Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4827513
Gene symbol: Ptp4a1
Gene name: protein tyrosine phosphatase 4a1
Probe: T31760
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_010021_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: forebrain Weak Regionally restricted euxassay_010021_01
Specimen euxassay_010021_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_010021_02
TS23: neural retina Weak Regionally restricted euxassay_010021_02
TS23: forebrain Weak Regionally restricted euxassay_010021_02
Specimen euxassay_010021_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_010021_03
TS23: neural retina Weak Regionally restricted euxassay_010021_03
TS23: hindbrain Weak Regionally restricted euxassay_010021_03
TS23: forebrain Weak Regionally restricted euxassay_010021_03
Specimen euxassay_010021_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_010021_04
TS23: neural retina Weak Regionally restricted euxassay_010021_04
TS23: hindbrain Weak Regionally restricted euxassay_010021_04
TS23: forebrain Weak Regionally restricted euxassay_010021_04
Specimen euxassay_010021_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_010021_05
TS23: adrenal gland Weak Regionally restricted euxassay_010021_05
TS23: stomach Moderate Regionally restricted euxassay_010021_05
TS23: midbrain Weak Regionally restricted euxassay_010021_05
TS23: hindbrain Weak Regionally restricted euxassay_010021_05
TS23: forebrain Weak Regionally restricted euxassay_010021_05
Specimen euxassay_010021_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_010021_06
TS23: adrenal gland Moderate Regionally restricted euxassay_010021_06
TS23: stomach Moderate Regionally restricted euxassay_010021_06
TS23: midbrain Weak Regionally restricted euxassay_010021_06
TS23: hindbrain Weak Regionally restricted euxassay_010021_06
TS23: forebrain Weak Regionally restricted euxassay_010021_06
Specimen euxassay_010021_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_010021_07
TS23: adrenal gland Moderate Regionally restricted euxassay_010021_07
TS23: submandibular gland primordium Weak Regionally restricted euxassay_010021_07
TS23: stomach Moderate Regionally restricted euxassay_010021_07
TS23: spinal cord Weak Regionally restricted euxassay_010021_07
TS23: midbrain Weak Regionally restricted euxassay_010021_07
TS23: hindbrain Weak Regionally restricted euxassay_010021_07
TS23: forebrain Weak Regionally restricted euxassay_010021_07
Specimen euxassay_010021_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_010021_08
TS23: submandibular gland primordium Weak Regionally restricted euxassay_010021_08
TS23: stomach Moderate Regionally restricted euxassay_010021_08
TS23: cervico-thoracic ganglion Weak Regionally restricted euxassay_010021_08
TS23: cervical ganglion Weak Regionally restricted euxassay_010021_08
TS23: spinal cord Weak Regionally restricted euxassay_010021_08
TS23: midbrain Weak Regionally restricted euxassay_010021_08
TS23: hindbrain Weak Regionally restricted euxassay_010021_08
TS23: forebrain Weak Regionally restricted euxassay_010021_08
Specimen euxassay_010021_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_010021_09
TS23: submandibular gland primordium Weak Regionally restricted euxassay_010021_09
TS23: stomach Weak Regionally restricted euxassay_010021_09
TS23: olfactory epithelium Weak Regionally restricted euxassay_010021_09
TS23: spinal cord Weak Regionally restricted euxassay_010021_09
TS23: midbrain Weak Regionally restricted euxassay_010021_09
TS23: hindbrain Weak Regionally restricted euxassay_010021_09
TS23: forebrain Weak Regionally restricted euxassay_010021_09
Specimen euxassay_010021_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_010021_10
TS23: thoracic ganglion Weak Regionally restricted euxassay_010021_10
TS23: olfactory epithelium Moderate Regionally restricted euxassay_010021_10
TS23: spinal cord Weak Regionally restricted euxassay_010021_10
TS23: hindbrain Weak Regionally restricted euxassay_010021_10
TS23: midbrain Weak Regionally restricted euxassay_010021_10
TS23: forebrain Weak Regionally restricted euxassay_010021_10
Specimen euxassay_010021_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_010021_11
TS23: thoracic ganglion Weak Regionally restricted euxassay_010021_11
TS23: olfactory epithelium Moderate Regionally restricted euxassay_010021_11
TS23: upper jaw incisor Weak Regionally restricted euxassay_010021_11
TS23: lower jaw incisor Weak Regionally restricted euxassay_010021_11
TS23: bladder wall Weak Regionally restricted euxassay_010021_11
TS23: spinal cord Weak Regionally restricted euxassay_010021_11
TS23: midbrain Weak Regionally restricted euxassay_010021_11
TS23: hindbrain Weak Regionally restricted euxassay_010021_11
TS23: forebrain Weak Regionally restricted euxassay_010021_11
Specimen euxassay_010021_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: olfactory epithelium Moderate Regionally restricted euxassay_010021_12
TS23: upper jaw incisor Weak Regionally restricted euxassay_010021_12
