Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4827891
Gene symbol: Scd3
Gene name: stearoyl-coenzyme A desaturase 3
Probe: T36992
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_012236_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Strong Regionally restricted euxassay_012236_01
TS23: orbito-sphenoid Strong Regionally restricted euxassay_012236_01
TS23: vault of skull Strong Regionally restricted euxassay_012236_01
TS23: temporal bone petrous part Strong Regionally restricted euxassay_012236_01
TS23: liver lobe Moderate Regionally restricted euxassay_012236_01
TS23: pharyngo-tympanic tube Moderate Regionally restricted euxassay_012236_01
TS23: lens Strong Regionally restricted euxassay_012236_01
Specimen euxassay_012236_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Strong Regionally restricted euxassay_012236_02
TS23: orbito-sphenoid Strong Regionally restricted euxassay_012236_02
TS23: vault of skull Strong Regionally restricted euxassay_012236_02
TS23: temporal bone petrous part Strong Regionally restricted euxassay_012236_02
TS23: rib Moderate Regionally restricted euxassay_012236_02
TS23: lung Moderate Regionally restricted euxassay_012236_02
TS23: telencephalon ventricular layer Moderate Regionally restricted euxassay_012236_02
TS23: mandible Moderate Regionally restricted euxassay_012236_02
TS23: liver lobe Moderate Regionally restricted euxassay_012236_02
TS23: pharyngo-tympanic tube Moderate Regionally restricted euxassay_012236_02
Specimen euxassay_012236_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Strong Regionally restricted euxassay_012236_03
TS23: orbito-sphenoid Strong Regionally restricted euxassay_012236_03
TS23: temporal bone petrous part Strong Regionally restricted euxassay_012236_03
TS23: trigeminal ganglion Strong Regionally restricted euxassay_012236_03
TS23: rib Strong Regionally restricted euxassay_012236_03
TS23: vibrissa Moderate Regionally restricted euxassay_012236_03
TS23: lung Moderate Regionally restricted euxassay_012236_03
TS23: telencephalon ventricular layer Strong Uniform euxassay_012236_03
TS23: rest of cerebellum ventricular layer Strong Uniform euxassay_012236_03
TS23: mandible Strong Regionally restricted euxassay_012236_03
TS23: liver lobe Moderate Regionally restricted euxassay_012236_03
TS23: pharyngo-tympanic tube Weak Regionally restricted euxassay_012236_03
Specimen euxassay_012236_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: orbito-sphenoid Strong Regionally restricted euxassay_012236_04
TS23: trigeminal ganglion Strong Regionally restricted euxassay_012236_04
TS23: rib Strong Regionally restricted euxassay_012236_04
TS23: vibrissa Strong Regionally restricted euxassay_012236_04
TS23: lung Strong Regionally restricted euxassay_012236_04
TS23: telencephalon ventricular layer Strong Uniform euxassay_012236_04
TS23: rest of cerebellum ventricular layer Strong Uniform euxassay_012236_04
TS23: stomach Weak Regionally restricted euxassay_012236_04
TS23: mandible Moderate Regionally restricted euxassay_012236_04
TS23: liver lobe Moderate Regionally restricted euxassay_012236_04
TS23: pharyngo-tympanic tube Weak Regionally restricted euxassay_012236_04
Specimen euxassay_012236_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_012236_05
TS23: temporal bone petrous part Moderate Regionally restricted euxassay_012236_05
TS23: trigeminal ganglion Strong Regionally restricted euxassay_012236_05
TS23: facial ganglion Strong Regionally restricted euxassay_012236_05
TS23: rib Strong Regionally restricted euxassay_012236_05
TS23: vibrissa Strong Regionally restricted euxassay_012236_05
TS23: lung Strong Regionally restricted euxassay_012236_05
TS23: telencephalon ventricular layer Strong Uniform euxassay_012236_05
TS23: rest of cerebellum ventricular layer Strong Uniform euxassay_012236_05
TS23: stomach Weak Regionally restricted euxassay_012236_05
TS23: mandible Moderate Regionally restricted euxassay_012236_05
TS23: maxilla Moderate Regionally restricted euxassay_012236_05
TS23: liver lobe Moderate Regionally restricted euxassay_012236_05
TS23: metanephros Weak Regionally restricted euxassay_012236_05
Specimen euxassay_012236_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_012236_06
TS23: trigeminal ganglion Strong Regionally restricted euxassay_012236_06
TS23: facial ganglion Strong Regionally restricted euxassay_012236_06
