Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4823066
Gene symbol: Akna
Gene name: AT-hook transcription factor
Probe: T55003
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_019530_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Weak Regionally restricted euxassay_019530_01

Specimen euxassay_019530_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Weak Regionally restricted euxassay_019530_02

Specimen euxassay_019530_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Weak Uniform euxassay_019530_03
TS23: neural retina Weak Regionally restricted euxassay_019530_03

Specimen euxassay_019530_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Weak Uniform euxassay_019530_04

Specimen euxassay_019530_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Weak Uniform euxassay_019530_05

Specimen euxassay_019530_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Weak Uniform euxassay_019530_06

Specimen euxassay_019530_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Moderate Uniform euxassay_019530_07
TS23: rest of cerebellum marginal layer Moderate Regionally restricted euxassay_019530_07

Specimen euxassay_019530_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Weak Uniform euxassay_019530_08
TS23: rest of cerebellum marginal layer Moderate Regionally restricted euxassay_019530_08

Specimen euxassay_019530_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Weak Uniform euxassay_019530_09
TS23: olfactory cortex ventricular layer Weak Uniform euxassay_019530_09
TS23: rest of cerebellum marginal layer Moderate Regionally restricted euxassay_019530_09
TS23: olfactory epithelium Weak Regionally restricted euxassay_019530_09

Specimen euxassay_019530_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Weak Uniform euxassay_019530_10
TS23: olfactory cortex ventricular layer Weak Uniform euxassay_019530_10
TS23: rest of cerebellum marginal layer Moderate Regionally restricted euxassay_019530_10
TS23: olfactory epithelium Weak Regionally restricted euxassay_019530_10

Specimen euxassay_019530_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Weak Uniform euxassay_019530_11
TS23: olfactory cortex ventricular layer Weak Uniform euxassay_019530_11
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_019530_11
TS23: rest of cerebellum marginal layer Moderate Regionally restricted euxassay_019530_11
TS23: olfactory epithelium Weak Regionally restricted euxassay_019530_11

Specimen euxassay_019530_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_019530_12
TS23: diencephalon lateral wall ventricular layer Weak Regionally restricted euxassay_019530_12
TS23: hypothalamus ventricular layer Weak Regionally restricted euxassay_019530_12
TS23: rest of cerebellum marginal layer Weak Regionally restricted euxassay_019530_12

Specimen euxassay_019530_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: thymus primordium Moderate Regionally restricted euxassay_019530_13
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_019530_13
TS23: diencephalon lateral wall ventricular layer Weak Regionally restricted euxassay_019530_13
TS23: hypothalamus ventricular layer Weak Regionally restricted euxassay_019530_13
TS23: rest of cerebellum marginal layer Moderate Regionally restricted euxassay_019530_13

Specimen euxassay_019530_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: thymus primordium Moderate Regionally restricted euxassay_019530_14
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_019530_14
TS23: diencephalon lateral wall ventricular layer Weak Regionally restricted euxassay_019530_14
TS23: hypothalamus ventricular layer Weak Regionally restricted euxassay_019530_14
TS23: rest of cerebellum marginal layer Moderate Regionally restricted euxassay_019530_14
TS23: olfactory epithelium Weak Regionally restricted euxassay_019530_14
TS23: vomeronasal organ Weak Regionally restricted euxassay_019530_14

Specimen euxassay_019530_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: thymus primordium Moderate Regionally restricted euxassay_019530_15
TS23: telencephalon ventricular layer Moderate Uniform euxassay_019530_15
TS23: olfactory cortex ventricular layer Moderate Uniform euxassay_019530_15
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_019530_15
TS23: diencephalon lateral wall ventricular layer Weak Regionally restricted euxassay_019530_15
TS23: hypothalamus ventricular layer Weak Regionally restricted euxassay_019530_15
TS23: olfactory epithelium Weak Regionally restricted euxassay_019530_15

Specimen euxassay_019530_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: thymus primordium Weak Regionally restricted euxassay_019530_16
TS23: olfactory cortex ventricular layer Moderate Uniform euxassay_019530_16
TS23: telencephalon ventricular layer Moderate Uniform euxassay_019530_16
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_019530_16
TS23: rest of cerebellum marginal layer Weak Regionally restricted euxassay_019530_16
TS23: olfactory epithelium Weak Regionally restricted euxassay_019530_16

Specimen euxassay_019530_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: thymus primordium Moderate Regionally restricted euxassay_019530_17
TS23: telencephalon ventricular layer Weak Uniform euxassay_019530_17
TS23: olfactory cortex ventricular layer Weak Uniform euxassay_019530_17
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_019530_17
TS23: rest of cerebellum marginal layer Moderate Regionally restricted euxassay_019530_17
TS23: olfactory epithelium Weak Regionally restricted euxassay_019530_17

Specimen euxassay_019530_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Weak Uniform euxassay_019530_18
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_019530_18
TS23: rest of cerebellum marginal layer Moderate Regionally restricted euxassay_019530_18

Specimen euxassay_019530_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Weak Uniform euxassay_019530_19
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_019530_19
TS23: rest of cerebellum marginal layer Moderate Regionally restricted euxassay_019530_19

Specimen euxassay_019530_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Weak Uniform euxassay_019530_20
TS23: midbrain ventricular layer Weak Regionally restricted euxassay_019530_20
TS23: rest of cerebellum marginal layer Moderate Regionally restricted euxassay_019530_20

Specimen euxassay_019530_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Weak Uniform euxassay_019530_21
TS23: rest of cerebellum marginal layer Moderate Regionally restricted euxassay_019530_21

Specimen euxassay_019530_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Weak Uniform euxassay_019530_22
TS23: rest of cerebellum marginal layer Moderate Regionally restricted euxassay_019530_22

Specimen euxassay_019530_23: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon ventricular layer Weak Uniform euxassay_019530_23
TS23: rest of cerebellum marginal layer Weak Regionally restricted euxassay_019530_23
TS23: neural retina Weak Regionally restricted euxassay_019530_23
