Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4827039
Gene symbol: Panx3
Gene name: pannexin 3
Probe: MGC clone 60761
Probe preparation: Antisense RNA labelled with digoxigenin
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_005128_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_005128_01
TS23: orbito-sphenoid Strong Regionally restricted euxassay_005128_01
TS23: tibia Strong Regionally restricted euxassay_005128_01
TS23: humerus Strong Regionally restricted euxassay_005128_01
TS23: frontal bone primordium Strong Regionally restricted euxassay_005128_01
TS23: parietal bone Strong Regionally restricted euxassay_005128_01

Specimen euxassay_005128_02: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_005128_02
TS23: mandible Moderate Regionally restricted euxassay_005128_02
TS23: orbito-sphenoid Strong Regionally restricted euxassay_005128_02
TS23: tibia Strong Regionally restricted euxassay_005128_02
TS23: humerus Strong Regionally restricted euxassay_005128_02
TS23: cranium Strong Regionally restricted euxassay_005128_02 occipital

Specimen euxassay_005128_03: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_005128_03
TS23: mandible Strong Regionally restricted euxassay_005128_03
TS23: orbito-sphenoid Strong Regionally restricted euxassay_005128_03
TS23: humerus Strong Regionally restricted euxassay_005128_03
TS23: femur Strong Regionally restricted euxassay_005128_03
TS23: cranium Strong Regionally restricted euxassay_005128_03 occipital

Specimen euxassay_005128_04: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_005128_04
TS23: mandible Strong Regionally restricted euxassay_005128_04
TS23: orbito-sphenoid Strong Regionally restricted euxassay_005128_04
TS23: clavicle Strong Regionally restricted euxassay_005128_04
TS23: femur Strong Regionally restricted euxassay_005128_04
TS23: cranium Strong Regionally restricted euxassay_005128_04 occipital

Specimen euxassay_005128_05: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_005128_05
TS23: maxilla Strong Regionally restricted euxassay_005128_05
TS23: mandible Strong Regionally restricted euxassay_005128_05
TS23: orbito-sphenoid Strong Regionally restricted euxassay_005128_05
TS23: clavicle Strong Regionally restricted euxassay_005128_05
TS23: femur Strong Regionally restricted euxassay_005128_05
TS23: cranium Strong Regionally restricted euxassay_005128_05 occipital

Specimen euxassay_005128_06: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_005128_06
TS23: maxilla Strong Regionally restricted euxassay_005128_06
TS23: mandible Strong Regionally restricted euxassay_005128_06
TS23: orbito-sphenoid Strong Regionally restricted euxassay_005128_06
TS23: clavicle Strong Regionally restricted euxassay_005128_06
TS23: cranium Strong Regionally restricted euxassay_005128_06 occipital

Specimen euxassay_005128_07: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_005128_07
TS23: maxilla Strong Regionally restricted euxassay_005128_07
TS23: mandible Strong Regionally restricted euxassay_005128_07
TS23: orbito-sphenoid Strong Regionally restricted euxassay_005128_07
TS23: clavicle Strong Regionally restricted euxassay_005128_07
TS23: cranium Strong Regionally restricted euxassay_005128_07 occipital

Specimen euxassay_005128_08: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_005128_08
TS23: maxilla Strong Regionally restricted euxassay_005128_08
TS23: mandible Strong Regionally restricted euxassay_005128_08
TS23: orbito-sphenoid Weak Regionally restricted euxassay_005128_08
TS23: clavicle Strong Regionally restricted euxassay_005128_08
TS23: femur Strong Regionally restricted euxassay_005128_08
TS23: foot Strong Regionally restricted euxassay_005128_08
TS23: cranium Strong Regionally restricted euxassay_005128_08 occipital

Specimen euxassay_005128_09: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_005128_09
TS23: maxilla Strong Regionally restricted euxassay_005128_09
TS23: mandible Strong Regionally restricted euxassay_005128_09
TS23: orbito-sphenoid Weak Regionally restricted euxassay_005128_09
TS23: clavicle Strong Regionally restricted euxassay_005128_09
TS23: pelvic girdle skeleton Strong Regionally restricted euxassay_005128_09
TS23: cranium Strong Regionally restricted euxassay_005128_09 occipital

Specimen euxassay_005128_10: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: maxilla Strong Regionally restricted euxassay_005128_10
TS23: mandible Strong Regionally restricted euxassay_005128_10
TS23: palatal shelf Strong Regionally restricted euxassay_005128_10
TS23: clavicle Strong Regionally restricted euxassay_005128_10
TS23: cranium Strong Regionally restricted euxassay_005128_10 occipital

