Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4823658
Gene symbol: Cbx1
Gene name: chromobox 1
Probe: T30402
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_012256_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Moderate Uniform euxassay_012256_01
TS23: neural retina Weak Regionally restricted euxassay_012256_01
TS23: cranial muscle Weak Regionally restricted euxassay_012256_01
Specimen euxassay_012256_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Moderate Uniform euxassay_012256_02
TS23: orbito-sphenoid Weak Regionally restricted euxassay_012256_02
TS23: cranial muscle Weak Regionally restricted euxassay_012256_02
Specimen euxassay_012256_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Strong Uniform euxassay_012256_03
TS23: orbito-sphenoid Weak Regionally restricted euxassay_012256_03
TS23: temporal bone petrous part Weak Regionally restricted euxassay_012256_03
TS23: vibrissa Weak Regionally restricted euxassay_012256_03
TS23: cranial muscle Weak Regionally restricted euxassay_012256_03
Specimen euxassay_012256_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Strong Uniform euxassay_012256_04
TS23: rest of cerebellum marginal layer Weak Regionally restricted euxassay_012256_04
TS23: temporal bone petrous part Weak Regionally restricted euxassay_012256_04
TS23: vibrissa Weak Regionally restricted euxassay_012256_04
TS23: cranial muscle Weak Regionally restricted euxassay_012256_04
Specimen euxassay_012256_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Strong Uniform euxassay_012256_05
TS23: rest of cerebellum marginal layer Weak Regionally restricted euxassay_012256_05
TS23: upper jaw molar Weak Regionally restricted euxassay_012256_05
TS23: lower jaw molar Weak Regionally restricted euxassay_012256_05
TS23: temporal bone petrous part Weak Regionally restricted euxassay_012256_05
TS23: lung Weak Regionally restricted euxassay_012256_05
TS23: olfactory epithelium Weak Regionally restricted euxassay_012256_05
Specimen euxassay_012256_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Strong Uniform euxassay_012256_06
TS23: rest of cerebellum marginal layer Weak Regionally restricted euxassay_012256_06
TS23: lung Weak Regionally restricted euxassay_012256_06
TS23: olfactory epithelium Weak Regionally restricted euxassay_012256_06
Specimen euxassay_012256_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Strong Uniform euxassay_012256_07
TS23: olfactory cortex ventricular layer Strong Uniform euxassay_012256_07
TS23: rest of cerebellum marginal layer Moderate Regionally restricted euxassay_012256_07
TS23: submandibular gland primordium Strong Regionally restricted euxassay_012256_07
TS23: lung Weak Regionally restricted euxassay_012256_07
TS23: olfactory epithelium Weak Regionally restricted euxassay_012256_07
Specimen euxassay_012256_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Strong Uniform euxassay_012256_08
TS23: olfactory cortex ventricular layer Strong Uniform euxassay_012256_08
TS23: rest of cerebellum marginal layer Moderate Regionally restricted euxassay_012256_08
TS23: renal cortex Strong Regionally restricted euxassay_012256_08
TS23: submandibular gland primordium Strong Regionally restricted euxassay_012256_08
TS23: upper jaw incisor Weak Regionally restricted euxassay_012256_08
TS23: lower jaw incisor Weak Regionally restricted euxassay_012256_08
TS23: lung Weak Regionally restricted euxassay_012256_08
TS23: olfactory epithelium Weak Regionally restricted euxassay_012256_08
Specimen euxassay_012256_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diencephalon lateral wall ventricular layer Strong Uniform euxassay_012256_09
TS23: hypothalamus ventricular layer Strong Uniform euxassay_012256_09
TS23: midbrain ventricular layer Moderate Regionally restricted euxassay_012256_09
TS23: renal cortex Moderate Regionally restricted euxassay_012256_09
