Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4824875
Gene symbol: Fkbp9
Gene name: FK506 binding protein 9
Probe: MGC clone 58069
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_007465_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Moderate Regionally restricted euxassay_007465_01
TS23: vault of skull Strong Regionally restricted euxassay_007465_01
TS23: orbito-sphenoid Strong Regionally restricted euxassay_007465_01
TS23: lower jaw incisor Moderate Regionally restricted euxassay_007465_01
TS23: tibia Moderate Regionally restricted euxassay_007465_01
TS23: fibula Moderate Regionally restricted euxassay_007465_01
TS23: radius Moderate Regionally restricted euxassay_007465_01
TS23: ulna Moderate Regionally restricted euxassay_007465_01
Specimen euxassay_007465_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_007465_02
TS23: vault of skull Strong Regionally restricted euxassay_007465_02
TS23: orbito-sphenoid Strong Regionally restricted euxassay_007465_02
TS23: humerus Moderate Regionally restricted euxassay_007465_02
TS23: fibula Moderate Regionally restricted euxassay_007465_02
TS23: tibia Moderate Regionally restricted euxassay_007465_02
TS23: foot mesenchyme Moderate Regionally restricted euxassay_007465_02
Specimen euxassay_007465_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_007465_03
TS23: exoccipital bone Strong Regionally restricted euxassay_007465_03
TS23: vault of skull Strong Regionally restricted euxassay_007465_03
TS23: orbito-sphenoid Strong Regionally restricted euxassay_007465_03
TS23: mandible Weak Regionally restricted euxassay_007465_03
TS23: tibia Moderate Regionally restricted euxassay_007465_03
TS23: fibula Moderate Regionally restricted euxassay_007465_03
TS23: humerus Moderate Regionally restricted euxassay_007465_03
TS23: femur Moderate Regionally restricted euxassay_007465_03
Specimen euxassay_007465_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_007465_04
TS23: temporal bone Strong Regionally restricted euxassay_007465_04
TS23: exoccipital bone Strong Regionally restricted euxassay_007465_04
TS23: vault of skull Strong Regionally restricted euxassay_007465_04
TS23: orbito-sphenoid Strong Regionally restricted euxassay_007465_04
TS23: mandible Weak Regionally restricted euxassay_007465_04
TS23: femur Moderate Regionally restricted euxassay_007465_04
TS23: tibia Moderate Regionally restricted euxassay_007465_04
TS23: humerus Moderate Regionally restricted euxassay_007465_04
Specimen euxassay_007465_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Moderate Regionally restricted euxassay_007465_05
TS23: temporal bone Strong Regionally restricted euxassay_007465_05
TS23: exoccipital bone Strong Regionally restricted euxassay_007465_05
TS23: orbito-sphenoid Strong Regionally restricted euxassay_007465_05
TS23: vault of skull Strong Regionally restricted euxassay_007465_05
TS23: maxilla Weak Regionally restricted euxassay_007465_05
TS23: mandible Weak Regionally restricted euxassay_007465_05
TS23: humerus Moderate Regionally restricted euxassay_007465_05
TS23: foot mesenchyme Moderate Regionally restricted euxassay_007465_05
Specimen euxassay_007465_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Moderate Regionally restricted euxassay_007465_06
TS23: turbinate bone primordium Strong Regionally restricted euxassay_007465_06
TS23: orbito-sphenoid Strong Regionally restricted euxassay_007465_06
TS23: vault of skull Strong Regionally restricted euxassay_007465_06
TS23: temporal bone Strong Regionally restricted euxassay_007465_06
TS23: exoccipital bone Strong Regionally restricted euxassay_007465_06
TS23: maxilla Weak Regionally restricted euxassay_007465_06
TS23: mandible Weak Regionally restricted euxassay_007465_06
TS23: hindlimb digit 1 phalanx Moderate Regionally restricted euxassay_007465_06
TS23: hindlimb digit 2 phalanx Moderate Regionally restricted euxassay_007465_06
TS23: hindlimb digit 3 phalanx Moderate Regionally restricted euxassay_007465_06
TS23: hindlimb digit 4 phalanx Moderate Regionally restricted euxassay_007465_06
Specimen euxassay_007465_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Moderate Regionally restricted euxassay_007465_07
TS23: temporal bone Strong Regionally restricted euxassay_007465_07
TS23: exoccipital bone Strong Regionally restricted euxassay_007465_07
TS23: orbito-sphenoid Strong Regionally restricted euxassay_007465_07
TS23: turbinate bone primordium Strong Regionally restricted euxassay_007465_07
TS23: maxilla Weak Regionally restricted euxassay_007465_07
TS23: mandible Weak Regionally restricted euxassay_007465_07
TS23: hindlimb digit 2 phalanx Moderate Regionally restricted euxassay_007465_07
TS23: hindlimb digit 3 phalanx Moderate Regionally restricted euxassay_007465_07
TS23: hindlimb digit 4 phalanx Moderate Regionally restricted euxassay_007465_07
