Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4823589
Gene symbol: Cadm1
Gene name: cell adhesion molecule 1
Probe: IMAGE clone 5372277
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_002076_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: brain Strong Uniform euxassay_002076_01
TS23: lung Strong Spotted euxassay_002076_01
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_002076_01
TS23: frontal bone primordium Moderate Regionally restricted euxassay_002076_01
TS23: pharyngo-tympanic tube Strong Regionally restricted euxassay_002076_01
TS23: cochlea Moderate Regionally restricted euxassay_002076_01
Specimen euxassay_002076_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: brain Strong Uniform euxassay_002076_02
TS23: trigeminal ganglion Strong Regionally restricted euxassay_002076_02
TS23: renal cortex Strong Regionally restricted euxassay_002076_02
TS23: lung Strong Spotted euxassay_002076_02
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_002076_02
TS23: frontal bone primordium Moderate Regionally restricted euxassay_002076_02
TS23: pharyngo-tympanic tube Strong Regionally restricted euxassay_002076_02
TS23: cochlea Moderate Regionally restricted euxassay_002076_02
Specimen euxassay_002076_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: brain Strong Uniform euxassay_002076_03
TS23: trigeminal ganglion Strong Regionally restricted euxassay_002076_03
TS23: facial ganglion Strong Regionally restricted euxassay_002076_03
TS23: Meckel's cartilage Strong Regionally restricted euxassay_002076_03
TS23: renal cortex Strong Regionally restricted euxassay_002076_03
TS23: lung Strong Spotted euxassay_002076_03
TS23: vibrissa Moderate Regionally restricted euxassay_002076_03
TS23: orbito-sphenoid Strong Regionally restricted euxassay_002076_03
TS23: cochlea Moderate Regionally restricted euxassay_002076_03
Specimen euxassay_002076_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: brain Strong Uniform euxassay_002076_04
TS23: trigeminal ganglion Strong Regionally restricted euxassay_002076_04
TS23: facial ganglion Strong Regionally restricted euxassay_002076_04
TS23: vestibulo-cochlear ganglion Strong Regionally restricted euxassay_002076_04
TS23: Meckel's cartilage Strong Regionally restricted euxassay_002076_04
TS23: renal cortex Strong Regionally restricted euxassay_002076_04
TS23: lung Strong Spotted euxassay_002076_04
TS23: vibrissa Moderate Regionally restricted euxassay_002076_04
TS23: orbito-sphenoid Strong Regionally restricted euxassay_002076_04
TS23: cochlea Moderate Regionally restricted euxassay_002076_04
Specimen euxassay_002076_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: brain Strong Uniform euxassay_002076_05
TS23: trigeminal ganglion Strong Regionally restricted euxassay_002076_05
TS23: facial ganglion Strong Regionally restricted euxassay_002076_05
TS23: glossopharyngeal ganglion Strong Regionally restricted euxassay_002076_05
TS23: vestibulo-cochlear ganglion Strong Regionally restricted euxassay_002076_05
TS23: upper jaw molar Strong Regionally restricted euxassay_002076_05
TS23: Meckel's cartilage Strong Regionally restricted euxassay_002076_05
TS23: renal cortex Strong Regionally restricted euxassay_002076_05
TS23: dorsal root ganglion Strong Regionally restricted euxassay_002076_05
TS23: lung Strong Spotted euxassay_002076_05
TS23: vibrissa Moderate Regionally restricted euxassay_002076_05
TS23: orbito-sphenoid Strong Regionally restricted euxassay_002076_05
TS23: cochlea Moderate Regionally restricted euxassay_002076_05
Specimen euxassay_002076_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: brain Strong Uniform euxassay_002076_06
TS23: spinal cord Strong Uniform euxassay_002076_06
TS23: glossopharyngeal ganglion Strong Regionally restricted euxassay_002076_06
TS23: trigeminal ganglion Strong Regionally restricted euxassay_002076_06
TS23: vestibulo-cochlear ganglion Strong Regionally restricted euxassay_002076_06
