Gene Expression Data
Assay Details
|
Assay
|
|
Reference:
|
J:49658
Thomas T, et al., A signaling cascade involving endothelin-1, dHAND and msx1 regulates development of neural-crest-derived branchial arch mesenchyme. Development. 1998 Aug;125(16):3005-14
|
|
Assay type:
|
RNA in situ
|
|
MGI Accession ID:
|
MGI:1331698
|
|
Gene symbol:
|
Hand1
|
|
Gene name:
|
heart and neural crest derivatives expressed 1
|
|
Probe:
|
eHAND probe2
|
|
Probe preparation:
|
labelled with digoxigenin RNA
|
|
Visualized with:
|
Alkaline phosphatase
|
|
|
Results
|
Specimen
not shown:
embryonic day 9.0
(more  )
Specimen
not shown:
(close  )
|
Genetic Background:
|
Not Specified
|
|
Age:
|
embryonic day 9.0
|
|
Sex:
|
Not Specified
|
|
Type:
|
whole mount
|
|
Fixation:
|
4% Paraformaldehyde
|
Specimen
1B:
embryonic day 10.0
(more )
Specimen
1B:
(close )
|
Genetic Background:
|
Not Specified
|
|
Age:
|
embryonic day 10.0
|
|
Sex:
|
Not Specified
|
|
Type:
|
whole mount
|
|
Fixation:
|
4% Paraformaldehyde
|
| Structure |
Level |
Pattern |
Image |
Note |
| TS16: 1st branchial arch |
Present |
Regionally restricted |
1B
|
Expression was limited to the distal portion of the arches, with dHAND expression being slightly broader than eHAND.
|
| TS16: 2nd branchial arch |
Present |
Regionally restricted |
1B
|
Expression was limited to the distal portion of the arches, with dHAND expression being slightly broader than eHAND.
|
Specimen
not shown:
embryonic day 10.0
(more )
Specimen
not shown:
(close )
|
Genetic Background:
|
Not Specified
|
|
Age:
|
embryonic day 10.0
|
|
Sex:
|
Not Specified
|
|
Type:
|
section
|
|
Fixation:
|
4% Paraformaldehyde
|
|
Embedding:
|
Paraffin
|
| Structure |
Level |
Pattern |
Image |
Note |
| TS16: 1st branchial arch |
Present |
Regionally restricted |
|
There was no expression in the epithelial layer of the branchial arch or in migratory neural crest cells. Transcripts were concentrated in the neural-crest-derived mesenchyme just underlying the most exterior portion of the branchial arches.
|
| TS16: 1st branchial arch mesenchyme derived from neural crest |
Present |
Regionally restricted |
|
There was no expression in the epithelial layer of the branchial arch or in migratory neural crest cells. Transcripts were concentrated in the neural-crest-derived mesenchyme just underlying the most exterior portion of the branchial arches.
|
| TS16: 2nd branchial arch |
Present |
Regionally restricted |
|
There was no expression in the epithelial layer of the branchial arch or in migratory neural crest cells. Transcripts were concentrated in the neural-crest-derived mesenchyme just underlying the most exterior portion of the branchial arches.
|
| TS16: 2nd branchial arch mesenchyme derived from neural crest |
Present |
Regionally restricted |
|
There was no expression in the epithelial layer of the branchial arch or in migratory neural crest cells. Transcripts were concentrated in the neural-crest-derived mesenchyme just underlying the most exterior portion of the branchial arches.
|
| TS16: 1st branchial arch ectoderm |
Absent |
|
|
|
| TS16: 2nd branchial arch ectoderm |
Absent |
|
|
|
| TS16: migrating neural crest |
Absent |
|
|
|
Specimen
2D:
embryonic day 10.0
(more )
Specimen
2D:
(close )
|
Genetic Background:
|
involves: 129X1/SvJ * C57BL/6
|
|
Age:
|
embryonic day 10.0
|
|
Sex:
|
Not Specified
|
|
Type:
|
whole mount
|
|
Fixation:
|
4% Paraformaldehyde
|
Specimen
2H:
(close )
|
Genetic Background:
|
involves: 129X1/SvJ * C57BL/6
|
|
Mutant Allele(s):
|
Edn1tm1Utj/Edn1tm1Utj
|
|
Age:
|
embryonic day 10.0
|
|
Sex:
|
Not Specified
|
|
Type:
|
whole mount
|
|
Fixation:
|
4% Paraformaldehyde
|
| Structure |
Level |
Pattern |
Image |
Note |
| TS16: primitive ventricle |
Present |
Regionally restricted |
2H
|
eHAND expression in the left ventricle was unchanged.
|
| TS16: 1st branchial arch |
Weak |
Regionally restricted |
2H
|
eHAND expression in the first and second branchial arches was much lower and restricted to a small region in Edn1-null embryos in comparison to wild type.
|
| TS16: 2nd branchial arch |
Weak |
Regionally restricted |
2H
|
eHAND expression in the first and second branchial arches was much lower and restricted to a small region in Edn1-null embryos in comparison to wild type.
|
|
