Gene Expression Data
Assay Details
Assay
Reference: J:171409 GUDMAP Consortium, GUDMAP: the GenitoUrinary Development Molecular Anatomy Project. www.gudmap.org. 2004;
Assay type: RNA in situ
MGI Accession ID: MGI:5540813
Gene symbol: Prickle2
Gene name: prickle planar cell polarity protein 2
Probe: RIKEN clone 6230400G14 subclone
Probe preparation: Antisense RNA labelled with digoxigenin
Visualized with: Alkaline phosphatase
Results
Specimen GUDMAP:8849: embryonic day 10.5 (more )
Note: Labeling was visualized using NBT/BCIP.
Structure Level Pattern Image Note
TS17: genitourinary system Present Regionally restricted GUDMAP:8849
TS17: mesonephros Present Regionally restricted GUDMAP:8849
TS17: mesonephros mesenchyme Present GUDMAP:8849
TS17: metanephric mesenchyme Present Regionally restricted GUDMAP:8849 signal appears restricted to the rostral portion adjacent to the mesonephros and in the dorsal mesenchyme
TS17: genitourinary system mesenchyme Ambiguous GUDMAP:8849
TS17: gonad primordium Ambiguous GUDMAP:8849
TS17: mesonephric tubule Ambiguous GUDMAP:8849 signal is likely to be absent from the tubules any staining seen is in the surrounding mesenchyme
TS17: nephric duct, mesonephric portion Ambiguous GUDMAP:8849
TS17: nephric duct, metanephric portion Ambiguous GUDMAP:8849
TS17: nephric duct Ambiguous GUDMAP:8849

Specimen GUDMAP:8850: embryonic day 13.5 (more )
Note: Labeling was visualized using NBT/BCIP.
Structure Level Pattern Image Note
TS21: male reproductive system Present GUDMAP:8850
TS21: mesonephros of male Present GUDMAP:8850
TS21: mesonephric mesenchyme of male Present GUDMAP:8850 weak signal
TS21: testis Present GUDMAP:8850
TS21: interstitium of the testis Present GUDMAP:8850 strong signal
TS21: mesonephric tubule of male Absent GUDMAP:8850
TS21: nephric duct of male, mesonephric portion Absent GUDMAP:8850
TS21: paramesonephric duct of male, mesonephric portion Absent GUDMAP:8850
TS21: coelomic epithelium of male mesonephros Ambiguous GUDMAP:8850
TS21: nephric duct of male, rest of Ambiguous GUDMAP:8850
TS21: mesenchyme of nephric duct of male Ambiguous GUDMAP:8850
TS21: paramesonephric duct of male, rest of Ambiguous GUDMAP:8850
TS21: mesenchyme of rest of paramesonephric duct of male Ambiguous GUDMAP:8850
TS21: coelomic epithelium of testis Ambiguous GUDMAP:8850
TS21: primary sex cord Ambiguous GUDMAP:8850 any signal seen is likely to be background staining

Specimen GUDMAP:8851: embryonic day 13.5 (more )
Note: Labeling was visualized using NBT/BCIP.
Structure Level Pattern Image Note
TS21: urinary system Present GUDMAP:8851
TS21: urogenital sinus Present GUDMAP:8851
TS21: primitive bladder Present GUDMAP:8851 speckled signal pattern
TS21: mesenchymal layer of primitive bladder Present GUDMAP:8851
TS21: urothelium of primitive bladder Ambiguous GUDMAP:8851

Specimen GUDMAP:8852: embryonic day 13.5 (more )
Note: Labeling was visualized using NBT/BCIP.
Structure Level Pattern Image Note
TS21: female reproductive system Present GUDMAP:8852
TS21: mesonephros of female Present GUDMAP:8852
TS21: mesonephric mesenchyme of female Present GUDMAP:8852
TS21: ovary Present GUDMAP:8852
TS21: mesonephric tubule of female Absent GUDMAP:8852
TS21: nephric duct of female, mesonephric portion Absent GUDMAP:8852
TS21: paramesonephric duct of female, mesonephric portion Absent GUDMAP:8852
TS21: coelomic epithelium of female mesonephros Ambiguous GUDMAP:8852
TS21: nephric duct of female, rest of Ambiguous GUDMAP:8852
TS21: mesenchyme of nephric duct of female Ambiguous GUDMAP:8852
TS21: paramesonephric duct of female, rest of Ambiguous GUDMAP:8852
TS21: mesenchyme of rest of paramesonephric duct of female Ambiguous GUDMAP:8852

