Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4823395
Gene symbol: Prrc2b
Gene name: proline-rich coiled-coil 2B
Probe: T30390
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_012252_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_012252_01
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_012252_01
Specimen euxassay_012252_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_012252_02
TS23: facial ganglion Moderate Regionally restricted euxassay_012252_02
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_012252_02
Specimen euxassay_012252_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_012252_03
TS23: facial ganglion Moderate Regionally restricted euxassay_012252_03
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_012252_03
Specimen euxassay_012252_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_012252_04
TS23: glossopharyngeal ganglion Moderate Regionally restricted euxassay_012252_04
TS23: vestibulo-cochlear ganglion Moderate Regionally restricted euxassay_012252_04
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_012252_04
Specimen euxassay_012252_05: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_012252_05
TS23: vestibulo-cochlear ganglion Moderate Regionally restricted euxassay_012252_05
TS23: glossopharyngeal ganglion Moderate Regionally restricted euxassay_012252_05
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_012252_05
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_012252_05
TS23: pons mantle layer Moderate Regionally restricted euxassay_012252_05 trigeminal motor nucleus
Specimen euxassay_012252_06: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_012252_06
TS23: vagus ganglion Moderate Regionally restricted euxassay_012252_06
TS23: vestibulo-cochlear ganglion Moderate Regionally restricted euxassay_012252_06
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_012252_06
TS23: olfactory epithelium Moderate Regionally restricted euxassay_012252_06
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_012252_06
TS23: medulla oblongata basal plate mantle layer Moderate Regionally restricted euxassay_012252_06 facial motor nucleus
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_012252_06
Specimen euxassay_012252_07: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: trigeminal nerve Weak Regionally restricted euxassay_012252_07
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_012252_07
TS23: olfactory epithelium Moderate Regionally restricted euxassay_012252_07
TS23: olfactory cortex marginal layer Weak Regionally restricted euxassay_012252_07
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_012252_07
TS23: medulla oblongata basal plate mantle layer Moderate Regionally restricted euxassay_012252_07 facial motor nucleus
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_012252_07
Specimen euxassay_012252_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_012252_08
TS23: olfactory epithelium Moderate Regionally restricted euxassay_012252_08
TS23: olfactory cortex marginal layer Weak Regionally restricted euxassay_012252_08
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_012252_08
TS23: midbrain mantle layer Weak Regionally restricted euxassay_012252_08
TS23: ventral grey horn Moderate Regionally restricted euxassay_012252_08
Specimen euxassay_012252_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_012252_09
TS23: olfactory epithelium Strong Regionally restricted euxassay_012252_09
TS23: olfactory cortex marginal layer Weak Regionally restricted euxassay_012252_09
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_012252_09
TS23: midbrain mantle layer Weak Regionally restricted euxassay_012252_09
TS23: ventral grey horn Weak Regionally restricted euxassay_012252_09
Specimen euxassay_012252_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_012252_10
TS23: olfactory epithelium Strong Regionally restricted euxassay_012252_10
TS23: vomeronasal organ Strong Regionally restricted euxassay_012252_10
TS23: olfactory cortex marginal layer Weak Regionally restricted euxassay_012252_10
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_012252_10
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_012252_10
TS23: ventral grey horn Weak Regionally restricted euxassay_012252_10
Specimen euxassay_012252_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_012252_11
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_012252_11
TS23: ventral grey horn Weak Regionally restricted euxassay_012252_11
Specimen euxassay_012252_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: olfactory epithelium Strong Regionally restricted euxassay_012252_12
TS23: midbrain mantle layer Weak Regionally restricted euxassay_012252_12
TS23: ventral grey horn Weak Regionally restricted euxassay_012252_12
Specimen euxassay_012252_13: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_012252_13
TS23: vomeronasal organ Strong Regionally restricted euxassay_012252_13
TS23: olfactory epithelium Strong Regionally restricted euxassay_012252_13
TS23: olfactory cortex marginal layer Weak Regionally restricted euxassay_012252_13
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_012252_13
TS23: medulla oblongata basal plate mantle layer Moderate Regionally restricted euxassay_012252_13 facial motor nucleus
TS23: midbrain mantle layer Weak Regionally restricted euxassay_012252_13
TS23: ventral grey horn Weak Regionally restricted euxassay_012252_13
Specimen euxassay_012252_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vagus ganglion Moderate Regionally restricted euxassay_012252_14
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_012252_14
TS23: olfactory epithelium Strong Regionally restricted euxassay_012252_14
TS23: olfactory cortex marginal layer Weak Regionally restricted euxassay_012252_14
TS23: cerebral cortex marginal layer Weak Regionally restricted euxassay_012252_14
TS23: ventral grey horn Weak Regionally restricted euxassay_012252_14
Specimen euxassay_012252_15: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_012252_15
TS23: glossopharyngeal ganglion Moderate Regionally restricted euxassay_012252_15
TS23: vestibulo-cochlear ganglion Moderate Regionally restricted euxassay_012252_15
TS23: trigeminal nerve Moderate Regionally restricted euxassay_012252_15
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_012252_15
TS23: olfactory epithelium Moderate Regionally restricted euxassay_012252_15
TS23: cerebral cortex marginal layer Moderate Regionally restricted euxassay_012252_15
TS23: olfactory cortex marginal layer Moderate Regionally restricted euxassay_012252_15
TS23: pons mantle layer Weak Regionally restricted euxassay_012252_15 trigeminal motor nucleus
TS23: ventral grey horn Weak Regionally restricted euxassay_012252_15
Specimen euxassay_012252_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_012252_16
TS23: vestibulo-cochlear ganglion Moderate Regionally restricted euxassay_012252_16
TS23: glossopharyngeal ganglion Moderate Regionally restricted euxassay_012252_16
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_012252_16
TS23: olfactory epithelium Moderate Regionally restricted euxassay_012252_16
TS23: cerebral cortex marginal layer Moderate Regionally restricted euxassay_012252_16
Specimen euxassay_012252_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_012252_17
TS23: facial ganglion Moderate Regionally restricted euxassay_012252_17
TS23: cerebral cortex marginal layer Moderate Regionally restricted euxassay_012252_17
Specimen euxassay_012252_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_012252_18
TS23: facial ganglion Moderate Regionally restricted euxassay_012252_18
TS23: cerebral cortex marginal layer Moderate Regionally restricted euxassay_012252_18
Specimen euxassay_012252_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_012252_19
TS23: cerebral cortex marginal layer Moderate Regionally restricted euxassay_012252_19
Specimen euxassay_012252_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex marginal layer Moderate Regionally restricted euxassay_012252_20
