Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4825737
Gene symbol: Kctd16
Gene name: potassium channel tetramerisation domain containing 16
Probe: T37765
Probe preparation: Antisense labelled with digoxigenin RNA
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_011293_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Strong Regionally restricted euxassay_011293_01
TS23: hand Weak Regionally restricted euxassay_011293_01

Specimen euxassay_011293_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Strong Regionally restricted euxassay_011293_02
TS23: foot Weak Regionally restricted euxassay_011293_02
TS23: hand Weak Regionally restricted euxassay_011293_02

Specimen euxassay_011293_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Strong Regionally restricted euxassay_011293_03
TS23: trigeminal ganglion Strong Regionally restricted euxassay_011293_03
TS23: hand Weak Regionally restricted euxassay_011293_03
TS23: foot Weak Regionally restricted euxassay_011293_03

Specimen euxassay_011293_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Weak Regionally restricted euxassay_011293_04
TS23: trigeminal ganglion Strong Regionally restricted euxassay_011293_04
TS23: facial ganglion Strong Regionally restricted euxassay_011293_04
TS23: rest of cerebellum mantle layer Moderate Regionally restricted euxassay_011293_04
TS23: hand Weak Regionally restricted euxassay_011293_04

Specimen euxassay_011293_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Regionally restricted euxassay_011293_05
TS23: rest of cerebellum mantle layer Moderate Regionally restricted euxassay_011293_05
TS23: hand Weak Regionally restricted euxassay_011293_05
TS23: foot Weak Regionally restricted euxassay_011293_05

Specimen euxassay_011293_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Regionally restricted euxassay_011293_06
TS23: rest of cerebellum mantle layer Moderate Regionally restricted euxassay_011293_06
TS23: pons mantle layer Moderate Regionally restricted euxassay_011293_06

Specimen euxassay_011293_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Regionally restricted euxassay_011293_07
TS23: glossopharyngeal ganglion Strong Regionally restricted euxassay_011293_07
TS23: vestibulo-cochlear ganglion Strong Regionally restricted euxassay_011293_07
TS23: diencephalon lateral wall mantle layer Weak Regionally restricted euxassay_011293_07
TS23: midbrain mantle layer Weak Regionally restricted euxassay_011293_07
TS23: pons mantle layer Moderate Regionally restricted euxassay_011293_07
TS23: rest of cerebellum mantle layer Moderate Regionally restricted euxassay_011293_07
TS23: medulla oblongata basal plate mantle layer Moderate Regionally restricted euxassay_011293_07

Specimen euxassay_011293_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: glossopharyngeal ganglion Moderate Regionally restricted euxassay_011293_08
TS23: vestibulo-cochlear ganglion Moderate Regionally restricted euxassay_011293_08
TS23: trigeminal ganglion Strong Regionally restricted euxassay_011293_08
TS23: dorsal root ganglion Weak Regionally restricted euxassay_011293_08
TS23: diencephalon lateral wall mantle layer Weak Regionally restricted euxassay_011293_08
TS23: midbrain mantle layer Weak Regionally restricted euxassay_011293_08
TS23: pons mantle layer Weak Regionally restricted euxassay_011293_08
TS23: rest of cerebellum mantle layer Weak Regionally restricted euxassay_011293_08
TS23: medulla oblongata basal plate mantle layer Weak Regionally restricted euxassay_011293_08

Specimen euxassay_011293_09: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: vestibulo-cochlear ganglion Moderate Regionally restricted euxassay_011293_09
TS23: glossopharyngeal ganglion Moderate Regionally restricted euxassay_011293_09
TS23: trigeminal ganglion Strong Regionally restricted euxassay_011293_09
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_011293_09
TS23: medulla oblongata basal plate mantle layer Strong Regionally restricted euxassay_011293_09 facial motor nucleus
TS23: olfactory epithelium Weak Regionally restricted euxassay_011293_09
TS23: diencephalon lateral wall mantle layer Weak Regionally restricted euxassay_011293_09
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_011293_09
TS23: pons mantle layer Moderate Regionally restricted euxassay_011293_09