TS23: vestibulo-cochlear ganglion Strong Regionally restricted euxassay_012236_06
TS23: glossopharyngeal ganglion Strong Regionally restricted euxassay_012236_06
TS23: rib Strong Regionally restricted euxassay_012236_06
TS23: vibrissa Strong Regionally restricted euxassay_012236_06
TS23: lung Strong Regionally restricted euxassay_012236_06
TS23: telencephalon ventricular layer Strong Uniform euxassay_012236_06
TS23: rest of cerebellum ventricular layer Strong Uniform euxassay_012236_06
TS23: pons ventricular layer Strong Uniform euxassay_012236_06
TS23: stomach Weak Regionally restricted euxassay_012236_06
TS23: otic capsule Moderate Regionally restricted euxassay_012236_06
TS23: maxilla Moderate Regionally restricted euxassay_012236_06
TS23: mandible Moderate Regionally restricted euxassay_012236_06
TS23: upper jaw molar Moderate Regionally restricted euxassay_012236_06
TS23: lower jaw molar Moderate Regionally restricted euxassay_012236_06
TS23: liver lobe Moderate Regionally restricted euxassay_012236_06
TS23: adrenal gland Weak Regionally restricted euxassay_012236_06
TS23: metanephros Weak Regionally restricted euxassay_012236_06
Specimen euxassay_012236_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: turbinate bone primordium Moderate Regionally restricted euxassay_012236_07
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_012236_07
TS23: trigeminal ganglion Strong Regionally restricted euxassay_012236_07
TS23: glossopharyngeal ganglion Strong Regionally restricted euxassay_012236_07
TS23: dorsal root ganglion Strong Regionally restricted euxassay_012236_07
TS23: rib Strong Regionally restricted euxassay_012236_07
TS23: lung Strong Regionally restricted euxassay_012236_07
TS23: telencephalon ventricular layer Strong Uniform euxassay_012236_07
TS23: pons ventricular layer Strong Uniform euxassay_012236_07
TS23: rest of cerebellum ventricular layer Strong Uniform euxassay_012236_07
TS23: midbrain ventricular layer Moderate Regionally restricted euxassay_012236_07
TS23: stomach Weak Regionally restricted euxassay_012236_07
TS23: midgut Moderate Regionally restricted euxassay_012236_07
TS23: otic capsule Moderate Regionally restricted euxassay_012236_07
TS23: upper jaw molar Moderate Regionally restricted euxassay_012236_07
TS23: lower jaw molar Moderate Regionally restricted euxassay_012236_07
TS23: mandible Moderate Regionally restricted euxassay_012236_07
TS23: maxilla Moderate Regionally restricted euxassay_012236_07
TS23: liver lobe Moderate Regionally restricted euxassay_012236_07
TS23: pancreas Moderate Regionally restricted euxassay_012236_07
TS23: adrenal gland Moderate Regionally restricted euxassay_012236_07
TS23: metanephros Weak Regionally restricted euxassay_012236_07
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_012236_07
Specimen euxassay_012236_08: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: turbinate bone primordium Moderate Regionally restricted euxassay_012236_08
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_012236_08
TS23: vagus ganglion Strong Regionally restricted euxassay_012236_08
TS23: trigeminal ganglion Strong Regionally restricted euxassay_012236_08
TS23: dorsal root ganglion Strong Regionally restricted euxassay_012236_08
TS23: lung Strong Regionally restricted euxassay_012236_08
TS23: telencephalon ventricular layer Strong Uniform euxassay_012236_08
TS23: pons ventricular layer Strong Uniform euxassay_012236_08
TS23: rest of cerebellum ventricular layer Moderate Uniform euxassay_012236_08
TS23: midbrain ventricular layer Strong Regionally restricted euxassay_012236_08
TS23: medulla oblongata basal plate ventricular layer Moderate Regionally restricted euxassay_012236_08
TS23: midgut Moderate Regionally restricted euxassay_012236_08
TS23: clavicle Strong Regionally restricted euxassay_012236_08
TS23: otic capsule Moderate Regionally restricted euxassay_012236_08
TS23: maxilla Moderate Regionally restricted euxassay_012236_08
TS23: mandible Moderate Regionally restricted euxassay_012236_08
TS23: liver lobe Strong Regionally restricted euxassay_012236_08
TS23: pancreas Moderate Regionally restricted euxassay_012236_08
TS23: adrenal gland Moderate Regionally restricted euxassay_012236_08
TS23: metanephros Weak Regionally restricted euxassay_012236_08
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_012236_08
TS23: medulla oblongata basal plate mantle layer Strong Regionally restricted euxassay_012236_08 facial motor nucleus
