Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4822718
Gene symbol: 4921524J17Rik
Gene name: RIKEN cDNA 4921524J17 gene
Probe: IMAGE clone 483649
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_000571_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: otic capsule Strong Regionally restricted euxassay_000571_01
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_000571_01
TS23: head mesenchyme Moderate Regionally restricted euxassay_000571_01
Specimen euxassay_000571_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: otic capsule Moderate Regionally restricted euxassay_000571_02
TS23: vertebral axis musculature Weak Regionally restricted euxassay_000571_02
TS23: head mesenchyme Moderate Regionally restricted euxassay_000571_02
Specimen euxassay_000571_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: otic capsule Weak Regionally restricted euxassay_000571_03
TS23: vertebral axis musculature Weak Regionally restricted euxassay_000571_03
TS23: lung Weak Regionally restricted euxassay_000571_03
TS23: head mesenchyme Weak Regionally restricted euxassay_000571_03
Specimen euxassay_000571_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: otic capsule Weak Regionally restricted euxassay_000571_04
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_000571_04
TS23: lung Moderate Regionally restricted euxassay_000571_04
TS23: Meckel's cartilage Moderate Regionally restricted euxassay_000571_04
TS23: head mesenchyme Moderate Regionally restricted euxassay_000571_04
Specimen euxassay_000571_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: otic capsule Weak Regionally restricted euxassay_000571_05
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_000571_05
TS23: lung Moderate Regionally restricted euxassay_000571_05
TS23: Meckel's cartilage Moderate Regionally restricted euxassay_000571_05
TS23: head mesenchyme Moderate Regionally restricted euxassay_000571_05
Specimen euxassay_000571_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: otic capsule Weak Regionally restricted euxassay_000571_06
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_000571_06
TS23: lung Moderate Regionally restricted euxassay_000571_06
TS23: Meckel's cartilage Moderate Regionally restricted euxassay_000571_06
TS23: head mesenchyme Moderate Regionally restricted euxassay_000571_06
Specimen euxassay_000571_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Weak Regionally restricted euxassay_000571_07
TS23: lung Weak Regionally restricted euxassay_000571_07
TS23: head mesenchyme Weak Regionally restricted euxassay_000571_07
Specimen euxassay_000571_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_000571_08
TS23: lung Moderate Regionally restricted euxassay_000571_08
TS23: Meckel's cartilage Moderate Regionally restricted euxassay_000571_08
TS23: head mesenchyme Moderate Regionally restricted euxassay_000571_08
TS23: turbinate bone primordium Weak Regionally restricted euxassay_000571_08
Specimen euxassay_000571_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_000571_09
TS23: lung Moderate Regionally restricted euxassay_000571_09
TS23: Meckel's cartilage Moderate Regionally restricted euxassay_000571_09
TS23: head mesenchyme Moderate Regionally restricted euxassay_000571_09
TS23: turbinate bone primordium Weak Regionally restricted euxassay_000571_09
Specimen euxassay_000571_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_000571_10
TS23: lung Moderate Regionally restricted euxassay_000571_10
TS23: lower jaw incisor Moderate Regionally restricted euxassay_000571_10
TS23: head mesenchyme Moderate Regionally restricted euxassay_000571_10
TS23: axial skeleton Moderate Regionally restricted euxassay_000571_10
TS23: turbinate bone primordium Weak Regionally restricted euxassay_000571_10
Specimen euxassay_000571_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_000571_12
TS23: lower jaw incisor Moderate Regionally restricted euxassay_000571_12
TS23: esophagus Moderate Regionally restricted euxassay_000571_12
TS23: axial skeleton Moderate Regionally restricted euxassay_000571_12
TS23: turbinate bone primordium Weak Regionally restricted euxassay_000571_12
Specimen euxassay_000571_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_000571_13
TS23: lower jaw incisor Moderate Regionally restricted euxassay_000571_13
TS23: axial skeleton Moderate Regionally restricted euxassay_000571_13
TS23: urethra Moderate Regionally restricted euxassay_000571_13 Originally this result was annotated to a male-specific term, but as the specimen was not sexed, it is likely the data annotator intended to use a non-sex specific term.
