Gene Expression Data
Assay Details
Assay
Reference: J:153498 Diez-Roux G, et al., A high-resolution anatomical atlas of the transcriptome in the mouse embryo. PLoS Biol. 2011;9(1):e1000582
Assay type: RNA in situ
MGI Accession ID: MGI:4824528
Gene symbol: Elmod1
Gene name: ELMO/CED-12 domain containing 1
Probe: T39634
Probe preparation: Antisense RNA labelled with digoxigenin
Visualized with: Alkaline phosphatase
Assay notes: Cryosections of fresh frozen material were fixed in 4% paraformaldehyde for 20 min. before further processing. A tyramide-biotin/streptavidin amplification step was included in the in situ hybridization procedure.
Results
Specimen euxassay_015979_02: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon mantle layer Moderate Regionally restricted euxassay_015979_02
TS23: cerebral cortex mantle layer Moderate Regionally restricted euxassay_015979_02

Specimen euxassay_015979_03: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex mantle layer Moderate Regionally restricted euxassay_015979_03
TS23: telencephalon mantle layer Moderate Regionally restricted euxassay_015979_03

Specimen euxassay_015979_04: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex mantle layer Moderate Regionally restricted euxassay_015979_04
TS23: telencephalon mantle layer Moderate Regionally restricted euxassay_015979_04

Specimen euxassay_015979_05: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vibrissa Moderate Regionally restricted euxassay_015979_05
TS23: cerebral cortex mantle layer Strong Regionally restricted euxassay_015979_05
TS23: telencephalon mantle layer Strong Regionally restricted euxassay_015979_05

Specimen euxassay_015979_06: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vibrissa Weak Regionally restricted euxassay_015979_06
TS23: cerebral cortex mantle layer Strong Regionally restricted euxassay_015979_06
TS23: telencephalon mantle layer Strong Regionally restricted euxassay_015979_06

Specimen euxassay_015979_07: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vibrissa Weak Regionally restricted euxassay_015979_07
TS23: cerebral cortex mantle layer Moderate Regionally restricted euxassay_015979_07
TS23: telencephalon mantle layer Moderate Regionally restricted euxassay_015979_07

Specimen euxassay_015979_08: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: olfactory cortex mantle layer Moderate Regionally restricted euxassay_015979_08
TS23: cerebral cortex mantle layer Moderate Regionally restricted euxassay_015979_08
TS23: telencephalon mantle layer Moderate Regionally restricted euxassay_015979_08
TS23: diencephalon lateral wall mantle layer Moderate Regionally restricted euxassay_015979_08
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_015979_08

Specimen euxassay_015979_09: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: olfactory cortex mantle layer Moderate Regionally restricted euxassay_015979_09
TS23: cerebral cortex mantle layer Moderate Regionally restricted euxassay_015979_09
TS23: diencephalon lateral wall mantle layer Moderate Regionally restricted euxassay_015979_09
TS23: midbrain mantle layer Moderate Regionally restricted euxassay_015979_09
TS23: pons mantle layer Moderate Regionally restricted euxassay_015979_09 trigeminal motor nucleus

Specimen euxassay_015979_10: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex mantle layer Moderate Regionally restricted euxassay_015979_10
TS23: olfactory cortex mantle layer Moderate Regionally restricted euxassay_015979_10
TS23: midbrain mantle layer Weak Regionally restricted euxassay_015979_10
TS23: diencephalon lateral wall mantle layer Weak Regionally restricted euxassay_015979_10

Specimen euxassay_015979_11: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: cerebral cortex mantle layer Moderate Regionally restricted euxassay_015979_11
TS23: olfactory cortex mantle layer Moderate Regionally restricted euxassay_015979_11
TS23: midbrain mantle layer Weak Regionally restricted euxassay_015979_11
TS23: diencephalon lateral wall mantle layer Weak Regionally restricted euxassay_015979_11
TS23: medulla oblongata basal plate mantle layer Moderate Regionally restricted euxassay_015979_11 facial motor nucleus

Specimen euxassay_015979_12: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex mantle layer Moderate Regionally restricted euxassay_015979_12
TS23: midbrain mantle layer Weak Regionally restricted euxassay_015979_12
TS23: diencephalon lateral wall mantle layer Weak Regionally restricted euxassay_015979_12
TS23: ventral grey horn Moderate Regionally restricted euxassay_015979_12

