Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4825372
Gene symbol: Hip1r
Gene name: huntingtin interacting protein 1 related
Probe: MGC clone 86079
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_012046_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Strong Regionally restricted euxassay_012046_01
TS23: temporal bone petrous part Moderate Regionally restricted euxassay_012046_01
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_012046_01
TS23: exoccipital bone Moderate Regionally restricted euxassay_012046_01
TS23: pharyngo-tympanic tube Weak Regionally restricted euxassay_012046_01
TS23: epidermis Moderate Regionally restricted euxassay_012046_01
TS23: tibia Moderate Regionally restricted euxassay_012046_01
TS23: liver lobe Moderate Regionally restricted euxassay_012046_01
TS23: cornea epithelium Moderate Regionally restricted euxassay_012046_01
TS23: telencephalon mantle layer Moderate Uniform euxassay_012046_01

Specimen euxassay_012046_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Strong Regionally restricted euxassay_012046_02
TS23: temporal bone petrous part Moderate Regionally restricted euxassay_012046_02
TS23: exoccipital bone Moderate Regionally restricted euxassay_012046_02
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_012046_02
TS23: pharyngo-tympanic tube Weak Regionally restricted euxassay_012046_02
TS23: epidermis Moderate Regionally restricted euxassay_012046_02
TS23: tibia Moderate Regionally restricted euxassay_012046_02
TS23: fibula Moderate Regionally restricted euxassay_012046_02
TS23: liver lobe Moderate Regionally restricted euxassay_012046_02
TS23: cornea epithelium Moderate Regionally restricted euxassay_012046_02
TS23: telencephalon mantle layer Moderate Uniform euxassay_012046_02

Specimen euxassay_012046_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Strong Regionally restricted euxassay_012046_03
TS23: exoccipital bone Moderate Regionally restricted euxassay_012046_03
TS23: temporal bone petrous part Moderate Regionally restricted euxassay_012046_03
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_012046_03
TS23: pharyngo-tympanic tube Weak Regionally restricted euxassay_012046_03
TS23: vibrissa Moderate Regionally restricted euxassay_012046_03
TS23: epidermis Moderate Regionally restricted euxassay_012046_03
TS23: tibia Weak Regionally restricted euxassay_012046_03
TS23: liver lobe Moderate Regionally restricted euxassay_012046_03
TS23: cornea epithelium Moderate Regionally restricted euxassay_012046_03
TS23: telencephalon mantle layer Moderate Uniform euxassay_012046_03
TS23: rest of cerebellum mantle layer Moderate Uniform euxassay_012046_03

Specimen euxassay_012046_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: exoccipital bone Moderate Regionally restricted euxassay_012046_04
TS23: temporal bone petrous part Moderate Regionally restricted euxassay_012046_04
TS23: stomach Strong Regionally restricted euxassay_012046_04
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_012046_04
TS23: facial ganglion Moderate Regionally restricted euxassay_012046_04
TS23: pharyngo-tympanic tube Weak Regionally restricted euxassay_012046_04
TS23: vibrissa Moderate Regionally restricted euxassay_012046_04
TS23: epidermis Moderate Regionally restricted euxassay_012046_04
TS23: tarsus Moderate Regionally restricted euxassay_012046_04
TS23: hindlimb digit 2 metatarsal Moderate Regionally restricted euxassay_012046_04
TS23: hindlimb digit 3 metatarsal Moderate Regionally restricted euxassay_012046_04
TS23: liver lobe Moderate Regionally restricted euxassay_012046_04
TS23: cornea epithelium Moderate Regionally restricted euxassay_012046_04
TS23: rest of cerebellum mantle layer Moderate Uniform euxassay_012046_04
TS23: telencephalon mantle layer Moderate Uniform euxassay_012046_04