Specimen euxassay_011293_10: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: dorsal root ganglion Moderate Regionally restricted euxassay_011293_10
TS23: medulla oblongata basal plate mantle layer Moderate Regionally restricted euxassay_011293_10 facial motor nucleus
TS23: olfactory epithelium Weak Regionally restricted euxassay_011293_10
TS23: midbrain mantle layer Weak Regionally restricted euxassay_011293_10
TS23: diencephalon lateral wall mantle layer Weak Regionally restricted euxassay_011293_10
TS23: pons mantle layer Moderate Regionally restricted euxassay_011293_10

Specimen euxassay_011293_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Strong Regionally restricted euxassay_011293_11
TS23: olfactory epithelium Weak Regionally restricted euxassay_011293_11
TS23: ventral grey horn Weak Single cells euxassay_011293_11
TS23: midbrain mantle layer Weak Regionally restricted euxassay_011293_11
TS23: diencephalon lateral wall mantle layer Weak Regionally restricted euxassay_011293_11
TS23: pons mantle layer Moderate Regionally restricted euxassay_011293_11
TS23: medulla oblongata basal plate mantle layer Moderate Regionally restricted euxassay_011293_11

Specimen euxassay_011293_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Strong Regionally restricted euxassay_011293_12
TS23: olfactory epithelium Weak Regionally restricted euxassay_011293_12
TS23: ventral grey horn Weak Single cells euxassay_011293_12
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_011293_12
TS23: diencephalon lateral wall mantle layer Moderate Regionally restricted euxassay_011293_12
TS23: pons mantle layer Moderate Regionally restricted euxassay_011293_12
TS23: medulla oblongata basal plate mantle layer Moderate Regionally restricted euxassay_011293_12

Specimen euxassay_011293_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: dorsal root ganglion Strong Regionally restricted euxassay_011293_13
TS23: ventral grey horn Moderate Single cells euxassay_011293_13
TS23: diencephalon lateral wall mantle layer Weak Regionally restricted euxassay_011293_13

Specimen euxassay_011293_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: ventral grey horn Moderate Single cells euxassay_011293_14
TS23: trachea Strong Regionally restricted euxassay_011293_14
TS23: diencephalon lateral wall mantle layer Weak Regionally restricted euxassay_011293_14
TS23: pons mantle layer Moderate Regionally restricted euxassay_011293_14
TS23: medulla oblongata basal plate mantle layer Moderate Regionally restricted euxassay_011293_14

Specimen euxassay_011293_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: olfactory epithelium Weak Regionally restricted euxassay_011293_15
TS23: vomeronasal organ Weak Regionally restricted euxassay_011293_15
TS23: ventral grey horn Moderate Single cells euxassay_011293_15
TS23: trachea Moderate Regionally restricted euxassay_011293_15
TS23: diencephalon lateral wall mantle layer Moderate Regionally restricted euxassay_011293_15
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_011293_15
TS23: pons mantle layer Weak Regionally restricted euxassay_011293_15
TS23: medulla oblongata basal plate mantle layer Weak Regionally restricted euxassay_011293_15

Specimen euxassay_011293_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: olfactory epithelium Weak Regionally restricted euxassay_011293_16
TS23: ventral grey horn Weak Single cells euxassay_011293_16
TS23: diencephalon lateral wall mantle layer Moderate Regionally restricted euxassay_011293_16
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_011293_16
TS23: pons mantle layer Weak Regionally restricted euxassay_011293_16
TS23: rest of cerebellum mantle layer Weak Regionally restricted euxassay_011293_16
TS23: medulla oblongata basal plate mantle layer Weak Regionally restricted euxassay_011293_16