TS23: facial ganglion Strong Regionally restricted euxassay_002076_06
TS23: upper jaw molar Strong Regionally restricted euxassay_002076_06
TS23: lower jaw molar Strong Regionally restricted euxassay_002076_06
TS23: Meckel's cartilage Strong Regionally restricted euxassay_002076_06
TS23: renal cortex Strong Regionally restricted euxassay_002076_06
TS23: dorsal root ganglion Strong Regionally restricted euxassay_002076_06
TS23: lung Strong Spotted euxassay_002076_06
TS23: vibrissa Moderate Regionally restricted euxassay_002076_06
TS23: cochlea Moderate Regionally restricted euxassay_002076_06
TS23: submandibular gland primordium Strong Regionally restricted euxassay_002076_06
Specimen euxassay_002076_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: spinal cord Strong Uniform euxassay_002076_07
TS23: brain Strong Uniform euxassay_002076_07
TS23: vagus ganglion Strong Regionally restricted euxassay_002076_07
TS23: trigeminal ganglion Strong Regionally restricted euxassay_002076_07
TS23: vestibulo-cochlear ganglion Strong Regionally restricted euxassay_002076_07
TS23: upper jaw molar Strong Regionally restricted euxassay_002076_07
TS23: lower jaw molar Strong Regionally restricted euxassay_002076_07
TS23: Meckel's cartilage Strong Regionally restricted euxassay_002076_07
TS23: cervico-thoracic ganglion Strong Regionally restricted euxassay_002076_07
TS23: cervical ganglion Strong Regionally restricted euxassay_002076_07
TS23: thoracic ganglion Strong Regionally restricted euxassay_002076_07
TS23: dorsal root ganglion Strong Regionally restricted euxassay_002076_07
TS23: lung Strong Spotted euxassay_002076_07
TS23: vibrissa Moderate Regionally restricted euxassay_002076_07
TS23: olfactory epithelium Strong Regionally restricted euxassay_002076_07
TS23: submandibular gland primordium Strong Regionally restricted euxassay_002076_07
Specimen euxassay_002076_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: spinal cord Strong Uniform euxassay_002076_08
TS23: brain Strong Uniform euxassay_002076_08
TS23: thoracic ganglion Strong Regionally restricted euxassay_002076_08
TS23: cervico-thoracic ganglion Strong Regionally restricted euxassay_002076_08
TS23: lung Moderate Spotted euxassay_002076_08
TS23: olfactory epithelium Strong Regionally restricted euxassay_002076_08
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_002076_08
Specimen euxassay_002076_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: spinal cord Strong Uniform euxassay_002076_09
TS23: brain Strong Uniform euxassay_002076_09
TS23: upper jaw incisor Strong Regionally restricted euxassay_002076_09
TS23: lower jaw incisor Strong Regionally restricted euxassay_002076_09
TS23: Meckel's cartilage Strong Regionally restricted euxassay_002076_09
TS23: thoracic ganglion Strong Regionally restricted euxassay_002076_09
TS23: urethra Moderate Regionally restricted euxassay_002076_09 Originally this result was annotated to a male-specific term, but as the specimen was not sexed, it is likely the data annotator intended to use a non-sex specific term.
TS23: lung Moderate Spotted euxassay_002076_09
TS23: olfactory epithelium Strong Regionally restricted euxassay_002076_09
TS23: pituitary gland Strong Regionally restricted euxassay_002076_09
Specimen euxassay_002076_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: spinal cord Strong Uniform euxassay_002076_10
TS23: brain Strong Uniform euxassay_002076_10
TS23: lower jaw incisor Strong Regionally restricted euxassay_002076_10
TS23: upper jaw incisor Strong Regionally restricted euxassay_002076_10
TS23: thoracic ganglion Strong Regionally restricted euxassay_002076_10
TS23: dorsal root ganglion Strong Regionally restricted euxassay_002076_10
TS23: urethra Moderate Regionally restricted euxassay_002076_10 Originally this result was annotated to a male-specific term, but as the specimen was not sexed, it is likely the data annotator intended to use a non-sex specific term.
