Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4825144
Gene symbol: Gnl3
Gene name: guanine nucleotide binding protein-like 3 (nucleolar)
Probe: IMAGE clone 1889603
Probe preparation: Antisense RNA labelled with digoxigenin
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_006219_01: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_006219_01
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_006219_01
TS23: liver left lobe Moderate Regionally restricted euxassay_006219_01
TS23: neural retina Weak Regionally restricted euxassay_006219_01

Specimen euxassay_006219_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_006219_02
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_006219_02
TS23: liver left lobe Moderate Regionally restricted euxassay_006219_02
TS23: neural retina Weak Regionally restricted euxassay_006219_02

Specimen euxassay_006219_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_006219_03
TS23: telencephalon ventricular layer Strong Uniform euxassay_006219_03
TS23: mandible Strong Regionally restricted euxassay_006219_03
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_006219_03
TS23: left lung Moderate Regionally restricted euxassay_006219_03
TS23: liver left lobe Moderate Regionally restricted euxassay_006219_03
TS23: neural retina Weak Regionally restricted euxassay_006219_03

Specimen euxassay_006219_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_006219_04
TS23: telencephalon ventricular layer Strong Uniform euxassay_006219_04
TS23: mandible Strong Regionally restricted euxassay_006219_04
TS23: orbito-sphenoid Strong Regionally restricted euxassay_006219_04
TS23: left lung Moderate Regionally restricted euxassay_006219_04
TS23: liver left lobe Moderate Regionally restricted euxassay_006219_04
TS23: neural retina Weak Regionally restricted euxassay_006219_04

Specimen euxassay_006219_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_006219_05
TS23: telencephalon ventricular layer Strong Uniform euxassay_006219_05
TS23: mandible Strong Regionally restricted euxassay_006219_05
TS23: maxilla Strong Regionally restricted euxassay_006219_05
TS23: orbito-sphenoid Strong Regionally restricted euxassay_006219_05
TS23: metencephalon rest of alar plate ventricular layer Moderate Regionally restricted euxassay_006219_05
TS23: metencephalon rest of alar plate marginal layer Moderate Regionally restricted euxassay_006219_05
TS23: vibrissa Strong Regionally restricted euxassay_006219_05
TS23: left lung Moderate Regionally restricted euxassay_006219_05
TS23: liver left lobe Moderate Regionally restricted euxassay_006219_05

Specimen euxassay_006219_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_006219_06
TS23: telencephalon ventricular layer Strong Uniform euxassay_006219_06
TS23: mandible Moderate Regionally restricted euxassay_006219_06
TS23: maxilla Moderate Regionally restricted euxassay_006219_06
TS23: orbito-sphenoid Strong Regionally restricted euxassay_006219_06
TS23: metencephalon rest of alar plate marginal layer Moderate Regionally restricted euxassay_006219_06
TS23: metencephalon rest of alar plate ventricular layer Moderate Regionally restricted euxassay_006219_06
TS23: vibrissa Strong Regionally restricted euxassay_006219_06
TS23: submandibular gland primordium Strong Regionally restricted euxassay_006219_06
TS23: testis Moderate Regionally restricted euxassay_006219_06
TS23: midgut Moderate Regionally restricted euxassay_006219_06
TS23: left lung Moderate Regionally restricted euxassay_006219_06
TS23: liver left lobe Moderate Regionally restricted euxassay_006219_06

Specimen euxassay_006219_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_006219_07
TS23: telencephalon ventricular layer Strong Uniform euxassay_006219_07
TS23: maxilla Moderate Regionally restricted euxassay_006219_07
TS23: upper jaw molar Moderate Regionally restricted euxassay_006219_07
TS23: lower jaw molar Moderate Regionally restricted euxassay_006219_07
TS23: mandible Moderate Regionally restricted euxassay_006219_07
TS23: orbito-sphenoid Weak Regionally restricted euxassay_006219_07
TS23: metencephalon rest of alar plate marginal layer Moderate Regionally restricted euxassay_006219_07
TS23: vibrissa Strong Regionally restricted euxassay_006219_07
TS23: submandibular gland primordium Strong Regionally restricted euxassay_006219_07
TS23: testis Moderate Regionally restricted euxassay_006219_07
TS23: renal cortex Moderate Regionally restricted euxassay_006219_07
TS23: midgut Moderate Regionally restricted euxassay_006219_07
TS23: left lung Moderate Regionally restricted euxassay_006219_07
TS23: liver left lobe Moderate Regionally restricted euxassay_006219_07

