Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4827225
Gene symbol: Pitx2
Gene name: paired-like homeodomain transcription factor 2
Probe: T55145
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen Table S8: embryonic day 14.5 (more )
Note: The annotations provided in this table refer to the entire set of Eurexpress images; thus the displayed image may not include the structures referred to in the annotations.
Structure Level Pattern Image Note
TS23: neocortex Absent euxassay_019470_12
TS23: hippocampus Absent euxassay_019470_12
TS23: corpus striatum Absent euxassay_019470_12
TS23: telencephalon septum Absent euxassay_019470_12
TS23: thalamus Moderate euxassay_019470_12
TS23: hypothalamus Strong euxassay_019470_12
TS23: pretectum Absent euxassay_019470_12
TS23: superior colliculus Strong euxassay_019470_12
TS23: inferior colliculus Weak euxassay_019470_12
TS23: midbrain tegmentum Absent euxassay_019470_12
TS23: cerebellum Absent euxassay_019470_12
TS23: spinal cord Weak euxassay_019470_12
TS23: skin Absent euxassay_019470_12
TS23: lung Absent euxassay_019470_12
TS23: metanephros Absent euxassay_019470_12
TS23: liver Absent euxassay_019470_12
TS23: thyroid gland Strong euxassay_019470_12
TS23: pituitary gland Absent euxassay_019470_12
TS23: pancreas Absent euxassay_019470_12
TS23: adrenal gland Absent euxassay_019470_12
TS23: heart Absent euxassay_019470_12
TS23: thymus primordium Absent euxassay_019470_12
TS23: vertebral axis musculature Absent euxassay_019470_12
TS23: axial skeleton Strong euxassay_019470_12
Specimen euxassay_019470_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: perioptic mesenchyme Strong Regionally restricted euxassay_019470_02
Specimen euxassay_019470_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: perioptic mesenchyme Strong Regionally restricted euxassay_019470_03
Specimen euxassay_019470_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: perioptic mesenchyme Strong Regionally restricted euxassay_019470_04
Specimen euxassay_019470_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: extrinsic ocular muscle Weak Regionally restricted euxassay_019470_05
TS23: perioptic mesenchyme Strong Regionally restricted euxassay_019470_05
Specimen euxassay_019470_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: extrinsic ocular muscle Weak Regionally restricted euxassay_019470_06
TS23: perioptic mesenchyme Moderate Regionally restricted euxassay_019470_06
TS23: trigeminal nerve Weak Regionally restricted euxassay_019470_06
TS23: midbrain mantle layer Strong Regionally restricted euxassay_019470_06
Specimen euxassay_019470_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: extrinsic ocular muscle Weak Regionally restricted euxassay_019470_07
TS23: perioptic mesenchyme Moderate Regionally restricted euxassay_019470_07
TS23: trigeminal nerve Moderate Regionally restricted euxassay_019470_07
TS23: midbrain mantle layer Strong Regionally restricted euxassay_019470_07
Specimen euxassay_019470_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: upper jaw molar Strong Regionally restricted euxassay_019470_08
TS23: lower jaw molar Strong Regionally restricted euxassay_019470_08
TS23: extrinsic ocular muscle Weak Regionally restricted euxassay_019470_08
TS23: trigeminal nerve Moderate Regionally restricted euxassay_019470_08
TS23: midbrain mantle layer Strong Regionally restricted euxassay_019470_08
TS23: pectoralis major Weak Regionally restricted euxassay_019470_08
TS23: pectoralis minor Weak Regionally restricted euxassay_019470_08
TS23: anterior abdominal wall muscle Weak Regionally restricted euxassay_019470_08
Specimen euxassay_019470_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lower jaw molar Strong Regionally restricted euxassay_019470_09
TS23: upper jaw molar Strong Regionally restricted euxassay_019470_09
TS23: midbrain mantle layer Strong Regionally restricted euxassay_019470_09
TS23: diencephalon lateral wall mantle layer Strong Regionally restricted euxassay_019470_09
TS23: pectoralis major Weak Regionally restricted euxassay_019470_09
TS23: pectoralis minor Weak Regionally restricted euxassay_019470_09
TS23: anterior abdominal wall muscle Moderate Regionally restricted euxassay_019470_09
Specimen euxassay_019470_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lower jaw molar Strong Regionally restricted euxassay_019470_10
TS23: diencephalon lateral wall mantle layer Strong Regionally restricted euxassay_019470_10