Specimen euxassay_012236_09: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: turbinate bone primordium Moderate Regionally restricted euxassay_012236_09
TS23: trigeminal nerve Strong Regionally restricted euxassay_012236_09
TS23: dorsal root ganglion Strong Regionally restricted euxassay_012236_09
TS23: lung Moderate Regionally restricted euxassay_012236_09
TS23: telencephalon ventricular layer Strong Uniform euxassay_012236_09
TS23: rest of cerebellum ventricular layer Moderate Uniform euxassay_012236_09
TS23: pons ventricular layer Strong Uniform euxassay_012236_09
TS23: midbrain ventricular layer Strong Regionally restricted euxassay_012236_09
TS23: medulla oblongata basal plate ventricular layer Strong Regionally restricted euxassay_012236_09
TS23: midgut Moderate Regionally restricted euxassay_012236_09
TS23: clavicle Strong Regionally restricted euxassay_012236_09
TS23: cervico-thoracic ganglion Strong Regionally restricted euxassay_012236_09
TS23: otic capsule Moderate Regionally restricted euxassay_012236_09
TS23: mandible Moderate Regionally restricted euxassay_012236_09
TS23: liver lobe Moderate Regionally restricted euxassay_012236_09
TS23: pancreas Weak Regionally restricted euxassay_012236_09
TS23: adrenal gland Weak Regionally restricted euxassay_012236_09
TS23: metanephros Weak Regionally restricted euxassay_012236_09
TS23: medulla oblongata basal plate mantle layer Moderate Regionally restricted euxassay_012236_09 facial motor nucleus
Specimen euxassay_012236_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: turbinate bone primordium Moderate Regionally restricted euxassay_012236_10
TS23: trigeminal nerve Moderate Regionally restricted euxassay_012236_10
TS23: dorsal root ganglion Strong Regionally restricted euxassay_012236_10
TS23: lung Moderate Regionally restricted euxassay_012236_10
TS23: telencephalon ventricular layer Moderate Uniform euxassay_012236_10
TS23: olfactory cortex ventricular layer Moderate Uniform euxassay_012236_10
TS23: olfactory cortex marginal layer Moderate Uniform euxassay_012236_10
TS23: pons ventricular layer Strong Uniform euxassay_012236_10
TS23: rest of cerebellum ventricular layer Weak Uniform euxassay_012236_10
TS23: midbrain ventricular layer Strong Regionally restricted euxassay_012236_10
TS23: medulla oblongata basal plate ventricular layer Strong Regionally restricted euxassay_012236_10
TS23: spinal cord ventricular layer Strong Regionally restricted euxassay_012236_10
TS23: ventral grey horn Moderate Regionally restricted euxassay_012236_10
TS23: midgut Moderate Regionally restricted euxassay_012236_10
TS23: thymus primordium Strong Regionally restricted euxassay_012236_10
TS23: pituitary gland Weak Regionally restricted euxassay_012236_10
TS23: lower jaw incisor Strong Regionally restricted euxassay_012236_10
TS23: mandible Moderate Regionally restricted euxassay_012236_10
TS23: liver lobe Moderate Regionally restricted euxassay_012236_10
Specimen euxassay_012236_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: axial skeleton Moderate Regionally restricted euxassay_012236_11
TS23: lung Moderate Regionally restricted euxassay_012236_11
TS23: olfactory cortex marginal layer Moderate Uniform euxassay_012236_11
TS23: olfactory cortex ventricular layer Moderate Uniform euxassay_012236_11
TS23: telencephalon ventricular layer Moderate Uniform euxassay_012236_11
TS23: rest of cerebellum ventricular layer Weak Uniform euxassay_012236_11
TS23: pons ventricular layer Strong Uniform euxassay_012236_11
TS23: midbrain ventricular layer Strong Regionally restricted euxassay_012236_11
TS23: diencephalon lateral wall ventricular layer Strong Regionally restricted euxassay_012236_11
TS23: hypothalamus ventricular layer Strong Regionally restricted euxassay_012236_11
TS23: medulla oblongata basal plate ventricular layer Strong Regionally restricted euxassay_012236_11
TS23: spinal cord ventricular layer Strong Regionally restricted euxassay_012236_11
TS23: ventral grey horn Moderate Regionally restricted euxassay_012236_11
TS23: hindgut Moderate Regionally restricted euxassay_012236_11
TS23: midgut Moderate Regionally restricted euxassay_012236_11
TS23: urethra Weak Regionally restricted euxassay_012236_11 Originally this result was annotated to a male-specific term, but as the specimen was not sexed, it is likely the data annotator intended to use a non-sex specific term.