Specimen euxassay_007465_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: turbinate bone primordium Strong Regionally restricted euxassay_007465_08
TS23: orbito-sphenoid Strong Regionally restricted euxassay_007465_08
TS23: mandible Weak Regionally restricted euxassay_007465_08
TS23: maxilla Weak Regionally restricted euxassay_007465_08
TS23: clavicle Moderate Regionally restricted euxassay_007465_08
TS23: hindlimb digit 2 phalanx Moderate Regionally restricted euxassay_007465_08
Specimen euxassay_007465_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: turbinate bone primordium Strong Regionally restricted euxassay_007465_09
TS23: mandible Weak Regionally restricted euxassay_007465_09
TS23: maxilla Weak Regionally restricted euxassay_007465_09
TS23: clavicle Moderate Regionally restricted euxassay_007465_09
TS23: hindlimb digit 3 phalanx Moderate Regionally restricted euxassay_007465_09
TS23: hindlimb digit 4 phalanx Moderate Regionally restricted euxassay_007465_09
TS23: hindlimb digit 5 phalanx Moderate Regionally restricted euxassay_007465_09
Specimen euxassay_007465_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: axial skeleton Moderate Regionally restricted euxassay_007465_10
TS23: mandible Moderate Regionally restricted euxassay_007465_10
TS23: clavicle Weak Regionally restricted euxassay_007465_10
TS23: nasal septum Strong Regionally restricted euxassay_007465_10
TS23: hindlimb digit 3 phalanx Moderate Regionally restricted euxassay_007465_10
Specimen euxassay_007465_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: axial skeleton Moderate Regionally restricted euxassay_007465_11
TS23: mandible Moderate Regionally restricted euxassay_007465_11
TS23: thyroid cartilage Moderate Regionally restricted euxassay_007465_11
TS23: bladder Moderate Regionally restricted euxassay_007465_11
TS23: nasal septum Strong Regionally restricted euxassay_007465_11
Specimen euxassay_007465_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: axial skeleton Moderate Regionally restricted euxassay_007465_12
TS23: thyroid cartilage Moderate Regionally restricted euxassay_007465_12
TS23: cricoid cartilage Moderate Regionally restricted euxassay_007465_12
TS23: bladder Moderate Regionally restricted euxassay_007465_12
TS23: nasal septum Moderate Regionally restricted euxassay_007465_12
TS23: tail mesenchyme Moderate Regionally restricted euxassay_007465_12
Specimen euxassay_007465_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: nucleus pulposus Strong Regionally restricted euxassay_007465_13
TS23: axial skeleton Moderate Regionally restricted euxassay_007465_13
TS23: orbito-sphenoid Strong Regionally restricted euxassay_007465_13
TS23: upper jaw incisor Moderate Regionally restricted euxassay_007465_13
TS23: lower jaw incisor Moderate Regionally restricted euxassay_007465_13
TS23: thyroid cartilage Moderate Regionally restricted euxassay_007465_13
TS23: sternum Moderate Regionally restricted euxassay_007465_13
TS23: bladder Moderate Regionally restricted euxassay_007465_13
TS23: nasal septum Strong Regionally restricted euxassay_007465_13
TS23: tail mesenchyme Moderate Regionally restricted euxassay_007465_13
Specimen euxassay_007465_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: axial skeleton Moderate Regionally restricted euxassay_007465_14
TS23: orbito-sphenoid Strong Regionally restricted euxassay_007465_14
TS23: thyroid cartilage Moderate Regionally restricted euxassay_007465_14
TS23: sternum Moderate Regionally restricted euxassay_007465_14
TS23: bladder Moderate Regionally restricted euxassay_007465_14
TS23: nasal septum Strong Regionally restricted euxassay_007465_14
Specimen euxassay_007465_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Moderate Regionally restricted euxassay_007465_15
TS23: axial skeleton Moderate Regionally restricted euxassay_007465_15
TS23: mandible Weak Regionally restricted euxassay_007465_15
TS23: thyroid cartilage Moderate Regionally restricted euxassay_007465_15
TS23: axial skeleton tail region Moderate Regionally restricted euxassay_007465_15
Specimen euxassay_007465_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Moderate Regionally restricted euxassay_007465_16
TS23: turbinate bone primordium Strong Regionally restricted euxassay_007465_16
TS23: mandible Weak Regionally restricted euxassay_007465_16
TS23: clavicle Moderate Regionally restricted euxassay_007465_16
TS23: otic capsule Strong Regionally restricted euxassay_007465_16
TS23: tail mesenchyme Moderate Regionally restricted euxassay_007465_16
Specimen euxassay_007465_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Moderate Regionally restricted euxassay_007465_17
TS23: turbinate bone primordium Strong Regionally restricted euxassay_007465_17
TS23: orbito-sphenoid Strong Regionally restricted euxassay_007465_17
TS23: maxilla Weak Regionally restricted euxassay_007465_17
TS23: mandible Weak Regionally restricted euxassay_007465_17