TS23: lung Strong Spotted euxassay_002076_10
TS23: olfactory epithelium Strong Regionally restricted euxassay_002076_10
TS23: pituitary gland Strong Regionally restricted euxassay_002076_10
TS23: trachea Moderate Regionally restricted euxassay_002076_10
Specimen euxassay_002076_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: spinal cord Strong Uniform euxassay_002076_11
TS23: brain Strong Uniform euxassay_002076_11
TS23: upper jaw molar Strong Regionally restricted euxassay_002076_11
TS23: renal cortex Strong Regionally restricted euxassay_002076_11
TS23: dorsal root ganglion Strong Regionally restricted euxassay_002076_11
TS23: urethra Moderate Regionally restricted euxassay_002076_11 Originally this result was annotated to a male-specific term, but as the specimen was not sexed, it is likely the data annotator intended to use a non-sex specific term.
TS23: lung Strong Spotted euxassay_002076_11
TS23: olfactory epithelium Strong Regionally restricted euxassay_002076_11
TS23: pituitary gland Strong Regionally restricted euxassay_002076_11
TS23: trachea Strong Regionally restricted euxassay_002076_11
Specimen euxassay_002076_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: spinal cord Strong Uniform euxassay_002076_12
TS23: brain Strong Uniform euxassay_002076_12
TS23: renal cortex Strong Regionally restricted euxassay_002076_12
TS23: dorsal root ganglion Strong Regionally restricted euxassay_002076_12
TS23: lung Strong Spotted euxassay_002076_12
TS23: pituitary gland Strong Regionally restricted euxassay_002076_12
Specimen euxassay_002076_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: spinal cord Strong Uniform euxassay_002076_13
TS23: brain Strong Uniform euxassay_002076_13
TS23: lower jaw incisor Strong Regionally restricted euxassay_002076_13
TS23: upper jaw incisor Strong Regionally restricted euxassay_002076_13
TS23: renal cortex Strong Regionally restricted euxassay_002076_13
TS23: cervico-thoracic ganglion Strong Regionally restricted euxassay_002076_13
TS23: dorsal root ganglion Strong Regionally restricted euxassay_002076_13
TS23: lung Strong Spotted euxassay_002076_13
TS23: olfactory epithelium Strong Regionally restricted euxassay_002076_13
TS23: pituitary gland Strong Regionally restricted euxassay_002076_13
Specimen euxassay_002076_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: brain Strong Uniform euxassay_002076_14
TS23: upper jaw incisor Strong Regionally restricted euxassay_002076_14
TS23: lower jaw incisor Strong Regionally restricted euxassay_002076_14
TS23: Meckel's cartilage Strong Regionally restricted euxassay_002076_14
TS23: renal cortex Strong Regionally restricted euxassay_002076_14
TS23: cervical ganglion Strong Regionally restricted euxassay_002076_14
TS23: dorsal root ganglion Strong Regionally restricted euxassay_002076_14
TS23: lung Strong Spotted euxassay_002076_14
TS23: olfactory epithelium Strong Regionally restricted euxassay_002076_14
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_002076_14
Specimen euxassay_002076_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: brain Strong Uniform euxassay_002076_15
TS23: vagus ganglion Strong Regionally restricted euxassay_002076_15
TS23: trigeminal ganglion Strong Regionally restricted euxassay_002076_15
TS23: vestibulo-cochlear ganglion Strong Regionally restricted euxassay_002076_15
TS23: upper jaw molar Strong Regionally restricted euxassay_002076_15
TS23: lower jaw molar Strong Regionally restricted euxassay_002076_15
TS23: Meckel's cartilage Strong Regionally restricted euxassay_002076_15
TS23: dorsal root ganglion Strong Regionally restricted euxassay_002076_15
TS23: lung Strong Spotted euxassay_002076_15
TS23: olfactory epithelium Strong Regionally restricted euxassay_002076_15
TS23: submandibular gland primordium Strong Regionally restricted euxassay_002076_15
Specimen euxassay_002076_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: brain Strong Uniform euxassay_002076_16
TS23: glossopharyngeal ganglion Strong Regionally restricted euxassay_002076_16
TS23: trigeminal ganglion Strong Regionally restricted euxassay_002076_16
TS23: vestibulo-cochlear ganglion Strong Regionally restricted euxassay_002076_16