Specimen euxassay_015979_13: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex mantle layer Moderate Regionally restricted euxassay_015979_13
TS23: ventral grey horn Moderate Regionally restricted euxassay_015979_13

Specimen euxassay_015979_14: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex mantle layer Moderate Regionally restricted euxassay_015979_14
TS23: ventral grey horn Moderate Regionally restricted euxassay_015979_14

Specimen euxassay_015979_15: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: olfactory cortex mantle layer Moderate Regionally restricted euxassay_015979_15
TS23: cerebral cortex mantle layer Moderate Regionally restricted euxassay_015979_15
TS23: midbrain mantle layer Weak Regionally restricted euxassay_015979_15
TS23: diencephalon lateral wall mantle layer Weak Regionally restricted euxassay_015979_15
TS23: ventral grey horn Moderate Regionally restricted euxassay_015979_15

Specimen euxassay_015979_16: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex mantle layer Moderate Regionally restricted euxassay_015979_16
TS23: olfactory cortex mantle layer Moderate Regionally restricted euxassay_015979_16
TS23: midbrain mantle layer Weak Regionally restricted euxassay_015979_16
TS23: diencephalon lateral wall mantle layer Weak Regionally restricted euxassay_015979_16
TS23: ventral grey horn Moderate Regionally restricted euxassay_015979_16

Specimen euxassay_015979_17: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: cerebral cortex mantle layer Moderate Regionally restricted euxassay_015979_17
TS23: ventral grey horn Moderate Regionally restricted euxassay_015979_17

Specimen euxassay_015979_18: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: cerebral cortex mantle layer Moderate Regionally restricted euxassay_015979_18
TS23: medulla oblongata basal plate mantle layer Moderate Regionally restricted euxassay_015979_18 facial motor nucleus
TS23: ventral grey horn Moderate Regionally restricted euxassay_015979_18

Specimen euxassay_015979_19: embryonic day 14.5 (more )
Note: Additional information for this specimen was included in the Eurexpress data submission file.
Structure Level Pattern Image Note
TS23: vibrissa Weak Regionally restricted euxassay_015979_19
TS23: cerebral cortex mantle layer Moderate Regionally restricted euxassay_015979_19
TS23: telencephalon mantle layer Moderate Regionally restricted euxassay_015979_19
TS23: diencephalon lateral wall mantle layer Weak Regionally restricted euxassay_015979_19
TS23: midbrain mantle layer Weak Regionally restricted euxassay_015979_19
TS23: pons mantle layer Moderate Regionally restricted euxassay_015979_19 trigeminal motor nucleus

Specimen euxassay_015979_20: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vibrissa Weak Regionally restricted euxassay_015979_20
TS23: telencephalon mantle layer Moderate Regionally restricted euxassay_015979_20
TS23: cerebral cortex mantle layer Moderate Regionally restricted euxassay_015979_20
TS23: midbrain mantle layer Weak Regionally restricted euxassay_015979_20

Specimen euxassay_015979_21: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: vibrissa Weak Regionally restricted euxassay_015979_21
TS23: telencephalon mantle layer Moderate Regionally restricted euxassay_015979_21
TS23: cerebral cortex mantle layer Moderate Regionally restricted euxassay_015979_21

Specimen euxassay_015979_22: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon mantle layer Moderate Regionally restricted euxassay_015979_22
TS23: cerebral cortex mantle layer Moderate Regionally restricted euxassay_015979_22

Specimen euxassay_015979_23: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon mantle layer Moderate Regionally restricted euxassay_015979_23
TS23: cerebral cortex mantle layer Moderate Regionally restricted euxassay_015979_23

Specimen euxassay_015979_24: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon mantle layer Strong Regionally restricted euxassay_015979_24

Specimen euxassay_015979_25: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon mantle layer Strong Regionally restricted euxassay_015979_25

Specimen euxassay_015979_26: embryonic day 14.5 (more )
Structure Level Pattern Image Note
TS23: telencephalon mantle layer Strong Regionally restricted euxassay_015979_26