Specimen euxassay_012046_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: exoccipital bone Weak Regionally restricted euxassay_012046_05
TS23: stomach Strong Regionally restricted euxassay_012046_05
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_012046_05
TS23: facial ganglion Moderate Regionally restricted euxassay_012046_05
TS23: vibrissa Moderate Regionally restricted euxassay_012046_05
TS23: epidermis Moderate Regionally restricted euxassay_012046_05
TS23: tarsus Moderate Regionally restricted euxassay_012046_05
TS23: liver lobe Moderate Regionally restricted euxassay_012046_05
TS23: rest of cerebellum mantle layer Moderate Uniform euxassay_012046_05
TS23: telencephalon mantle layer Moderate Uniform euxassay_012046_05
TS23: midbrain mantle layer Moderate Uniform euxassay_012046_05

Specimen euxassay_012046_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: orbito-sphenoid Weak Regionally restricted euxassay_012046_06
TS23: stomach Strong Regionally restricted euxassay_012046_06
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_012046_06
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_012046_06
TS23: glossopharyngeal ganglion Weak Regionally restricted euxassay_012046_06
TS23: epidermis Moderate Regionally restricted euxassay_012046_06
TS23: vibrissa Moderate Regionally restricted euxassay_012046_06
TS23: liver lobe Moderate Regionally restricted euxassay_012046_06
TS23: midbrain mantle layer Moderate Uniform euxassay_012046_06
TS23: rest of cerebellum mantle layer Moderate Uniform euxassay_012046_06
TS23: telencephalon mantle layer Moderate Uniform euxassay_012046_06

Specimen euxassay_012046_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: orbito-sphenoid Weak Regionally restricted euxassay_012046_07
TS23: turbinate bone primordium Weak Regionally restricted euxassay_012046_07
TS23: stomach Strong Regionally restricted euxassay_012046_07
TS23: upper jaw molar Moderate Regionally restricted euxassay_012046_07
TS23: lower jaw molar Moderate Regionally restricted euxassay_012046_07
TS23: pancreas Strong Regionally restricted euxassay_012046_07
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_012046_07
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_012046_07
TS23: glossopharyngeal ganglion Moderate Regionally restricted euxassay_012046_07
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_012046_07
TS23: metanephros Moderate Regionally restricted euxassay_012046_07
TS23: vibrissa Moderate Regionally restricted euxassay_012046_07
TS23: epidermis Moderate Regionally restricted euxassay_012046_07
TS23: rib Weak Regionally restricted euxassay_012046_07
TS23: liver lobe Moderate Regionally restricted euxassay_012046_07
TS23: midbrain mantle layer Moderate Uniform euxassay_012046_07
TS23: rest of cerebellum mantle layer Moderate Uniform euxassay_012046_07
TS23: telencephalon mantle layer Moderate Uniform euxassay_012046_07
TS23: diencephalon lateral wall mantle layer Moderate Uniform euxassay_012046_07
TS23: pons mantle layer Moderate Uniform euxassay_012046_07

Specimen euxassay_012046_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: turbinate bone primordium Moderate Regionally restricted euxassay_012046_08
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_012046_08
TS23: stomach Strong Regionally restricted euxassay_012046_08
TS23: lower jaw molar Moderate Regionally restricted euxassay_012046_08
TS23: upper jaw molar Moderate Regionally restricted euxassay_012046_08
TS23: pancreas Strong Regionally restricted euxassay_012046_08
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_012046_08
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_012046_08
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_012046_08
TS23: metanephros Moderate Regionally restricted euxassay_012046_08
TS23: epidermis Moderate Regionally restricted euxassay_012046_08
TS23: rib Moderate Regionally restricted euxassay_012046_08
TS23: liver lobe Moderate Regionally restricted euxassay_012046_08
TS23: diencephalon lateral wall mantle layer Moderate Uniform euxassay_012046_08
TS23: telencephalon mantle layer Moderate Uniform euxassay_012046_08
TS23: rest of cerebellum mantle layer Moderate Uniform euxassay_012046_08
TS23: pons mantle layer Moderate Uniform euxassay_012046_08
TS23: midbrain mantle layer Moderate Uniform euxassay_012046_08
TS23: spinal cord mantle layer Moderate Uniform euxassay_012046_08

