Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4823719
Gene symbol: Cd2
Gene name: CD2 antigen
Probe: MGC clone 60541
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_013609_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_013609_04
Specimen euxassay_013609_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_013609_06
TS23: lung Weak Regionally restricted euxassay_013609_06
Specimen euxassay_013609_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_013609_07
TS23: lung Moderate Regionally restricted euxassay_013609_07
Specimen euxassay_013609_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_013609_08
TS23: lung Moderate Regionally restricted euxassay_013609_08
Specimen euxassay_013609_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_013609_09
TS23: lung Moderate Regionally restricted euxassay_013609_09
Specimen euxassay_013609_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_013609_10
TS23: lung Moderate Regionally restricted euxassay_013609_10
Specimen euxassay_013609_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_013609_11
TS23: lung Moderate Regionally restricted euxassay_013609_11
Specimen euxassay_013609_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_013609_12
TS23: lung Moderate Regionally restricted euxassay_013609_12
Specimen euxassay_013609_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Weak Regionally restricted euxassay_013609_13
TS23: lung Moderate Regionally restricted euxassay_013609_13
TS23: ventral grey horn Weak Regionally restricted euxassay_013609_13
Specimen euxassay_013609_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_013609_14
TS23: ventral grey horn Weak Regionally restricted euxassay_013609_14
Specimen euxassay_013609_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_013609_15
TS23: ventral grey horn Moderate Regionally restricted euxassay_013609_15
Specimen euxassay_013609_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Weak Regionally restricted euxassay_013609_16
TS23: lung Moderate Regionally restricted euxassay_013609_16
Specimen euxassay_013609_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Moderate Regionally restricted euxassay_013609_17
Specimen euxassay_013609_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Weak Regionally restricted euxassay_013609_18
TS23: lung Moderate Regionally restricted euxassay_013609_18
Specimen euxassay_013609_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_013609_19
TS23: lung Moderate Regionally restricted euxassay_013609_19
Specimen euxassay_013609_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_013609_20
TS23: lung Moderate Regionally restricted euxassay_013609_20
Specimen euxassay_013609_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_013609_21
TS23: lung Moderate Regionally restricted euxassay_013609_21