Specimen GUDMAP:8853: embryonic day 13.5 (more )
Note: Labeling was visualized using NBT/BCIP. Male and female were examined; only the female is shown. Annotators reported the male expression pattern in the metanephros is identical to female.
Structure Level Pattern Image Note
TS21: urinary system Present GUDMAP:8853
TS21: urogenital mesentery Present GUDMAP:8853
TS21: metanephros Present GUDMAP:8853
TS21: renal interstitium Present GUDMAP:8853
TS21: renal capsule Ambiguous GUDMAP:8853
TS21: nephrogenic zone Ambiguous GUDMAP:8853
TS21: nephrogenic interstitium Ambiguous GUDMAP:8853
TS21: cap mesenchyme Ambiguous GUDMAP:8853 signal appears to be absent from the cap mesenchyme; staining seen is likely to be background
TS21: pretubular aggregate Ambiguous GUDMAP:8853 signal appears to be absent; staining seen is likely to be background
TS21: ureteric tip Ambiguous GUDMAP:8853 signal appears to be absent from the tips; staining seen is likely to be background
TS21: early nephron Ambiguous GUDMAP:8853 signal appears to be absent; staining seen is likely to be background
TS21: renal pelvis Ambiguous GUDMAP:8853 this structure is masked by the signal on the surface of the metanephros
TS21: ureter Ambiguous GUDMAP:8853

Specimen GUDMAP:9776: embryonic day 15.5 (more )
Note: Labeling was visualized using BM purple.
Structure Level Pattern Image Note
TS23: urinary system Present GUDMAP:9776
TS23: metanephros Present Regionally restricted GUDMAP:9776
TS23: nephrogenic zone Present Regionally restricted GUDMAP:9776
TS23: nephrogenic interstitium Present Regionally restricted GUDMAP:9776 spotted expression
TS23: renal cortex Present Regionally restricted GUDMAP:9776
TS23: renal cortical interstitium Present Regionally restricted GUDMAP:9776 spotted expression
TS23: renal medulla Present Regionally restricted GUDMAP:9776
TS23: renal medullary interstitium Present Regionally restricted GUDMAP:9776 spotted expression
TS23: renal pelvis Present Regionally restricted GUDMAP:9776
TS23: pelvic smooth muscle Present GUDMAP:9776
TS23: ureter Present Regionally restricted GUDMAP:9776
TS23: ureteral mesenchyme Present GUDMAP:9776
TS23: ureteral smooth muscle layer Present GUDMAP:9776
TS23: renal interstitium Present GUDMAP:9776
TS23: cap mesenchyme Absent GUDMAP:9776
TS23: ureteric tip Absent GUDMAP:9776
TS23: ureteric tree terminal branch excluding tip itself Absent GUDMAP:9776
TS23: renal vesicle Absent GUDMAP:9776
TS23: comma-shaped body Absent GUDMAP:9776
TS23: s-shaped body Absent GUDMAP:9776
TS23: capillary loop renal corpuscle Absent GUDMAP:9776
TS23: maturing renal corpuscle Absent GUDMAP:9776
TS23: cortical renal tubule Absent GUDMAP:9776
TS23: cortical collecting duct Absent GUDMAP:9776
TS23: renal cortical capillary Absent GUDMAP:9776
TS23: immature loop of Henle Absent GUDMAP:9776
TS23: renal medullary capillary Absent GUDMAP:9776
TS23: medullary collecting duct Absent GUDMAP:9776
TS23: pelvic urothelial lining Absent GUDMAP:9776
TS23: urothelium of ureter Absent GUDMAP:9776
TS23: developing capillary loop stage nephron group Absent GUDMAP:9776
TS23: maturing nephron Absent GUDMAP:9776
TS23: collecting duct Absent GUDMAP:9776
TS23: early nephron Absent GUDMAP:9776
TS23: late tubule Absent GUDMAP:9776
TS23: renal medullary vasculature Ambiguous GUDMAP:9776 possible expression
TS23: renal cortical vasculature Ambiguous GUDMAP:9776 possible expression
TS23: perihilar interstitium Ambiguous GUDMAP:9776 possible weak spotted expression
TS23: ureteral mesenchyme outer layer Ambiguous GUDMAP:9776

Specimen GUDMAP:9777: embryonic day 15.5 (more )
Note: Labeling was visualized using BM purple.
Structure Level Pattern Image Note
TS23: ureter Present Regionally restricted GUDMAP:9777
TS23: ureteral mesenchyme Present GUDMAP:9777
TS23: ureteral smooth muscle layer Present GUDMAP:9777
TS23: urothelium of ureter Absent GUDMAP:9777
TS23: ureteral mesenchyme outer layer Ambiguous GUDMAP:9777 possible weak spotted expression

Specimen GUDMAP:9778: postnatal adult (more )
Note: This animal was sexually mature. Labeling was visualized using BM purple.
Structure Level Pattern Image Note
TS28: metanephros Absent GUDMAP:9778
TS28: ureter Absent GUDMAP:9778

Specimen GUDMAP:9779: postnatal adult (more )
Note: This animal was sexually mature. Labeling was visualized using BM purple.
Structure Level Pattern Image Note
TS28: ureter Absent GUDMAP:9779
