Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4829001
Gene symbol: Ttn
Gene name: titin
Probe: T38075
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_012439_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Strong Regionally restricted euxassay_012439_01
TS23: diaphragm Strong Regionally restricted euxassay_012439_01
TS23: forearm rest of mesenchyme Strong Regionally restricted euxassay_012439_01
TS23: upper arm muscle Strong Regionally restricted euxassay_012439_01
TS23: lower leg rest of mesenchyme Strong Regionally restricted euxassay_012439_01
Specimen euxassay_012439_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Strong Regionally restricted euxassay_012439_02
TS23: diaphragm Strong Regionally restricted euxassay_012439_02
TS23: lower leg rest of mesenchyme Strong Regionally restricted euxassay_012439_02
TS23: forearm rest of mesenchyme Strong Regionally restricted euxassay_012439_02
TS23: upper arm muscle Strong Regionally restricted euxassay_012439_02
TS23: extrinsic ocular muscle Strong Regionally restricted euxassay_012439_02
Specimen euxassay_012439_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Strong Regionally restricted euxassay_012439_03
TS23: diaphragm Strong Regionally restricted euxassay_012439_03
TS23: lower leg rest of mesenchyme Strong Regionally restricted euxassay_012439_03
TS23: upper leg muscle Strong Regionally restricted euxassay_012439_03
TS23: upper arm muscle Strong Regionally restricted euxassay_012439_03
TS23: extrinsic ocular muscle Strong Regionally restricted euxassay_012439_03
Specimen euxassay_012439_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Strong Regionally restricted euxassay_012439_04
TS23: diaphragm Strong Regionally restricted euxassay_012439_04
TS23: upper leg muscle Strong Regionally restricted euxassay_012439_04
TS23: lower leg rest of mesenchyme Strong Regionally restricted euxassay_012439_04
TS23: upper arm muscle Strong Regionally restricted euxassay_012439_04
TS23: extrinsic ocular muscle Strong Regionally restricted euxassay_012439_04
Specimen euxassay_012439_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Strong Regionally restricted euxassay_012439_05
TS23: diaphragm Strong Regionally restricted euxassay_012439_05
TS23: upper leg muscle Strong Regionally restricted euxassay_012439_05
TS23: upper arm muscle Strong Regionally restricted euxassay_012439_05
TS23: extrinsic ocular muscle Strong Regionally restricted euxassay_012439_05
Specimen euxassay_012439_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Strong Regionally restricted euxassay_012439_06
TS23: diaphragm Strong Regionally restricted euxassay_012439_06
TS23: heart atrium Moderate Regionally restricted euxassay_012439_06
TS23: upper leg muscle Strong Regionally restricted euxassay_012439_06
TS23: tarsus Strong Regionally restricted euxassay_012439_06
TS23: extrinsic ocular muscle Strong Regionally restricted euxassay_012439_06
Specimen euxassay_012439_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Strong Regionally restricted euxassay_012439_07
TS23: diaphragm Strong Regionally restricted euxassay_012439_07
TS23: heart atrium Moderate Regionally restricted euxassay_012439_07
TS23: upper leg muscle Strong Regionally restricted euxassay_012439_07
TS23: tarsus Strong Regionally restricted euxassay_012439_07
TS23: extrinsic ocular muscle Strong Regionally restricted euxassay_012439_07
Specimen euxassay_012439_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Strong Regionally restricted euxassay_012439_08
TS23: diaphragm Strong Regionally restricted euxassay_012439_08
TS23: heart ventricle Strong Regionally restricted euxassay_012439_08
TS23: heart atrium Strong Regionally restricted euxassay_012439_08
TS23: upper leg muscle Strong Regionally restricted euxassay_012439_08
TS23: tarsus Strong Regionally restricted euxassay_012439_08
Specimen euxassay_012439_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Strong Regionally restricted euxassay_012439_09
TS23: diaphragm Strong Regionally restricted euxassay_012439_09
TS23: heart atrium Strong Regionally restricted euxassay_012439_09
TS23: heart ventricle Strong Regionally restricted euxassay_012439_09
Specimen euxassay_012439_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Strong Regionally restricted euxassay_012439_10
TS23: diaphragm Strong Regionally restricted euxassay_012439_10
TS23: tongue muscle Strong Regionally restricted euxassay_012439_10
TS23: heart ventricle Strong Regionally restricted euxassay_012439_10
TS23: heart atrium Strong Regionally restricted euxassay_012439_10
Specimen euxassay_012439_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Strong Regionally restricted euxassay_012439_11
TS23: tongue muscle Strong Regionally restricted euxassay_012439_11
TS23: heart atrium Strong Regionally restricted euxassay_012439_11
TS23: heart ventricle Strong Regionally restricted euxassay_012439_11
Specimen euxassay_012439_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Strong Regionally restricted euxassay_012439_12
TS23: tail mesenchyme Strong Regionally restricted euxassay_012439_12
TS23: tongue muscle Strong Regionally restricted euxassay_012439_12
TS23: heart atrium Strong Regionally restricted euxassay_012439_12
TS23: heart ventricle Strong Regionally restricted euxassay_012439_12
Specimen euxassay_012439_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Strong Regionally restricted euxassay_012439_13