TS23: clavicle Moderate Regionally restricted euxassay_007465_17
TS23: otic capsule Strong Regionally restricted euxassay_007465_17
TS23: tail mesenchyme Moderate Regionally restricted euxassay_007465_17
Specimen euxassay_007465_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: orbito-sphenoid Strong Regionally restricted euxassay_007465_18
TS23: turbinate bone primordium Strong Regionally restricted euxassay_007465_18
TS23: maxilla Weak Regionally restricted euxassay_007465_18
TS23: mandible Weak Regionally restricted euxassay_007465_18
TS23: otic capsule Strong Regionally restricted euxassay_007465_18
Specimen euxassay_007465_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_007465_19
TS23: orbito-sphenoid Strong Regionally restricted euxassay_007465_19
TS23: maxilla Weak Regionally restricted euxassay_007465_19
TS23: mandible Weak Regionally restricted euxassay_007465_19
TS23: otic capsule Strong Regionally restricted euxassay_007465_19
Specimen euxassay_007465_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_007465_20
TS23: orbito-sphenoid Strong Regionally restricted euxassay_007465_20
TS23: vault of skull Strong Regionally restricted euxassay_007465_20
TS23: exoccipital bone Strong Regionally restricted euxassay_007465_20
TS23: mandible Moderate Regionally restricted euxassay_007465_20
TS23: maxilla Moderate Regionally restricted euxassay_007465_20
TS23: otic capsule Strong Regionally restricted euxassay_007465_20
Specimen euxassay_007465_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_007465_21
TS23: temporal bone Strong Regionally restricted euxassay_007465_21
TS23: exoccipital bone Strong Regionally restricted euxassay_007465_21
TS23: vault of skull Strong Regionally restricted euxassay_007465_21
TS23: orbito-sphenoid Strong Regionally restricted euxassay_007465_21
TS23: mandible Moderate Regionally restricted euxassay_007465_21
TS23: hindlimb digit 5 phalanx Moderate Regionally restricted euxassay_007465_21
TS23: hindlimb digit 4 phalanx Moderate Regionally restricted euxassay_007465_21
Specimen euxassay_007465_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_007465_22
TS23: exoccipital bone Strong Regionally restricted euxassay_007465_22
TS23: orbito-sphenoid Strong Regionally restricted euxassay_007465_22
TS23: vault of skull Strong Regionally restricted euxassay_007465_22
TS23: mandible Moderate Regionally restricted euxassay_007465_22
TS23: hindlimb digit 5 phalanx Moderate Regionally restricted euxassay_007465_22
TS23: hindlimb digit 4 phalanx Moderate Regionally restricted euxassay_007465_22
TS23: hindlimb digit 3 phalanx Moderate Regionally restricted euxassay_007465_22
TS23: hindlimb digit 2 phalanx Moderate Regionally restricted euxassay_007465_22
TS23: humerus Moderate Regionally restricted euxassay_007465_22
Specimen euxassay_007465_23: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_007465_23
TS23: exoccipital bone Strong Regionally restricted euxassay_007465_23
TS23: orbito-sphenoid Strong Regionally restricted euxassay_007465_23
TS23: vault of skull Strong Regionally restricted euxassay_007465_23
TS23: hindlimb digit 1 metatarsal Moderate Regionally restricted euxassay_007465_23
TS23: hindlimb digit 1 phalanx Moderate Regionally restricted euxassay_007465_23
TS23: hindlimb digit 2 phalanx Moderate Regionally restricted euxassay_007465_23
TS23: hindlimb digit 2 metatarsal Moderate Regionally restricted euxassay_007465_23
TS23: hindlimb digit 3 phalanx Moderate Regionally restricted euxassay_007465_23
TS23: hindlimb digit 3 metatarsal Moderate Regionally restricted euxassay_007465_23
TS23: hindlimb digit 4 phalanx Moderate Regionally restricted euxassay_007465_23
TS23: hindlimb digit 4 metatarsal Moderate Regionally restricted euxassay_007465_23
TS23: humerus Moderate Regionally restricted euxassay_007465_23
Specimen euxassay_007465_24: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Moderate Regionally restricted euxassay_007465_24
TS23: vault of skull Strong Regionally restricted euxassay_007465_24
TS23: temporal bone Strong Regionally restricted euxassay_007465_24
TS23: orbito-sphenoid Strong Regionally restricted euxassay_007465_24
TS23: hindlimb digit 1 metatarsal Moderate Regionally restricted euxassay_007465_24
TS23: hindlimb digit 2 metatarsal Moderate Regionally restricted euxassay_007465_24
TS23: humerus Moderate Regionally restricted euxassay_007465_24
TS23: tibia Moderate Regionally restricted euxassay_007465_24
TS23: femur Moderate Regionally restricted euxassay_007465_24
Contributing Projects:
Mouse Genome Database (MGD), Gene Expression Database (GXD), Mouse Models of Human Cancer database (MMHCdb) (formerly Mouse Tumor Biology (MTB)), Gene Ontology (GO)
Citing These Resources
Funding Information
Warranty Disclaimer, Privacy Notice, Licensing, & Copyright
Send questions and comments to User Support. 		last database update
01/06/2026
MGI 6.24 		The Jackson Laboratory