TS23: turbinate bone primordium Weak Regionally restricted euxassay_000571_13
Specimen euxassay_000571_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_000571_14
TS23: lung Moderate Regionally restricted euxassay_000571_14
TS23: lower jaw incisor Moderate Regionally restricted euxassay_000571_14
TS23: axial skeleton Moderate Regionally restricted euxassay_000571_14
TS23: urethra Moderate Regionally restricted euxassay_000571_14 Originally this result was annotated to a male-specific term, but as the specimen was not sexed, it is likely the data annotator intended to use a non-sex specific term.
TS23: turbinate bone primordium Weak Regionally restricted euxassay_000571_14
Specimen euxassay_000571_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lower jaw incisor Weak Regionally restricted euxassay_000571_15
TS23: turbinate bone primordium Weak Regionally restricted euxassay_000571_15
Specimen euxassay_000571_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: otic capsule Weak Regionally restricted euxassay_000571_16
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_000571_16
TS23: lung Moderate Regionally restricted euxassay_000571_16
TS23: Meckel's cartilage Moderate Regionally restricted euxassay_000571_16
TS23: turbinate bone primordium Weak Regionally restricted euxassay_000571_16
Specimen euxassay_000571_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: otic capsule Weak Regionally restricted euxassay_000571_17
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_000571_17
TS23: lung Moderate Regionally restricted euxassay_000571_17
TS23: Meckel's cartilage Moderate Regionally restricted euxassay_000571_17
TS23: head mesenchyme Moderate Regionally restricted euxassay_000571_17
TS23: axial skeleton Moderate Regionally restricted euxassay_000571_17
TS23: turbinate bone primordium Weak Regionally restricted euxassay_000571_17
Specimen euxassay_000571_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: otic capsule Weak Regionally restricted euxassay_000571_18
TS23: vertebral axis musculature Weak Regionally restricted euxassay_000571_18
TS23: lung Moderate Regionally restricted euxassay_000571_18
TS23: Meckel's cartilage Moderate Regionally restricted euxassay_000571_18
TS23: head mesenchyme Moderate Regionally restricted euxassay_000571_18
TS23: turbinate bone primordium Weak Regionally restricted euxassay_000571_18
Specimen euxassay_000571_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: otic capsule Weak Regionally restricted euxassay_000571_19
TS23: Meckel's cartilage Weak Regionally restricted euxassay_000571_19
TS23: head mesenchyme Moderate Regionally restricted euxassay_000571_19
TS23: turbinate bone primordium Weak Regionally restricted euxassay_000571_19
Specimen euxassay_000571_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: otic capsule Weak Regionally restricted euxassay_000571_20
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_000571_20
TS23: lung Moderate Regionally restricted euxassay_000571_20
TS23: Meckel's cartilage Weak Regionally restricted euxassay_000571_20
TS23: head mesenchyme Moderate Regionally restricted euxassay_000571_20
TS23: turbinate bone primordium Weak Regionally restricted euxassay_000571_20
Specimen euxassay_000571_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: otic capsule Weak Regionally restricted euxassay_000571_21
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_000571_21
TS23: lung Moderate Regionally restricted euxassay_000571_21
TS23: Meckel's cartilage Weak Regionally restricted euxassay_000571_21
TS23: head mesenchyme Moderate Regionally restricted euxassay_000571_21
Specimen euxassay_000571_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: otic capsule Moderate Regionally restricted euxassay_000571_22
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_000571_22
TS23: lung Moderate Regionally restricted euxassay_000571_22
TS23: Meckel's cartilage Weak Regionally restricted euxassay_000571_22
TS23: head mesenchyme Moderate Regionally restricted euxassay_000571_22
Specimen euxassay_000571_23: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: otic capsule Weak Regionally restricted euxassay_000571_23
TS23: vertebral axis musculature Weak Regionally restricted euxassay_000571_23
TS23: Meckel's cartilage Weak Regionally restricted euxassay_000571_23
TS23: head mesenchyme Weak Regionally restricted euxassay_000571_23
Specimen euxassay_000571_24: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: otic capsule Moderate Regionally restricted euxassay_000571_24
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_000571_24