TS23: lower jaw incisor Weak Regionally restricted euxassay_010021_12
TS23: bladder wall Weak Regionally restricted euxassay_010021_12
TS23: spinal cord Weak Regionally restricted euxassay_010021_12
TS23: midbrain Weak Regionally restricted euxassay_010021_12
TS23: hindbrain Weak Regionally restricted euxassay_010021_12
TS23: forebrain Weak Regionally restricted euxassay_010021_12
Specimen euxassay_010021_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_010021_13
TS23: olfactory epithelium Moderate Regionally restricted euxassay_010021_13
TS23: bladder wall Weak Regionally restricted euxassay_010021_13
TS23: midbrain Weak Regionally restricted euxassay_010021_13
TS23: hindbrain Weak Regionally restricted euxassay_010021_13
TS23: forebrain Weak Regionally restricted euxassay_010021_13
TS23: spinal cord Weak Regionally restricted euxassay_010021_13
Specimen euxassay_010021_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_010021_14
TS23: adrenal gland Weak Regionally restricted euxassay_010021_14
TS23: olfactory epithelium Weak Regionally restricted euxassay_010021_14
TS23: bladder wall Weak Regionally restricted euxassay_010021_14
TS23: midbrain Weak Regionally restricted euxassay_010021_14
TS23: hindbrain Weak Regionally restricted euxassay_010021_14
TS23: forebrain Weak Regionally restricted euxassay_010021_14
Specimen euxassay_010021_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_010021_15
TS23: adrenal gland Weak Regionally restricted euxassay_010021_15
TS23: cervico-thoracic ganglion Weak Regionally restricted euxassay_010021_15
TS23: olfactory epithelium Weak Regionally restricted euxassay_010021_15
TS23: upper jaw incisor Weak Regionally restricted euxassay_010021_15
TS23: lower jaw incisor Weak Regionally restricted euxassay_010021_15
TS23: midbrain Weak Regionally restricted euxassay_010021_15
TS23: hindbrain Weak Regionally restricted euxassay_010021_15
TS23: forebrain Weak Regionally restricted euxassay_010021_15
Specimen euxassay_010021_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_010021_16
TS23: cervical ganglion Weak Regionally restricted euxassay_010021_16
TS23: olfactory epithelium Moderate Regionally restricted euxassay_010021_16
TS23: upper jaw incisor Weak Regionally restricted euxassay_010021_16
TS23: lower jaw incisor Weak Regionally restricted euxassay_010021_16
TS23: midbrain Weak Regionally restricted euxassay_010021_16
TS23: hindbrain Weak Regionally restricted euxassay_010021_16
TS23: forebrain Weak Regionally restricted euxassay_010021_16
Specimen euxassay_010021_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_010021_17
TS23: olfactory epithelium Weak Regionally restricted euxassay_010021_17
TS23: midbrain Weak Regionally restricted euxassay_010021_17
TS23: hindbrain Weak Regionally restricted euxassay_010021_17
TS23: forebrain Weak Regionally restricted euxassay_010021_17
Specimen euxassay_010021_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_010021_18
TS23: submandibular gland primordium Weak Regionally restricted euxassay_010021_18
TS23: olfactory epithelium Weak Regionally restricted euxassay_010021_18
TS23: midbrain Weak Regionally restricted euxassay_010021_18
TS23: hindbrain Weak Regionally restricted euxassay_010021_18
TS23: forebrain Weak Regionally restricted euxassay_010021_18
Specimen euxassay_010021_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_010021_19
TS23: submandibular gland primordium Weak Regionally restricted euxassay_010021_19
TS23: hindbrain Weak Regionally restricted euxassay_010021_19
TS23: forebrain Weak Regionally restricted euxassay_010021_19
Specimen euxassay_010021_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_010021_20
TS23: forebrain Weak Regionally restricted euxassay_010021_20
TS23: hindbrain Weak Regionally restricted euxassay_010021_20
Specimen euxassay_010021_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_010021_21
TS23: forebrain Moderate Regionally restricted euxassay_010021_21
TS23: hindbrain Weak Regionally restricted euxassay_010021_21
Specimen euxassay_010021_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_010021_22
TS23: forebrain Moderate Regionally restricted euxassay_010021_22
Specimen euxassay_010021_23: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_010021_23
TS23: neural retina Weak Regionally restricted euxassay_010021_23
TS23: forebrain Moderate Regionally restricted euxassay_010021_23
Specimen euxassay_010021_24: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Weak Regionally restricted euxassay_010021_24
TS23: forebrain Moderate Regionally restricted euxassay_010021_24
Contributing Projects:
Mouse Genome Database (MGD), Gene Expression Database (GXD), Mouse Models of Human Cancer database (MMHCdb) (formerly Mouse Tumor Biology (MTB)), Gene Ontology (GO)
Citing These Resources
Funding Information
Warranty Disclaimer, Privacy Notice, Licensing, & Copyright
Send questions and comments to User Support. 		last database update
03/25/2025
MGI 6.24 		The Jackson Laboratory