Specimen euxassay_012046_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: turbinate bone primordium Moderate Regionally restricted euxassay_012046_09
TS23: stomach Strong Regionally restricted euxassay_012046_09
TS23: pancreas Strong Regionally restricted euxassay_012046_09
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_012046_09
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_012046_09
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_012046_09
TS23: metanephros Moderate Regionally restricted euxassay_012046_09
TS23: epidermis Moderate Regionally restricted euxassay_012046_09
TS23: rib Moderate Regionally restricted euxassay_012046_09
TS23: clavicle Strong Regionally restricted euxassay_012046_09
TS23: liver lobe Moderate Regionally restricted euxassay_012046_09
TS23: diencephalon lateral wall mantle layer Moderate Uniform euxassay_012046_09
TS23: telencephalon mantle layer Moderate Uniform euxassay_012046_09
TS23: rest of cerebellum mantle layer Moderate Uniform euxassay_012046_09
TS23: pons mantle layer Moderate Uniform euxassay_012046_09
TS23: midbrain mantle layer Moderate Uniform euxassay_012046_09
TS23: spinal cord mantle layer Moderate Uniform euxassay_012046_09

Specimen euxassay_012046_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: stomach Strong Regionally restricted euxassay_012046_10
TS23: lower jaw incisor Moderate Regionally restricted euxassay_012046_10
TS23: pancreas Strong Regionally restricted euxassay_012046_10
TS23: olfactory epithelium Moderate Regionally restricted euxassay_012046_10
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_012046_10
TS23: metanephros Moderate Regionally restricted euxassay_012046_10
TS23: epidermis Moderate Regionally restricted euxassay_012046_10
TS23: rib Moderate Regionally restricted euxassay_012046_10
TS23: pituitary gland Moderate Regionally restricted euxassay_012046_10
TS23: liver lobe Moderate Regionally restricted euxassay_012046_10
TS23: midbrain mantle layer Moderate Uniform euxassay_012046_10
TS23: pons mantle layer Moderate Uniform euxassay_012046_10
TS23: rest of cerebellum mantle layer Moderate Uniform euxassay_012046_10
TS23: telencephalon mantle layer Moderate Uniform euxassay_012046_10
TS23: diencephalon lateral wall mantle layer Moderate Uniform euxassay_012046_10
TS23: spinal cord mantle layer Moderate Uniform euxassay_012046_10

Specimen euxassay_012046_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: thymus primordium Moderate Regionally restricted euxassay_012046_11
TS23: thyroid gland Weak Regionally restricted euxassay_012046_11
TS23: upper jaw incisor Moderate Regionally restricted euxassay_012046_11
TS23: lower jaw incisor Moderate Regionally restricted euxassay_012046_11
TS23: pancreas Strong Regionally restricted euxassay_012046_11
TS23: olfactory epithelium Moderate Regionally restricted euxassay_012046_11
TS23: naris Moderate Regionally restricted euxassay_012046_11
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_012046_11
TS23: metanephros Moderate Regionally restricted euxassay_012046_11
TS23: epidermis Moderate Regionally restricted euxassay_012046_11
TS23: rib Moderate Regionally restricted euxassay_012046_11
TS23: pituitary gland Moderate Regionally restricted euxassay_012046_11
TS23: liver lobe Moderate Regionally restricted euxassay_012046_11
TS23: diencephalon lateral wall mantle layer Moderate Uniform euxassay_012046_11
TS23: telencephalon mantle layer Moderate Uniform euxassay_012046_11
TS23: rest of cerebellum mantle layer Moderate Uniform euxassay_012046_11
TS23: pons mantle layer Moderate Uniform euxassay_012046_11
TS23: midbrain mantle layer Moderate Uniform euxassay_012046_11
TS23: spinal cord mantle layer Moderate Uniform euxassay_012046_11

