Gene Expression Data
Assay Details
Assay
Reference: J:46142 Fuchs M, et al., Differential expression of MAM-subfamily protein tyrosine phosphatases during mouse development. Mech Dev. 1998 Jan;70(1-2):91-109
Assay type: RNA in situ
MGI Accession ID: MGI:5903117
Gene symbol: Ptpru
Gene name: protein tyrosine phosphatase, receptor type, U
Probe: PCP2 probe1
Probe preparation: Antisense RNA labelled with S35
Visualized with: Autoradiography
Results
Specimen 8A/B: embryonic day 12.5 (more )
Structure Level Pattern Image Note
TS20: cerebral cortex Present Regionally restricted 8A/B Expression in neuroepithelium of cerebral cortex, and posterior hypothalamus.
TS20: hypothalamus Present Regionally restricted 8A/B Expression in neuroepithelium of cerebral cortex, and posterior hypothalamus.
TS20: telencephalon subventricular zone Present Regionally restricted 8A/B Expression in subventricular zone of pallidum.
TS20: olfactory epithelium Present 8A/B Limited expression in olfactory epithelium of nasal cavity, epithelium lining oral cavity, oropharynx and intestine.
TS20: oral epithelium Present 8A/B Limited expression in olfactory epithelium of nasal cavity, epithelium lining oral cavity, oropharynx and intestine.
TS20: oropharynx Present 8A/B Limited expression in olfactory epithelium of nasal cavity, epithelium lining oral cavity, oropharynx and intestine.
TS20: ventricular layer Strong Regionally restricted 8A/B High expression levels in upper and lower plate of ependymal layer of neural tube.
TS20: intestine epithelium Strong 8A/B
TS20: stomach epithelium Strong 8A/B
TS20: lung Absent 8A/B

Specimen 8D/E: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS22: brain meninges Strong 8D/E
TS22: lung Present 8D/E Expression first detected lungs.
TS22: intestine epithelium Weak 8D/E Significantly decreased expression in epithelial layers of stomach and intestine.
TS22: stomach epithelium Weak 8D/E Significantly decreased expression in epithelial layers of stomach and intestine.
TS22: maturing glomerular tuft Strong 8D/E

Specimen 8G/H: embryonic day 16.5 (more )
Structure Level Pattern Image Note
TS24: vibrissa follicle Strong 8G/H
TS24: bone Strong Regionally restricted 8G/H Abundant expression in periostal collar of bone.
TS24: lung Strong 8G/H
TS24: intestine epithelium Weak 8G/H Significantly decreased expression in epithelial layers of stomach and intestine.
TS24: stomach epithelium Weak 8G/H Significantly decreased expression in epithelial layers of stomach and intestine.
TS24: maturing glomerular tuft Strong 8G/H

Specimen 8K/L: embryonic day 18.5 (more )
Structure Level Pattern Image Note
TS26: enamel organ Present 8K/L
TS26: nasal cavity epithelium Strong 8K/L
TS26: lung Weak 8K/L
TS26: intestine epithelium Absent 8K/L Authors state expression in epithelial layers of stomach and intestine was almost completely detectable.
TS26: stomach epithelium Absent 8K/L Authors state expression in epithelial layers of stomach and intestine was almost completely detectable.

Specimen 9A1/A2: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS22: lens fiber Strong 9A1/A2
TS22: neural retina Weak Regionally restricted 9A1/A2 Lower expression in inner nuclear layer of neural retina.

Specimen day 18.5 not shown: embryonic day 18.5 (more )
Structure Level Pattern Image Note
TS26: retina inner nuclear layer Weak Diminished expression in the inner nuclear layer of the neural retina.

Specimen 9B1/B2: embryonic day 18.5 (more )
Structure Level Pattern Image Note
TS26: nasal cavity epithelium Strong 9B1/B2
TS26: intestine epithelium Absent 9B1/B2 Authors state expression in epithelial layers of stomach and intestine was almost completely detectable.
TS26: stomach epithelium Absent 9B1/B2 Authors state expression in epithelial layers of stomach and intestine was almost completely detectable.

Specimen 9C1/C2: embryonic day 18.5 (more )
Structure Level Pattern Image Note
TS26: esophagus Present 9C1/C2

Specimen 9D1/D2: embryonic day 18.5 (more )
Structure Level Pattern Image Note
TS26: cochlear duct Present 9D1/D2

Specimen 9E1/E2: embryonic day 18.5 (more )
Structure Level Pattern Image Note
TS26: enamel organ Present 9E1/E2

Specimen 10C/F: postnatal day 4.5 (more )
Structure Level Pattern Image Note
TS28: cortical amygdaloid nucleus Strong 10C/F
TS28: lateral amygdaloid nucleus Strong 10C/F
TS28: thalamic nucleus Strong Regionally restricted 10C/F Strong expression in nuclei in the mediate thalamus.
TS28: lateral habenular nucleus Strong 10C/F
TS28: medial habenular nucleus Strong 10C/F
TS28: amygdala Weak Regionally restricted 10C/F Low levels of expression in intragranular part of cortical plate of cingulate and, at even lesser intensity, in the central cortex and amygdala.
TS28: cingulate cortex Weak Regionally restricted 10C/F Low levels of expression in intragranular part of cortical plate of cingulate and, at even lesser intensity, in the central cortex and amygdala.
TS28: neocortex Weak Regionally restricted 10C/F Low levels of expression in intragranular part of cortical plate of cingulate and, at even lesser intensity, in the central cortex and amygdala.
TS28: hippocampus CA1 Strong 10C/F
TS28: hippocampus CA2 Strong 10C/F
TS28: subiculum Strong 10C/F
TS28: dentate gyrus Absent 10C/F
TS28: hippocampus CA3 Absent 10C/F

Specimen 11E/F: postnatal adult (more )
Structure Level Pattern Image Note
TS28: cerebral cortex subventricular zone Present 11E/F
TS28: hippocampus CA1 Strong 11E/F
TS28: hippocampus CA2 Strong 11E/F
TS28: subiculum Strong 11E/F
TS28: pontine nucleus Strong Regionally restricted 11E/F High levels of expression in pontine gray nucleus,
TS28: interpeduncular nucleus Strong 11E/F
TS28: cerebellum granule cell layer Present 11E/F
TS28: cerebellum white matter Absent 11E/F

Specimen 12C: postnatal adult (more )
Structure Level Pattern Image Note
TS28: hippocampus CA1 Strong 12C
TS28: hippocampus CA2 Strong 12C
TS28: subiculum Strong 12C

Specimen 12F: postnatal adult (more )
Structure Level Pattern Image Note
TS28: cerebellum granule cell layer Present 12F
TS28: cerebellum white matter Absent