Specimen euxassay_006219_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_006219_08
TS23: telencephalon ventricular layer Strong Uniform euxassay_006219_08
TS23: upper jaw molar Moderate Regionally restricted euxassay_006219_08
TS23: maxilla Moderate Regionally restricted euxassay_006219_08
TS23: lower jaw molar Moderate Regionally restricted euxassay_006219_08
TS23: mandible Moderate Regionally restricted euxassay_006219_08
TS23: metencephalon rest of alar plate marginal layer Moderate Regionally restricted euxassay_006219_08
TS23: submandibular gland primordium Strong Regionally restricted euxassay_006219_08
TS23: renal cortex Moderate Regionally restricted euxassay_006219_08
TS23: midgut Moderate Regionally restricted euxassay_006219_08
TS23: left lung Moderate Regionally restricted euxassay_006219_08
TS23: liver left lobe Moderate Regionally restricted euxassay_006219_08

Specimen euxassay_006219_09: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_006219_09
TS23: telencephalon ventricular layer Strong Uniform euxassay_006219_09
TS23: mandible Moderate Regionally restricted euxassay_006219_09
TS23: palatal shelf Moderate Regionally restricted euxassay_006219_09
TS23: metencephalon rest of alar plate marginal layer Moderate Regionally restricted euxassay_006219_09
TS23: midbrain ventricular layer Moderate Regionally restricted euxassay_006219_09
TS23: renal cortex Moderate Regionally restricted euxassay_006219_09
TS23: midgut Moderate Regionally restricted euxassay_006219_09
TS23: left lung Moderate Regionally restricted euxassay_006219_09
TS23: liver left lobe Moderate Regionally restricted euxassay_006219_09

Specimen euxassay_006219_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_006219_10
TS23: telencephalon ventricular layer Strong Uniform euxassay_006219_10
TS23: maxilla Moderate Regionally restricted euxassay_006219_10
TS23: mandible Moderate Regionally restricted euxassay_006219_10
TS23: upper jaw incisor Moderate Regionally restricted euxassay_006219_10
TS23: lower jaw incisor Moderate Regionally restricted euxassay_006219_10
TS23: metencephalon rest of alar plate marginal layer Moderate Regionally restricted euxassay_006219_10
TS23: midbrain ventricular layer Moderate Regionally restricted euxassay_006219_10
TS23: renal cortex Moderate Regionally restricted euxassay_006219_10
TS23: midgut Moderate Regionally restricted euxassay_006219_10
TS23: thymus primordium Moderate Uniform euxassay_006219_10
TS23: left lung Moderate Regionally restricted euxassay_006219_10
TS23: liver left lobe Moderate Regionally restricted euxassay_006219_10

Specimen euxassay_006219_11: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_006219_11
TS23: olfactory cortex ventricular layer Strong Uniform euxassay_006219_11
TS23: telencephalon ventricular layer Strong Uniform euxassay_006219_11
TS23: upper jaw incisor Moderate Regionally restricted euxassay_006219_11
TS23: metencephalon rest of alar plate marginal layer Moderate Regionally restricted euxassay_006219_11
TS23: midbrain ventricular layer Moderate Regionally restricted euxassay_006219_11
TS23: renal cortex Moderate Regionally restricted euxassay_006219_11
TS23: midgut Moderate Regionally restricted euxassay_006219_11
TS23: thymus primordium Moderate Uniform euxassay_006219_11
TS23: left lung Moderate Regionally restricted euxassay_006219_11
TS23: liver left lobe Moderate Regionally restricted euxassay_006219_11

Specimen euxassay_006219_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_006219_12
TS23: telencephalon ventricular layer Strong Uniform euxassay_006219_12
TS23: metencephalon rest of alar plate marginal layer Moderate Regionally restricted euxassay_006219_12
TS23: midbrain ventricular layer Moderate Regionally restricted euxassay_006219_12
TS23: midgut Moderate Regionally restricted euxassay_006219_12
TS23: thymus primordium Moderate Uniform euxassay_006219_12
TS23: left lung Moderate Regionally restricted euxassay_006219_12
TS23: liver left lobe Moderate Regionally restricted euxassay_006219_12