Specimen euxassay_012046_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: thymus primordium Moderate Regionally restricted euxassay_012046_12
TS23: lower jaw incisor Moderate Regionally restricted euxassay_012046_12
TS23: upper jaw incisor Moderate Regionally restricted euxassay_012046_12
TS23: pancreas Strong Regionally restricted euxassay_012046_12
TS23: olfactory epithelium Moderate Regionally restricted euxassay_012046_12
TS23: naris Moderate Regionally restricted euxassay_012046_12
TS23: larynx Moderate Regionally restricted euxassay_012046_12
TS23: trachea Weak Regionally restricted euxassay_012046_12
TS23: esophagus Moderate Regionally restricted euxassay_012046_12
TS23: epidermis Moderate Regionally restricted euxassay_012046_12
TS23: pituitary gland Moderate Regionally restricted euxassay_012046_12
TS23: liver lobe Moderate Regionally restricted euxassay_012046_12
TS23: midbrain mantle layer Moderate Uniform euxassay_012046_12
TS23: pons mantle layer Moderate Uniform euxassay_012046_12
TS23: rest of cerebellum mantle layer Moderate Uniform euxassay_012046_12
TS23: telencephalon mantle layer Moderate Uniform euxassay_012046_12
TS23: diencephalon lateral wall mantle layer Moderate Uniform euxassay_012046_12
TS23: spinal cord mantle layer Moderate Uniform euxassay_012046_12

Specimen euxassay_012046_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: thymus primordium Moderate Regionally restricted euxassay_012046_13
TS23: midgut Strong Regionally restricted euxassay_012046_13
TS23: rectum Strong Regionally restricted euxassay_012046_13
TS23: lower jaw incisor Strong Regionally restricted euxassay_012046_13
TS23: pancreas Strong Regionally restricted euxassay_012046_13
TS23: larynx Moderate Regionally restricted euxassay_012046_13
TS23: trachea Moderate Regionally restricted euxassay_012046_13
TS23: esophagus Moderate Regionally restricted euxassay_012046_13
TS23: bladder fundus Strong Regionally restricted euxassay_012046_13
TS23: urethra Strong Regionally restricted euxassay_012046_13 Originally this result was annotated to a male-specific term, but as the specimen was not sexed, it is likely the data annotator intended to use a non-gender specific term.
TS23: epidermis Moderate Regionally restricted euxassay_012046_13
TS23: pituitary gland Moderate Regionally restricted euxassay_012046_13
TS23: liver lobe Moderate Regionally restricted euxassay_012046_13
TS23: midbrain mantle layer Moderate Uniform euxassay_012046_13
TS23: pons mantle layer Moderate Uniform euxassay_012046_13
TS23: rest of cerebellum mantle layer Moderate Uniform euxassay_012046_13
TS23: telencephalon mantle layer Moderate Uniform euxassay_012046_13
TS23: diencephalon lateral wall mantle layer Moderate Uniform euxassay_012046_13
TS23: spinal cord mantle layer Moderate Uniform euxassay_012046_13

Specimen euxassay_012046_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: thymus primordium Moderate Regionally restricted euxassay_012046_14
TS23: midgut Strong Regionally restricted euxassay_012046_14
TS23: rectum Strong Regionally restricted euxassay_012046_14
TS23: lower jaw incisor Moderate Regionally restricted euxassay_012046_14
TS23: pancreas Strong Regionally restricted euxassay_012046_14
TS23: naris Moderate Regionally restricted euxassay_012046_14
TS23: bladder fundus Strong Regionally restricted euxassay_012046_14
TS23: epidermis Moderate Regionally restricted euxassay_012046_14
TS23: rib Moderate Regionally restricted euxassay_012046_14
TS23: pituitary gland Moderate Regionally restricted euxassay_012046_14
TS23: liver lobe Moderate Regionally restricted euxassay_012046_14
TS23: diencephalon lateral wall mantle layer Moderate Uniform euxassay_012046_14
TS23: telencephalon mantle layer Moderate Uniform euxassay_012046_14
TS23: rest of cerebellum mantle layer Moderate Uniform euxassay_012046_14
TS23: pons mantle layer Moderate Uniform euxassay_012046_14
TS23: midbrain mantle layer Moderate Uniform euxassay_012046_14
TS23: spinal cord mantle layer Moderate Uniform euxassay_012046_14

