Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4826067
Gene symbol: Mal2
Gene name: mal, T cell differentiation protein 2
Probe: IMAGE clone 1400700
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_007855_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: left lung Strong Regionally restricted euxassay_007855_02
TS23: stomach Moderate Regionally restricted euxassay_007855_02
Specimen euxassay_007855_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: left lung Strong Regionally restricted euxassay_007855_03
TS23: stomach Moderate Regionally restricted euxassay_007855_03
Specimen euxassay_007855_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: left lung Strong Regionally restricted euxassay_007855_04
TS23: stomach Moderate Regionally restricted euxassay_007855_04
Specimen euxassay_007855_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: left lung Strong Regionally restricted euxassay_007855_05
TS23: stomach Moderate Regionally restricted euxassay_007855_05
TS23: renal calyx Strong Regionally restricted euxassay_007855_05
Specimen euxassay_007855_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: left lung Strong Regionally restricted euxassay_007855_06
TS23: stomach Weak Regionally restricted euxassay_007855_06
TS23: renal calyx Strong Regionally restricted euxassay_007855_06
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_007855_06
Specimen euxassay_007855_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: left lung Strong Regionally restricted euxassay_007855_07
TS23: stomach Weak Regionally restricted euxassay_007855_07
TS23: renal calyx Strong Regionally restricted euxassay_007855_07
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_007855_07
Specimen euxassay_007855_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: left lung Strong Regionally restricted euxassay_007855_08
TS23: olfactory epithelium Moderate Regionally restricted euxassay_007855_08
TS23: bladder fundus Moderate Regionally restricted euxassay_007855_08
TS23: trachea Moderate Regionally restricted euxassay_007855_08
Specimen euxassay_007855_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: left lung Strong Regionally restricted euxassay_007855_09
TS23: olfactory epithelium Moderate Regionally restricted euxassay_007855_09
TS23: bladder fundus Moderate Regionally restricted euxassay_007855_09
TS23: urethra Weak Regionally restricted euxassay_007855_09 Originally this result was annotated to a male-specific term, but as the specimen was not sexed, it is likely the data annotator intended to use a non-gender specific term.
TS23: rectum Moderate Regionally restricted euxassay_007855_09
Specimen euxassay_007855_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: left lung Strong Regionally restricted euxassay_007855_10
TS23: renal calyx Strong Regionally restricted euxassay_007855_10
TS23: thyroid gland Moderate Regionally restricted euxassay_007855_10
TS23: bladder fundus Moderate Regionally restricted euxassay_007855_10
TS23: urethra Weak Regionally restricted euxassay_007855_10 Originally this result was annotated to a male-specific term, but as the specimen was not sexed, it is likely the data annotator intended to use a non-gender specific term.
Specimen euxassay_007855_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: left lung Strong Regionally restricted euxassay_007855_11
TS23: renal calyx Strong Regionally restricted euxassay_007855_11
TS23: thyroid gland Moderate Regionally restricted euxassay_007855_11
Specimen euxassay_007855_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: right lung Strong Regionally restricted euxassay_007855_12
TS23: olfactory epithelium Moderate Regionally restricted euxassay_007855_12
TS23: renal calyx Strong Regionally restricted euxassay_007855_12
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_007855_12
Specimen euxassay_007855_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: right lung Strong Regionally restricted euxassay_007855_13
TS23: olfactory epithelium Strong Regionally restricted euxassay_007855_13
TS23: renal calyx Strong Regionally restricted euxassay_007855_13
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_007855_13
Specimen euxassay_007855_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: right lung Strong Regionally restricted euxassay_007855_14
TS23: olfactory epithelium Strong Regionally restricted euxassay_007855_14
TS23: renal calyx Strong Regionally restricted euxassay_007855_14
TS23: submandibular gland primordium Moderate Regionally restricted euxassay_007855_14
Specimen euxassay_007855_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: right lung Strong Regionally restricted euxassay_007855_15
TS23: olfactory epithelium Strong Regionally restricted euxassay_007855_15
Specimen euxassay_007855_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: right lung Strong Regionally restricted euxassay_007855_16
Specimen euxassay_007855_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: right lung Strong Regionally restricted euxassay_007855_17
