Legend:

Primary key columns

Columns with indexes

Implied relationships

Excluded column relationships

< n > number of related tables

Column

Type

Size

Nulls

Auto

Default

Children

Parents

Comments

_synonymtype_key

int4

mgi_synonym._synonymtype_key

Implied Constraint R

_mgitype_key

int4

√

null

acc_mgitype._mgitype_key

mgi_synonymtype__mgitype_key R

_organism_key

int4

√

null

mgi_organism._organism_key

mgi_synonymtype__organism_key R

synonymtype

varchar

255

definition

varchar

255

√

null

allowonlyone

int2

_createdby_key

int4

mgi_user._user_key

mgi_synonymtype__createdby_key R

_modifiedby_key

int4

mgi_user._user_key

mgi_synonymtype__modifiedby_key R

creation_date

timestamp

29,6

modification_date

timestamp

29,6

Table contained 29 rows at Mon Sep 26 19:11 EDT 2011

Indexes:

Column(s)	Type	Sort	Constraint Name
_synonymtype_key	Primary key	Asc	mgi_synonymtype_pkey
_synonymtype_key	Must be unique	Asc	mgi_synonymtype_idx_synonymtype_key
lower(synonymtype)	Performance	Asc	mgi_synonymtype_0
_createdby_key	Performance	Asc	mgi_synonymtype_idx_createdby_key
_mgitype_key	Performance	Asc	mgi_synonymtype_idx_mgitype_key
_modifiedby_key	Performance	Asc	mgi_synonymtype_idx_modifiedby_key
_organism_key	Performance	Asc	mgi_synonymtype_idx_organism_key
