Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4823953
Gene symbol: Cnga2
Gene name: cyclic nucleotide gated channel alpha 2
Probe: MGC clone 54771
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_003698_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_003698_02
Specimen euxassay_003698_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_003698_03
Specimen euxassay_003698_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_003698_04
Specimen euxassay_003698_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_003698_05
Specimen euxassay_003698_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_003698_06
TS23: heart Moderate Regionally restricted euxassay_003698_06
Specimen euxassay_003698_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_003698_07
TS23: heart Moderate Regionally restricted euxassay_003698_07
Specimen euxassay_003698_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_003698_08
TS23: heart Moderate Regionally restricted euxassay_003698_08
Specimen euxassay_003698_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_003698_09
TS23: heart Moderate Regionally restricted euxassay_003698_09
TS23: olfactory epithelium Moderate Regionally restricted euxassay_003698_09
Specimen euxassay_003698_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_003698_10
TS23: heart Moderate Regionally restricted euxassay_003698_10
TS23: olfactory epithelium Moderate Regionally restricted euxassay_003698_10
TS23: urethra Moderate Spotted euxassay_003698_10 Originally this result was annotated to a male-specific term, but as the specimen was not sexed, it is likely the data annotator intended to use a non-sex specific term.
Specimen euxassay_003698_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_003698_11
TS23: heart Moderate Regionally restricted euxassay_003698_11
TS23: olfactory epithelium Moderate Regionally restricted euxassay_003698_11
TS23: urethra Moderate Spotted euxassay_003698_11 Originally this result was annotated to a male-specific term, but as the specimen was not sexed, it is likely the data annotator intended to use a non-sex specific term.
Specimen euxassay_003698_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_003698_12
TS23: heart Moderate Regionally restricted euxassay_003698_12
TS23: olfactory epithelium Moderate Regionally restricted euxassay_003698_12
Specimen euxassay_003698_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_003698_13
TS23: heart Moderate Regionally restricted euxassay_003698_13
TS23: olfactory epithelium Moderate Regionally restricted euxassay_003698_13
Specimen euxassay_003698_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_003698_14
TS23: heart Moderate Regionally restricted euxassay_003698_14
Specimen euxassay_003698_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_003698_15
TS23: heart Moderate Regionally restricted euxassay_003698_15
TS23: olfactory epithelium Moderate Regionally restricted euxassay_003698_15
Specimen euxassay_003698_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_003698_16
TS23: heart Moderate Regionally restricted euxassay_003698_16
TS23: olfactory epithelium Moderate Regionally restricted euxassay_003698_16
Specimen euxassay_003698_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_003698_17
TS23: heart Moderate Regionally restricted euxassay_003698_17
TS23: olfactory epithelium Moderate Regionally restricted euxassay_003698_17
Specimen euxassay_003698_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_003698_18
TS23: olfactory epithelium Moderate Regionally restricted euxassay_003698_18
Specimen euxassay_003698_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_003698_19
Specimen euxassay_003698_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_003698_20