TS23: hypothalamus mantle layer Strong Regionally restricted euxassay_019470_10
TS23: midbrain mantle layer Strong Regionally restricted euxassay_019470_10
TS23: pectoralis major Weak Regionally restricted euxassay_019470_10
TS23: pectoralis minor Weak Regionally restricted euxassay_019470_10
TS23: anterior abdominal wall muscle Moderate Regionally restricted euxassay_019470_10
Specimen euxassay_019470_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: pituitary gland Strong Regionally restricted euxassay_019470_11
TS23: midbrain mantle layer Strong Regionally restricted euxassay_019470_11
TS23: diencephalon lateral wall mantle layer Strong Regionally restricted euxassay_019470_11
TS23: hypothalamus mantle layer Strong Regionally restricted euxassay_019470_11
TS23: foot mesenchyme Weak Regionally restricted euxassay_019470_11
TS23: pectoralis minor Moderate Regionally restricted euxassay_019470_11
TS23: pectoralis major Moderate Regionally restricted euxassay_019470_11
TS23: anterior abdominal wall muscle Moderate Regionally restricted euxassay_019470_11
Specimen euxassay_019470_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: pituitary gland Strong Regionally restricted euxassay_019470_12
TS23: hypothalamus mantle layer Strong Regionally restricted euxassay_019470_12
TS23: diencephalon lateral wall mantle layer Strong Regionally restricted euxassay_019470_12
TS23: foot mesenchyme Weak Regionally restricted euxassay_019470_12
TS23: pectoralis major Weak Regionally restricted euxassay_019470_12
TS23: pectoralis minor Weak Regionally restricted euxassay_019470_12
TS23: anterior abdominal wall muscle Moderate Regionally restricted euxassay_019470_12
Specimen euxassay_019470_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: upper jaw incisor Strong Regionally restricted euxassay_019470_13
TS23: lower jaw incisor Strong Regionally restricted euxassay_019470_13
TS23: pituitary gland Strong Regionally restricted euxassay_019470_13
TS23: hypothalamus mantle layer Strong Regionally restricted euxassay_019470_13
TS23: diencephalon lateral wall mantle layer Strong Regionally restricted euxassay_019470_13
TS23: anterior abdominal wall muscle Weak Regionally restricted euxassay_019470_13
TS23: pectoralis major Weak Regionally restricted euxassay_019470_13
TS23: pectoralis minor Weak Regionally restricted euxassay_019470_13
Specimen euxassay_019470_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: upper jaw incisor Strong Regionally restricted euxassay_019470_14
TS23: lower jaw incisor Strong Regionally restricted euxassay_019470_14
TS23: pituitary gland Strong Regionally restricted euxassay_019470_14
TS23: tongue muscle Weak Regionally restricted euxassay_019470_14
TS23: hypothalamus mantle layer Strong Regionally restricted euxassay_019470_14
TS23: diencephalon lateral wall mantle layer Strong Regionally restricted euxassay_019470_14
TS23: midbrain mantle layer Strong Regionally restricted euxassay_019470_14
TS23: pectoralis minor Weak Regionally restricted euxassay_019470_14
TS23: pectoralis major Weak Regionally restricted euxassay_019470_14
TS23: anterior abdominal wall muscle Moderate Regionally restricted euxassay_019470_14
Specimen euxassay_019470_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: upper jaw incisor Strong Regionally restricted euxassay_019470_15
TS23: lower jaw incisor Strong Regionally restricted euxassay_019470_15
TS23: pituitary gland Strong Regionally restricted euxassay_019470_15
TS23: midbrain mantle layer Strong Regionally restricted euxassay_019470_15
TS23: diencephalon lateral wall mantle layer Strong Regionally restricted euxassay_019470_15
TS23: hypothalamus mantle layer Strong Regionally restricted euxassay_019470_15
TS23: tail mesenchyme Weak Regionally restricted euxassay_019470_15
TS23: anterior abdominal wall muscle Moderate Regionally restricted euxassay_019470_15
Specimen euxassay_019470_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: pituitary gland Moderate Regionally restricted euxassay_019470_16
TS23: tongue muscle Weak Regionally restricted euxassay_019470_16
TS23: midbrain mantle layer Strong Regionally restricted euxassay_019470_16
TS23: diencephalon lateral wall mantle layer Strong Regionally restricted euxassay_019470_16
TS23: hypothalamus mantle layer Strong Regionally restricted euxassay_019470_16
TS23: tail mesenchyme Weak Regionally restricted euxassay_019470_16