TS23: lung Weak Regionally restricted euxassay_012256_09
TS23: pituitary gland Weak Regionally restricted euxassay_012256_09
TS23: olfactory epithelium Weak Regionally restricted euxassay_012256_09
Specimen euxassay_012256_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: olfactory cortex ventricular layer Strong Uniform euxassay_012256_10
TS23: diencephalon lateral wall ventricular layer Strong Uniform euxassay_012256_10
TS23: hypothalamus ventricular layer Strong Uniform euxassay_012256_10
TS23: midbrain ventricular layer Strong Regionally restricted euxassay_012256_10
TS23: thymus primordium Weak Regionally restricted euxassay_012256_10
TS23: upper jaw incisor Weak Regionally restricted euxassay_012256_10
TS23: lung Weak Regionally restricted euxassay_012256_10
TS23: pituitary gland Moderate Regionally restricted euxassay_012256_10
TS23: olfactory epithelium Weak Regionally restricted euxassay_012256_10
Specimen euxassay_012256_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Moderate Uniform euxassay_012256_11
TS23: olfactory cortex ventricular layer Moderate Uniform euxassay_012256_11
TS23: hypothalamus ventricular layer Moderate Uniform euxassay_012256_11
TS23: diencephalon lateral wall marginal layer Moderate Uniform euxassay_012256_11
TS23: midbrain ventricular layer Strong Regionally restricted euxassay_012256_11
TS23: thymus primordium Weak Regionally restricted euxassay_012256_11
TS23: upper jaw incisor Weak Regionally restricted euxassay_012256_11
TS23: lower jaw incisor Weak Regionally restricted euxassay_012256_11
TS23: lung Weak Regionally restricted euxassay_012256_11
TS23: pituitary gland Weak Regionally restricted euxassay_012256_11
TS23: olfactory epithelium Weak Regionally restricted euxassay_012256_11
Specimen euxassay_012256_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: hypothalamus ventricular layer Weak Uniform euxassay_012256_12
TS23: diencephalon lateral wall ventricular layer Weak Uniform euxassay_012256_12
TS23: olfactory cortex ventricular layer Weak Uniform euxassay_012256_12
TS23: telencephalon ventricular layer Weak Uniform euxassay_012256_12
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_012256_12
TS23: thymus primordium Weak Regionally restricted euxassay_012256_12
TS23: lower jaw incisor Weak Regionally restricted euxassay_012256_12
TS23: upper jaw incisor Weak Regionally restricted euxassay_012256_12
TS23: lung Weak Regionally restricted euxassay_012256_12
TS23: pituitary gland Weak Regionally restricted euxassay_012256_12
Specimen euxassay_012256_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Moderate Uniform euxassay_012256_13
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_012256_13
TS23: thymus primordium Weak Regionally restricted euxassay_012256_13
TS23: lung Weak Regionally restricted euxassay_012256_13
TS23: pituitary gland Weak Regionally restricted euxassay_012256_13
TS23: olfactory epithelium Weak Regionally restricted euxassay_012256_13
Specimen euxassay_012256_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Strong Uniform euxassay_012256_14
TS23: rest of cerebellum marginal layer Weak Regionally restricted euxassay_012256_14
TS23: midbrain ventricular layer Strong Regionally restricted euxassay_012256_14
TS23: thymus primordium Moderate Regionally restricted euxassay_012256_14
TS23: lung Weak Regionally restricted euxassay_012256_14
TS23: olfactory epithelium Weak Regionally restricted euxassay_012256_14
Specimen euxassay_012256_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Moderate Uniform euxassay_012256_15
TS23: rest of cerebellum marginal layer Weak Regionally restricted euxassay_012256_15
TS23: midbrain ventricular layer Strong Regionally restricted euxassay_012256_15
TS23: renal cortex Moderate Regionally restricted euxassay_012256_15
TS23: submandibular gland primordium Strong Regionally restricted euxassay_012256_15
