Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4827427
Gene symbol: Prkg1
Gene name: protein kinase, cGMP-dependent, type I
Probe: T36900
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_009525_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: stomach Weak Regionally restricted euxassay_009525_01
TS23: head mesenchyme Weak Regionally restricted euxassay_009525_01
Specimen euxassay_009525_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Regionally restricted euxassay_009525_02
TS23: stomach Weak Regionally restricted euxassay_009525_02
TS23: midgut Weak Regionally restricted euxassay_009525_02
TS23: head mesenchyme Weak Regionally restricted euxassay_009525_02
Specimen euxassay_009525_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Regionally restricted euxassay_009525_03
TS23: facial ganglion Strong Regionally restricted euxassay_009525_03
TS23: midgut Weak Regionally restricted euxassay_009525_03
TS23: stomach Weak Regionally restricted euxassay_009525_03
TS23: head mesenchyme Weak Regionally restricted euxassay_009525_03
Specimen euxassay_009525_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Regionally restricted euxassay_009525_04
TS23: facial ganglion Strong Regionally restricted euxassay_009525_04
TS23: midgut Weak Regionally restricted euxassay_009525_04
TS23: stomach Weak Regionally restricted euxassay_009525_04
Specimen euxassay_009525_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Regionally restricted euxassay_009525_05
TS23: vestibulo-cochlear ganglion Strong Regionally restricted euxassay_009525_05
Specimen euxassay_009525_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Regionally restricted euxassay_009525_06
TS23: vestibulo-cochlear ganglion Strong Regionally restricted euxassay_009525_06
TS23: glossopharyngeal ganglion Strong Regionally restricted euxassay_009525_06
TS23: dorsal root ganglion Strong Regionally restricted euxassay_009525_06
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_009525_06
TS23: stomach Weak Regionally restricted euxassay_009525_06
TS23: midgut Weak Regionally restricted euxassay_009525_06
Specimen euxassay_009525_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Regionally restricted euxassay_009525_07
TS23: glossopharyngeal ganglion Strong Regionally restricted euxassay_009525_07
TS23: vestibulo-cochlear ganglion Strong Regionally restricted euxassay_009525_07
TS23: dorsal root ganglion Strong Regionally restricted euxassay_009525_07
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_009525_07
TS23: medulla oblongata basal plate mantle layer Moderate Regionally restricted euxassay_009525_07
TS23: pons mantle layer Moderate Regionally restricted euxassay_009525_07
TS23: turbinate bone primordium Moderate Regionally restricted euxassay_009525_07
Specimen euxassay_009525_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Strong Regionally restricted euxassay_009525_08
TS23: pons mantle layer Moderate Regionally restricted euxassay_009525_08
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_009525_08
TS23: turbinate bone primordium Moderate Regionally restricted euxassay_009525_08
TS23: ventral grey horn Moderate Single cells euxassay_009525_08
TS23: midgut Weak Regionally restricted euxassay_009525_08
Specimen euxassay_009525_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_009525_09
TS23: turbinate bone primordium Moderate Regionally restricted euxassay_009525_09
TS23: ventral grey horn Moderate Single cells euxassay_009525_09
TS23: midgut Weak Regionally restricted euxassay_009525_09
Specimen euxassay_009525_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: midbrain mantle layer Weak Regionally restricted euxassay_009525_10
TS23: pons mantle layer Weak Regionally restricted euxassay_009525_10
TS23: turbinate bone primordium Weak Regionally restricted euxassay_009525_10
TS23: ventral grey horn Moderate Single cells euxassay_009525_10
TS23: midgut Weak Regionally restricted euxassay_009525_10
TS23: hindgut Weak Regionally restricted euxassay_009525_10
Specimen euxassay_009525_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Strong Regionally restricted euxassay_009525_11
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_009525_11