TS23: anterior abdominal wall muscle Weak Regionally restricted euxassay_019470_16
TS23: pectoralis minor Weak Regionally restricted euxassay_019470_16
TS23: pectoralis major Weak Regionally restricted euxassay_019470_16
Specimen euxassay_019470_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: pituitary gland Strong Regionally restricted euxassay_019470_17
TS23: tongue muscle Weak Regionally restricted euxassay_019470_17
TS23: midbrain mantle layer Strong Regionally restricted euxassay_019470_17
TS23: diencephalon lateral wall mantle layer Strong Regionally restricted euxassay_019470_17
TS23: hypothalamus mantle layer Strong Regionally restricted euxassay_019470_17
TS23: tail mesenchyme Weak Regionally restricted euxassay_019470_17
TS23: pectoralis minor Weak Regionally restricted euxassay_019470_17
TS23: pectoralis major Weak Regionally restricted euxassay_019470_17
TS23: anterior abdominal wall muscle Weak Regionally restricted euxassay_019470_17
Specimen euxassay_019470_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: upper jaw incisor Strong Regionally restricted euxassay_019470_18
TS23: lower jaw incisor Strong Regionally restricted euxassay_019470_18
TS23: pituitary gland Strong Regionally restricted euxassay_019470_18
TS23: tongue muscle Weak Regionally restricted euxassay_019470_18
TS23: midbrain mantle layer Strong Regionally restricted euxassay_019470_18
TS23: diencephalon lateral wall mantle layer Strong Regionally restricted euxassay_019470_18
TS23: hypothalamus mantle layer Strong Regionally restricted euxassay_019470_18
TS23: pectoralis minor Weak Regionally restricted euxassay_019470_18
TS23: pectoralis major Weak Regionally restricted euxassay_019470_18
TS23: anterior abdominal wall muscle Weak Regionally restricted euxassay_019470_18
Specimen euxassay_019470_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: upper jaw incisor Strong Regionally restricted euxassay_019470_19
TS23: lower jaw incisor Strong Regionally restricted euxassay_019470_19
TS23: hypothalamus mantle layer Strong Regionally restricted euxassay_019470_19
TS23: diencephalon lateral wall mantle layer Strong Regionally restricted euxassay_019470_19
TS23: anterior abdominal wall muscle Weak Regionally restricted euxassay_019470_19
Specimen euxassay_019470_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: upper jaw incisor Strong Regionally restricted euxassay_019470_20
TS23: lower jaw incisor Strong Regionally restricted euxassay_019470_20
TS23: diencephalon lateral wall mantle layer Strong Regionally restricted euxassay_019470_20
TS23: pectoralis major Weak Regionally restricted euxassay_019470_20
TS23: pectoralis minor Weak Regionally restricted euxassay_019470_20
TS23: anterior abdominal wall muscle Weak Regionally restricted euxassay_019470_20
Specimen euxassay_019470_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: anterior abdominal wall muscle Weak Regionally restricted euxassay_019470_21
Specimen euxassay_019470_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lower jaw molar Strong Regionally restricted euxassay_019470_22
TS23: anterior abdominal wall muscle Weak Regionally restricted euxassay_019470_22
Specimen euxassay_019470_23: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lower jaw molar Strong Regionally restricted euxassay_019470_23
TS23: upper jaw molar Strong Regionally restricted euxassay_019470_23
TS23: extrinsic ocular muscle Weak Regionally restricted euxassay_019470_23
TS23: anterior abdominal wall muscle Moderate Regionally restricted euxassay_019470_23
Specimen euxassay_019470_24: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: upper jaw molar Strong Regionally restricted euxassay_019470_24
TS23: lower jaw molar Strong Regionally restricted euxassay_019470_24
TS23: extrinsic ocular muscle Weak Regionally restricted euxassay_019470_24
TS23: foot mesenchyme Weak Regionally restricted euxassay_019470_24
TS23: anterior abdominal wall muscle Moderate Regionally restricted euxassay_019470_24
Contributing Projects:
Mouse Genome Database (MGD), Gene Expression Database (GXD), Mouse Models of Human Cancer database (MMHCdb) (formerly Mouse Tumor Biology (MTB)), Gene Ontology (GO)
Citing These Resources
Funding Information
Warranty Disclaimer, Privacy Notice, Licensing, & Copyright
Send questions and comments to User Support. 		last database update
04/23/2024
MGI 6.23 		The Jackson Laboratory
