Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4826650
Gene symbol: Ndufv2
Gene name: NADH:ubiquinone oxidoreductase core subunit V2
Probe: T31479
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_014298_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: humerus Moderate Regionally restricted euxassay_014298_01
TS23: scapula Moderate Regionally restricted euxassay_014298_01
TS23: temporal bone petrous part Weak Regionally restricted euxassay_014298_01
TS23: orbito-sphenoid Weak Regionally restricted euxassay_014298_01
Specimen euxassay_014298_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: humerus Moderate Regionally restricted euxassay_014298_02
TS23: scapula Moderate Regionally restricted euxassay_014298_02
TS23: orbito-sphenoid Weak Regionally restricted euxassay_014298_02
TS23: temporal bone petrous part Weak Regionally restricted euxassay_014298_02
Specimen euxassay_014298_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: humerus Moderate Regionally restricted euxassay_014298_03
TS23: tibia Weak Regionally restricted euxassay_014298_03
TS23: scapula Moderate Regionally restricted euxassay_014298_03
Specimen euxassay_014298_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: humerus Moderate Regionally restricted euxassay_014298_04
TS23: fibula Moderate Regionally restricted euxassay_014298_04
TS23: tibia Moderate Regionally restricted euxassay_014298_04
TS23: scapula Moderate Regionally restricted euxassay_014298_04
Specimen euxassay_014298_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: femur Moderate Regionally restricted euxassay_014298_05
TS23: tibia Weak Regionally restricted euxassay_014298_05
TS23: Meckel's cartilage Moderate Regionally restricted euxassay_014298_05
Specimen euxassay_014298_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: femur Moderate Regionally restricted euxassay_014298_06
TS23: tibia Weak Regionally restricted euxassay_014298_06
TS23: Meckel's cartilage Moderate Regionally restricted euxassay_014298_06
TS23: orbito-sphenoid Weak Regionally restricted euxassay_014298_06
Specimen euxassay_014298_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: femur Moderate Regionally restricted euxassay_014298_07
TS23: Meckel's cartilage Moderate Regionally restricted euxassay_014298_07
TS23: orbito-sphenoid Weak Regionally restricted euxassay_014298_07
Specimen euxassay_014298_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: femur Moderate Regionally restricted euxassay_014298_08
TS23: Meckel's cartilage Weak Regionally restricted euxassay_014298_08
TS23: turbinate bone primordium Weak Regionally restricted euxassay_014298_08
TS23: orbito-sphenoid Weak Regionally restricted euxassay_014298_08
Specimen euxassay_014298_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: femur Weak Regionally restricted euxassay_014298_09
Specimen euxassay_014298_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: pelvic girdle skeleton Weak Regionally restricted euxassay_014298_11
Specimen euxassay_014298_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: pelvic girdle skeleton Moderate Regionally restricted euxassay_014298_12
Specimen euxassay_014298_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: Meckel's cartilage Weak Regionally restricted euxassay_014298_13
Specimen euxassay_014298_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: Meckel's cartilage Weak Regionally restricted euxassay_014298_14
Specimen euxassay_014298_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: Meckel's cartilage Weak Regionally restricted euxassay_014298_16
Specimen euxassay_014298_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: Meckel's cartilage Weak Regionally restricted euxassay_014298_17
Specimen euxassay_014298_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: Meckel's cartilage Moderate Regionally restricted euxassay_014298_18
TS23: pelvic girdle skeleton Weak Regionally restricted euxassay_014298_18
TS23: turbinate bone primordium Weak Regionally restricted euxassay_014298_18
TS23: orbito-sphenoid Weak Regionally restricted euxassay_014298_18
Specimen euxassay_014298_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: Meckel's cartilage Moderate Regionally restricted euxassay_014298_19
TS23: pelvic girdle skeleton Moderate Regionally restricted euxassay_014298_19
TS23: orbito-sphenoid Weak Regionally restricted euxassay_014298_19
TS23: turbinate bone primordium Weak Regionally restricted euxassay_014298_19
Specimen euxassay_014298_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: humerus Weak Regionally restricted euxassay_014298_20
TS23: femur Weak Regionally restricted euxassay_014298_20
TS23: scapula Moderate Regionally restricted euxassay_014298_20
TS23: Meckel's cartilage Moderate Regionally restricted euxassay_014298_20
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_014298_20
TS23: turbinate bone primordium Moderate Regionally restricted euxassay_014298_20
Specimen euxassay_014298_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: humerus Weak Regionally restricted euxassay_014298_21
TS23: femur Weak Regionally restricted euxassay_014298_21
TS23: scapula Moderate Regionally restricted euxassay_014298_21
Specimen euxassay_014298_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: humerus Weak Regionally restricted euxassay_014298_22
TS23: femur Weak Regionally restricted euxassay_014298_22
Specimen euxassay_014298_23: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: humerus Weak Regionally restricted euxassay_014298_23
Specimen euxassay_014298_24: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: humerus Weak Regionally restricted euxassay_014298_24
TS23: femur Weak Regionally restricted euxassay_014298_24