TS23: pons mantle layer Moderate Regionally restricted euxassay_009525_11
TS23: ventral grey horn Moderate Single cells euxassay_009525_11
TS23: hindgut Weak Regionally restricted euxassay_009525_11
TS23: midgut Weak Regionally restricted euxassay_009525_11
Specimen euxassay_009525_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Strong Regionally restricted euxassay_009525_12
TS23: pons mantle layer Moderate Regionally restricted euxassay_009525_12
TS23: turbinate bone primordium Weak Regionally restricted euxassay_009525_12
TS23: ventral grey horn Moderate Single cells euxassay_009525_12
TS23: midgut Weak Regionally restricted euxassay_009525_12
TS23: hindgut Weak Regionally restricted euxassay_009525_12
Specimen euxassay_009525_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Strong Regionally restricted euxassay_009525_13
TS23: pons mantle layer Moderate Regionally restricted euxassay_009525_13
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_009525_13
TS23: turbinate bone primordium Weak Regionally restricted euxassay_009525_13
TS23: ventral grey horn Moderate Single cells euxassay_009525_13
Specimen euxassay_009525_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Strong Regionally restricted euxassay_009525_14
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_009525_14
TS23: turbinate bone primordium Weak Regionally restricted euxassay_009525_14
Specimen euxassay_009525_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Strong Regionally restricted euxassay_009525_15
TS23: midbrain mantle layer Weak Regionally restricted euxassay_009525_15
TS23: pons mantle layer Weak Regionally restricted euxassay_009525_15
TS23: medulla oblongata basal plate mantle layer Weak Regionally restricted euxassay_009525_15
TS23: turbinate bone primordium Moderate Regionally restricted euxassay_009525_15
Specimen euxassay_009525_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Regionally restricted euxassay_009525_16
TS23: vestibulo-cochlear ganglion Strong Regionally restricted euxassay_009525_16
TS23: glossopharyngeal ganglion Strong Regionally restricted euxassay_009525_16
TS23: dorsal root ganglion Strong Regionally restricted euxassay_009525_16
TS23: medulla oblongata basal plate mantle layer Weak Regionally restricted euxassay_009525_16
TS23: pons mantle layer Weak Regionally restricted euxassay_009525_16
TS23: midbrain mantle layer Weak Regionally restricted euxassay_009525_16
TS23: turbinate bone primordium Moderate Regionally restricted euxassay_009525_16
Specimen euxassay_009525_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Regionally restricted euxassay_009525_17
TS23: vestibulo-cochlear ganglion Strong Regionally restricted euxassay_009525_17
TS23: glossopharyngeal ganglion Strong Regionally restricted euxassay_009525_17
TS23: midbrain mantle layer Weak Regionally restricted euxassay_009525_17
TS23: pons mantle layer Weak Regionally restricted euxassay_009525_17
TS23: turbinate bone primordium Moderate Regionally restricted euxassay_009525_17
Specimen euxassay_009525_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Regionally restricted euxassay_009525_18
TS23: vestibulo-cochlear ganglion Strong Regionally restricted euxassay_009525_18
TS23: facial ganglion Strong Regionally restricted euxassay_009525_18
TS23: turbinate bone primordium Moderate Regionally restricted euxassay_009525_18
Specimen euxassay_009525_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Regionally restricted euxassay_009525_19
TS23: facial ganglion Strong Regionally restricted euxassay_009525_19
TS23: head mesenchyme Weak Regionally restricted euxassay_009525_19
Specimen euxassay_009525_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: facial ganglion Strong Regionally restricted euxassay_009525_20
TS23: trigeminal ganglion Strong Regionally restricted euxassay_009525_20
TS23: head mesenchyme Weak Regionally restricted euxassay_009525_20
Specimen euxassay_009525_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Regionally restricted euxassay_009525_21
TS23: head mesenchyme Weak Regionally restricted euxassay_009525_21
Specimen euxassay_009525_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: head mesenchyme Weak Regionally restricted euxassay_009525_22
