Alcam RNA in situ Gene Expression Assay

Gene Expression Data
Assay Details

Assay

Reference:	J:84355 Fraboulet S, et al., BEN/DM-GRASP/SC1 expression during mouse facial development: differential expression and regulation in molars and incisors. Gene Expr Patterns. 2003 Jun;3(3):255-9
Assay type:	RNA in situ
MGI Accession ID:	MGI:2669979
Gene symbol:	Alcam
Gene name:	activated leukocyte cell adhesion molecule

Probe:	BEN cDNA
Probe preparation:	Antisense labelled with digoxigenin RNA

Results

Specimen Not Shown: embryonic day 9.0 (more

)

Structure	Level	Pattern	Image	Note
TS15: head	Absent

Specimen Not Shown: embryonic day 10.0 (more

)

Structure	Level	Pattern	Image	Note
TS16: head	Absent

1A ©

Specimen 1A: embryonic day 14.0 (more

)

Structure	Level	Pattern	Image	Note
TS22: sublingual gland primordium epithelium	Present		1A
TS22: submandibular gland primordium epithelium	Present		1A

1B ©

Specimen 1B: embryonic day 16.0 (more

)

Structure	Level	Pattern	Image	Note
TS24: sublingual gland epithelium	Present		1B
TS24: submandibular gland epithelium	Present		1B

1C ©

Specimen 1C: embryonic day 14.0 (more

)

Structure	Level	Pattern	Image	Note
TS22: nose	Present	Regionally restricted	1C	Expression is in the epithelium of the nose-associated glands.

1D ©

Specimen 1D: embryonic day 13.0 (more

)

Structure	Level	Pattern	Image	Note
TS21: inner ear	Present	Regionally restricted	1D	Expression is in the epithelium.

1E ©

Specimen 1E: embryonic day 13.0 (more

)

Structure	Level	Pattern	Image	Note
TS21: olfactory epithelium	Present	Uniform	1E

1F ©

Specimen 1F: embryonic day 14.0 (more

)

Structure	Level	Pattern	Image	Note
TS22: olfactory epithelium	Present		1F
TS22: nose	Present	Regionally restricted	1F	Expression is in the mesenchyme and myogenic cells surrounding the nasal cavities.

1G ©

Specimen 1G: embryonic day 17.0 (more

)

Structure	Level	Pattern	Image	Note
TS25: nose	Present	Regionally restricted	1G	Expression is in nose cartilage.

1H ©

Specimen 1H: embryonic day 14.0 (more

)

Structure	Level	Pattern	Image	Note
TS22: tongue epithelium	Present		1H

1I ©

Specimen 1I: embryonic day 17.0 (more

)

Structure	Level	Pattern	Image	Note
TS25: tongue epithelium	Present		1I

1J ©

Specimen 1J: embryonic day 15.0 (more

)

Structure	Level	Pattern	Image	Note
TS23: skin	Present		1J
TS23: vibrissa	Present		1J

2A ©

Specimen 2A: embryonic day 11.0 (more

)

Structure	Level	Pattern	Image	Note
TS18: 1st branchial arch mandibular component	Absent		2A	Expression is absent in the molar placodes.
TS18: 1st branchial arch maxillary component	Absent		2A	Expression is absent in the molar placodes.

2B ©

Specimen 2B: embryonic day 12.0 (more

)

Structure	Level	Pattern	Image	Note
TS20: mandibular process mesenchyme	Strong	Regionally restricted	2B	Expression is in the mesenchyme of the molars.
TS20: maxillary process mesenchyme	Strong	Regionally restricted	2B	Expression is in the mesenchyme of the molars.

2C ©

Specimen 2C: embryonic day 13.0 (more

)

Structure	Level	Pattern	Image	Note
TS21: lower jaw molar mesenchyme	Strong		2C
TS21: upper jaw molar mesenchyme	Strong		2C
TS21: lower jaw molar epithelium	Present	Regionally restricted	2C	Expression is in part of the dental epithelium.
TS21: upper jaw molar epithelium	Present	Regionally restricted	2C	Expression is in part of the dental epithelium.

2D ©

Specimen 2D: embryonic day 14.0 (more

)

Structure	Level	Pattern	Image	Note
TS22: lower jaw molar mesenchyme	Present	Regionally restricted	2D	Expression is in the area that is not in contact with the epithelium.

2E ©

Specimen 2E: embryonic day 15.0 (more

)

Structure	Level	Pattern	Image	Note
TS23: lower jaw molar dental papilla	Absent		2E
TS23: lower jaw molar mesenchyme	Present	Regionally restricted	2E	Expression is strong in the lingual part of the dental follicle and weak in its labial part.
TS23: lower jaw molar enamel organ	Weak	Patchy	2E

2F ©

2G ©

Specimen 2F,G: embryonic day 18.0 (more

)
Note: (G) Higher magnification of (F)

Structure	Level	Pattern	Image	Note
TS26: lower jaw molar mesenchyme	Present	Regionally restricted	2F , 2G	Expression is in the dental follicle at the cervical area.

2H ©

Specimen 2H: embryonic day 13.0 (more

)

Structure	Level	Pattern	Image	Note
TS21: lower jaw incisor epithelium	Present	Regionally restricted	2H	Expression is in the posterior part of the bud.
TS21: upper jaw incisor epithelium	Present	Regionally restricted	2H	Expression is in the posterior part of the bud.
TS21: lower jaw incisor mesenchyme	Absent		2H
TS21: upper jaw incisor mesenchyme	Absent		2H

Specimen Not Shown: embryonic day 14.0 (more

)

Structure	Level	Pattern	Image	Note
TS22: lower jaw incisor	Absent
TS22: upper jaw incisor	Absent

Specimen Not Shown: embryonic day 15.0 (more

)

Structure	Level	Pattern	Image	Note
TS23: lower jaw incisor	Absent
TS23: upper jaw incisor	Absent

Specimen Not Shown: embryonic day 16.0 (more

)

Structure	Level	Pattern	Image	Note
TS24: lower jaw incisor	Absent
TS24: upper jaw incisor	Absent

Specimen Not Shown: embryonic day 17.0 (more

)

Structure	Level	Pattern	Image	Note
TS25: lower jaw incisor	Absent
TS25: upper jaw incisor	Absent

Specimen Not Shown: embryonic day 18.0 (more

)

Structure	Level	Pattern	Image	Note
TS26: lower jaw incisor	Absent
TS26: upper jaw incisor	Absent