Specimen euxassay_012046_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: thymus primordium Moderate Regionally restricted euxassay_012046_15
TS23: thyroid gland Weak Regionally restricted euxassay_012046_15
TS23: midgut Strong Regionally restricted euxassay_012046_15
TS23: upper jaw incisor Moderate Regionally restricted euxassay_012046_15
TS23: lower jaw incisor Moderate Regionally restricted euxassay_012046_15
TS23: pancreas Strong Regionally restricted euxassay_012046_15
TS23: olfactory epithelium Moderate Regionally restricted euxassay_012046_15
TS23: naris Moderate Regionally restricted euxassay_012046_15
TS23: epidermis Moderate Regionally restricted euxassay_012046_15
TS23: rib Moderate Regionally restricted euxassay_012046_15
TS23: pituitary gland Moderate Regionally restricted euxassay_012046_15
TS23: liver lobe Moderate Regionally restricted euxassay_012046_15
TS23: midbrain mantle layer Moderate Uniform euxassay_012046_15
TS23: pons mantle layer Moderate Uniform euxassay_012046_15
TS23: rest of cerebellum mantle layer Moderate Uniform euxassay_012046_15
TS23: telencephalon mantle layer Moderate Uniform euxassay_012046_15
TS23: diencephalon lateral wall mantle layer Moderate Uniform euxassay_012046_15
TS23: spinal cord mantle layer Moderate Uniform euxassay_012046_15

Specimen euxassay_012046_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: midgut Strong Regionally restricted euxassay_012046_16
TS23: lower jaw incisor Moderate Regionally restricted euxassay_012046_16
TS23: upper jaw incisor Moderate Regionally restricted euxassay_012046_16
TS23: pancreas Strong Regionally restricted euxassay_012046_16
TS23: olfactory epithelium Moderate Regionally restricted euxassay_012046_16
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_012046_16
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_012046_16
TS23: epidermis Moderate Regionally restricted euxassay_012046_16
TS23: rib Weak Regionally restricted euxassay_012046_16
TS23: clavicle Strong Regionally restricted euxassay_012046_16
TS23: liver lobe Moderate Regionally restricted euxassay_012046_16
TS23: midbrain mantle layer Moderate Uniform euxassay_012046_16
TS23: pons mantle layer Moderate Uniform euxassay_012046_16
TS23: rest of cerebellum mantle layer Moderate Uniform euxassay_012046_16
TS23: telencephalon mantle layer Moderate Uniform euxassay_012046_16
TS23: diencephalon lateral wall mantle layer Moderate Uniform euxassay_012046_16
TS23: spinal cord mantle layer Moderate Uniform euxassay_012046_16

Specimen euxassay_012046_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: turbinate bone primordium Moderate Regionally restricted euxassay_012046_17
TS23: midgut Strong Regionally restricted euxassay_012046_17
TS23: pancreas Strong Regionally restricted euxassay_012046_17
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_012046_17
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_012046_17
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_012046_17
TS23: metanephros Weak Regionally restricted euxassay_012046_17
TS23: epidermis Moderate Regionally restricted euxassay_012046_17
TS23: rib Weak Regionally restricted euxassay_012046_17
TS23: liver lobe Moderate Regionally restricted euxassay_012046_17
TS23: midbrain mantle layer Moderate Uniform euxassay_012046_17
TS23: pons mantle layer Moderate Uniform euxassay_012046_17
TS23: rest of cerebellum mantle layer Moderate Uniform euxassay_012046_17
TS23: telencephalon mantle layer Moderate Uniform euxassay_012046_17
TS23: diencephalon lateral wall mantle layer Moderate Uniform euxassay_012046_17
TS23: spinal cord mantle layer Moderate Uniform euxassay_012046_17

