Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4826695
Gene symbol: Nfrkb
Gene name: nuclear factor related to kappa B binding protein
Probe: T55122
Probe preparation: Antisense RNA labelled with digoxigenin
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_019503_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_019503_04

Specimen euxassay_019503_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_019503_05
TS23: facial ganglion Weak Regionally restricted euxassay_019503_05

Specimen euxassay_019503_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_019503_06
TS23: facial ganglion Weak Regionally restricted euxassay_019503_06
TS23: lung Weak Regionally restricted euxassay_019503_06

Specimen euxassay_019503_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_019503_07
TS23: vibrissa Weak Regionally restricted euxassay_019503_07
TS23: lung Weak Regionally restricted euxassay_019503_07

Specimen euxassay_019503_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_019503_08
TS23: trigeminal ganglion Weak Regionally restricted euxassay_019503_08
TS23: glossopharyngeal ganglion Weak Regionally restricted euxassay_019503_08
TS23: vibrissa Weak Regionally restricted euxassay_019503_08
TS23: lung Weak Regionally restricted euxassay_019503_08

Specimen euxassay_019503_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_019503_09
TS23: trigeminal ganglion Moderate Regionally restricted euxassay_019503_09
TS23: glossopharyngeal ganglion Moderate Regionally restricted euxassay_019503_09
TS23: vibrissa Weak Regionally restricted euxassay_019503_09
TS23: lung Weak Regionally restricted euxassay_019503_09
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_019503_09
TS23: metanephros Weak Regionally restricted euxassay_019503_09

Specimen euxassay_019503_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_019503_10
TS23: vagus ganglion Weak Regionally restricted euxassay_019503_10
TS23: trigeminal ganglion Weak Regionally restricted euxassay_019503_10
TS23: lung Weak Regionally restricted euxassay_019503_10
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_019503_10
TS23: metanephros Weak Regionally restricted euxassay_019503_10

Specimen euxassay_019503_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_019503_11
TS23: lung Weak Regionally restricted euxassay_019503_11
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_019503_11
TS23: olfactory epithelium Weak Regionally restricted euxassay_019503_11
TS23: metanephros Weak Regionally restricted euxassay_019503_11

Specimen euxassay_019503_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_019503_12

Specimen euxassay_019503_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_019503_13
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_019503_13
TS23: olfactory epithelium Weak Regionally restricted euxassay_019503_13

Specimen euxassay_019503_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_019503_14

Specimen euxassay_019503_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_019503_15

Specimen euxassay_019503_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_019503_16

Specimen euxassay_019503_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: lung Weak Regionally restricted euxassay_019503_17
TS23: olfactory epithelium Weak Regionally restricted euxassay_019503_17

Specimen euxassay_019503_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_019503_18
TS23: lung Weak Regionally restricted euxassay_019503_18
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_019503_18
TS23: olfactory epithelium Weak Regionally restricted euxassay_019503_18

Specimen euxassay_019503_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_019503_19
TS23: vagus ganglion Weak Regionally restricted euxassay_019503_19
TS23: trigeminal ganglion Weak Regionally restricted euxassay_019503_19
TS23: vestibulo-cochlear ganglion Weak Regionally restricted euxassay_019503_19
TS23: lung Weak Regionally restricted euxassay_019503_19
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_019503_19
TS23: olfactory epithelium Weak Regionally restricted euxassay_019503_19
TS23: metanephros Weak Regionally restricted euxassay_019503_19

Specimen euxassay_019503_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_019503_20
TS23: trigeminal ganglion Weak Regionally restricted euxassay_019503_20
TS23: glossopharyngeal ganglion Weak Regionally restricted euxassay_019503_20
TS23: vestibulo-cochlear ganglion Weak Regionally restricted euxassay_019503_20
TS23: lung Weak Regionally restricted euxassay_019503_20
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_019503_20
TS23: olfactory epithelium Weak Regionally restricted euxassay_019503_20

Specimen euxassay_019503_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_019503_21
TS23: trigeminal ganglion Weak Regionally restricted euxassay_019503_21
TS23: facial ganglion Weak Regionally restricted euxassay_019503_21
TS23: vibrissa Weak Regionally restricted euxassay_019503_21
TS23: lung Weak Regionally restricted euxassay_019503_21
TS23: metanephros Weak Regionally restricted euxassay_019503_21

Specimen euxassay_019503_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_019503_22
TS23: trigeminal ganglion Weak Regionally restricted euxassay_019503_22
TS23: facial ganglion Weak Regionally restricted euxassay_019503_22
TS23: vibrissa Weak Regionally restricted euxassay_019503_22
TS23: lung Weak Regionally restricted euxassay_019503_22
TS23: metanephros Weak Regionally restricted euxassay_019503_22

Specimen euxassay_019503_23: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_019503_23
TS23: facial ganglion Weak Regionally restricted euxassay_019503_23
TS23: vibrissa Weak Regionally restricted euxassay_019503_23
TS23: lung Weak Regionally restricted euxassay_019503_23

Specimen euxassay_019503_24: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Weak Regionally restricted euxassay_019503_24
TS23: lung Weak Regionally restricted euxassay_019503_24