TS23: thymus primordium Strong Regionally restricted euxassay_012236_11
TS23: thoracic ganglion Strong Regionally restricted euxassay_012236_11
TS23: pituitary gland Weak Regionally restricted euxassay_012236_11
TS23: lower jaw incisor Strong Regionally restricted euxassay_012236_11
TS23: upper jaw incisor Strong Regionally restricted euxassay_012236_11
TS23: liver lobe Strong Regionally restricted euxassay_012236_11
Specimen euxassay_012236_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: axial skeleton tail region Moderate Regionally restricted euxassay_012236_12
TS23: nucleus pulposus Strong Regionally restricted euxassay_012236_12
TS23: lung Moderate Regionally restricted euxassay_012236_12
TS23: olfactory cortex marginal layer Moderate Uniform euxassay_012236_12
TS23: telencephalon ventricular layer Moderate Uniform euxassay_012236_12
TS23: pons ventricular layer Strong Uniform euxassay_012236_12
TS23: midbrain ventricular layer Strong Regionally restricted euxassay_012236_12
TS23: diencephalon lateral wall ventricular layer Strong Regionally restricted euxassay_012236_12
TS23: hypothalamus ventricular layer Strong Regionally restricted euxassay_012236_12
TS23: spinal cord ventricular layer Strong Regionally restricted euxassay_012236_12
TS23: medulla oblongata basal plate ventricular layer Strong Regionally restricted euxassay_012236_12
TS23: basal columns Moderate Regionally restricted euxassay_012236_12
TS23: midgut Moderate Regionally restricted euxassay_012236_12
TS23: hindgut Moderate Regionally restricted euxassay_012236_12
TS23: rectum Strong Regionally restricted euxassay_012236_12
TS23: urethra Weak Regionally restricted euxassay_012236_12 Originally this result was annotated to a male-specific term, but as the specimen was not sexed, it is likely the data annotator intended to use a non-sex specific term.
TS23: nephric duct of male Weak Regionally restricted euxassay_012236_12
TS23: thymus primordium Strong Regionally restricted euxassay_012236_12
TS23: trachea Weak Regionally restricted euxassay_012236_12
TS23: larynx Weak Regionally restricted euxassay_012236_12
TS23: pituitary gland Weak Regionally restricted euxassay_012236_12
TS23: upper jaw incisor Strong Regionally restricted euxassay_012236_12
TS23: lower jaw incisor Strong Regionally restricted euxassay_012236_12
TS23: liver lobe Strong Regionally restricted euxassay_012236_12
TS23: tongue muscle Weak Regionally restricted euxassay_012236_12
Specimen euxassay_012236_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: axial skeleton Moderate Regionally restricted euxassay_012236_13
TS23: axial skeleton tail region Moderate Regionally restricted euxassay_012236_13
TS23: lung Strong Regionally restricted euxassay_012236_13
TS23: pons ventricular layer Strong Uniform euxassay_012236_13
TS23: rest of cerebellum ventricular layer Moderate Uniform euxassay_012236_13
TS23: midbrain ventricular layer Strong Regionally restricted euxassay_012236_13
TS23: diencephalon lateral wall ventricular layer Strong Regionally restricted euxassay_012236_13
TS23: hypothalamus ventricular layer Strong Regionally restricted euxassay_012236_13
TS23: medulla oblongata basal plate ventricular layer Strong Regionally restricted euxassay_012236_13
TS23: ventral grey horn Moderate Regionally restricted euxassay_012236_13
TS23: midgut Strong Regionally restricted euxassay_012236_13
TS23: hindgut Strong Regionally restricted euxassay_012236_13
TS23: urethra Moderate Regionally restricted euxassay_012236_13 Originally this result was annotated to a male-specific term, but as the specimen was not sexed, it is likely the data annotator intended to use a non-sex specific term.
