Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4827252
Gene symbol: Plcd1
Gene name: phospholipase C, delta 1
Probe: T30285
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_010490_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: radius Moderate Regionally restricted euxassay_010490_01
TS23: humerus Moderate Regionally restricted euxassay_010490_01
TS23: tibia Moderate Regionally restricted euxassay_010490_01
TS23: fibula Moderate Regionally restricted euxassay_010490_01
Specimen euxassay_010490_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: radius Weak Regionally restricted euxassay_010490_02
TS23: humerus Moderate Regionally restricted euxassay_010490_02
TS23: rib Moderate Regionally restricted euxassay_010490_02
TS23: orbito-sphenoid Strong Regionally restricted euxassay_010490_02
TS23: tibia Moderate Regionally restricted euxassay_010490_02
TS23: fibula Moderate Regionally restricted euxassay_010490_02
Specimen euxassay_010490_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: humerus Moderate Regionally restricted euxassay_010490_03
TS23: scapula Moderate Regionally restricted euxassay_010490_03
TS23: rib Strong Regionally restricted euxassay_010490_03
TS23: mandible Moderate Regionally restricted euxassay_010490_03
TS23: orbito-sphenoid Strong Regionally restricted euxassay_010490_03
TS23: femur Weak Regionally restricted euxassay_010490_03
Specimen euxassay_010490_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: humerus Moderate Regionally restricted euxassay_010490_04
TS23: clavicle Moderate Regionally restricted euxassay_010490_04
TS23: scapula Moderate Regionally restricted euxassay_010490_04
TS23: rib Strong Regionally restricted euxassay_010490_04
TS23: mandible Strong Regionally restricted euxassay_010490_04
TS23: orbito-sphenoid Strong Regionally restricted euxassay_010490_04
TS23: tarsus Weak Regionally restricted euxassay_010490_04
TS23: hindlimb digit 2 metatarsal Weak Regionally restricted euxassay_010490_04
TS23: hindlimb digit 3 metatarsal Weak Regionally restricted euxassay_010490_04
TS23: hindlimb digit 1 metatarsal Weak Regionally restricted euxassay_010490_04
TS23: femur Weak Regionally restricted euxassay_010490_04
Specimen euxassay_010490_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: clavicle Moderate Regionally restricted euxassay_010490_05
TS23: rib Strong Regionally restricted euxassay_010490_05
TS23: maxilla Strong Regionally restricted euxassay_010490_05
TS23: mandible Strong Regionally restricted euxassay_010490_05
TS23: orbito-sphenoid Strong Regionally restricted euxassay_010490_05
TS23: hindlimb digit 3 metatarsal Weak Regionally restricted euxassay_010490_05
TS23: hindlimb digit 4 metatarsal Weak Regionally restricted euxassay_010490_05
TS23: hindlimb digit 5 metatarsal Weak Regionally restricted euxassay_010490_05
TS23: femur Weak Regionally restricted euxassay_010490_05
Specimen euxassay_010490_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: clavicle Moderate Regionally restricted euxassay_010490_06
TS23: rib Strong Regionally restricted euxassay_010490_06
TS23: maxilla Strong Regionally restricted euxassay_010490_06
TS23: mandible Strong Regionally restricted euxassay_010490_06
TS23: orbito-sphenoid Strong Regionally restricted euxassay_010490_06
Specimen euxassay_010490_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: clavicle Moderate Regionally restricted euxassay_010490_07
TS23: rib Moderate Regionally restricted euxassay_010490_07
TS23: maxilla Strong Regionally restricted euxassay_010490_07
TS23: mandible Strong Regionally restricted euxassay_010490_07
Specimen euxassay_010490_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: clavicle Moderate Regionally restricted euxassay_010490_08
TS23: rib Moderate Regionally restricted euxassay_010490_08
TS23: maxilla Strong Regionally restricted euxassay_010490_08
TS23: mandible Strong Regionally restricted euxassay_010490_08
Specimen euxassay_010490_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: clavicle Moderate Regionally restricted euxassay_010490_09
TS23: palatal shelf Strong Regionally restricted euxassay_010490_09
TS23: mandible Strong Regionally restricted euxassay_010490_09
TS23: maxilla Strong Regionally restricted euxassay_010490_09
Specimen euxassay_010490_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: maxilla Strong Regionally restricted euxassay_010490_10
TS23: mandible Strong Regionally restricted euxassay_010490_10
TS23: palatal shelf Moderate Regionally restricted euxassay_010490_10
Specimen euxassay_010490_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: maxilla Strong Regionally restricted euxassay_010490_11
TS23: mandible Strong Regionally restricted euxassay_010490_11
Specimen euxassay_010490_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: maxilla Strong Regionally restricted euxassay_010490_12
TS23: mandible Strong Regionally restricted euxassay_010490_12
TS23: bladder fundus Moderate Regionally restricted euxassay_010490_12
TS23: urethra Moderate Regionally restricted euxassay_010490_12 Originally this result was annotated to a male-specific term, but as the specimen was not sexed, it is likely the data annotator intended to use a non-gender specific term.