TS23: lung Weak Regionally restricted euxassay_012256_15
TS23: vibrissa Weak Regionally restricted euxassay_012256_15
Specimen euxassay_012256_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Moderate Uniform euxassay_012256_16
TS23: rest of cerebellum marginal layer Weak Regionally restricted euxassay_012256_16
TS23: midbrain ventricular layer Moderate Regionally restricted euxassay_012256_16
TS23: renal cortex Strong Regionally restricted euxassay_012256_16
TS23: submandibular gland primordium Strong Regionally restricted euxassay_012256_16
TS23: upper jaw molar Moderate Regionally restricted euxassay_012256_16
TS23: lower jaw molar Moderate Regionally restricted euxassay_012256_16
TS23: lung Weak Regionally restricted euxassay_012256_16
TS23: vibrissa Weak Regionally restricted euxassay_012256_16
Specimen euxassay_012256_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Moderate Uniform euxassay_012256_17
TS23: rest of cerebellum marginal layer Weak Regionally restricted euxassay_012256_17
TS23: midbrain ventricular layer Moderate Regionally restricted euxassay_012256_17
TS23: renal cortex Strong Regionally restricted euxassay_012256_17
TS23: submandibular gland primordium Strong Regionally restricted euxassay_012256_17
TS23: orbito-sphenoid Weak Regionally restricted euxassay_012256_17
TS23: lung Weak Regionally restricted euxassay_012256_17
TS23: vibrissa Weak Regionally restricted euxassay_012256_17
Specimen euxassay_012256_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Strong Uniform euxassay_012256_18
TS23: rest of cerebellum marginal layer Moderate Regionally restricted euxassay_012256_18
TS23: renal cortex Strong Regionally restricted euxassay_012256_18
TS23: orbito-sphenoid Weak Regionally restricted euxassay_012256_18
TS23: lung Weak Regionally restricted euxassay_012256_18
TS23: cranial muscle Weak Regionally restricted euxassay_012256_18
Specimen euxassay_012256_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Strong Uniform euxassay_012256_19
TS23: rest of cerebellum marginal layer Moderate Regionally restricted euxassay_012256_19
TS23: neural retina Weak Regionally restricted euxassay_012256_19
TS23: orbito-sphenoid Weak Regionally restricted euxassay_012256_19
TS23: lung Weak Regionally restricted euxassay_012256_19
TS23: cranial muscle Weak Regionally restricted euxassay_012256_19
Specimen euxassay_012256_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Strong Uniform euxassay_012256_20
TS23: rest of cerebellum marginal layer Moderate Regionally restricted euxassay_012256_20
TS23: neural retina Weak Regionally restricted euxassay_012256_20
TS23: orbito-sphenoid Weak Regionally restricted euxassay_012256_20
TS23: temporal bone petrous part Weak Regionally restricted euxassay_012256_20
TS23: lung Weak Regionally restricted euxassay_012256_20
TS23: cranial muscle Weak Regionally restricted euxassay_012256_20
Specimen euxassay_012256_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Strong Uniform euxassay_012256_21
TS23: neural retina Weak Regionally restricted euxassay_012256_21
TS23: temporal bone petrous part Weak Regionally restricted euxassay_012256_21
TS23: lung Weak Regionally restricted euxassay_012256_21
TS23: cranial muscle Weak Regionally restricted euxassay_012256_21
Specimen euxassay_012256_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: temporal bone petrous part Weak Regionally restricted euxassay_012256_22
TS23: cranial muscle Weak Regionally restricted euxassay_012256_22
Contributing Projects:
Mouse Genome Database (MGD), Gene Expression Database (GXD), Mouse Models of Human Cancer database (MMHCdb) (formerly Mouse Tumor Biology (MTB)), Gene Ontology (GO)
Citing These Resources
Funding Information
Warranty Disclaimer, Privacy Notice, Licensing, & Copyright
Send questions and comments to User Support. 		last database update
03/25/2025
MGI 6.24 		The Jackson Laboratory