TS23: thymus primordium Strong Regionally restricted euxassay_012236_13
TS23: trachea Weak Regionally restricted euxassay_012236_13
TS23: larynx Moderate Regionally restricted euxassay_012236_13
TS23: pituitary gland Moderate Regionally restricted euxassay_012236_13
TS23: lower jaw incisor Strong Regionally restricted euxassay_012236_13
TS23: liver lobe Strong Regionally restricted euxassay_012236_13
TS23: tongue muscle Weak Regionally restricted euxassay_012236_13
Specimen euxassay_012236_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Strong Regionally restricted euxassay_012236_14
TS23: axial skeleton tail region Moderate Regionally restricted euxassay_012236_14
TS23: tail mesenchyme Moderate Regionally restricted euxassay_012236_14
TS23: lung Strong Regionally restricted euxassay_012236_14
TS23: olfactory cortex marginal layer Moderate Uniform euxassay_012236_14
TS23: telencephalon ventricular layer Moderate Uniform euxassay_012236_14
TS23: rest of cerebellum ventricular layer Weak Uniform euxassay_012236_14
TS23: pons ventricular layer Strong Uniform euxassay_012236_14
TS23: midbrain ventricular layer Strong Regionally restricted euxassay_012236_14
TS23: diencephalon lateral wall ventricular layer Strong Regionally restricted euxassay_012236_14
TS23: hypothalamus ventricular layer Strong Regionally restricted euxassay_012236_14
TS23: medulla oblongata basal plate ventricular layer Strong Regionally restricted euxassay_012236_14
TS23: ventral grey horn Moderate Regionally restricted euxassay_012236_14
TS23: midgut Strong Regionally restricted euxassay_012236_14
TS23: thymus primordium Strong Regionally restricted euxassay_012236_14
TS23: pituitary gland Moderate Regionally restricted euxassay_012236_14
TS23: lower jaw incisor Strong Regionally restricted euxassay_012236_14
TS23: liver lobe Strong Regionally restricted euxassay_012236_14
TS23: tongue muscle Weak Regionally restricted euxassay_012236_14
Specimen euxassay_012236_15: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: dorsal root ganglion Strong Regionally restricted euxassay_012236_15
TS23: tail mesenchyme Moderate Regionally restricted euxassay_012236_15
TS23: lung Strong Regionally restricted euxassay_012236_15
TS23: telencephalon ventricular layer Strong Regionally restricted euxassay_012236_15
TS23: olfactory cortex ventricular layer Strong Regionally restricted euxassay_012236_15
TS23: olfactory cortex marginal layer Strong Regionally restricted euxassay_012236_15
TS23: pons ventricular layer Strong Uniform euxassay_012236_15
TS23: rest of cerebellum ventricular layer Weak Uniform euxassay_012236_15
TS23: midbrain ventricular layer Strong Regionally restricted euxassay_012236_15
TS23: medulla oblongata basal plate ventricular layer Strong Regionally restricted euxassay_012236_15
TS23: midgut Moderate Regionally restricted euxassay_012236_15
TS23: clavicle Strong Regionally restricted euxassay_012236_15
TS23: cervico-thoracic ganglion Strong Regionally restricted euxassay_012236_15
TS23: otic capsule Moderate Regionally restricted euxassay_012236_15
TS23: pituitary gland Moderate Regionally restricted euxassay_012236_15
TS23: lower jaw incisor Strong Regionally restricted euxassay_012236_15
TS23: upper jaw incisor Strong Regionally restricted euxassay_012236_15
TS23: mandible Moderate Regionally restricted euxassay_012236_15
TS23: liver lobe Strong Regionally restricted euxassay_012236_15
TS23: adrenal gland Moderate Regionally restricted euxassay_012236_15
TS23: metanephros Weak Regionally restricted euxassay_012236_15
TS23: medulla oblongata basal plate mantle layer Moderate Regionally restricted euxassay_012236_15 facial motor nucleus
Specimen euxassay_012236_16: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: turbinate bone primordium Moderate Regionally restricted euxassay_012236_16
TS23: trigeminal nerve Moderate Regionally restricted euxassay_012236_16
TS23: dorsal root ganglion Strong Regionally restricted euxassay_012236_16
TS23: lung Moderate Regionally restricted euxassay_012236_16
TS23: telencephalon ventricular layer Strong Regionally restricted euxassay_012236_16
TS23: olfactory cortex ventricular layer Strong Regionally restricted euxassay_012236_16