Specimen euxassay_012046_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: turbinate bone primordium Moderate Regionally restricted euxassay_012046_18
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_012046_18
TS23: midgut Strong Regionally restricted euxassay_012046_18
TS23: lower jaw molar Moderate Regionally restricted euxassay_012046_18
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_012046_18
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_012046_18
TS23: glossopharyngeal ganglion Moderate Regionally restricted euxassay_012046_18
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_012046_18
TS23: metanephros Weak Regionally restricted euxassay_012046_18
TS23: epidermis Moderate Regionally restricted euxassay_012046_18
TS23: rib Weak Regionally restricted euxassay_012046_18
TS23: liver lobe Moderate Regionally restricted euxassay_012046_18
TS23: midbrain mantle layer Moderate Uniform euxassay_012046_18
TS23: pons mantle layer Moderate Uniform euxassay_012046_18
TS23: rest of cerebellum mantle layer Moderate Uniform euxassay_012046_18
TS23: telencephalon mantle layer Moderate Uniform euxassay_012046_18
TS23: diencephalon lateral wall mantle layer Moderate Uniform euxassay_012046_18

Specimen euxassay_012046_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_012046_19
TS23: turbinate bone primordium Moderate Regionally restricted euxassay_012046_19
TS23: exoccipital bone Moderate Regionally restricted euxassay_012046_19
TS23: upper jaw molar Moderate Regionally restricted euxassay_012046_19
TS23: lower jaw molar Moderate Regionally restricted euxassay_012046_19
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_012046_19
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_012046_19
TS23: metanephros Moderate Regionally restricted euxassay_012046_19
TS23: vibrissa Moderate Regionally restricted euxassay_012046_19
TS23: epidermis Moderate Regionally restricted euxassay_012046_19
TS23: rib Weak Regionally restricted euxassay_012046_19
TS23: liver lobe Moderate Regionally restricted euxassay_012046_19
TS23: midbrain mantle layer Moderate Uniform euxassay_012046_19
TS23: pons mantle layer Moderate Uniform euxassay_012046_19
TS23: rest of cerebellum mantle layer Moderate Uniform euxassay_012046_19
TS23: telencephalon mantle layer Moderate Uniform euxassay_012046_19
TS23: diencephalon lateral wall mantle layer Moderate Uniform euxassay_012046_19

Specimen euxassay_012046_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_012046_20
TS23: exoccipital bone Moderate Regionally restricted euxassay_012046_20
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_012046_20
TS23: facial ganglion Moderate Regionally restricted euxassay_012046_20
TS23: metanephros Moderate Regionally restricted euxassay_012046_20
TS23: vibrissa Moderate Regionally restricted euxassay_012046_20
TS23: epidermis Moderate Regionally restricted euxassay_012046_20
TS23: rib Moderate Regionally restricted euxassay_012046_20
TS23: liver lobe Moderate Regionally restricted euxassay_012046_20
TS23: midbrain mantle layer Moderate Uniform euxassay_012046_20
TS23: telencephalon mantle layer Moderate Uniform euxassay_012046_20
TS23: rest of cerebellum mantle layer Moderate Uniform euxassay_012046_20

Specimen euxassay_012046_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_012046_21
TS23: temporal bone Moderate Regionally restricted euxassay_012046_21
TS23: exoccipital bone Moderate Regionally restricted euxassay_012046_21
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_012046_21
TS23: facial ganglion Moderate Regionally restricted euxassay_012046_21
TS23: pharyngo-tympanic tube Weak Regionally restricted euxassay_012046_21
TS23: metanephros Weak Regionally restricted euxassay_012046_21
TS23: vibrissa Moderate Regionally restricted euxassay_012046_21
TS23: epidermis Moderate Regionally restricted euxassay_012046_21
TS23: liver lobe Moderate Regionally restricted euxassay_012046_21
TS23: rest of cerebellum mantle layer Moderate Uniform euxassay_012046_21
TS23: telencephalon mantle layer Moderate Uniform euxassay_012046_21