Specimen euxassay_011293_17: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: dorsal root ganglion Strong Regionally restricted euxassay_011293_17
TS23: medulla oblongata basal plate mantle layer Strong Regionally restricted euxassay_011293_17 facial motor nucleus
TS23: olfactory epithelium Weak Regionally restricted euxassay_011293_17
TS23: ventral grey horn Moderate Regionally restricted euxassay_011293_17
TS23: diencephalon lateral wall mantle layer Moderate Regionally restricted euxassay_011293_17
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_011293_17
TS23: pons mantle layer Weak Regionally restricted euxassay_011293_17
TS23: rest of cerebellum mantle layer Weak Regionally restricted euxassay_011293_17

Specimen euxassay_011293_18: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Regionally restricted euxassay_011293_18
TS23: glossopharyngeal ganglion Strong Regionally restricted euxassay_011293_18
TS23: vestibulo-cochlear ganglion Strong Regionally restricted euxassay_011293_18
TS23: dorsal root ganglion Strong Regionally restricted euxassay_011293_18
TS23: medulla oblongata basal plate mantle layer Moderate Regionally restricted euxassay_011293_18 facial motor nucleus
TS23: olfactory epithelium Weak Regionally restricted euxassay_011293_18
TS23: ventral grey horn Moderate Regionally restricted euxassay_011293_18
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_011293_18
TS23: diencephalon lateral wall mantle layer Moderate Regionally restricted euxassay_011293_18
TS23: pons mantle layer Weak Regionally restricted euxassay_011293_18
TS23: rest of cerebellum mantle layer Weak Regionally restricted euxassay_011293_18

Specimen euxassay_011293_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: glossopharyngeal ganglion Moderate Regionally restricted euxassay_011293_19
TS23: vestibulo-cochlear ganglion Moderate Regionally restricted euxassay_011293_19
TS23: trigeminal ganglion Strong Regionally restricted euxassay_011293_19
TS23: dorsal root ganglion Strong Regionally restricted euxassay_011293_19
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_011293_19
TS23: diencephalon lateral wall mantle layer Weak Regionally restricted euxassay_011293_19
TS23: rest of cerebellum mantle layer Weak Regionally restricted euxassay_011293_19
TS23: pons mantle layer Moderate Regionally restricted euxassay_011293_19
TS23: medulla oblongata basal plate mantle layer Moderate Regionally restricted euxassay_011293_19

Specimen euxassay_011293_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Regionally restricted euxassay_011293_20
TS23: glossopharyngeal ganglion Moderate Regionally restricted euxassay_011293_20
TS23: vestibulo-cochlear ganglion Moderate Regionally restricted euxassay_011293_20
TS23: diencephalon lateral wall mantle layer Weak Regionally restricted euxassay_011293_20
TS23: midbrain mantle layer Weak Regionally restricted euxassay_011293_20
TS23: rest of cerebellum mantle layer Weak Regionally restricted euxassay_011293_20

Specimen euxassay_011293_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Regionally restricted euxassay_011293_21
TS23: facial ganglion Strong Regionally restricted euxassay_011293_21
TS23: rest of cerebellum mantle layer Weak Regionally restricted euxassay_011293_21
TS23: foot Weak Regionally restricted euxassay_011293_21

Specimen euxassay_011293_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: trigeminal ganglion Strong Regionally restricted euxassay_011293_22
TS23: rest of cerebellum mantle layer Weak Regionally restricted euxassay_011293_22
TS23: foot Weak Regionally restricted euxassay_011293_22

Specimen euxassay_011293_23: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: neural retina Weak Regionally restricted euxassay_011293_23
TS23: trigeminal ganglion Strong Regionally restricted euxassay_011293_23
TS23: foot Weak Regionally restricted euxassay_011293_23


Contributing Projects:
Mouse Genome Database (MGD), Gene Expression Database (GXD), Mouse Models of Human Cancer database (MMHCdb) (formerly Mouse Tumor Biology (MTB)), Gene Ontology (GO)
Citing These Resources
Funding Information
Warranty Disclaimer, Copyright, and Privacy Statement
Send questions and comments to User Support.
last database update
11/22/2022
MGI 6.22
The Jackson Laboratory