Specimen euxassay_006219_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_006219_13
TS23: telencephalon ventricular layer Strong Uniform euxassay_006219_13
TS23: lower jaw incisor Moderate Regionally restricted euxassay_006219_13
TS23: mandible Moderate Regionally restricted euxassay_006219_13
TS23: midbrain ventricular layer Moderate Regionally restricted euxassay_006219_13
TS23: midgut Moderate Regionally restricted euxassay_006219_13
TS23: thymus primordium Moderate Uniform euxassay_006219_13
TS23: right lung Moderate Regionally restricted euxassay_006219_13
TS23: liver left lobe Moderate Regionally restricted euxassay_006219_13

Specimen euxassay_006219_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_006219_14
TS23: telencephalon ventricular layer Moderate Uniform euxassay_006219_14
TS23: lower jaw incisor Moderate Regionally restricted euxassay_006219_14
TS23: upper jaw incisor Moderate Regionally restricted euxassay_006219_14
TS23: mandible Moderate Regionally restricted euxassay_006219_14
TS23: diencephalon lateral wall ventricular layer Moderate Regionally restricted euxassay_006219_14
TS23: midbrain ventricular layer Moderate Regionally restricted euxassay_006219_14
TS23: midgut Moderate Regionally restricted euxassay_006219_14
TS23: thymus primordium Moderate Uniform euxassay_006219_14
TS23: right lung Moderate Regionally restricted euxassay_006219_14
TS23: liver left lobe Moderate Regionally restricted euxassay_006219_14

Specimen euxassay_006219_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_006219_15
TS23: mandible Moderate Regionally restricted euxassay_006219_15
TS23: upper jaw incisor Moderate Regionally restricted euxassay_006219_15
TS23: midbrain ventricular layer Moderate Regionally restricted euxassay_006219_15
TS23: diencephalon lateral wall ventricular layer Moderate Regionally restricted euxassay_006219_15
TS23: submandibular gland primordium Strong Regionally restricted euxassay_006219_15
TS23: right lung Moderate Regionally restricted euxassay_006219_15
TS23: liver right lobe Moderate Regionally restricted euxassay_006219_15

Specimen euxassay_006219_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_006219_16
TS23: telencephalon ventricular layer Moderate Uniform euxassay_006219_16
TS23: mandible Moderate Regionally restricted euxassay_006219_16
TS23: metencephalon rest of alar plate marginal layer Moderate Regionally restricted euxassay_006219_16
TS23: midbrain ventricular layer Moderate Regionally restricted euxassay_006219_16
TS23: submandibular gland primordium Strong Regionally restricted euxassay_006219_16
TS23: renal cortex Moderate Regionally restricted euxassay_006219_16
TS23: right lung Moderate Regionally restricted euxassay_006219_16
TS23: liver right lobe Moderate Regionally restricted euxassay_006219_16

Specimen euxassay_006219_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_006219_17
TS23: telencephalon ventricular layer Strong Uniform euxassay_006219_17
TS23: olfactory cortex ventricular layer Strong Uniform euxassay_006219_17
TS23: lower jaw molar Strong Regionally restricted euxassay_006219_17
TS23: upper jaw molar Strong Regionally restricted euxassay_006219_17
TS23: mandible Strong Regionally restricted euxassay_006219_17
TS23: metencephalon rest of alar plate marginal layer Moderate Regionally restricted euxassay_006219_17
TS23: midbrain ventricular layer Moderate Regionally restricted euxassay_006219_17
TS23: submandibular gland primordium Strong Regionally restricted euxassay_006219_17
TS23: renal cortex Moderate Regionally restricted euxassay_006219_17
TS23: right lung Moderate Regionally restricted euxassay_006219_17
TS23: liver right lobe Moderate Regionally restricted euxassay_006219_17

Specimen euxassay_006219_18: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_006219_18
TS23: telencephalon ventricular layer Strong Uniform euxassay_006219_18
TS23: upper jaw molar Moderate Regionally restricted euxassay_006219_18
TS23: maxilla Moderate Regionally restricted euxassay_006219_18
TS23: lower jaw molar Moderate Regionally restricted euxassay_006219_18
TS23: mandible Moderate Regionally restricted euxassay_006219_18
TS23: metencephalon rest of alar plate marginal layer Moderate Regionally restricted euxassay_006219_18
TS23: midbrain ventricular layer Moderate Regionally restricted euxassay_006219_18
TS23: submandibular gland primordium Strong Regionally restricted euxassay_006219_18
TS23: testis Weak Regionally restricted euxassay_006219_18
TS23: renal cortex Moderate Regionally restricted euxassay_006219_18
TS23: right lung Moderate Regionally restricted euxassay_006219_18
TS23: liver right lobe Moderate Regionally restricted euxassay_006219_18

