upper jaw molar Weak Regionally restricted euxassay_012641_17
TS23: lower jaw molar Weak Regionally restricted euxassay_012641_17
TS23: submandibular gland primordium Weak Regionally restricted euxassay_012641_17
TS23: trigeminal ganglion Weak Regionally restricted euxassay_012641_17
TS23: liver lobe Weak Regionally restricted euxassay_012641_17
Specimen euxassay_012641_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Moderate Uniform euxassay_012641_18
TS23: lower jaw molar Moderate Regionally restricted euxassay_012641_18
TS23: submandibular gland primordium Weak Regionally restricted euxassay_012641_18
TS23: trigeminal ganglion Weak Regionally restricted euxassay_012641_18
TS23: liver lobe Weak Regionally restricted euxassay_012641_18
Specimen euxassay_012641_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Weak Uniform euxassay_012641_19
TS23: upper jaw molar Moderate Regionally restricted euxassay_012641_19
TS23: lower jaw molar Moderate Regionally restricted euxassay_012641_19
TS23: submandibular gland primordium Weak Regionally restricted euxassay_012641_19
TS23: trigeminal ganglion Weak Regionally restricted euxassay_012641_19
TS23: liver lobe Weak Regionally restricted euxassay_012641_19
Specimen euxassay_012641_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Weak Uniform euxassay_012641_20
TS23: trigeminal ganglion Weak Regionally restricted euxassay_012641_20
TS23: liver lobe Weak Regionally restricted euxassay_012641_20
Specimen euxassay_012641_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_012641_21
TS23: liver lobe Weak Regionally restricted euxassay_012641_21
Specimen euxassay_012641_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Weak Uniform euxassay_012641_22
TS23: trigeminal ganglion Weak Regionally restricted euxassay_012641_22
TS23: liver lobe Weak Regionally restricted euxassay_012641_22
