Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4826071
Gene symbol: Mamld1
Gene name: mastermind-like domain containing 1
Probe: T37715
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_011718_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Uniform euxassay_011718_01
TS23: vertebral axis musculature Strong Spotted euxassay_011718_01
TS23: diaphragm Strong Spotted euxassay_011718_01
Specimen euxassay_011718_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Uniform euxassay_011718_02
TS23: facial ganglion Strong Uniform euxassay_011718_02
TS23: vertebral axis musculature Strong Spotted euxassay_011718_02
TS23: diaphragm Strong Spotted euxassay_011718_02
TS23: lung Strong Regionally restricted euxassay_011718_02
Specimen euxassay_011718_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Uniform euxassay_011718_03
TS23: facial ganglion Strong Uniform euxassay_011718_03
TS23: diaphragm Strong Spotted euxassay_011718_03
TS23: vertebral axis musculature Strong Spotted euxassay_011718_03
TS23: lung Strong Regionally restricted euxassay_011718_03
Specimen euxassay_011718_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Uniform euxassay_011718_04
TS23: facial ganglion Strong Uniform euxassay_011718_04
TS23: diaphragm Strong Spotted euxassay_011718_04
TS23: vertebral axis musculature Strong Spotted euxassay_011718_04
TS23: lung Strong Regionally restricted euxassay_011718_04
Specimen euxassay_011718_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Uniform euxassay_011718_05
TS23: diaphragm Strong Spotted euxassay_011718_05
TS23: vertebral axis musculature Strong Spotted euxassay_011718_05
TS23: lung Strong Regionally restricted euxassay_011718_05
Specimen euxassay_011718_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Uniform euxassay_011718_06
TS23: glossopharyngeal ganglion Strong Uniform euxassay_011718_06
TS23: diaphragm Strong Spotted euxassay_011718_06
TS23: vertebral axis musculature Strong Spotted euxassay_011718_06
TS23: lung Strong Regionally restricted euxassay_011718_06
Specimen euxassay_011718_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vagus ganglion Strong Uniform euxassay_011718_07
TS23: dorsal root ganglion Strong Uniform euxassay_011718_07
TS23: diaphragm Strong Spotted euxassay_011718_07
TS23: vertebral axis musculature Strong Spotted euxassay_011718_07
TS23: lung Strong Regionally restricted euxassay_011718_07
Specimen euxassay_011718_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Strong Uniform euxassay_011718_08
TS23: diaphragm Strong Spotted euxassay_011718_08
TS23: vertebral axis musculature Strong Spotted euxassay_011718_08
TS23: lung Strong Regionally restricted euxassay_011718_08
Specimen euxassay_011718_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Strong Uniform euxassay_011718_09
TS23: diaphragm Strong Spotted euxassay_011718_09
TS23: vertebral axis musculature Strong Spotted euxassay_011718_09
TS23: lung Strong Regionally restricted euxassay_011718_09
Specimen euxassay_011718_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Spotted euxassay_011718_10
TS23: vertebral axis musculature Strong Spotted euxassay_011718_10
TS23: lung Strong Regionally restricted euxassay_011718_10
Specimen euxassay_011718_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Spotted euxassay_011718_11
TS23: vertebral axis musculature Strong Spotted euxassay_011718_11
TS23: lung Strong Regionally restricted euxassay_011718_11
Specimen euxassay_011718_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Spotted euxassay_011718_12
TS23: vertebral axis musculature Strong Spotted euxassay_011718_12
TS23: lung Strong Regionally restricted euxassay_011718_12
Specimen euxassay_011718_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Spotted euxassay_011718_13
TS23: vertebral axis musculature Strong Spotted euxassay_011718_13
TS23: lung Strong Regionally restricted euxassay_011718_13
Specimen euxassay_011718_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Spotted euxassay_011718_14
TS23: vertebral axis musculature Strong Spotted euxassay_011718_14
TS23: lung Strong Regionally restricted euxassay_011718_14
Specimen euxassay_011718_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Uniform euxassay_011718_15
TS23: diaphragm Strong Spotted euxassay_011718_15
TS23: vertebral axis musculature Strong Spotted euxassay_011718_15
TS23: lung Strong Regionally restricted euxassay_011718_15
Specimen euxassay_011718_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Uniform euxassay_011718_16
TS23: vagus ganglion Strong Uniform euxassay_011718_16
TS23: dorsal root ganglion Strong Uniform euxassay_011718_16
TS23: diaphragm Strong Spotted euxassay_011718_16
TS23: vertebral axis musculature Strong Spotted euxassay_011718_16
TS23: lung Strong Regionally restricted euxassay_011718_16
Specimen euxassay_011718_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Uniform euxassay_011718_17
TS23: glossopharyngeal ganglion Strong Uniform euxassay_011718_17
TS23: dorsal root ganglion Strong Uniform euxassay_011718_17
TS23: diaphragm Strong Spotted euxassay_011718_17
TS23: vertebral axis musculature Strong Spotted euxassay_011718_17
TS23: lung Strong Regionally restricted euxassay_011718_17
Specimen euxassay_011718_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Uniform euxassay_011718_18
TS23: glossopharyngeal ganglion Strong Uniform euxassay_011718_18
TS23: diaphragm Strong Spotted euxassay_011718_18
TS23: vertebral axis musculature Strong Spotted euxassay_011718_18
TS23: lung Strong Regionally restricted euxassay_011718_18
Specimen euxassay_011718_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Uniform euxassay_011718_19
TS23: facial ganglion Strong Uniform euxassay_011718_19
TS23: diaphragm Strong Spotted euxassay_011718_19
TS23: vertebral axis musculature Strong Spotted euxassay_011718_19
TS23: lung Strong Regionally restricted euxassay_011718_19
Specimen euxassay_011718_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Uniform euxassay_011718_20
TS23: diaphragm Strong Spotted euxassay_011718_20
TS23: vertebral axis musculature Strong Spotted euxassay_011718_20
TS23: lung Strong Regionally restricted euxassay_011718_20
Specimen euxassay_011718_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Spotted euxassay_011718_21
TS23: vertebral axis musculature Strong Spotted euxassay_011718_21
TS23: lung Strong Regionally restricted euxassay_011718_21
Specimen euxassay_011718_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Spotted euxassay_011718_22
TS23: vertebral axis musculature Strong Spotted euxassay_011718_22
TS23: lung Strong Regionally restricted euxassay_011718_22
Specimen euxassay_011718_23: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diaphragm Strong Spotted euxassay_011718_23
TS23: vertebral axis musculature Strong Spotted euxassay_011718_23
Specimen euxassay_011718_24: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Strong Spotted euxassay_011718_24