TS23: upper jaw molar Strong Regionally restricted euxassay_002076_16
TS23: lower jaw molar Strong Regionally restricted euxassay_002076_16
TS23: Meckel's cartilage Strong Regionally restricted euxassay_002076_16
TS23: lung Strong Spotted euxassay_002076_16
TS23: olfactory epithelium Strong Regionally restricted euxassay_002076_16
TS23: cochlea Moderate Regionally restricted euxassay_002076_16
TS23: submandibular gland primordium Strong Regionally restricted euxassay_002076_16
Specimen euxassay_002076_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: brain Strong Uniform euxassay_002076_17
TS23: trigeminal ganglion Strong Regionally restricted euxassay_002076_17
TS23: facial ganglion Strong Regionally restricted euxassay_002076_17
TS23: vestibulo-cochlear ganglion Strong Regionally restricted euxassay_002076_17
TS23: glossopharyngeal ganglion Strong Regionally restricted euxassay_002076_17
TS23: upper jaw molar Strong Regionally restricted euxassay_002076_17
TS23: lower jaw molar Strong Regionally restricted euxassay_002076_17
TS23: Meckel's cartilage Strong Regionally restricted euxassay_002076_17
TS23: lung Strong Spotted euxassay_002076_17
TS23: olfactory epithelium Strong Regionally restricted euxassay_002076_17
TS23: cochlea Moderate Regionally restricted euxassay_002076_17
Specimen euxassay_002076_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: brain Strong Uniform euxassay_002076_18
TS23: trigeminal ganglion Strong Regionally restricted euxassay_002076_18
TS23: facial ganglion Strong Regionally restricted euxassay_002076_18
TS23: upper jaw molar Strong Regionally restricted euxassay_002076_18
TS23: lower jaw molar Strong Regionally restricted euxassay_002076_18
TS23: Meckel's cartilage Strong Regionally restricted euxassay_002076_18
TS23: lung Strong Spotted euxassay_002076_18
TS23: vibrissa Moderate Regionally restricted euxassay_002076_18
TS23: cochlea Moderate Regionally restricted euxassay_002076_18
Specimen euxassay_002076_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: brain Strong Uniform euxassay_002076_19
TS23: trigeminal ganglion Strong Regionally restricted euxassay_002076_19
TS23: facial ganglion Strong Regionally restricted euxassay_002076_19
TS23: upper jaw molar Strong Regionally restricted euxassay_002076_19
TS23: Meckel's cartilage Strong Regionally restricted euxassay_002076_19
TS23: lung Strong Spotted euxassay_002076_19
TS23: vibrissa Moderate Regionally restricted euxassay_002076_19
TS23: orbito-sphenoid Strong Regionally restricted euxassay_002076_19
Specimen euxassay_002076_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: brain Strong Uniform euxassay_002076_20
TS23: trigeminal ganglion Strong Regionally restricted euxassay_002076_20
TS23: Meckel's cartilage Strong Regionally restricted euxassay_002076_20
TS23: vibrissa Moderate Regionally restricted euxassay_002076_20
TS23: orbito-sphenoid Strong Regionally restricted euxassay_002076_20
Specimen euxassay_002076_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: brain Strong Uniform euxassay_002076_21
TS23: Meckel's cartilage Strong Regionally restricted euxassay_002076_21
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_002076_21
TS23: frontal bone primordium Moderate Regionally restricted euxassay_002076_21
TS23: pharyngo-tympanic tube Strong Regionally restricted euxassay_002076_21
Specimen euxassay_002076_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: brain Strong Uniform euxassay_002076_22
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_002076_22
TS23: frontal bone primordium Moderate Regionally restricted euxassay_002076_22
TS23: pharyngo-tympanic tube Strong Regionally restricted euxassay_002076_22
Specimen euxassay_002076_23: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: pharyngo-tympanic tube Strong Regionally restricted euxassay_002076_23
Contributing Projects:
Mouse Genome Database (MGD), Gene Expression Database (GXD), Mouse Models of Human Cancer database (MMHCdb) (formerly Mouse Tumor Biology (MTB)), Gene Ontology (GO)
Citing These Resources
Funding Information
Warranty Disclaimer, Privacy Notice, Licensing, & Copyright
Send questions and comments to User Support. 		last database update
03/25/2025
MGI 6.24 		The Jackson Laboratory
