Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4828440
Gene symbol: Srgap2
Gene name: SLIT-ROBO Rho GTPase activating protein 2
Probe: T39393
Probe preparation: Antisense RNA labelled with digoxigenin
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_013988_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: midbrain mantle layer Strong Regionally restricted euxassay_013988_02

Specimen euxassay_013988_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: midbrain mantle layer Strong Regionally restricted euxassay_013988_03

Specimen euxassay_013988_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: midbrain mantle layer Strong Regionally restricted euxassay_013988_04
TS23: cerebral cortex ventricular layer Strong Regionally restricted euxassay_013988_04

Specimen euxassay_013988_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: thalamus mantle layer Moderate Regionally restricted euxassay_013988_05
TS23: midbrain mantle layer Strong Regionally restricted euxassay_013988_05
TS23: dorsal grey horn Strong Regionally restricted euxassay_013988_05

Specimen euxassay_013988_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: thalamus mantle layer Moderate Regionally restricted euxassay_013988_06
TS23: midbrain mantle layer Strong Regionally restricted euxassay_013988_06
TS23: dorsal grey horn Strong Regionally restricted euxassay_013988_06

Specimen euxassay_013988_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diencephalon lateral wall mantle layer Moderate Regionally restricted euxassay_013988_07
TS23: thalamus mantle layer Moderate Regionally restricted euxassay_013988_07
TS23: midbrain mantle layer Strong Regionally restricted euxassay_013988_07
TS23: dorsal grey horn Strong Regionally restricted euxassay_013988_07

Specimen euxassay_013988_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: diencephalon lateral wall mantle layer Moderate Regionally restricted euxassay_013988_08
TS23: thalamus mantle layer Moderate Regionally restricted euxassay_013988_08
TS23: midbrain mantle layer Strong Regionally restricted euxassay_013988_08

Specimen euxassay_013988_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: thalamus mantle layer Moderate Regionally restricted euxassay_013988_09
TS23: diencephalon lateral wall mantle layer Moderate Regionally restricted euxassay_013988_09
TS23: dorsal grey horn Strong Regionally restricted euxassay_013988_09

Specimen euxassay_013988_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: midbrain mantle layer Strong Regionally restricted euxassay_013988_10
TS23: dorsal grey horn Strong Regionally restricted euxassay_013988_10

Specimen euxassay_013988_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: olfactory cortex mantle layer Moderate Regionally restricted euxassay_013988_11
TS23: midbrain mantle layer Strong Regionally restricted euxassay_013988_11
TS23: dorsal grey horn Strong Regionally restricted euxassay_013988_11

Specimen euxassay_013988_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: olfactory cortex mantle layer Moderate Regionally restricted euxassay_013988_12
TS23: midbrain mantle layer Strong Regionally restricted euxassay_013988_12
TS23: heart ventricle Moderate Spotted euxassay_013988_12

Specimen euxassay_013988_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: olfactory cortex mantle layer Moderate Regionally restricted euxassay_013988_13
TS23: midbrain mantle layer Strong Regionally restricted euxassay_013988_13
TS23: heart ventricle Moderate Spotted euxassay_013988_13

Specimen euxassay_013988_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: thalamus mantle layer Moderate Regionally restricted euxassay_013988_14
TS23: midbrain mantle layer Strong Regionally restricted euxassay_013988_14
TS23: heart ventricle Strong Spotted euxassay_013988_14

Specimen euxassay_013988_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: olfactory cortex mantle layer Moderate Regionally restricted euxassay_013988_15
TS23: thalamus mantle layer Moderate Regionally restricted euxassay_013988_15
TS23: diencephalon lateral wall mantle layer Moderate Regionally restricted euxassay_013988_15
TS23: midbrain mantle layer Strong Regionally restricted euxassay_013988_15
TS23: heart ventricle Strong Spotted euxassay_013988_15

Specimen euxassay_013988_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: olfactory cortex mantle layer Moderate Regionally restricted euxassay_013988_16
TS23: thalamus mantle layer Moderate Regionally restricted euxassay_013988_16
TS23: diencephalon lateral wall mantle layer Moderate Regionally restricted euxassay_013988_16
TS23: midbrain mantle layer Strong Regionally restricted euxassay_013988_16
TS23: heart ventricle Moderate Regionally restricted euxassay_013988_16

Specimen euxassay_013988_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: olfactory cortex mantle layer Moderate Regionally restricted euxassay_013988_17
TS23: heart ventricle Moderate Regionally restricted euxassay_013988_17

Specimen euxassay_013988_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex mantle layer Strong Regionally restricted euxassay_013988_18