TS23: rest of cerebellum ventricular layer Weak Uniform euxassay_012236_16
TS23: pons ventricular layer Strong Uniform euxassay_012236_16
TS23: midbrain ventricular layer Moderate Regionally restricted euxassay_012236_16
TS23: clavicle Moderate Regionally restricted euxassay_012236_16
TS23: vagus ganglion Strong Regionally restricted euxassay_012236_16
TS23: otic capsule Moderate Regionally restricted euxassay_012236_16
TS23: mandible Moderate Regionally restricted euxassay_012236_16
TS23: upper jaw incisor Strong Regionally restricted euxassay_012236_16
TS23: liver lobe Strong Regionally restricted euxassay_012236_16
TS23: adrenal gland Moderate Regionally restricted euxassay_012236_16
TS23: metanephros Weak Regionally restricted euxassay_012236_16
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_012236_16
TS23: medulla oblongata basal plate mantle layer Strong Regionally restricted euxassay_012236_16 facial motor nucleus
Specimen euxassay_012236_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: turbinate bone primordium Moderate Regionally restricted euxassay_012236_17
TS23: glossopharyngeal ganglion Strong Regionally restricted euxassay_012236_17
TS23: vestibulo-cochlear ganglion Strong Regionally restricted euxassay_012236_17
TS23: dorsal root ganglion Strong Regionally restricted euxassay_012236_17
TS23: rib Strong Regionally restricted euxassay_012236_17
TS23: lung Strong Regionally restricted euxassay_012236_17
TS23: telencephalon ventricular layer Strong Regionally restricted euxassay_012236_17
TS23: pons ventricular layer Strong Uniform euxassay_012236_17
TS23: rest of cerebellum ventricular layer Strong Uniform euxassay_012236_17
TS23: otic capsule Moderate Regionally restricted euxassay_012236_17
TS23: maxilla Moderate Regionally restricted euxassay_012236_17
TS23: mandible Moderate Regionally restricted euxassay_012236_17
TS23: liver lobe Strong Regionally restricted euxassay_012236_17
TS23: adrenal gland Weak Regionally restricted euxassay_012236_17
TS23: metanephros Weak Regionally restricted euxassay_012236_17
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_012236_17
Specimen euxassay_012236_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: turbinate bone primordium Moderate Regionally restricted euxassay_012236_18
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_012236_18
TS23: trigeminal ganglion Strong Regionally restricted euxassay_012236_18
TS23: facial ganglion Strong Regionally restricted euxassay_012236_18
TS23: vestibulo-cochlear ganglion Strong Regionally restricted euxassay_012236_18
TS23: rib Strong Regionally restricted euxassay_012236_18
TS23: lung Strong Regionally restricted euxassay_012236_18
TS23: telencephalon ventricular layer Strong Regionally restricted euxassay_012236_18
TS23: rest of cerebellum ventricular layer Strong Uniform euxassay_012236_18
TS23: otic capsule Moderate Regionally restricted euxassay_012236_18
TS23: upper jaw molar Moderate Regionally restricted euxassay_012236_18
TS23: lower jaw molar Moderate Regionally restricted euxassay_012236_18
TS23: mandible Moderate Regionally restricted euxassay_012236_18
TS23: maxilla Moderate Regionally restricted euxassay_012236_18
TS23: liver lobe Moderate Regionally restricted euxassay_012236_18
TS23: metanephros Weak Regionally restricted euxassay_012236_18
TS23: submandibular gland primordium Weak Regionally restricted euxassay_012236_18
Specimen euxassay_012236_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: temporal bone petrous part Moderate Regionally restricted euxassay_012236_19
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_012236_19
TS23: trigeminal ganglion Strong Regionally restricted euxassay_012236_19
TS23: facial ganglion Strong Regionally restricted euxassay_012236_19
TS23: rib Strong Regionally restricted euxassay_012236_19
TS23: vibrissa Strong Regionally restricted euxassay_012236_19
TS23: lung Strong Regionally restricted euxassay_012236_19
TS23: telencephalon ventricular layer Strong Regionally restricted euxassay_012236_19
TS23: rest of cerebellum ventricular layer Strong Uniform euxassay_012236_19
TS23: upper jaw molar Moderate Regionally restricted euxassay_012236_19