TS23: tail mesenchyme Strong Regionally restricted euxassay_012439_13
TS23: tongue muscle Strong Regionally restricted euxassay_012439_13
TS23: heart ventricle Strong Regionally restricted euxassay_012439_13
TS23: heart atrium Strong Regionally restricted euxassay_012439_13
Specimen euxassay_012439_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Strong Regionally restricted euxassay_012439_14
TS23: tail mesenchyme Strong Regionally restricted euxassay_012439_14
TS23: tongue muscle Strong Regionally restricted euxassay_012439_14
TS23: heart ventricle Strong Regionally restricted euxassay_012439_14
TS23: heart atrium Strong Regionally restricted euxassay_012439_14
Specimen euxassay_012439_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: tail mesenchyme Strong Regionally restricted euxassay_012439_15
TS23: vertebral axis musculature Strong Regionally restricted euxassay_012439_15
TS23: tongue muscle Strong Regionally restricted euxassay_012439_15
TS23: heart ventricle Strong Regionally restricted euxassay_012439_15
TS23: heart atrium Strong Regionally restricted euxassay_012439_15
Specimen euxassay_012439_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Strong Regionally restricted euxassay_012439_16
TS23: tail mesenchyme Strong Regionally restricted euxassay_012439_16
TS23: tongue muscle Strong Regionally restricted euxassay_012439_16
TS23: heart ventricle Strong Regionally restricted euxassay_012439_16
TS23: heart atrium Strong Regionally restricted euxassay_012439_16
Specimen euxassay_012439_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Strong Regionally restricted euxassay_012439_17
TS23: tail mesenchyme Strong Regionally restricted euxassay_012439_17
TS23: tongue muscle Strong Regionally restricted euxassay_012439_17
TS23: heart atrium Strong Regionally restricted euxassay_012439_17
TS23: heart ventricle Strong Regionally restricted euxassay_012439_17
Specimen euxassay_012439_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: tail mesenchyme Strong Regionally restricted euxassay_012439_18
TS23: vertebral axis musculature Strong Regionally restricted euxassay_012439_18
TS23: diaphragm Strong Regionally restricted euxassay_012439_18
TS23: heart atrium Strong Regionally restricted euxassay_012439_18
TS23: heart ventricle Strong Regionally restricted euxassay_012439_18
TS23: extrinsic ocular muscle Strong Regionally restricted euxassay_012439_18
Specimen euxassay_012439_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Strong Regionally restricted euxassay_012439_19
TS23: diaphragm Strong Regionally restricted euxassay_012439_19
TS23: heart atrium Moderate Regionally restricted euxassay_012439_19
TS23: extrinsic ocular muscle Strong Regionally restricted euxassay_012439_19
Specimen euxassay_012439_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Strong Regionally restricted euxassay_012439_20
TS23: diaphragm Strong Regionally restricted euxassay_012439_20
TS23: heart atrium Moderate Regionally restricted euxassay_012439_20
TS23: extrinsic ocular muscle Strong Regionally restricted euxassay_012439_20
Specimen euxassay_012439_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Strong Regionally restricted euxassay_012439_21
TS23: diaphragm Strong Regionally restricted euxassay_012439_21
TS23: heart atrium Moderate Regionally restricted euxassay_012439_21
TS23: tarsus Strong Regionally restricted euxassay_012439_21
TS23: upper arm muscle Strong Regionally restricted euxassay_012439_21
TS23: extrinsic ocular muscle Strong Regionally restricted euxassay_012439_21
Specimen euxassay_012439_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Strong Regionally restricted euxassay_012439_22
TS23: diaphragm Strong Regionally restricted euxassay_012439_22
TS23: heart atrium Moderate Regionally restricted euxassay_012439_22
TS23: tarsus Strong Regionally restricted euxassay_012439_22
TS23: upper arm muscle Strong Regionally restricted euxassay_012439_22
TS23: extrinsic ocular muscle Strong Regionally restricted euxassay_012439_22
Specimen euxassay_012439_23: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Strong Regionally restricted euxassay_012439_23
TS23: diaphragm Strong Regionally restricted euxassay_012439_23
TS23: heart atrium Moderate Regionally restricted euxassay_012439_23
TS23: upper leg muscle Strong Regionally restricted euxassay_012439_23
TS23: tarsus Strong Regionally restricted euxassay_012439_23
TS23: upper arm muscle Strong Regionally restricted euxassay_012439_23
TS23: extrinsic ocular muscle Strong Regionally restricted euxassay_012439_23
Specimen euxassay_012439_24: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Strong Regionally restricted euxassay_012439_24
TS23: diaphragm Strong Regionally restricted euxassay_012439_24
TS23: upper leg muscle Strong Regionally restricted euxassay_012439_24
TS23: upper arm muscle Strong Regionally restricted euxassay_012439_24
TS23: extrinsic ocular muscle Strong Regionally restricted euxassay_012439_24
Contributing Projects:
Mouse Genome Database (MGD), Gene Expression Database (GXD), Mouse Models of Human Cancer database (MMHCdb) (formerly Mouse Tumor Biology (MTB)), Gene Ontology (GO)
Citing These Resources
Funding Information
Warranty Disclaimer, Privacy Notice, Licensing, & Copyright
Send questions and comments to User Support. 		last database update
03/25/2025
MGI 6.24 		The Jackson Laboratory