Specimen euxassay_010490_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: bladder fundus Moderate Regionally restricted euxassay_010490_13
TS23: urethra Moderate Regionally restricted euxassay_010490_13 Originally this result was annotated to a male-specific term, but as the specimen was not sexed, it is likely the data annotator intended to use a non-gender specific term.
Specimen euxassay_010490_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: clavicle Moderate Regionally restricted euxassay_010490_15
TS23: mandible Strong Regionally restricted euxassay_010490_15
Specimen euxassay_010490_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: clavicle Moderate Regionally restricted euxassay_010490_16
TS23: maxilla Strong Regionally restricted euxassay_010490_16
TS23: mandible Strong Regionally restricted euxassay_010490_16
Specimen euxassay_010490_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: clavicle Moderate Regionally restricted euxassay_010490_17
TS23: rib Moderate Regionally restricted euxassay_010490_17
TS23: maxilla Strong Regionally restricted euxassay_010490_17
TS23: mandible Strong Regionally restricted euxassay_010490_17
Specimen euxassay_010490_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: clavicle Weak Regionally restricted euxassay_010490_18
TS23: rib Moderate Regionally restricted euxassay_010490_18
TS23: maxilla Strong Regionally restricted euxassay_010490_18
TS23: palatal shelf Strong Regionally restricted euxassay_010490_18
TS23: mandible Strong Regionally restricted euxassay_010490_18
Specimen euxassay_010490_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_010490_19
TS23: maxilla Strong Regionally restricted euxassay_010490_19
TS23: mandible Strong Regionally restricted euxassay_010490_19
Specimen euxassay_010490_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: scapula Weak Regionally restricted euxassay_010490_20
TS23: rib Strong Regionally restricted euxassay_010490_20
TS23: maxilla Strong Regionally restricted euxassay_010490_20
TS23: mandible Strong Regionally restricted euxassay_010490_20
TS23: hindlimb digit 5 metatarsal Weak Regionally restricted euxassay_010490_20
TS23: femur Weak Regionally restricted euxassay_010490_20
Specimen euxassay_010490_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: humerus Weak Regionally restricted euxassay_010490_21
TS23: scapula Weak Regionally restricted euxassay_010490_21
TS23: rib Strong Regionally restricted euxassay_010490_21
TS23: mandible Strong Regionally restricted euxassay_010490_21
TS23: maxilla Strong Regionally restricted euxassay_010490_21
TS23: orbito-sphenoid Strong Regionally restricted euxassay_010490_21
TS23: hindlimb digit 4 metatarsal Weak Regionally restricted euxassay_010490_21
TS23: hindlimb digit 3 metatarsal Weak Regionally restricted euxassay_010490_21
TS23: femur Weak Regionally restricted euxassay_010490_21
Specimen euxassay_010490_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: humerus Moderate Regionally restricted euxassay_010490_22
TS23: rib Strong Regionally restricted euxassay_010490_22
TS23: mandible Strong Regionally restricted euxassay_010490_22
TS23: maxilla Strong Regionally restricted euxassay_010490_22
TS23: orbito-sphenoid Strong Regionally restricted euxassay_010490_22
TS23: tarsus Weak Regionally restricted euxassay_010490_22
TS23: femur Weak Regionally restricted euxassay_010490_22
Specimen euxassay_010490_23: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: humerus Moderate Regionally restricted euxassay_010490_23
TS23: rib Strong Regionally restricted euxassay_010490_23
TS23: orbito-sphenoid Strong Regionally restricted euxassay_010490_23
TS23: tibia Weak Regionally restricted euxassay_010490_23
TS23: fibula Weak Regionally restricted euxassay_010490_23
TS23: femur Weak Regionally restricted euxassay_010490_23