Specimen euxassay_005128_11: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: maxilla Strong Regionally restricted euxassay_005128_11
TS23: mandible Strong Regionally restricted euxassay_005128_11
TS23: palatal shelf Strong Regionally restricted euxassay_005128_11
TS23: basisphenoid bone Strong Regionally restricted euxassay_005128_11
TS23: cranium Strong Regionally restricted euxassay_005128_11 occipital

Specimen euxassay_005128_12: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: maxilla Strong Regionally restricted euxassay_005128_12
TS23: mandible Strong Regionally restricted euxassay_005128_12
TS23: basisphenoid bone Strong Regionally restricted euxassay_005128_12
TS23: cranium Strong Regionally restricted euxassay_005128_12 occipital

Specimen euxassay_005128_13: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: maxilla Strong Regionally restricted euxassay_005128_13
TS23: mandible Strong Regionally restricted euxassay_005128_13
TS23: basisphenoid bone Strong Regionally restricted euxassay_005128_13
TS23: cranium Strong Regionally restricted euxassay_005128_13 occipital

Specimen euxassay_005128_14: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_005128_14
TS23: maxilla Strong Regionally restricted euxassay_005128_14
TS23: mandible Strong Regionally restricted euxassay_005128_14
TS23: palatal shelf Strong Regionally restricted euxassay_005128_14
TS23: basisphenoid bone Weak Regionally restricted euxassay_005128_14
TS23: cranium Strong Regionally restricted euxassay_005128_14 occipital

Specimen euxassay_005128_15: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_005128_15
TS23: palatal shelf Strong Regionally restricted euxassay_005128_15
TS23: cranium Strong Regionally restricted euxassay_005128_15 occipital

Specimen euxassay_005128_16: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_005128_16
TS23: palatal shelf Strong Regionally restricted euxassay_005128_16
TS23: clavicle Strong Regionally restricted euxassay_005128_16
TS23: cranium Strong Regionally restricted euxassay_005128_16 occipital

Specimen euxassay_005128_17: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_005128_17
TS23: maxilla Strong Regionally restricted euxassay_005128_17
TS23: mandible Strong Regionally restricted euxassay_005128_17
TS23: clavicle Strong Regionally restricted euxassay_005128_17
TS23: cranium Strong Regionally restricted euxassay_005128_17 occipital

Specimen euxassay_005128_18: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_005128_18
TS23: maxilla Strong Regionally restricted euxassay_005128_18
TS23: mandible Strong Regionally restricted euxassay_005128_18
TS23: clavicle Strong Regionally restricted euxassay_005128_18
TS23: cranium Strong Regionally restricted euxassay_005128_18 occipital

Specimen euxassay_005128_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_005128_19
TS23: maxilla Strong Regionally restricted euxassay_005128_19
TS23: mandible Strong Regionally restricted euxassay_005128_19
TS23: clavicle Strong Regionally restricted euxassay_005128_19
TS23: femur Strong Regionally restricted euxassay_005128_19
TS23: parietal bone Strong Regionally restricted euxassay_005128_19

Specimen euxassay_005128_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_005128_20
TS23: orbito-sphenoid Strong Regionally restricted euxassay_005128_20
TS23: clavicle Strong Regionally restricted euxassay_005128_20
TS23: femur Strong Regionally restricted euxassay_005128_20
TS23: scapula Strong Regionally restricted euxassay_005128_20
TS23: parietal bone Strong Regionally restricted euxassay_005128_20

Specimen euxassay_005128_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: rib Strong Regionally restricted euxassay_005128_21
TS23: mandible Strong Regionally restricted euxassay_005128_21
TS23: maxilla Strong Regionally restricted euxassay_005128_21
TS23: orbito-sphenoid Strong Regionally restricted euxassay_005128_21
TS23: femur Strong Regionally restricted euxassay_005128_21
TS23: scapula Strong Regionally restricted euxassay_005128_21
TS23: parietal bone Strong Regionally restricted euxassay_005128_21


Contributing Projects:
Mouse Genome Database (MGD), Gene Expression Database (GXD), Mouse Models of Human Cancer database (MMHCdb) (formerly Mouse Tumor Biology (MTB), Gene Ontology (GO)
Citing These Resources
Funding Information
Warranty Disclaimer & Copyright Notice
Send questions and comments to User Support.
last database update
10/05/2021
MGI 6.17
The Jackson Laboratory
