Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4823128
Gene symbol: Ankrd1
Gene name: ankyrin repeat domain 1
Probe: MGC clone 46879
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_007103_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_007103_01
Specimen euxassay_007103_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_007103_02
Specimen euxassay_007103_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_007103_03
TS23: heart atrium Strong Regionally restricted euxassay_007103_03
Specimen euxassay_007103_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_007103_04
TS23: heart atrium Strong Regionally restricted euxassay_007103_04
Specimen euxassay_007103_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_007103_05
TS23: heart atrium Strong Regionally restricted euxassay_007103_05
Specimen euxassay_007103_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_007103_06
TS23: heart atrium Strong Regionally restricted euxassay_007103_06
Specimen euxassay_007103_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_007103_07
TS23: heart atrium Strong Regionally restricted euxassay_007103_07
TS23: heart left ventricle Moderate Regionally restricted euxassay_007103_07
Specimen euxassay_007103_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_007103_08
TS23: heart left ventricle Moderate Regionally restricted euxassay_007103_08
TS23: heart atrium Strong Regionally restricted euxassay_007103_08
Specimen euxassay_007103_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_007103_09
TS23: heart atrium Strong Regionally restricted euxassay_007103_09
TS23: heart left ventricle Moderate Regionally restricted euxassay_007103_09
Specimen euxassay_007103_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_007103_10
TS23: heart left ventricle Moderate Regionally restricted euxassay_007103_10
TS23: heart atrium Strong Regionally restricted euxassay_007103_10
Specimen euxassay_007103_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_007103_11
TS23: tongue muscle Strong Regionally restricted euxassay_007103_11
TS23: heart atrium Strong Regionally restricted euxassay_007103_11
TS23: heart left ventricle Moderate Regionally restricted euxassay_007103_11
Specimen euxassay_007103_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_007103_12
TS23: tongue muscle Strong Regionally restricted euxassay_007103_12
TS23: heart left ventricle Moderate Regionally restricted euxassay_007103_12
TS23: heart atrium Strong Regionally restricted euxassay_007103_12
Specimen euxassay_007103_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_007103_13
TS23: tongue muscle Strong Regionally restricted euxassay_007103_13
TS23: heart atrium Strong Regionally restricted euxassay_007103_13
TS23: heart right ventricle Strong Regionally restricted euxassay_007103_13
Specimen euxassay_007103_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_007103_14
TS23: tongue muscle Strong Regionally restricted euxassay_007103_14
TS23: heart right ventricle Strong Regionally restricted euxassay_007103_14
TS23: heart atrium Strong Regionally restricted euxassay_007103_14
Specimen euxassay_007103_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_007103_15
TS23: tongue muscle Strong Regionally restricted euxassay_007103_15
TS23: heart atrium Strong Regionally restricted euxassay_007103_15
TS23: heart right ventricle Strong Regionally restricted euxassay_007103_15
Specimen euxassay_007103_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_007103_16
TS23: tongue muscle Moderate Regionally restricted euxassay_007103_16
TS23: heart atrium Strong Regionally restricted euxassay_007103_16
TS23: heart right ventricle Moderate Regionally restricted euxassay_007103_16
Specimen euxassay_007103_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_007103_17
TS23: tongue muscle Moderate Regionally restricted euxassay_007103_17
TS23: heart atrium Strong Regionally restricted euxassay_007103_17
Specimen euxassay_007103_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_007103_18
TS23: heart atrium Strong Regionally restricted euxassay_007103_18
Specimen euxassay_007103_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_007103_19
TS23: heart atrium Strong Regionally restricted euxassay_007103_19
Specimen euxassay_007103_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_007103_20
TS23: heart atrium Strong Regionally restricted euxassay_007103_20
Specimen euxassay_007103_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_007103_21
TS23: heart atrium Strong Regionally restricted euxassay_007103_21
Specimen euxassay_007103_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_007103_22
TS23: heart atrium Strong Regionally restricted euxassay_007103_22