Specimen euxassay_012046_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: temporal bone petrous part Moderate Regionally restricted euxassay_012046_22
TS23: exoccipital bone Moderate Regionally restricted euxassay_012046_22
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_012046_22
TS23: pharyngo-tympanic tube Weak Regionally restricted euxassay_012046_22
TS23: vibrissa Moderate Regionally restricted euxassay_012046_22
TS23: epidermis Moderate Regionally restricted euxassay_012046_22
TS23: hindlimb digit 1 metatarsal Moderate Regionally restricted euxassay_012046_22
TS23: hindlimb digit 2 metatarsal Moderate Regionally restricted euxassay_012046_22
TS23: hindlimb digit 3 metatarsal Moderate Regionally restricted euxassay_012046_22
TS23: hindlimb digit 4 metatarsal Moderate Regionally restricted euxassay_012046_22
TS23: hindlimb digit 5 metatarsal Moderate Regionally restricted euxassay_012046_22
TS23: liver lobe Moderate Regionally restricted euxassay_012046_22
TS23: telencephalon mantle layer Moderate Uniform euxassay_012046_22

Specimen euxassay_012046_23: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Strong Regionally restricted euxassay_012046_23
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_012046_23
TS23: temporal bone petrous part Moderate Regionally restricted euxassay_012046_23
TS23: exoccipital bone Moderate Regionally restricted euxassay_012046_23
TS23: pharyngo-tympanic tube Moderate Regionally restricted euxassay_012046_23
TS23: vibrissa Moderate Regionally restricted euxassay_012046_23
TS23: epidermis Moderate Regionally restricted euxassay_012046_23
TS23: tarsus Moderate Regionally restricted euxassay_012046_23
TS23: hindlimb digit 2 metatarsal Moderate Regionally restricted euxassay_012046_23
TS23: hindlimb digit 3 metatarsal Moderate Regionally restricted euxassay_012046_23
TS23: hindlimb digit 4 metatarsal Moderate Regionally restricted euxassay_012046_23
TS23: liver lobe Moderate Regionally restricted euxassay_012046_23
TS23: cornea epithelium Moderate Regionally restricted euxassay_012046_23
TS23: telencephalon mantle layer Moderate Uniform euxassay_012046_23

Specimen euxassay_012046_24: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Strong Regionally restricted euxassay_012046_24
TS23: exoccipital bone Moderate Regionally restricted euxassay_012046_24
TS23: temporal bone petrous part Moderate Regionally restricted euxassay_012046_24
TS23: basisphenoid bone Moderate Regionally restricted euxassay_012046_24
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_012046_24
TS23: pharyngo-tympanic tube Moderate Regionally restricted euxassay_012046_24
TS23: epidermis Moderate Regionally restricted euxassay_012046_24
TS23: tarsus Moderate Regionally restricted euxassay_012046_24
TS23: liver lobe Moderate Regionally restricted euxassay_012046_24
TS23: cornea epithelium Moderate Regionally restricted euxassay_012046_24
TS23: telencephalon mantle layer Moderate Uniform euxassay_012046_24


Contributing Projects:
Mouse Genome Database (MGD), Gene Expression Database (GXD), Mouse Models of Human Cancer database (MMHCdb) (formerly Mouse Tumor Biology (MTB)), Gene Ontology (GO)
Citing These Resources
Funding Information
Warranty Disclaimer, Privacy Notice, Licensing, & Copyright
Send questions and comments to User Support.
last database update
10/22/2024
MGI 6.24
The Jackson Laboratory