Specimen euxassay_006219_19: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_006219_19
TS23: telencephalon ventricular layer Strong Uniform euxassay_006219_19
TS23: lower jaw molar Moderate Regionally restricted euxassay_006219_19
TS23: upper jaw molar Moderate Regionally restricted euxassay_006219_19
TS23: mandible Moderate Regionally restricted euxassay_006219_19
TS23: metencephalon rest of alar plate marginal layer Moderate Regionally restricted euxassay_006219_19
TS23: vibrissa Moderate Regionally restricted euxassay_006219_19
TS23: testis Weak Regionally restricted euxassay_006219_19
TS23: renal cortex Moderate Regionally restricted euxassay_006219_19
TS23: right lung Moderate Regionally restricted euxassay_006219_19
TS23: liver right lobe Moderate Regionally restricted euxassay_006219_19

Specimen euxassay_006219_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_006219_20
TS23: telencephalon ventricular layer Strong Uniform euxassay_006219_20
TS23: mandible Moderate Regionally restricted euxassay_006219_20
TS23: upper jaw molar Moderate Regionally restricted euxassay_006219_20
TS23: lower jaw molar Moderate Regionally restricted euxassay_006219_20
TS23: orbito-sphenoid Weak Regionally restricted euxassay_006219_20
TS23: metencephalon rest of alar plate marginal layer Moderate Regionally restricted euxassay_006219_20
TS23: vibrissa Strong Regionally restricted euxassay_006219_20
TS23: testis Weak Regionally restricted euxassay_006219_20
TS23: renal cortex Moderate Regionally restricted euxassay_006219_20
TS23: right lung Moderate Regionally restricted euxassay_006219_20
TS23: liver right lobe Moderate Regionally restricted euxassay_006219_20

Specimen euxassay_006219_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_006219_21
TS23: telencephalon ventricular layer Strong Uniform euxassay_006219_21
TS23: mandible Strong Regionally restricted euxassay_006219_21
TS23: orbito-sphenoid Strong Regionally restricted euxassay_006219_21
TS23: metencephalon rest of alar plate marginal layer Moderate Regionally restricted euxassay_006219_21
TS23: metencephalon rest of alar plate ventricular layer Moderate Regionally restricted euxassay_006219_21
TS23: vibrissa Strong Regionally restricted euxassay_006219_21
TS23: right lung Moderate Regionally restricted euxassay_006219_21
TS23: liver right lobe Moderate Regionally restricted euxassay_006219_21

Specimen euxassay_006219_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_006219_22
TS23: telencephalon ventricular layer Strong Uniform euxassay_006219_22
TS23: mandible Strong Regionally restricted euxassay_006219_22
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_006219_22
TS23: metencephalon rest of alar plate marginal layer Moderate Regionally restricted euxassay_006219_22
TS23: metencephalon rest of alar plate ventricular layer Moderate Regionally restricted euxassay_006219_22
TS23: liver right lobe Moderate Regionally restricted euxassay_006219_22
TS23: neural retina Weak Regionally restricted euxassay_006219_22

Specimen euxassay_006219_23: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_006219_23
TS23: telencephalon ventricular layer Strong Uniform euxassay_006219_23
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_006219_23
TS23: liver right lobe Moderate Regionally restricted euxassay_006219_23
TS23: neural retina Weak Regionally restricted euxassay_006219_23

Specimen euxassay_006219_24: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vertebral axis musculature Moderate Regionally restricted euxassay_006219_24
TS23: telencephalon ventricular layer Moderate Uniform euxassay_006219_24
TS23: orbito-sphenoid Moderate Regionally restricted euxassay_006219_24
TS23: liver right lobe Moderate Regionally restricted euxassay_006219_24
TS23: neural retina Weak Regionally restricted euxassay_006219_24


Contributing Projects:
Mouse Genome Database (MGD), Gene Expression Database (GXD), Mouse Models of Human Cancer database (MMHCdb) (formerly Mouse Tumor Biology (MTB), Gene Ontology (GO)
Citing These Resources
Funding Information
Warranty Disclaimer & Copyright Notice
Send questions and comments to User Support.
last database update
08/04/2020
MGI 6.15
The Jackson Laboratory
