Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4828682
Gene symbol: Tgif1
Gene name: TGFB-induced factor homeobox 1
Probe: IMAGE clone 1546796
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_007804_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_007804_02
TS23: vibrissa Weak Regionally restricted euxassay_007804_02
Specimen euxassay_007804_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_007804_03
TS23: vibrissa Moderate Regionally restricted euxassay_007804_03
TS23: testis Weak Regionally restricted euxassay_007804_03
Specimen euxassay_007804_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_007804_04
TS23: vibrissa Moderate Regionally restricted euxassay_007804_04
TS23: telencephalon ventricular layer Moderate Regionally restricted euxassay_007804_04
TS23: testis Weak Regionally restricted euxassay_007804_04
Specimen euxassay_007804_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_007804_05
TS23: telencephalon ventricular layer Moderate Regionally restricted euxassay_007804_05
TS23: testis Weak Regionally restricted euxassay_007804_05
TS23: renal cortex Weak Regionally restricted euxassay_007804_05
Specimen euxassay_007804_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_007804_06
TS23: telencephalon ventricular layer Weak Regionally restricted euxassay_007804_06
TS23: midgut Weak Regionally restricted euxassay_007804_06
TS23: renal cortex Weak Regionally restricted euxassay_007804_06
Specimen euxassay_007804_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_007804_07
TS23: telencephalon ventricular layer Moderate Regionally restricted euxassay_007804_07
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_007804_07
TS23: midgut Weak Regionally restricted euxassay_007804_07
TS23: renal cortex Weak Regionally restricted euxassay_007804_07
Specimen euxassay_007804_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_007804_08
TS23: telencephalon ventricular layer Moderate Regionally restricted euxassay_007804_08
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_007804_08
TS23: esophagus Moderate Regionally restricted euxassay_007804_08
TS23: midgut Weak Regionally restricted euxassay_007804_08
Specimen euxassay_007804_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_007804_09
TS23: telencephalon ventricular layer Moderate Regionally restricted euxassay_007804_09
TS23: midbrain ventricular layer Moderate Regionally restricted euxassay_007804_09
TS23: bladder fundus Weak Regionally restricted euxassay_007804_09
TS23: urethra Weak Regionally restricted euxassay_007804_09 Originally this result was annotated to a male-specific term, but as the specimen was not sexed, it is likely the data annotator intended to use a non-sex specific term.
TS23: midgut Weak Regionally restricted euxassay_007804_09
Specimen euxassay_007804_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_007804_10
TS23: telencephalon ventricular layer Moderate Regionally restricted euxassay_007804_10
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_007804_10
TS23: diencephalon lateral wall ventricular layer Weak Regionally restricted euxassay_007804_10
TS23: bladder fundus Weak Regionally restricted euxassay_007804_10
TS23: urethra Weak Regionally restricted euxassay_007804_10 Originally this result was annotated to a male-specific term, but as the specimen was not sexed, it is likely the data annotator intended to use a non-sex specific term.
TS23: midgut Weak Regionally restricted euxassay_007804_10
TS23: rectum Weak Regionally restricted euxassay_007804_10
TS23: hindgut Weak Regionally restricted euxassay_007804_10
Specimen euxassay_007804_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_007804_11
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_007804_11
TS23: diencephalon lateral wall ventricular layer Weak Regionally restricted euxassay_007804_11
TS23: midgut Weak Regionally restricted euxassay_007804_11
Specimen euxassay_007804_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_007804_12
TS23: telencephalon ventricular layer Moderate Regionally restricted euxassay_007804_12
TS23: midbrain ventricular layer Moderate Regionally restricted euxassay_007804_12
TS23: diencephalon lateral wall ventricular layer Weak Regionally restricted euxassay_007804_12
TS23: renal cortex Weak Regionally restricted euxassay_007804_12
Specimen euxassay_007804_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_007804_13
TS23: telencephalon ventricular layer Moderate Regionally restricted euxassay_007804_13
TS23: midbrain ventricular layer Moderate Regionally restricted euxassay_007804_13
TS23: renal cortex Weak Regionally restricted euxassay_007804_13
Specimen euxassay_007804_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_007804_14
TS23: telencephalon ventricular layer Moderate Regionally restricted euxassay_007804_14
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_007804_14
TS23: testis Weak Regionally restricted euxassay_007804_14
TS23: renal cortex Weak Regionally restricted euxassay_007804_14
Specimen euxassay_007804_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_007804_15
TS23: telencephalon ventricular layer Moderate Regionally restricted euxassay_007804_15
TS23: midbrain ventricular layer Moderate Regionally restricted euxassay_007804_15
TS23: testis Weak Regionally restricted euxassay_007804_15
TS23: renal cortex Weak Regionally restricted euxassay_007804_15
Specimen euxassay_007804_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_007804_16
TS23: vibrissa Moderate Regionally restricted euxassay_007804_16
TS23: telencephalon ventricular layer Moderate Regionally restricted euxassay_007804_16
Specimen euxassay_007804_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_007804_17
TS23: vibrissa Moderate Regionally restricted euxassay_007804_17
TS23: telencephalon ventricular layer Moderate Regionally restricted euxassay_007804_17
Specimen euxassay_007804_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vibrissa Moderate Regionally restricted euxassay_007804_18
TS23: telencephalon ventricular layer Moderate Regionally restricted euxassay_007804_18