TS23: lower jaw molar Moderate Regionally restricted euxassay_012236_19
TS23: mandible Moderate Regionally restricted euxassay_012236_19
TS23: maxilla Moderate Regionally restricted euxassay_012236_19
TS23: liver lobe Strong Regionally restricted euxassay_012236_19
TS23: metanephros Weak Regionally restricted euxassay_012236_19
Specimen euxassay_012236_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_012236_20
TS23: temporal bone petrous part Moderate Regionally restricted euxassay_012236_20
TS23: trigeminal ganglion Strong Regionally restricted euxassay_012236_20
TS23: facial ganglion Strong Regionally restricted euxassay_012236_20
TS23: rib Strong Regionally restricted euxassay_012236_20
TS23: vibrissa Strong Regionally restricted euxassay_012236_20
TS23: lung Strong Regionally restricted euxassay_012236_20
TS23: telencephalon ventricular layer Strong Regionally restricted euxassay_012236_20
TS23: rest of cerebellum ventricular layer Moderate Uniform euxassay_012236_20
TS23: maxilla Moderate Regionally restricted euxassay_012236_20
TS23: mandible Moderate Regionally restricted euxassay_012236_20
TS23: liver lobe Strong Regionally restricted euxassay_012236_20
Specimen euxassay_012236_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: orbito-sphenoid Strong Regionally restricted euxassay_012236_21
TS23: temporal bone petrous part Strong Regionally restricted euxassay_012236_21
TS23: trigeminal ganglion Strong Regionally restricted euxassay_012236_21
TS23: rib Strong Regionally restricted euxassay_012236_21
TS23: vibrissa Strong Regionally restricted euxassay_012236_21
TS23: lung Strong Regionally restricted euxassay_012236_21
TS23: telencephalon ventricular layer Strong Regionally restricted euxassay_012236_21
TS23: rest of cerebellum ventricular layer Moderate Uniform euxassay_012236_21
TS23: mandible Moderate Regionally restricted euxassay_012236_21
TS23: maxilla Moderate Regionally restricted euxassay_012236_21
TS23: liver lobe Strong Regionally restricted euxassay_012236_21
TS23: pharyngo-tympanic tube Weak Regionally restricted euxassay_012236_21
Specimen euxassay_012236_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Strong Regionally restricted euxassay_012236_22
TS23: orbito-sphenoid Strong Regionally restricted euxassay_012236_22
TS23: temporal bone petrous part Strong Regionally restricted euxassay_012236_22
TS23: rib Strong Regionally restricted euxassay_012236_22
TS23: lung Strong Regionally restricted euxassay_012236_22
TS23: telencephalon ventricular layer Strong Regionally restricted euxassay_012236_22
TS23: mandible Strong Regionally restricted euxassay_012236_22
TS23: liver lobe Strong Regionally restricted euxassay_012236_22
TS23: pharyngo-tympanic tube Weak Regionally restricted euxassay_012236_22
Specimen euxassay_012236_23: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Strong Regionally restricted euxassay_012236_23
TS23: orbito-sphenoid Strong Regionally restricted euxassay_012236_23
TS23: vault of skull Strong Regionally restricted euxassay_012236_23
TS23: temporal bone petrous part Strong Regionally restricted euxassay_012236_23
TS23: rib Moderate Regionally restricted euxassay_012236_23
TS23: liver lobe Strong Regionally restricted euxassay_012236_23
TS23: pharyngo-tympanic tube Weak Regionally restricted euxassay_012236_23
Specimen euxassay_012236_24: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Strong Regionally restricted euxassay_012236_24
TS23: vault of skull Strong Regionally restricted euxassay_012236_24
TS23: orbito-sphenoid Strong Regionally restricted euxassay_012236_24
TS23: rib Moderate Regionally restricted euxassay_012236_24
TS23: liver lobe Strong Regionally restricted euxassay_012236_24
TS23: pharyngo-tympanic tube Weak Regionally restricted euxassay_012236_24
TS23: lens Strong Regionally restricted euxassay_012236_24
Contributing Projects:
Mouse Genome Database (MGD), Gene Expression Database (GXD), Mouse Models of Human Cancer database (MMHCdb) (formerly Mouse Tumor Biology (MTB)), Gene Ontology (GO)
Citing These Resources
Funding Information
Warranty Disclaimer, Privacy Notice, Licensing, & Copyright
Send questions and comments to User Support. 		last database update
03/25/2025
MGI 6.24 		The Jackson Laboratory
